Alarm Lock RR-4BKEYFOB Installation manual

1
OVERVIEW
The 4-button Wireless Remote Release (order part RR-
4BKEYFOB) is used to wirelessly unlock up to four separate
Trilogy Networx™series locking devices, OR locking devices
wired to the RR-RECEIVER (see WI2012). The Wireless Re-
mote is intended as a portable pocket-size remote release (for
a 1-button model intended for fixed mounting at a hidden loca-
tion, see model "RR-1BUTTON"). The Wireless Remote re-
quires one battery (pre-installed) that features a service life of
up to 12,000 openings (use a 3V Lithium type CR2032 or Dura-
cell DL2032 only). During normal operation, the locking device
typically opens within 2 seconds of the button press.
Each of the four buttons can be "paired" (connected) with one
Networx locking device (four buttons can be paired with four
separate locking devices). In addition, each individual Networx
locking device contains ten (10) "slots", with each slot available
to accommodate one keyfob button. Therefore, each individual
Networx locking device can ultimately be paired with up to ten
Wireless Remote buttons on multiple keyfobs. Note: Each but-
ton can ONLY be paired with one specific Networx locking de-
vice at a time (thus when a previously paired button is later
paired with a second locking device, the first pairing is erased).
The Wireless Remote is not currently supported by PL Series
Networx locking devices. Visit the Alarm Lock website (www.
alarmlock.com) for supported firmware versions.
PAIRING PROCEDURE
Pairing is performed locally at the keypad. Important: This
pairing procedure should be performed after the locking device
has been programmed by DL-Windows.
1. Open DL-Windows, select the desired Lock Profile, open
the Programmable Features screen, Remote tab. Check
to enable one of the following desired features:
•Remote Release (Momentary)
--or--
•Remote Toggles Passage Mode
If neither are checked, the Wireless Remote pairing will be
disabled upon subsequent DL-Windows programming
downloads. Therefore, check to enable one of these two
features and then send the programming to the locking de-
vice (see OI352 for complete DL-Windows programming
instructions). This will ensure that the pairings to be
added now will be unaffected by later downloads.
2. At the locking device keypad, enter Program Mode
(press the Master Code followed by ;).
3. To pair the first remote, press:
;65;1:
Verify keypad sounds "beep-beep-beep" continuously.
(The "beep-beep-beep" indicates the locking device is
ready and will wait about 30 seconds for the next step).
4. With the Wireless Remote in hand, observe its LED as
you perform the next steps:
a. Press and hold one of the four buttons.
b. The red LED lights...keep holding the button…
c. When the LED flashes green, release the button...
d. Wait a few seconds...observe the LED as follows:
•LED solid green = Pairing successful. Go to step 5 to
pair another Wireless Remote; otherwise go to step 6.
•LED solid red = Pairing unsuccessful. Start again at
step 3.
5. To pair another Wireless Remote, you will need to start
again at step 3, but with a slight change, as follows:
As previously stated, up to ten (10) Wireless Remote but-
tons may be enrolled into one locking device. Each Wire-
less Remote button added occupies a "slot" (numbered 1-
10); therefore, increment the "slot" number of the new Wire-
less Remote button in step 3. For example, when pairing
the first remote in step 3, you pressed:
;65;1:
To pair a second remote, you will need to press:
;65;2:
To pair a third remote, you will need to press:
;65;3:
...and so on. Therefore, to enroll another Wireless Remote,
go to step 3, but use the incremented Wireless Remote
"slot" number. Use the table below to track the location of
each Wireless Remote button in your system:
Use this table to track the fob button and its device pair:
© ALARM LOCK 2012 WI2004 7/12
345 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs 1-800-ALA-LOCK
For Technical Service 1-800-645-9440
(Note: Technical Service is for security professionals only)
Publicly traded on NASDAQ Symbol: NSSC
Slot 1: Slot 6:
Slot 2: Slot 7:
Slot 3: Slot 8:
Slot 4: Slot 9:
Slot 5: Slot 10:
Location of Locking Device:
Keyfob Location of Locking Device:
Button 1
Button 2
Button 3
Button 4
RR-4BKEYFOB Wireless Remote Release Keyfob
Programming Instructions
When Used with Trilogy Networx™Locking Devices

2
6. Test to ensure correct operation:
Testing the Wireless Remote is required to synchronize the
Wireless Remote with the locking device. Furthermore, the
first time you perform the test below, the locking device may
not always open on the first try. DO NOT BE CON-
CERNED, this is normal during this testing process. Test
as follows:
a. At the keypad, exit Program Mode by pressing and
holding any keypad button.
b. Press and release the paired Wireless Remote button.
c. The LED lights red...
d. ...within two seconds, the LED turns off...the locking de-
vice should open. If not, do not be concerned, this is
normal. Wait a few seconds and start again at step b
above. When the locking device unlocks and relocks,
the testing process ends and "normal" Networx system
operation resumes.
Note: During normal operation, the locking device is
designed to always open on the first button press (no
need to "press and hold"; one press is sufficient).
CLEARING THE FOB
This procedure removes the pairings of all Wireless Remote
buttons to all locking devices (essentially "un-pairing" the fob of
all paired data and restoring the fob to its default settings).
Note: This procedure is not required to allow a previously
paired button to be paired with a new locking device; simply pair
the button with the new locking device as per the "PAIRING
PROCEDURE" on page 1 and the first pairing will be erased.
But if you wish to remove the pairings of all buttons, proceed as
follows:
1. Remove the key ring from the Wireless Remote case.
2. Carefully insert the edge of a small coin in the notch
located in the bottom right corner of the Wireless Remote
(near the key ring loop). Open the case by gently twisting
the coin. Lift off the top cover.
3. Carefully remove the circuit board.
4. On the bottom side of the circuit board, push the bat-
tery cell out of its metal holder with a sharp pencil. The
cell will slide out of its holder as shown in the image be-
low. Note the orientation of the cell polarity, with its posi-
tive side up, before fully
removing the cell.
5. Press and hold any
Wireless Remote but-
ton on the circuit
board. Keep holding
the button and replace
the battery positive (+)
side up, by sliding the
battery into its metal
bracket. Continue
holding the button.
6. While holding, wait until the LED rapidly toggles between
red and green ("red-green-red-green" continuously),
then release the button. All buttons will be "un-paired",
and will be available for future pairings.
7. Reassemble the case by first placing the circuit board,
battery side down, into the Wireless Remote base.
Place the top of the Wireless Remote (with its rubber
button/gasket in place) on the Wireless Remote base
and press to snap the two Wireless Remote pieces to-
gether.
8. Test the Wireless Remote operation.
CLEAR A LOCKING DEVICE
Up to ten (10) Wireless Remote buttons (on multiple keyfobs)
can be simultaneously paired with one individual Networx lock-
ing device. To remove all paired Wireless Remote buttons from
a single locking device, use Function 64, as follows:
1. At the locking device keypad, enter Program Mode
(press the Master Code and press ;).
2. Press the following: ;64:
Note: Function 64 will disable all hardwired remote re-
lease ("Remote Input") switches, if present. In addition, if
a Wireless Remote is misplaced or stolen, it will be nec-
essary to remove ALL Wireless Remote buttons from the
locking device to ensure system security.
3. Exit Program Mode (press and hold any button until a
series of beeps is heard).
LOW BATTERY INDICATION
During normal operation, when a button on the Wireless Re-
mote is pressed and its battery is weak, the LED on the Wire-
less Remote will flash red-green repeatedly for several seconds.
Always replace a weak battery as soon as possible (see below
"BATTERY REPLACEMENT" procedure).
BATTERY REPLACEMENT
Use a 3V Lithium type CR2032 or Duracell DL2032 only; use of
another battery may present a risk of fire or explosion. Be care-
ful NOT to press any buttons during this procedure.
1. Remove the key ring from the Wireless Remote case.
2. Carefully insert the edge of a small coin in the notch
located in the bottom right corner of the Wireless Re-
mote (near the key ring loop). Open the case by gently
twisting the coin. Lift off the top cover.
3. With the bottom half of the Wireless Remote facing
upwards, carefully remove the circuit board.
4. On the bottom side of the circuit board, push the bat-
tery out of its metal holder with a sharp pencil. The bat-
tery will slide out of its holder as shown in the image at
left. Note the orientation of the battery polarity, with its
positive side up, before fully removing the battery.
5. Replace with a new battery, positive (+) side up, by
sliding the battery into its metal bracket. Be certain of
battery polarity before installation.
6. Reassemble the case by first placing the circuit board,
battery side down, into the Wireless Remote base.
Place the top of the Wireless Remote (with its rubber
button/gasket in place) on the Wireless Remote base
and press to snap the two Wireless Remote pieces to-
gether.
7. Test the Wireless Remote operation. Follow the steps
detailed on page 1 in the "PAIRING PROCEDURE" step
6.
REPLACING A LOCKING DEVICE
If the paired locking device is physically replaced with a new
locking device, the "PAIRING PROCEDURE" must be repeated
with each desired Wireless Remote button.
Battery Replacement
Insert pencil and
push cell out of
holder as shown
