Alcatel OmniPCX 4400 User manual

Alcatel Mobile Reflexes
OK
ARCHITECTS OF AN INTERNET WORLD
Alcatel OmniPCX 4400

1
This approved DECT telephone is intended to be used with an ALCATEL
cordless PABX.
The following conditions of use must be respected, particularly as regards
the use of radioelectric frequencies:
- DECT equipment can only be used to establish links between fixed
points if these links are temporary and the equivalent isotropically
radiated power at the antenna is less than 250 mW.
- The conditions of access to a DECT equipment telepoint network shall
be stipulated by contract with the operator of the authorized telepoint
network concerned.
This telephone is specially designed for use with an Alcatel OmniPCX 4400
system as described in the guide.
Do not expose your telephone to severe conditions (rain, sea air, dust,
etc.).
Correct operation of your telephone is not guaranteed in temperatures
outside the range -10 °C to +45°°C.
You must not switch on or use your telephone near gas or inflammable
liquids.
You have just acquired a Mobile 100 or 200 and we thank you for making
this choice: it is a reliable telephone designed to make life easier for you.
Precautions for use

2

3
Precautions for use
Your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 4
Display and corresponding icons . . . . . . . . . . . . . . . . . p. 5
1.1 Status icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 5
1.2 MENU icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 6
1.3 Call icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p.² 7
1.4 How to read this guide . . . . . . . . . . . . . . . . . . . . . . . p. 8
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 9
2.1 Charging the telephone . . . . . . . . . . . . . . . . . . . . . . . p. 9
2.2 Switching on your telephone . . . . . . . . . . . . . . . . . . . p. 10
2.3 Accessing the MENU and navigating . . . . . . . . . . . . . . p. 10
Using your telephone . . . . . . . . . . . . . . . . . . . . . . . p.11
3.1 Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 11
3.2 Answering a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 11
3.3 Calling from your personal directory . . . . . . . . . . . . . p. 12
3.4 Calling your correspondent by name . . . . . . . . . . . . . p. 12
3.5 Calling back one of the last 6 numbers dialled (Redial) p. 13
3.6 Making a call-back request . . . . . . . . . . . . . . . . . . . . . p. 13
Handling several calls . . . . . . . . . . . . . . . . . . . . . . . p.14
4.1 Calling a second correspondent (enquiry call) . . . . . . p. 14
4.2 Answering a second call . . . . . . . . . . . . . . . . . . . . . . . p. 14
4.3 Switching between calls (broker call) . . . . . . . . . . . . . p. 14
4.4 Transferring a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 15
While you are away - When you return . . . . . . . . p.16
5.1 Forwarding your calls to another number
(immediate forward) . . . . . . . . . . . . . . . . . . . . . . . . . p. 16
5.2 Forwarding your calls to the voice mail . . . . . . . . . . . p. 17
5.3 Cancelling all forwards . . . . . . . . . . . . . . . . . . . . . . . . p. 17
5.4 Making another type of forward . . . . . . . . . . . . . . . . p. 18
5.5 Consulting the messages left while you were away . . p. 19
Customizing your telephone . . . . . . . . . . . . . . . . . p.21
6.1 Programming your password . . . . . . . . . . . . . . . . . . . p. 21
6.2 Creating a sheet in your personal directory . . . . . . . p. 22
6.2 Activating the vibrator or ringer (Mobile 200) . . . . . . p. 23
6.3 Customizing the ringer . . . . . . . . . . . . . . . . . . . . . . . p. 23
6.4 Selecting the language . . . . . . . . . . . . . . . . . . . . . . . . p. 24
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p.25
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p.27
Contents
1.
2.
3.
4.
5.
6.
7.

4
Your telephone
Headphone
connector
·Erase a character
·Display previous
menu
·Erase complete field
(long press)
·Hang up
·Return to idle
·Lock/unlock the
keypad (long press)
·Activate / deactivate
vibrator*(long press)
·Phone book
·Microphone
* depending on your model of telephone
Light indicating :
·Going out of radio
coverage (fast flashing)
·New message (slow
flashing)
- green: Mobile 100
- red: Mobile 200
For further information, visit our web site www.alcatel.com
·Adjust audio
volume
·Access to the MENU
·Navigate
·Confirm
·Off-hook
·Redial (long press)
·Switching between
calls (during enquiry call)
·Activate/deactivate
loudspeaker
·Activate the secret on
hands-free charger
·On / Off (long press)
·Access to the On/Off menu (1st press) to
switch off the telephone, activate/disable the
vibrator, activate/disable the ringer, lock the
keypad
MARTIN PAUL
31/08/00 16:30

5
Display and corresponding icons
The display features 1 line of status icons and 3 lines of 16
alphanumerical characters. The Mobile 200 also features a display and
backlit keypad.
The status icons are displayed on the welcome screen and indicate the
status of the telephone.
Battery charge level
Messages received:
voice and text messages, call-back requests and unanswered
calls
Calls received that have remained unanswered (if no
other types of message)
Forward activated
Ringer active
Vibrator active (Mobile 200)
Ringer disabled
Programmed call-back time
Radio reception quality
You can obtain details on the status icons from the tooltips that appear
on the welcome screen when you use the navigator:
Press the key to make these tooltips disappear.
Display and corresponding icons1.
11. Status icons
Battery
full power

6
The MENU is accessible from the welcome screen by pressing the
navigation key
It provides access to all the functions available on your system.
Directories:
manage your personal directory and access the phone
book.
Redial:
call back one of the last 6 numbers dialled.
Forwarding:
forward your calls to another number.
Mail:
consult the messages and send voice and text messages.
Manager/secretary*
Supervision*
Adjustment:
adjust contrast, activate or deactivate the beeps,
lighting, etc.
Guide:
programming, function list, etc.
Selecting the language
12. MENU icons

7
Display and corresponding icons
Adjusting the ringer
Appointment:
program a call-back time
System lock:
prohibit outgoing calls and modification of the
programming
System selection
Installation (installation reserved)
* These icons are only proposed if the corresponding functions are installed.
Making a call
Answering a call*
In conversation*
Call on hold*
Accessing the directories
Transferring a call
Switching to DTMF signals
Setting up a conference
Additional options
Call duration
* In the event of a multiple call, the icons are given indices to represent the different
correspondents.
13. Call icons

8
Press briefly on the navigation key to access the MENU and
to confirm.
Move the navigation key up or down.
Move the navigation key to the left or right.
Use the keypad to enter digits and letters.
Important information.
These symbols can be supplemented by small icons or texts.
All default or customized function codes are given in the table of codes
supplied with the telephone.
The functions described in this guide only concern telephones
programmed in multiline mode which is the default configuration when
the mobile is installed.
14. How to read this guide

9
Getting started
·Installing the battery:
·Charging the battery:
Recharge your telephone battery regularly. The telephone can be on
or off when recharging the battery.
If the telephone is to remain unused or out of its charger for several
weeks, remove the battery and store it separately.
The Mobile 100 functions exclusively with the Ni-Mh battery, and the
Mobile 200 with the Li-Ion battery.
* battery charged after 3h or 5h depending on the model.
Getting started2.
21. Charging the telephone
Position the battery in
the slide following the
mark on the label
Slide it until it clicks
into place
Connect the charger and
place the telephone in the
charging holder
The battery is charged*.
The light is on and the battery
icon is displayed.

10
·Switching off your telephone:
Press the key (long press).
·Accessing the functions:
22. Switching on your telephone
MARTIN Paul
31/08/00 16 :30
Switch on
(long press) Wait a moment (about 3 seconds) Your telephone is switched on
23. Accessing the MENU and navigating
MARTIN Paul
31/08/00 16 :30
Confirm
Confirm
Select a function in the
MENU
Associate
Overflow
Password
Within the function you can
move horizontally along the
different icons or vertically in
the text menus
Main menu
Welcome screen

11
Using your telephone
Using your telephone3.
31. Making a call
Dial Send the call You are in
conversation
SMITH John
in conversation
Transfer
Hang up
32. Answering a call
You are receiving a
call
BELLER Yves
is calling
Take the Call
Off-hook You are in
conversation
BELLER Yves
in conversation
Transfer
Hang up
To make an external call, dial the outside line access code
before your correspondent's number.
The ringer does not ring if:
-the vibrator is active and the ringer is disabled, the icon is
displayed on the welcome screen,
-the ringer is disabled and the icon is displayed on the
welcome screen.
The light flashes if both the ringer and the vibrator are disabled.

12
You can also activate your directory by using the "Personal Dir"
option of the function.
You can also activate your directory by using the "Phone Book"
option of the function.
34. Calling your correspondent by name
Press the "Phone
book" key
Enter the name or initials
(first name and name) of your
correspondent (see § 6.2) Confirm
BELL --------
Name?
33. Calling from your personal directory
Move the navigator
down Select the name of the person you wish to call
SMITH JOHN
WEBER PIERRE
MARTIN Paul
31/08/00 16 :30
Send the
call
.Name
.Initials
.Name & 1stName
BELL
BELL Joseph
BELLER Yves
2 Answers
Select the desired type of search
(by surname, initials, or surname
and first name) Confirm Select the desired name
Send the call

13
Using your telephone
To call back the last number dialled press (long press).
When your correspondent's number does not reply or is busy:
35. Calling back one of the last 6 numbers dialled (Redial)
Select the "Redial"
function Confirm
Select the name or
number
WEBER Pierre
SMITH John
0145681721
Send the call
Or else
36. Making a call-back request
SMITH John
is alerted
Call Back
CallBk accepted
Confirm the "Call
Back" option The request is
accepted Hang up

14
Certain functions can be activated either by using the text menu or by
selecting an icon in the icon strip with the navigator.
During a call, a second correspondent tries to contact you:
Handling several calls4.
41. Calling a second correspondent (enquiry call)
WEBER Pierre
in conversation
Transfer
102 ---------
Number ?
Dial the number Send the call
SMITH John
in conversation
Transfer
Hang up to
cancel the
enquiry call
Off-hook to
retrieve the
first
correspondent
The first
correspondent is
placed on hold
42. Answering a second call
BELLER Yves
is calling
Take the Call
Off-hook
The first
correspondent is
automatically placed
on hold
A second call comes
in and is indicated by
a series of beeps
BELLER Yves
in conversation
Transfer

15
Handling several calls
To switch from one correspondent to the other:
You are holding a conversation. Make an enquiry call to contact the
transfer destination number, then:
43. Switching between calls (broker call)
SMITH John
in conversation
Transfer
Recover the
correspondent on hold
WEBER Pierre
in conversation
Transfer
44. Transferring a call
SMITH John
in conversation
Transfer
Confirm the option
"Transfer"
The first correspondent
is placed on hold
Transfer Succeed
Transfer accepted
Hang up

16
T
o activate forward to the same number
To change the forward destination number
While you are away - When you return5.
51. Forwarding your calls to another number (immediate
foward)
Select the "Forward"
function Confirm The system displays
the last immediate
forward made
Fwd immediate
00388674526
Desactivated
Confirm
Confirm activation of the
forward The forward is
accepted
Programming OK
.Activate Fwd
.Modify Fwd
.Back
Fwd immediate
Return
to idle
Fwd immediate
.Activate Fwd
.Modify Fwd
.Back
.Dial a Number
.Personal Dir
.Phone Book
Fwd immediate
Addressee?
0130030306-----
Programming OK
Select the "Modify Fwd"
function Confirm Select "Dial a number" or
use the directories
Confirm Enter the forward
destination number Confirm
The forward is accepted Return to idle

17
While you are away - When you return
52. Forwarding your calls to the voice mail
Select the "Forward"
function Confirm Select the "Voice mail"
icon
Fwd immediate
Voice Mail
Confirm
Programming OK
The forward is accepted Return to
idle
53. Cancelling all forwards
Select the "Forward"
function Confirm The programmed
forward is displayed
Immediate Fwd to
01302254
Activated
Select the "Forward
cancellation" icon
Deact Forward
Deact FollowMe
Deact Rem Fwd
Confirm
"Deact
Forward"
Cancellation of the
forward is accepted
Forwarding off
Hang up

18
You can program call forward on busy, on no reply, etc.
54. Making another type of forward
Select the "Forward"
function Confirm
Select the "List of
forwards" icon
Fwd On Busy
Fwd On No Rep
Fwd Busy/NoRep
.Activate Fwd
.Modify Fwd
.Back
Fwd On Busy
Fwd immediate
00388674526
Desactivated
Fwd On Busy
.Activate Fwd
.Modify Fwd
.Back
Or else
The programmed
forward is displayed
Select the type of forward
then confirm
Confirm the "Activate Fwd"
selection for a diversion to
the same number
Select "Modify Fwd" and
confirm to change the
destination number
