Akva Modulex User manual

AKVA Modulex and Modulex Q 2016
Assemble the base. (See also assembly instructions for Akva bases.)
The bottom plates are placed on the base and joined with the 4 legged plates. The side of
the bottom plates that should be turning up is the one with the threaded bushings –like
shown on these pictures.
Upholstered frame: the frame parts of the bed are assembled with angle brackets. They
are only to be tightened loosely at this point.
The frame parts are positioned on the bottom plates, but the screws are not to be tightened
firmly at this point.

The angle brackets are tightened loosely at the corners. Then one by one the screws at
each corner are tightened firmly. It is important to begin with the inner screws. After this the
angle brackets are all to be tightend firmly.
Wooden frame: the frame parts are assembled with angle brackets that are to be tightend
firmly. Then screw the angle brackets to the bottom plates, position the frame parts and
screw them to the bottom plates, but not quite 100% firm yet.
Dowels and angle brackets are placed in the hed- and foodend frame parts. These parts
are positioned on the bed and fasted to the long side parts of the frame. Finally tighten all
screws firmly.

The lower part of the cover is positioned with the AKVA logo at the foot end. The top cover
is zipped off and put aside. The fixing paddles are put through the holes in the lower part of
the cover and fixed to the bottom plates.
At first the long sides of the foam frame are placed in the cover, then the head and food end
parts.
Modulex has sloaping sides, and Modulex Q has straight sides.
Shown here is the Modulex:
The heater(s) is positioned, and the wire is led under the foam frame and through the hole
in the lower part of the cover. (See assembly instructions Akva Vital Electronics heater
before installing the heater.)
The safety liner Zipliner is placed in the bed and zipped onto the cover.
If this is a bed with a dual mattress system the divider is now placed in the middle.
The water mattress(es) is placed in the safety liner. (See instructions for water mattresses.)
After filling the mattress, removing the surplus of air and adding one or two bottles of Long
Life the top cover is zipped on the lower part of the cover. (See instructions for covers.)
