AKX AKX-CH4 User manual

REVISION DATE
20150123
DOCUMENT NUMBER
NOTICE The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
U.S. Patent No. 8,856,780
INSTALL GUIDE
AKXCHRSCH4AKXCH4EN
HARDWARE
AKXCH4/AKXCH41BAM/AKXCH42WSS
ACCESSORIES
ADSUSB REQUIRED
COMPATIBLE RFKIT OPTIONAL
DIRECTED SMARTSTART & ADSHRNRSSM01 OPTIONAL
FIRMWARE
AKXCHRSCH4AKXCH4
www.autokinetix.comAutomotive Data Solutions Inc. © 2015
20290

U.S. Patent No. 8,856,780
VEHICLE LIST - 1 OF 1
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS 3X LOCK START/STANDALONE MOD. PRIORITY UNLOCK DOOR LOCK DOOR UNLOCK ARM OEM ALARM DISARM OEM ALARM TRUNK/HATCH RELEASE POWER LIFTGATE POWER SLIDING DOOR (L) POWER SLIDING DOOR (R) DATA/MUX IGNITION CTRL RAP SHUTDOWN CTRL HOOD STATUS (W/OEM SW) DOOR STATUS BRAKE PEDAL STATUS TACHOMETER STATUS SECURE TAKEOVER PARKING LIGHT CTRL*
CHRYSLER
300 AT 08-10 1 • • • • • • • • • • • • • • • •
300 Limited AT 08-10 1 • • • • • • • • • • • • • • • •
300c AT 08-10 1 • • • • • • • • • • • • • • • •
300c SRT8 AT 08-10 1 • • • • • • • • • • • • • • • •
Town & Country AT 08-14 1 • • • • • • • • • • • • • • • • • •
DODGE
Caravan AT 08-10 1 • • • • • • • • • • • • • • • • • •
Challenger SXT AT 08-14 1 • • • • • • • • • • • • • • • •
Challenger R/T AT 08-14 1 • • • • • • • • • • • • • • • •
Challenger SRT8 AT 08-14 1 • • • • • • • • • • • • • • • •
Charger SE AT 08-10 1 • • • • • • • • • • • • • • • •
Charger R/T AT 08-10 1 • • • • • • • • • • • • • • • •
Charger SRT8 AT 08-10 1 • • • • • • • • • • • • • • • •
Durango AT 11-13 1 • • • • • • • • • • • • • • •
Grand Caravan AT 08-15 1 • • • • • • • • • • • • • • • • • •
Journey AT 09-10 1 • • • • • • • • • • • • • • • •
Magnum AT 08 1 • • • • • • • • • • • • • • • •
JEEP
Commander AT 08-10 1 • • • • • • • • • • • • • • • •
Grand Cherokee AT 08-13 1 • • • • • • • • • • • • • • • •
RAM
C/V AT 10-131••••••• •••••••••••
1500 AT 10-12 1 • •••••• ••••••••
2500 AT 10-12 1 • • • • • • • • • • • • • • •
3500 AT 10-12 1 • • • • • • • • • • • • • • •
4500 AT 11-12 1 • • • • • • • • • • • • • • •
5500 AT 11-12 1 • • • • • • • • • • • • • • •
VW
Routan AT 09-12 1 • • • • • • • • • • • • • • • • • •
* May require additional parts.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 2 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
BOX CONTENTS - 1 OF 1
VS1VS1
VS2VS2
MS1MS1
MS2MS2
3
6
4
1
2
5
C
B
A
F
G
E
D
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
2
1
3
7
9
3
10
8
6
4
12
5
2
1
3
4
2
1
3
4
BOX CONTENTS
T-HARNESS 1
AFTERMARKET HOOD SWITCH AND CABLE
WARNING STICKER
10 PIN CONNECTOR
12 PIN CONNECTOR
BLUE
PROGRAMMING
BUTTON
LED 2
LED 1
MODULE
BLACK
BLACK
BLACK
RF PORT/
WEBLINK PORT
BLACK
BLUE
TELEMATIC
PORT
WHITE
WEBLINK CABLE (required accessory sold separately)
WEBLINK CABLE
COMPUTER
USB PORT
4 PIN BLACK CABLE
MODULE
WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 3 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 4 OF 20
• 20150123
COMPATIBLE ACCESSORIES - 1 OF 1
RF KIT
RF KIT (Visit our website to see if this accessory is included with your product)
ANTENNA
FLASH RF DECODER
BEFORE INSTALLATION
RF DECODERBLUE CABLE BLACK CABLE
(NC) RED
(NC) BLACK
BLACK
BLUE
MODULE
RF PORT
TELEMATIC KIT (accessories sold separately)
(NC)
(NC)
(NC)
DIRECTED SMARTSTART
ADS-HRN(RS)-SM01
MODULE
TELEMATIC PORT
DOC.: #20290

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 1 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHRYSLER
300 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
300 Limited 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
300C 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
300 SRT8 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Town & Country 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Town & Country 11-14 Parking Light D2242 Black 6 pin 3 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
DODGE
Caravan 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Challenger R/T 08-14 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Challenger SXT 08-14 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Challenger SRT8 08-14 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Charger SE 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Charger R/T 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Charger SRT8 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Durango 11-13 Parking Light D2242 Black 6 pin 1 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Grand Caravan 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Grand Caravan 11-15 Parking Light D2242 Black 6 pin 3 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Journey 09-10 Parking Light ~ ~ ~ ~ White/Violet (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Magnum 08 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 5 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 2 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
JEEP
Commander 08-10 Parking Light ~ ~ ~ ~ Pin #1 of relay #7 (-) Power module in engine compartment ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Grand cherokee 08-10 Parking Light ~ ~ ~ ~ Pin #1 of relay #7 (-) Power module in engine compartment ~
Driver Door Pin ~ ~ 20 pin 05 Purple (-) Driver door module ~
Grand cherokee 11-13 Parking Light ~ Black 10 pin 01 White/LtGreen (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel, door harness ~
RAM
C/V 10 Parking Light D2242 Black 10 pin 01 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
C/V 11-13 Parking Light D2242 Black 6 pin 01 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
1500 10-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
2500 10-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
3500 10-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
4500 11-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
5500 11-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
VW
Routan 09-12 Parking Light D2242 Black 10 pin 01 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 6 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
86
30
87
87A
85
VS1VS1
VS2VS2
MS1MS1
MS2MS2
A1
A2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
A1
10 AMPS
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
IGNITION CONNECTOR
VEHICLE IGNITION SWITCH
VEHICLE
MODULE
IGNITION HARNESS
DRIVER DOOR PIN (-)
02 GRAY - RAP SHUTDOWN (-) OUTPUT
WHITE/BROWN - PARKING LIGHT (MUX) OUTPUT PARKING LIGHT (MUX)
PARKING LIGHT (-)
PARKING LIGHT (+)
12V (+)
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
WHITE/RED (NC)
WHITE/GREEN (NC)
TYPE 1 - WIRING DIAGRAM - 1 OF 1
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (MUX)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (-)
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (+)
OR
OR
PARKING LIGHT CONNECTION
HORN (-)
11 GRAY/GREEN - HORN (-) OUTPUT
OPTIONAL
AFTERMARKET HOOD SWITCH (-)
04 GRAY/WHITE - HOOD STATUS (-) INPUT
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 7 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
01
02
03
OFF
ACC ON
START
04
OFF
ACC ON
START
05
06
07
OFF
ACC ON
START
08
OFF
ACC ON
START
09
10
11
MODULE PROGRAMMING PROCEDURE - STD KEY - 1 OF 1
Close driver door.
Re-open driver door to wake up data bus.
Insert key into ignition.
Turn key to ON position.
LED will turn solid RED.
Within 5 seconds, LED will flash GREEN
rapidly.
Turn key to OFF position.
Remove key.
Press UNLOCK on the OEM remote. If vehicle
is not equipped with OEM remote, press
module programming button.
Wait, LED will turn solid GREEN for 2 seconds.
Module Programming Procedure completed.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 8 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
01
02
03
ENGINE
START
STOP
STOP ACC ON START
ON
04
05
06
ENGINE
START
STOP
STOP ACC ON START
STOP
07
08
09
MODULE PROGRAMMING PROCEDURE - PTS - 1 OF 1
Close driver door.
Re-open driver door to wake up data bus.
DO NOT PRESS BRAKE PEDAL. Push start
button twice [2x] to ON position.
LED will turn solid RED.
Within 5 seconds, LED will flash GREEN
rapidly.
DO NOT PRESS BRAKE PEDAL. Push start
button once [1x] to OFF position.
Press UNLOCK on the OEM remote.
Wait, LED will turn solid GREEN for 2 seconds.
Module Programming Procedure completed.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 9 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
>>
01
02
ENGINE
START
STOP
OFF ACC ON START
ON
03
04
ENGINE
START
STOP
OFF ACC ON STARTOFF
05
>>
VALET MODE PROGRAMMING PROCEDURE - 1 OF 1
NOTE: In Valet Mode, the Remote starter is not
functional. Keyless entry, Lock and Unlock will
remain functional. See RF kit user manual for
alternate valet mode programming.
Time restriction. Complete next step within 7
seconds.
Cycle ignition ON five times [5x OFF/ON]
rapidly.
Wait, LED 1 will turn solid RED for 2 seconds.
Set ignition to OFF position.
Valet Mode Programming Procedure
completed.
To exit valet mode: repeat steps 1 to 5.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 10 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
>>
01
02
ENGINE
START
STOP
OFF ACC ON START
ON
03
04
05
06
07
>>
08
09
ENGINE
START
STOP
OFF ACC ON STARTOFF
10
AFTERMARKET REMOTE PROGRAMMING PROCEDURE - 1 OF 1
WARNING: Program aftermarket remotes
before usage. A maximum of four [4x]
aftermarket remotes per system.
Time restriction. Complete next step within 7
seconds.
Cycle ignition ON five times [5x OFF/ON]
rapidly.
LED 1 will turn solid RED.
Time restriction. Complete next step within 2
seconds from previous step.
Press once [1x] on LOCK button of aftermarket
remote.
LED 1 will flash GREEN once [1x].
LED 1 will turn solid RED.
To program additional remotes: repeat steps 4
to 7 using each additional remote.
Wait, LED 1 will turn OFF.
Set ignition to OFF position.
Aftermarket Remote Programming Procedure
completed.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 11 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
>>
>>
>>
01
ENGINE
START
STOP
OFF ACC ON STARTOFF
02
03 [X]
04
05 [Y]
06
07 [Z]
08 [Z]
09
10
11 [Y]
12
13
14
>>
MODULE NAVIGATION PROCEDURE - 1 OF 1
It is mandatory to exit the Module Navigation
at the end of this procedure. Failure to exit the
Module Navigation will drain vehicle battery.
To exit the Module Navigation at any time:
Follow STEP 13.
Module must be programmed to the vehicle.
Use the Module Navigation Chart on the next
page.
Set ignition to OFF position.
TO ACCESS THE MENUS: Press and hold
programming button until LED 1 turns solid
GREEN.
IN THE MENUS: Press the programming
button as many times as the menu number
indicates. LED 1 will flash GREEN an equal
amount of times continuously.
TO ACCESS THE OPTIONS: Press and hold
programming button until LED 1 turns solid
RED.
IN THE OPTIONS: Press the programming
button as many times as the option number
indicates. LED 1 will flash RED an equal
amount of times continuously.
TO ACCESS THE SETTINGS: Press and hold
programming button until LED 1 turns solid
GREEN.
LED 1 will flash GREEN as many times as
the current (or default) setting number,
continuously.
IN THE SETTINGS: Press the programming
button as many times as necessary to access
your setting. LED 1 will flash GREEN an equal
amount of times continuously.
To return to the MENUS: exit the Module
Navigation and redo the Module Navigation
Procedure.
To save and return to the OPTIONS: Press and
hold programming button until LED 1 turns
solid RED.
LED 1 will flash RED as many times as the
current option number continuously.
Configure every other setting and proceed to
step 13.
MANDATORY: EXIT MODULE NAVIGATION.
Press and hold programming button for 7
seconds. LED 1 will flash RED rapidly. Release
programming button. LED 1 will turn OFF.
Module navigation completed.
Failure to exit the Module Navigation will drain
vehicle battery.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 12 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
MODULE NAVIGATION CHART - 1 OF 2
MODULE NAVIGATION CHART:
NOTES
[X] MENUS [Y] OPTIONS [Z] SETTINGS
I Default settings are listed in bold.
01 CONFIGURATION
01 DISARM/UNLOCK BEFORE START 01 OFF
II Make sure the option is covered on the vehicle before
attempting to change the setting.
02 ON
02 RELOCK AFTER START 01 OFF
02 ON
03 RELOCK AFTER SHUTDOWN 01 OFF
02 ON
04 FORCE UNLOCK ALL ON FIRST PRESS 01 OFF
02 ON
05 TAKEOVER 01 ENABLE
02 DISABLE*
06 N/A 01 N/A
07 FACTORY KEYLESS RS SEQUENCE
01 DISABLE
02 N/A
03 LOCK + UNLOCK + LOCK
04 LOCK + LOCK + LOCK
08 MODULE RUN TIME
01 03 MIN
02 05 MIN
03 10 MIN
04 15 MIN
05 25 MIN
06 30 MIN
07 35 MIN
08 15 MIN
09 WAIT TO START DELAY
01 02 SEC
02 05 SEC
03 08 SEC
04 10 SEC
05 15 SEC
06 20 SEC
07 25 SEC
08 30 SEC
10 N/A 01 N/A
11 N/A 01 N/A
12 N/A 01 N/A
13 N/A 01 N/A
*Vehicle will shutdown when a door is opened.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 13 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
MODULE NAVIGATION CHART - 2 OF 2
MODULE NAVIGATION CHART:
NOTES
[X] MENUS [Y] OPTIONS [Z] SETTINGS
01 CONFIGURATION
14 HORN EVENT TRIGGER
01 DOUBLE LOCK
02 LOCK + UNLOCK
03 LOCK + UNLOCK + START
04 DOUBLE LOCK + START
15 HORN CHIRPS WIDTH
01 30 mSEC
02 15 mSec
03 60 mSec
02-07 Technical Support only 01 N/A 01 N/A
*Vehicle will shutdown when a door is opened.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 14 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
REMOTE STARTER ERROR CODES - 1 OF 1
REMOTE STARTER ERROR CODES:
NOTES
[X] NUMBER OF PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking
lights are connected and supported by the system.
01 Engine running.
02 Key in ignition at ON position.
II After a remote starter failure, the parking lights will fl ash
three [3x] times, then will fl ash [X] number times to
indicate an error code. See table.
03 N/A
04 Trunk is open.
05 Foot brake is ON.
06 Hood is open.
07 N/A
08 Tach failure.
09 N/A
10 System is in Valet Mode.
11 CAN communication failure
12 RS not synchronized. Start vehicle with OEM key for 15 sec before trying a new RS sequence.
REMOTE STARTER SHUTDOWN ERROR CODES:
NOTES
[Y] NUMBER OF PARKING LIGHT FLASHES DIAGNOSTIC
I WARNING: The following applies only when the parking
lights are connected and supported by the system.
01 Engine tach signal is lost.
02 N/A
II If the engine shuts down after a remote starter sequence:
Press and hold the Trunk button and the Start button at the
same time for 2.5 seconds when using a 1-WAY remote.
OR
Press once [1x] on button “4” when using a 2-WAY remote.
The parking lights will flash four [4x] times, then will flash
[Y] number times to indicate an error code. See table.
03 Foot brake is ON.
04 Hood is open.
05 Engine RPM limiter is ON.
06 Glow plug timeout error.
07 Vehicle is moving (VSS).
08 Check engine warning light is ON.
09 Low fuel warning light is ON.
10 N/A
11 CAN communication failure during RS sequence.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 15 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
MODULE DIAGNOSTICS - 1 OF 1
TEST MODULE
LED 1 STATUS DIAGNOSTIC
I DURING PROGRAMMING
Flashing RED Missing/wrong information from firmware or vehicle.
Solid RED Module waiting for more vehicle information.
Flashing GREEN Additional steps required to complete module programming.
Solid GREEN then OFF Module correctly programmed.
OFF No activity or module already programmed.
II DURING REMOTE START
Flashing RED Module incorrectly programmed.
Solid RED Module incorrectly programmed.
Flashing GREEN Module correctly programmed and operational.
Solid GREEN then OFF Reset in progress.
OFF Invalid ground when running status from remote starter.
III WITH IGNITION OFF
Flashing RED Module incorrectly programmed or connected.
Solid RED Module not programmed. Waiting for more vehicle information.
Flashing GREEN False ground when running status from remote starter.
Solid GREEN then OFF Reset in progress.
OFF Module at rest and ready for a remote start sequence.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 16 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
01
02
03
04
05
06
07
08
>>
MODULE RESET PROCEDURE - 1 OF 1
Disconnect all connectors from module except
the BLACK 20-PIN connector.
Disconnect the BLACK 20-PIN connector.
PRESS AND HOLD programming button while
connecting the BLACK 20-PIN connector.
Wait, LED 1 will flash RED. RELEASE
programming button.
LED 1 will turn RED for 2 seconds.
Module RESET completed.
Reconnect all connectors.
Repeat programming procedure.
Failure to follow procedure may result with a
DTC or a CHECK ENGINE error message.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 17 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
>>
01
02
OFF
ACC ON
START
03
OFF
ACC ON
START
04
05
>>
TAKEOVER PROCEDURE - STD KEY - 1 OF 1
All vehicle doors must be closed and locked
prior to remote start sequence.
Press unlock on OEM or aftermarket remote.
Insert key into ignition.
Turn key to ON position.
Press and release BRAKE pedal.
Take over procedure completed.
Failure to follow procedure will result in
vehicle engine shutdown.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 18 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
>>
01
02
ENGINE
START
STOP
STOP ACC ON START
ON
03
04
>>
TAKEOVER PROCEDURE - PTS - 1 OF 1
All vehicle doors must be closed and locked
prior to remote start sequence.
Press unlock on OEM or aftermarket remote
or request switch.
DO NOT PRESS BRAKE PEDAL. Push start
button twice [2x] to ON position. Wait 2
seconds for key validation.
Press and release BRAKE pedal.
Take over procedure completed.
Failure to follow procedure will result in
vehicle engine shutdown.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 19 OF 20
• 20150123
DOC.: #20290

U.S. Patent No. 8,856,780
INSTALLATION CHECKLIST - 1 OF 1
1 WARNING: Vehicle engine will start many times. Test in a well ventilated area.
2 Close all vehicle doors, hood and trunk.
3Press the LOCK button once [1x] on the aftermarket keyfob.
¨
Question 1: Do the doors lock?
YES: Go to next step.
¨
NO: Verify the remote programming, the RF connections and the wired door lock/unlock
connections as illustrated in the wiring diagram, if applicable. Repeat the test and call
technical support, if the problem persists.
4Press the UNLOCK button once [1x] on the aftermarket keyfob.
¨
Question 2: Do the doors unlock?
YES: Go to next step.
¨
NO: Verify the remote programming, the RF connections and the wired door lock/unlock
connections as illustrated in the wiring diagram, if applicable. Repeat the test and call
technical support, if the problem persists.
5Press the TRUNK release button once [1x] on the aftermarket keyfob if supported.
¨
Question 3: Does the trunk or hatch open/unlock?
YES: Close trunk or hatch and go to next step.
¨
NO: Verify the remote programming, the RF connections and the wired trunk/hatch
connections as illustrated in the wiring diagram, if applicable. Repeat the test and call
technical support, if the problem persists.
6Press the AUX 1 button once [1x] on the aftermarket keyfob if supported.
¨
Question 4: Does the driver side sliding door open?
YES: Press the AUX 1 button once [1x] to close the driver sliding door and go to next step.
¨NO: Verify the remote programming and the RF connections. Repeat the test and call
technical support, if the problem persists.
7Press the AUX 2 button once [1x] on the aftermarket keyfob if supported.
¨
Question 5: Does the passenger side sliding door open?
YES: Press the AUX 2 button once [1x] to close the passenger sliding door and go to next step.
¨NO: Verify the remote programming and the RF connections. Repeat the test and call
technical support, if the problem persists.
8Press the START/STOP button once [1x] on the aftermarket keyfob to remote start vehicle.
¨
Question 6: Does the vehicle remote start?
YES: Go to next step.
¨NO: Verify the remote programming, the RF connections and check the remote start error
codes. Repeat the test and call technical support, if the problem persists.
9Press the START/STOP button once [1x] on the aftermarket keyfob to shut down vehicle.
¨
Question 7: Does the vehicle shut down?
YES: Go to next step.
¨NO: Repeat step. If problem persists, press the brake pedal once [1x] to shut down the vehicle
and call technical support.
10 RAP and auto light shutdown test
¨
Question 8: Did the radio, interior controls and headlights turn off within 60 seconds after
remote start shutdown?
YES: Go to next step.
¨NO: Verify the RAP SHUTDOWN connections as illustrated in the wiring diagram. Repeat the
test and call technical support if the problem persists.
11 Open hood.
12 If not already installed, affi x the mandatory orange warning sticker under the hood and
proceed to next step.
13 Press the START/STOP button once [1x] on the aftermarket keyfob to remote start vehicle.
¨
Question 9: Does the vehicle remote start?
YES: The vehicle is not equipped with a factory hood pin. Install a mandatory aftermarket hood
switch, then repeat the test.
¨NO: Go to next step.
14 Close hood.
15 Enter vehicle and close the doors.
16 Press the START/STOP button once [1x] on the aftermarket keyfob to remote start vehicle.
17 Wait for the vehicle to start.
18 Press brake pedal.
¨
Question 10: Does the vehicle shut down?
YES: Go to next step.
¨
NO: The module does NOT detect the brake pedal signal. Press the START/STOP button once
[1x] on the aftermarket keyfob to shut down vehicle, check connection as illustrated in the
wiring diagram, if applicable, and call technical support.
19 Exit vehicle.
20 Installation checklist completed.
CHECKLIST
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXCHRSCH4AKXCH4EN
PAGE 20 OF 20
• 20150123
DOC.: #20290
