Akuvox EA40 User manual

Wireless Headset Adapter---EA40 User
Manual
05/06/2015

Content
Overview..............................................................................................3
Introduction............................................................................................................ 3
Features.................................................................................................................. 3
Packaging Contents.............................................................................4
Port Description...................................................................................5
Cord Description.................................................................................. 5
Connecting IP Phone and Headset..................................................... 6

Overview
Introduction
The Wireless Headset Adapter——EA40, is perfect for connecting Akuvox SIP- R59P
IP phones and wireless headsets, such as Jabra(GN Netcom)、Plantronics 、
Sennheiser.
Features
Main Features
Fully compatible with Jabra, Plantronics and Sennheiser wireless headsets
Answer, Talk and Hangup calls remotely
Plug and Play
Powered by Akuvox IP phone SP-R59P

Physical Features
1 x RJ12(6P6C) port connected to Akuvox IP phone SP-R59P
1 x 3.5mm Jack for Plantronics headset
1 x RJ45(8P8C) Jack for Jabra and Sennheiser headset
Dimensions (H x L x D): 23 x 67.5 x 45mm
Gift Box Size: 160 x 85 x 30mm
G.W.: 0.15Kg
QTY/Carton: 20pcs
Carton Meas: 360 x 350 x 122mm
Packaging Contents

Port Description
Port ①: Connect this port and the IP phone EXT/EHS port or Expansion Module EXT
port (the expansion module has been connected to the phone) using the RJ12 cord.
Port ② : Connect this port and Wireless headset using the RJ45 cord.
Port ③ : Connect this port and Wireless headset using the 3.5 mm DC Jack.
Cord Description
In addition to the cords mentioned in the Port Description section,the RJ9 Cord is
provided.
RJ9 Cord: For the audio connection between the IP phone headset port and the
wireless headset.

Connecting IP Phone and Headset
This section introduces the connection between SIP-R59P IP phone and the wireless
headset.
Working with Jabra(GN Netcom) wireless headset.
Working with Plantronics wireless headsets.

Working with Sennheiser wireless headsets.
