Summary of Installation Steps
•WLAN Planning. Usually, a comprehensive site survey is required
before installation, such as installation location, brackets, cables,
power source, etc.
•Unpack the AP box and check all contents
•Install the AP bracket on ceiling or wall
•Installing the AP
•Connecting required cables
•Power connection
•Verifying post-installation connectivity
•AP provisioning
Access points are radio transmission devices and are subject to
governmental regulation. Network administrators who are
responsible for the configuration and operation of access points must
comply with local broadcast regulations. Specifically, access point
must use channel assignments appropriate to the location where the
access point will be deployed.
Package Contents
Item
Name
Qty
Unit
1
Access Point
1
Pcs
2
Quick Start Guide
1
Pcs
Installation Guide
1
Pcs
Regulatory Compliance and Safety
Information
1
Pcs
User Guide Info Card
1
Pcs
◆Optional Accessories（To be ordered separately）
Item
Name
Description
1
OAW-AP-MNT-B
Indoor mounting kit, Type B1(9/16") and
B2(15/16") for T shaped ceiling rail.
2
OAW-AP-MNT-C
Indoor mounting kit, Type C1(Open
Silhouette) and C2 (Flanged Interlude),
for other shaped ceiling rail mounting.
3
OAW-AP-MNT-W
Indoor mounting kit, Type W wall and
ceiling mounting with screws.
Figure1: Product Packing
Inform your ALE sales representative of incorrect, missing, or
damaged parts. If possible, retain the carton, including the
original packing materials. Use these materials to repack and
return the unit to the supplier if needed. Additional mounting
kits for use with the OmniAccess Stellar access points are sold
separately. Contact your ALE sales representative for details.
Hardware Overview
The following sections outline the hardware components of the OAW-
AP1311 Series access point.
Figure 2: OAW-AP1311 Front View
LED
The OAW-AP1311 Series access point is equipped with hidden LED display
that indicates different status with different color.
For the details of the LED status, please refer to the Quick Start Guide.
Figure 3: OAW-AP1311 Back View
◆OAW-AP1311 series External Interfaces
Table 1
Interface
Specifications
1 Gigabit
Eth0
1x 10/100/1000BASE-T autosensing (RJ-45) port, Power
over Ethernet (PoE). In case of only one WAN link，Eth0
would be preferred.
1 Gigabit
Eht1
1x 10/100/1000BASE-T autosensing (RJ-45) port, Power
over Ethernet (PoE). In case of only one WAN link，
either of Eth0 and Eth1 could work as WAN, Eth0 would
be more preferred. In case of two WAN links，Eth0 +
Eth1 would be preferred.
1 Gigabit
LAN
1x 10/100/1000BASE-T autosensing (RJ-45) port.
Console
RJ-45 female connector, default is RS-232 Console for
Service & Support only. Support software configure to
RS-485 mode.
USB
USB 2.0 host interface (Type C, output current 0.5A )
DC Power
Socket
DC 48V power jack, support powering AP through a
designated AC-DC power adapter.
Reset
Factory reset. Press reset button for 5s, AP LEDs will
quickly flash for 3s, then AP will restart and restore
factory configurations.
Security
Lock Slot
The AP is equipped with a security lock slot for
additional security.

Table 2
Ethernet Port Pinout
Connector
Pin
Signal
Name
PoE
1
2
3
4
5
6
7
8
1
RJ45_DA+
PoE-
2
RJ45_DA–
PoE-
3
RJ45_DB+
PoE+
4
RJ45_DC+
PoE+
5
RJ45_DC–
PoE+
6
RJ45_DB–
PoE+
7
RJ45_DD+
PoE-
8
RJ45_DD–
PoE-
Table 3
Console Port Pinout
Connector
Pin
Signal Name
Function
1
2
3
4
5
6
7
8
3
TXD
Transmit
4
GND
Ground
5
GND
Ground
6
RXD
Receive
Pins not listed are not connected.
Table 4
RS-485 Port Pinout
Connector
Pin
Signal Name
Function
1
2
3
4
5
6
7
8
1
RS485_B
Data-
2
RS485_A
Data+
4
GND
Ground
5
GND
Ground
7
PSE_12V
12V+ OUT
8
PSE_12V
12V+ OUT
Pins not listed are not connected.
Note: The serial console port allows you to connect the AP to a
serial terminal or a laptop for direct local management. This port
is an RJ-45 female connector with the pinouts described in Table 3.
Currently for use by Service & Support only.
Note: The RS-485 port allows you to connect the AP to a RS-485
terminal. The maximum allowable current of PSE 12V power output
is 300mA. In addition, PSE 12V power output can be turned on and
off by software. This port is an RJ-45 female connector with the
pinouts described in Table 4.
Power
The OAW-AP1311 series access point supports direct DC power adapter
(48V DC nominal, sold separately) and Power over Ethernet (PoE).
The DC power connector port is located on the back of the device, as
shown in Figure 3.
The PoE allows the Ethernet port to draw power from an IEEE
802.3at compliant source.
OmniAccess Stella AP supports the power adapter provided by ALE
ONLY.
Before You Begin
Refer to the sections below before beginning the installation process.
Pre-installation Checklist
Before installing your OAW-AP1311 Stellar access point, be sure that
you have the following items:
•8-conductor, CAT5 or better UTP cable of required length.
•One of the following power sources:
◼IEEE 802.3at compliant Power over Ethernet (PoE) source
(PoE switch or PoE injector).
◼AC-DC adapter (sold separately)，output voltage DC 48V,
output current ≥0.6A
•A terminal or a notebook
Identifying Specific Installation Locations
You can mount the OmniAccess Stellar AP on a ceiling rail or on a
wall. You should first determine the location of the installation. The
installation position is located at the center of the required
coverage area and should be free from obstructions or obvious
sources of interference.
•Minimize the number of obstructions (such as walls) between the
AP and user terminals.
•Electronic equipment or devices (such as microwave ovens) which
may produce radio frequency noise should be away from the
installation position of the AP.
It is strictly prohibited to install around stagnant water, water seepage,
leakage or condensation. Avoid cable condensation or water seepage
along the cables connecting to the AP.
AP Installation
Refer to mounting kits installation Guide.
Verifying Post-Installation Connectivity
The LED on the AP can be used to verify that the AP is receiving power
and initializing successfully.
Product Specifications
OAW-AP1311 series Dimensions/Weight
Unboxed OAW-AP1311:
•Net Weight: 1.64lbs / 0.74kg
•Dimensions (HxWxD): 7.1 inches x 7.1 inches x 1.42 inches
(18 cm x 18cm x 3.6cm)
Environmental
•Operating :
▪Temperature: 0°C to +50°C (+32°F to +122°F)
▪Humidity: 10% to 90% non-condensing
•Storage and transportation :
▪Temperature: -40°C to +70°C(-40°F to +158°F)
For additional specifications on this product, please refer to the
Datasheet.
Contacting Alcatel-Lucent Enterprise
Website Support
Main Site
https://www.al-enterprise.com/
Support Site
https:// businessportal2.alcatel-lucent.com
Support Email
[email protected]
Telephone Support
North America
1-800-995-2696
Latin America
1-877-919-9526
Europe
[phone] (Toll Free) or [phone]
Asia Pacific
[phone]
Other Region
1-818-878-4507
Alcatel-Lucent Enterprise
OmniAccess Stellar AP1311 Regulatory
Compliance and Safety Information
xxxxxx-xx Rev. A
*xxxxxx-xx Rev. A*
◼Introduction
This document contains domestic and international regulatory compliance
information for the access point. To ensure that this device complies with the
regulatory standards for your region, please refer to the content below.
FCC Part 15:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generate, uses and can
radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the
following measures:
⚫Reorient or relocate the receiving antenna.
⚫Increase the separation between the equipment and receiver.
⚫Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
⚫Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
RF exposure warning
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This product may not be collocated or operated in conjunction with any other
antenna or transmitter
This equipment must be installed and operated in accordance with provided
instructions and the antenna(s) used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all persons and must not be
collocated or operating in conjunction with any other antenna or transmitter.
California Proposition 65 Warning
WARNING: This product contains chemicals known to the State of California to
cause cancer and birth defects or other reproductive harm.
