Alcatel POP S9 7050Y User manual

English - CJB6116ALAAA
Quick Start Guide
Important:
Please note your phone is battery embedded design with removable
back cover and not removable battery. Unauthorized personnel are
strictly prohibited from disassembling the phone.
If your phone isn’t working normally, try to restart it by pressing
and holding the Power key for at least 9 seconds until the startup
screen appears.
If your phone develops a serious error and can’t be restored by
restarting it, you may need to restore factory settings by pressing
and holding the Power key and Volume up key until the startup
screen appears. Then select "reboot system now" and press the
Power key to confirm.
Note: Please take care when performing such operations because
they will erase personalized settings and data saved in your phone,
such as SMS, Contacts, Music, etc.
For more information about how to use the cellphone, please go to
www.alcatelonetouch.com to download the complete user manual.
In addition, from the website you can also consult the FAQ, perform
software upgrades, etc.

1
1 Your mobile������������������
1�1 Keys and connectors
Micro-USB Connector
Front camera
LED indicator
Headset connector
Home key
Touch screen
Back key
Menu key
Power key
Volume key
Camera
Camera Flash/
Flashlight
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker
is in use.
Table of contents
1 Your mobile ��������������������������������������������������������������������1
2 Text input����������������������������������������������������������������������12
3 Phone call ����������������������������������������������������������������������13
4 Contacts ������������������������������������������������������������������������16
5 Messaging ����������������������������������������������������������������������17
6 Email ������������������������������������������������������������������������������18
7 Getting connected��������������������������������������������������������19
8 Find my location using GPS satellites������������������������21
9 Data backup ������������������������������������������������������������������22
10 Factory data reset ��������������������������������������������������������23
11 Applications & Internal storage����������������������������������23
12 Making the most of your phone����������������������������������24
Safety and use�������������������������������������������������������������������������26
General information ��������������������������������������������������������������34
Warranty���������������������������������������������������������������������������������36
Troubleshooting���������������������������������������������������������������������37
www.sar-tick.com
This product meets applicable national SAR limits
of 2.0 W/kg. The specific maximum SAR values
can be found on page 30 of this user guide.
When carrying the product or using it while worn
on your body, either use an approved accessory
such as a holster or otherwise maintain a
distance of 1.0 cm from the body to ensure
compliance with RF exposure requirements.
Note that the product may be transmitting even
if you are not making a phone call.

2 3
1�2 Getting started
1�2�1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls.You do not need
to power off your phone before inserting or removing the SIM card
as this phone can support hot swap.
To install, place the SIM card with the chip facing upwards in to the
housing, and then slide it into its slot. Make sure that it is correctly
inserted.To remove the card, press and slide it out.
Your phone only supports micro-SIM cards. Do not attempt
to insert other SIM type like mini and nano cards,
otherwise this may cause phone damage.
Back key
• Touch to go back to the previous screen, or to close
a dialog box, options menu, the notification panel, etc.
• Touch and hold:Touch and hold to start dual screen.
Home key
• From any application or screen, touch to return to the
Home screen.
Menu key
• Touch to access settings options.
• Touch and hold to open a list of thumbnail images of
apps you've worked with recently.
These keys are visible when the screen lights up.
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the pop-up menu to select from
Power off/Restart/Airplane mode/Quick start.
• Press the Power key for more than 9s to restart.
• Press the Power key and Volume up key to reset.
• Press the Power key and Volume down key to
capture a screenshot.
Volume Keys
• In call mode, adjusts the earpiece or headset volume.
• In Music/Video/Streaming mode, adjusts the media
volume.
• In general mode, adjusts the ringtone volume.
• Mutes the ringtone of an incoming call.

4 5
Installing and removing the microSD card
Insert the microSD card with golden contact facing downwards into
the slot.To remove the microSD card, slide it out.
To avoid data loss and SD card damage, before removing
the SD card, please ensure that the SD card is unmounted
(Settings\Storage\Unmount SD card).
Charging the battery
Connect the battery charger to your phone and mains socket
respectively, the LED indicator will light while charging.
To reduce power consumption and energy waste when the
battery is fully charged, disconnect your charger from the
plug; switch off Wi-Fi, GPS, Bluetooth or background-
running applications when not in use; reduce the backlight
time, etc.
1�2�2 Power on your phone
Hold down the Power key until the phone powers on. It will take
some seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you should set the following
options: language, input method, date & time, etc.
Even if no SIM card is installed, your phone will still power on and
you will be able to connect to aWi-Fi network, sign into your Google
account and use some of the phone's features.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the phone
options appear, select Power off.
1�3 Home screen
You can bring all the items (applications, shortcuts, folders and
widgets) you love or use most frequently to your Home screen for
quick access.Touch the Home key to switch to the Home screen.
Status bar
• Status/Notification indicators
• Touch and drag down to open the
notification panel.
Touch an icon to open an application,
folder, etc.
Touch to enter application list.
Favorite tray applications
• Touch to enter the application.
• Touch and hold to move or change
applications.
The Home screen is provided in an extended format to allow more
space for adding applications, shortcuts etc. Slide the Home screen
horizontally left and right to get a complete view.

6 7
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Touch and Hold
To enter the available options for an item, touch and hold the item.
For example, select a contact in Contacts, touch and hold this
contact, an options list will then appear on screen.
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen to scroll up and down the applications, images, web
pages… at your convenience.
The device also supports one finger zoom in (Message, Browser,
Email and Gallery) by double tapping the screen then slide with one
finger to zoom in/out).
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them
apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways to have a better view.
1�3�2 Status bar
From the status bar, you can view both phone status and notification
information.
Status icons
GPRS connected Airplane mode
GPRS in use Alarm is set
EDGE connected Speakerphone is on
EDGE in use Signal strength
3G connected Roaming
3G in use No signal
HSPA (3G+) connected No SIM card installed
HSPA (3G+) in use Vibrate mode
HSPAP connected Ringer is silenced
HSPAP in use Phone microphone
is mute
4G connected Battery is very low
4G in use Battery is low
Wi-Fi is on Battery is partially
drained
Connected to a Wi-Fi
network Battery is full
Bluetooth is on Battery is charging
Connected to a
Bluetooth device
/
Headset connected
NFC is on

8 9
Touch and drag down the Status bar to open the Quick setting panel
or Notification panel.Touch and drag up to close it.When there are
notifications, you can touch them to access notifications directly.
Quick setting panel
Touch and drag down the Status bar to open the Quick setting
panel, where you can enable or disable functions or change modes
by touching the icons.
Touch to switch to the notification panel.
Touch to access Settings, where you
can set more items.
Notification panel
When there are notifications, touch and drag down the Status bar to
open the Notification panel to read the detailed information.
Touch to clear all event–based
notifications (other ongoing
notifications will remain)
Touch to switch to the quick setting panel.
Notification icons
New Gmail message Missed call
New Email message Call forwarding is on
New text or multimedia
message Song is playing
Problem with SMS or
MMS delivery Connected to VPN
New Google Hangouts
message Disconnected from VPN
New voicemail Radio is on
Upcoming event Uploading data
Screenshot error Downloading data
Screenshot captured Download finished
microSD card is full Select input method
safe to remove SD card Phone is connected via
USB cable
preparing SD card System update available
Both USB tethering and
portable hotspot are on
Carrier data use
threshold approaching
or exceeded
USB tethering is on GPS is on
Portable Wi-Fi hotspot
is on
Receiving location data
from GPS
An open Wi-Fi network
is available

10 11
1�3�3 Search bar
The phone provides a Search function which can be used to locate
information within applications, the phone or the web.
1�3�4 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by
creating a variety of patterns, PIN or password etc.
1�3�5 Personalize your Home screen
Add
You can touch and hold a folder, an application or a widget to activate
the Move mode, and drag the item to any Home screen as you prefer.
Reposition
Touch and hold the item to be repositioned to activate the Move
mode, drag the item to the desired position and then release. You can
move items both on the Home screen and the Favourite tray. Hold
the icon on the left or right edge of the screen to drag the item to
another Home screen.
Remove
Touch and hold the item to be removed to activate the Move mode,
drag the item up to the top of the icon, and release after the
item turns red.
Create folders
To improve the organization of items (shortcuts or applications) on
the Home screen and the Favourite tray, you can add them to a folder
by stacking one item on top of another. To rename a folder, open it
and touch the folder’s title bar to input the new name.
Wallpaper customization
Touch the Menu key on the Home screen then touch Set
wallpaper to customize wallpaper.
1�3�6 Volume adjustment
You can set the ringer, media and phone ringtone volumes to your
preference by pressing the Volume up/down key, or touching
Settings\Sound\Volume to set the volume.
1�4 Dual screen
Touch and hold the Back key to start or hide dual screen launcher.
Touch to run the
selected App.
Touch to open
or close the dual
window launcher.
• Touch Edit to display all Apps within the dual screen launcher.
• Touch and hold the App and drag it to dual screen launcher or
dual screen list.
• After edit, touch Done.
When an App is running, open the dual screen launcher, touch and
hold the 2nd App move to 1st App, you can then check information
for two applications on one window.
Move the split bar to
adjust the size of the
window.
Only supports the Apps within the dual screen list.

12 13
2 Text input ���������������������
2�1 Using Onscreen Keyboard
Onscreen Keyboard settings
Touch the Menu key from the Home screen, select Settings\
Language & input, touch the Settings icon on the right of
Android keyboard,and a series of settings will become available
for your selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard
orientation. You can also adjust it by changing the settings (Touch
the Menu key on the Home screen, then touch Settings\Display\
Auto-rotate screen).
2�1�1 Android keyboard
Touch to switch
between symbol and
numeric keyboard.
Touch & hold to
select symbols.
Touch to enter
text or numbers.
Touch to enter voice
input; touch & hold to
show input options.
Touch to switch
"abc/Abc" mode;
Touch & hold to
switch "ABC/abc"
mode.
2�2 Text editing
You can edit the text you have entered.
• Touch and hold or double-tap within the text you would like
to edit.
• Drag the tabs to change the highlighted selection.
• The following options will show: Select all , Cut , Copy
and Paste .
• Touch the icon to go back without any action.
3 Phone call ����������������
3�1 Placing a call
You can easily launch a call using Phone. Touch the Application tab
from the Home screen and select Phone.
Touch and hold to
access voicemail.
Display the
suggested
number(s).
Slide to access
the Call log and
Contacts.
Touch to call the
previewed number.
Touch to hide/
display keyboard
Enter the desired number from the keyboard directly or select a
contact from Contacts or Call log by sliding or touching tabs, then
touch to place the call.
The number you entered can be saved to Contacts by touching
and then touching Create new contact.
If you make a mistake, you can delete the incorrect digits by touching
.

14 15
To hang up a call, touch or the Power key (when the Call
settings\Power key ends call option is activated).
You can turn on or turn off one hand mode by touching the Menu
key and touching Turn on/off one hand dialer.
3�2 Speed dial settings
You can access this settings screen by touching the Menu key and
then touching Speed dial on the Dial screen. Select contacts to
define the 2-9 screen keys as a speed dialers.
3�3 Answering or rejecting a call
When you receive a call:
• Slide the icon to the right to answer;
• Slide the icon to the left to reject;
• Slide the icon upwards to reject the call by sending a preset
message.
To mute the ringtone volume of an incoming call, press the Volume
up/down key or turn over the phone (when the Call settings\Turn
over to mute option is activated).
3�4 Answering modes
Touch to select
answering mode
If you have kept this phone and SIDEKICK(1) connected by Bluetooth,
SIDEKICK will be the default answering mode. However, any of the
following answering modes can be selected:
Handset earpiece: You can only start a conversation by
using handset earpiece.
Speaker: You can only start a conversation by using
speaker.
Bluetooth: You can only start a conversation by using
SIDEKICK.
3�5 Consulting your call memory
You can access your call memory by touching from the Dial
screen to view call history in categories of Missed calls, Outgoing
calls and Incoming calls.
(1) SIDEKICK (Bluetooth phone) is an accessory which is optional in box.

16 17
4 Contacts�������������������
You can view and create contacts on your phone and synchronize
these with your Gmail contacts or other applications on the web
or on your phone.
4�1 Adding a contact
Touch Application tab on the Home screen, select Contacts, then
touch the icon in the contact list to create a new contact.
4�2 Importing, exporting and sharing
contacts
From the Contacts screen, touch the Menu key to open the options
menu, touch Import/export, then select Import from SIM card,
Export to SIM card, Import from phone/SD storage, Export
to phone/SD storage or Share visible contacts.
To import/export a single contact from/to your SIM card, choose
an account and target SIM card(s), select the contact you want to
import/export, and touch the √ icon to confirm.
To import/export all contacts from/to your SIM card, choose an
account and target SIM card(s), select Select all and touch the √
icon to confirm.
You can share a single contact or contacts with others by sending the
contact's vCard to them via Bluetooth, Gmail, etc.
Touch a contact you want to share, touch the Menu key and Share
from the contact details screen, then select the application to
perform this action.
4�3 Synchronizing contacts in multiple
accounts
Contacts,data or other information can be synchronized from multiple
accounts, depending on the applications installed on your phone.
5 Messaging�����������������
You can create, edit and receive SMS and MMS with this phone.
To access this feature, touch the Application tab from the Home
screen, then select Messaging.
To consult messages stored in your SIM card, touch the
Menu key from the Messaging screen, then touch
Settings\Manage SIM messages.
5�1 Write message
On the message list screen, touch the new message icon to write
text/multimedia messages.
Touch to create a new message.
Touch to search in all messages.
• Touch to view the whole message thread.
• Touch & hold to activate delete mode.
Sending a text message
Enter the mobile phone number of the recipient in the To bar or
touch to add recipients and touch the Type message bar to
enter the text of the message.Touch the icon to insert emotions.
When finished, touch to send the text message.
An SMS of more than 160 characters will be charged as
several SMS. Specific letters (accent) will also increase the
size of the SMS, this may cause multiple SMS to be sent to
your recipient.
