Digitus DA-70851 User manual

USB to HDMI®Adapter
User’s Manual
DA-70851

1
Table of Contents
1. Introduction .......................................................................................................2
Applications ........................................................................................................3
Features..............................................................................................................3
Package Contents...............................................................................................4
System Requirements.........................................................................................4
2. Installation .........................................................................................................6
On Windows 7
®
...................................................................................................6
On Windows Vista
®
.............................................................................................9
On Windows
®
XP..............................................................................................12
On Mac .............................................................................................................14
3. Using the Adapter ...........................................................................................19
On Windows .....................................................................................................19
Display Properties.............................................................................................19
Display Modes ..................................................................................................20
Extend Your Windows Desktop to Secondary Monitor (Default) .......................20
Video and DVD Playback in Extened Mode..................................................22
Mirror Your Windows Desktop...........................................................................23
Be the Primary Monitor .....................................................................................24
Adjusting Resolution and Refresh Rate ............................................................25
Configure the components................................................................................26
Fit to TV Function..............................................................................................29
Standby and Hibernate, Shut Down and Restart...............................................32
Inferred Modes..................................................................................................32
Disconnecting the Adapter ................................................................................33
Using Dual Adapters .........................................................................................33
On Mac .............................................................................................................35
Managing Multiple Displays ..............................................................................35
Setting the Display Resolutions and Rotation ...................................................35
Setting the Position of Displays ........................................................................36
Display Positions ..............................................................................................36
Setting the Display to Mirror / Extend mode......................................................37
Changing the Main Display ...............................................................................38
Configuring Display from the Menu Bar ............................................................38
Verifying the Driver Installation..........................................................................39
On Windows .....................................................................................................39
On Mac .............................................................................................................40
Uninstall the Adapter and Driver .......................................................................41
4. Troubleshooting ..............................................................................................42
5. Specifications..................................................................................................44
6. Regulatory Compliance ..................................................................................46
FCC Conditions ................................................................................................46
CE.....................................................................................................................46
WEEE Information ............................................................................................46

1. Introduction
This USB to HDMI
®
Adapter enables you to connect one more monitor, LCD or projector to
a computer with a USB 2.0 port. For desktop users adding an extra monitor via USB
connection is easier than ever without having to open the computer chassis to install an
internal video card. Once the installation is done, the USB-attached monitor soon wakes up.
No function key hassle to swap a second monitor.
With this handy adapter, you can enjoy many benefits brought by an add-on monitor. The
most obvious one is that you get more desktop area to have more applications visible at
one time. For example, you may work on one monitor while your family watching video on
the other. No more stacking windows within the confines of a single display. Or you may
span an application, e.g. spreadsheets, across two sides of displays. What’s more, the
adapter is hot pluggable. If your system performance is an important issue when using
multiple monitors. Another benefit of this adapter is that it uses little computer resource;
ensuring users get quality display without comprising computer performance.
HDMI monitor
USB-enabled computer

3
Applications
Office workstation
View your large spreadsheets across two screens with display continuity
Multitask more effectively without overlapping windows
Edit on one screen while surfing the Internet information on the other
On the road
Do multiple screen presentations without bringing another computer
Easily provide multiple screen exhibitions in a trade show
Graphics workstation
Use second display for palettes/tools
Get a panoramic view of large documents
Editing workstation
Type documents on one screen while viewing reference material on the other
Compare two documents simultaneously across two screens
Financial analysis
Have one monitor per data stream
View charts and live data at the same time
Entertainment
View videos/TV on one screen and reviews on the other
Get additional perspectives when playing games
Features
Add-on monitor, LCD or projector through a single USB 2.0 port
Hot-plug; add or remove monitor without system reboot
Small in size, works with all HDMI
®
displays
Supports High Resolution up to 1920 x 1080
Extend and Mirror mode support
Resumes from hibernation and suspend modes
Supports up to 6 USB display adapter to work simultaneously

Package Contents
Before installation, please check the items in the package. The package should
contain the following items:
USB to HDMI
®
Adapter x1
Product support CD(User’s Manual) x1
USBCable x1
Quick Installation Guide x1
System Requirements
The minimum requirements for the PC are:
With Single Core CPU at 1.2GHz or higher processor clock. Intel
®
Pentium
®
/Celeron
®
family, or AMD
®
K6
®
/Athlon/Duronfamily, or
compatible processor
512MB memory
At least one USB 2.0 port
30MB of available disk space
Windows
®
XP Home or Professional SP2 or SP3, Windows Vista
®
SP1 or SP2
(32-bit or 64-bit), and Windows
®
7 (32-bit or 64-bit).
Supports all Intel-based Macs. (Including Snow Leopard 10.6.2, Leopard
10.5.8, Tiger 10.4.11).
Super VGA (800 x 600) or higher resolution monitor
To play DVD on the adapter-attached monitor, in addition to the requirements
above, the following requirements should also be met:
With dual core CPU at 2.0 GHz processor clock

5
If the PC specification is below this, performance will be lower (or CPU loading
higher than acceptable).
Windows
®
XP
For 1-2 monitors, business usage, productivity target.
This may not provide full frame rate DVD playback at full screen.
1.2GHz Single Core CPU
512MB memory
For 3 monitors, where 1 could run DVD video while also targeting productivity and
business apps.
Will support only 1 video of DVD resolution at full screen：.
1.8GHz CPU
1GB memory
For 6 screen where 1 screen can run full screen DVD video：
1.6GHz Dual Core
1GB memory

2. Installation
On Windows 7®
Caution: DO NOT connect the USB to HDMI
®
Adapter to your computer before you install
the provided driver.
Follow the procedures below to install the driver and then connect the adapter:
1. Insert the provided CD into your disc drive and installer program will run
automatically. Please click on Run Setup.exe to execute the install program.
Note：
If the installer program doesn’t run automatically, please locate and double-click on
the Setup.exe file in the Driver folder to launch the setup program.
If you encounter a User Account Control dialog box when attempting to install a
program, enter an administrator password or click Yes to start the installation.

7
2. When you see the License Agreement screen prompted as below, please click on
I Accept to install the software for USB display adapter...
3. Please wait while Windows configures DisplayLink Core Software. Your screens
may temporarily go black or flash during this process.
4. When finished, the installation screen will disappear and you will return
to your desktop.
5. Connect the USB to HDMI
®
Adapter to your computer and monitor.

6. When yohe following window will appear.
Please wait while DisplayLink software is configured for first use. Your screens
may temporarily go black or flash during this process. Please click “OK” to start to
use USB to HDMI
®
Adapter.
7. You can change the appearance of your displays through the Window. Moreover,
additional controls are available in Windows
®
7: Orientation (Portrait, landscape,
rotated portrait, rotated landscape)
8. To control the behavior of an attached DisplayLink device (or screen), it is possible
to use Windows Key+P to display a menu (and cycle through it) to allow:
Disconnect Projector, Duplicate, Extend, Projector Only.
*Actual strings depend on your operation system. These screen shots are from Windows
®
7 and
might vary slightly for each operation system.

9
On Windows Vista®
Caution: DO NOT connect the USB to HDMI
®
Adapter to your computer before you install
the provided driver.
Follow the procedures below to install the driver and then connect the adapter:
1. Insert the provided CD into your disc drive and install program will run
automatically. Please click on Run Setup.exe to execute the install program.
Note：
If the installer program doesn’t run automatically, please locate and double-click on
the Setup.exe file in the Driver folder to launch the setup program.
If you encounter a User Account Control dialog box when attempting to install a
program, enter an administrator password or click Allow to start the installation.

2. When you see the License Agreement screen prompted as below, please click on
I Accept to install the software for USB display adapter.
3. Please wait while Windows configures DisplayLink Core Software. Your screens
may temporarily go black or flash during this process.
4. When finished, the installation screen will disappear and you will return to your
desktop.
5. Connect the USB to HDMI
®
Adapter to your computer and monitor.

11
The following window will appear. Please wait while DisplayLink software is
configured for first use. Your screens may temporarily go black or flash during this
process. Please click “OK” to start to use USB to HDMI
®
Adapter.
6.
Notice：
If prompting to restart your computer, click Yes to restart or No to manually restart
later.
7. You will see the DisplayLink Manager Icon in system tray that looks like a monitor
as below. Click on the icon to bring up the menu.
*Actual strings depend on your operation system. These screen shots are from Windows Vista
®
and
might vary slightly for each operation system.
- Extend Mode: The screen is part of the
extended desktop.
-
Mirror Mode: The screen copies the contents of
the primary screen.
-
Off Mode: The screen is black.
-
Set as Main Monitor: The screen is the primary
screen.

On Windows®XP
Caution: DO NOT connect the USB to HDMI
®
Adapter to your computer before you install
the provided driver.
Follow the procedures below to install the driver and then connect the adapter:
1. Insert the provided CD into your disc drive. You may see the License agreement
screen prompted as below. Please click on I Accept to start the Driver installation.
Note:
If the installer program doesn’t run automatically, please locate and double-click on
the Autorun.exe file in the CD to launch the install program.

13
2. Please wait while Windows configures DisplayLink Core Software. Your screens
may temporarily go black or flash during this process.
*Actual strings depend on your operation system. These screen shots are from Windows
®
XP
and might vary slightly for each operation system.
3. You must restart your computer before the new setting will take effect.
4. When finished, the installation screen will disappear and you will return to your
desktop.
5. Connect the USB to HDMI
®
Adapter to your computer and monitor.
6. You will see the DisplayLink Manager Icon system tray that looks like a monitor as
below. Click on the icon to bring up the
menu.
- Extend Mode: The screen is part of the
extended desktop.
-
Mirror Mode: The screen copies the contents
of the primary screen.
-
Off Mode: The screen is black.
-
Set as Main Monitor: The screen is the
primary screen.

On Mac
Caution: DO NOT connect the USB to HDMI
®
Adapter to your computer before you install
the provided driver.
Follow the procedures below to install the driver and then connect the adapter:
1. Insert the provided CD into your disc drive. Locate and double-click the Driver
folder > Mac folder > DisplayLink Installer 1.6b3.dmg to launch the setup
program.
2. Select “DisplayLink Software Installer” to begin installing the DisplayLink Driver on
your Mac.
3. When the following Window appears, please click Continue to install the driver.

15
4. Click Continue to install this software.
5. Please click Continue after reading Software License Agreement.

6. Click Agree to continue the installation and quit the installer.
7. Click Install to perform a standard installation of this software on the disk
“Macintosh HD”.

17
8. Type your password to allow Installer to make changes. And click Continue
Installation to install.
9. The installation was successful, please click Restart to finfish installing the
software.

7. When finished, the installation screen will disappear and you will return to your
desktop.
8. Connect the USB to HDMI
®
Adapter to your computer and monitor.

19
3. Using the Adapter
On Windows
Display Properties
Display Properties allows you to configuration the display mode, screen resolution, and
physical arrangement of your monitors.
Easy Setting
Click on the DisplayLink Device icon and select Advanced to configuration Display
Properties as above or manually setting as below description.
On Windows
®
7, the DisplayLink Device icon will be hidden. Please click the arrow sign
and right click the DisplayLink Device icon to select Advanced.
Manually Setting
Position the mouse anywhere on your computer desktop, right-click and select Screen
Resolution on Windows
®
7, Personalize > Display Settings on Vista
®
or Properties >
Settings on Windows
®
XP.
