ALDEN AE-1800 User manual

AE–1800 Instruction Manual
UM–AE1800–1.0
First Edition January, 2008
ALDEN
NAVTEX RECEIVER
MODEL AE–1800
INSTRUCTION MANUAL

AE–1800 Instruction Manual
WARRANTY
WARRANTY
MORCOM International, Inc. (MORCOM) warrants the AE–1800 NAVTEX Receiver
and its active antenna ANT–2000 against defects in materials and workmanship for a
period of one year from the date of shipping from the factory, during which time
MORCOM will, at its option, either repair or replace the products that prove to be
defective.
Users shall ship defective products, freight prepaid, back to a specified MORCOM dealer
for warranty service.
The warranty shall not apply to defects caused by:
●Misuse or incorrect usage
●Static discharges/lightning strikes to the antenna or to the receiver or other types of
natural disaster
●RF power from radio transmitters in excess of 30V RMS at the antenna input
●Improper or inadequate maintenance by the user
●Unauthorized service including modification, realignment of the receiver/antenna
●User–supplied software or interfacing
●Operation outside the environmental specifications listed in the manual, or
●Improper installation
The above warranty applies to the original user with a proof of purchase.
Before returning the unit to your MORCOM dealer for warranty service, please obtain
MORCOM’s return authorization.
When shipping the unit to your dealers for service, please be sure to include the
following types of information:
･Serial number
･Software release date and revision (REV.) number
･Power supply voltage
･Installation details, including antenna height and surrounding environment
･Detailed description of trouble
･Valid proof of purchase from authorized MORCOM dealer
MORCOM International, Inc.
3656 Centerview Drive, Unit #1
Chantilly, VA 20151 – U. S. A.
PHONE: [phone]
FAX: [phone]
www.morcom.com

AE–1800 Instruction Manual
IIMPORTANT NOTES
IMPORTANT NOTES
1. RADIO FREQUENCY INTERFERENCE
This equipment has been tested and found to comply with the limits for a
Class A digital device pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when this equipment is operated in a commercial environment.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his/her own expense.
2. PURPOSE OF THIS MANUAL
The purpose of this manual is to help the user operate and maintain the
equipment. The information provided is not to be considered as a contractual
specification.
3. USER’S RESPONSIBILITY
The Alden Model AE–1800 NAVTEX Receiver obtains data transmitted
from Government facilities. MORCOM International Inc. (MORCOM)
makes no claim as to the accuracy, completeness or currency of the data
since the AE–1800 only provides a means of receiving the data. Users are
completely responsible for verifying the correctness and currency of all
data received, and MORCOM shall not be liable to users for any loss,
damage or liability caused directly or indirectly by such use. Users are
solely responsible for action taken or not taken as a result of the reception
or non–reception of data.
MORCOM International, Inc.
3656 Centerview Drive, Unit #1
Chantilly, VA 20151 – U. S. A.
PHONE: [phone]
FAX: [phone]
www.morcom.com

AE–1800 Instruction Manual
WARNINGS
< WARNINGS >
1. INSTALLATION & OPERATING ENVIRONMENT
THE DISPLAY CABINET IS IN THE “PROTECTED” EQUIPMENT
CATEGORY AS DEFINED UNDER IEC 60945(2002), AND IS NOT
WEATHERIZED FOR OUTDOOR INSTALLATION/OPERATION. ANY
DAMAGE CAUSED DIRECTLY OR INDIRECTLY THROUGH WATER
INTRUSION IS NOT COVERED BY THE MANUFACTURER’S OR
DEALER’S WARRANTY.
2. INSTALLATION & OPERATING PROCEDURES
ANY DAMAGE CAUSED BY INSTALLING OR OPERATING THE
EQUIPMENT OUTSIDE THE SPECIFICATIONS DESCRIBED IN THIS
MANUAL IS NOT COVERED BY THE MANUFACTURER’S OR
DEALER’S WARRANTY.
CONTACT YOUR DEALER FOR WARRANTY CONDITIONS.
3. LIABILITY
●OPERATION
NEITHER THE MANUFACTURER NOR ITS DEALER IS RESPONSIBLE
FOR ANY LOSS OF LIFE, PERSONAL INJURY OR DAMAGE TO THE
PROPERTY RESULTING FROM THE USE OF THIS EQUIPMENT OR
FROM BEING, FOR ANY REASON, UNABLE TO EITHER OPERATE
THE EQUIPMENT OR RECEIVE INTENDED NAVTEX MESSAGES.
●MANUAL
REASONABLE PRECAUTIONS HAVE BEEN TAKEN TO PREPARE THIS
MANUAL. HOWEVER, NEITHER THE MANUFACTURER NOR ITS
DEALER ASSUMES ANY RESPONSIBILITY FOR ERRORS OR
OMISSIONS.

AE–1800 Instruction Manual
CAUTIONS
< CAUTIONS >
1: Operational – Memory Retention Period
Do not leave the equipment switched off for more than 10 days
continuously, or all stored messages will be erased, whether
they are protected or not. Important messages you wish to
preserve should be output to an optional printer or to a PC via
an appropriate rear panel interface connector if the unit is to be
kept turned off for extended periods of time.
2: Operational – “Memory–Full” Indication
As soon as the equipment has stored a total of 199
messages, the following caution will show up in the bottom
command/prompts line along with 3 beeps:
MEMORY FULL ! [CLR]TO ACKNLG.
The oldest message will then be erased from memory
automatically after reception of a next new message. As
soon as you notice the above warning, be sure to
acknowledge each unread message by pressing , and if
necessary, press to protect important messages you
wish to retain for permanent storage.
3: Environmental Safety – Equipment Disposal
The display cabinet and the active antenna unit are
considered environmentally safe in their original, assembled
forms. However, if either unit is to be discarded for any reason,
be sure to follow all relevant local ordinances/regulations, and
contact your dealer or the manufacturer (contact information
given below) for assistance or instructions before disposing
of it. Do not destroy the cabinet or the antenna casing.
MORCOM International, Inc.
3656 Centerview Drive, Unit #1
Chantilly, VA 20151 – U. S. A.
PHONE: [phone]
FAX: [phone]
www.morcom.com

AE–1800 Instruction Manual
Index
1. Typical NAVTEX Message Screen.............................................................1-1
1.1. Introduction........................................................................................................1-1
1.2. Indication of Reception and Storage of New NAVTEX Message......................1-6
2. Control Panel Functions .........................................................................2-1
3. Basic Operating Procedure.......................................................................3-1
3.1. Introduction........................................................................................................3-1
3.2. Turning the Equipment On/Off.........................................................................3-1
3.3. Adjusting Screen Brightness ...........................................................................3-2
3.4. Adjusting Keypad Backlighting Level ..............................................................3-2
3.5. Switching First and Second Receivers ..............................................................3-2
3.6. Scrolling NAVTEX Messages.............................................................................3-3
3.7. Stopping Audible and Visual Alarm ..................................................................3-4
3.8. Protecting Messages for Permanent Storage....................................................3-5
3.8.1. Introduction ..............................................................................................3-5
3.8.2. Protecting Procedure ..............................................................................3-5
3.8.3. Removing Protection Tag ......................................................................3-6
4. Customizing Operation via Menu System...................................................4-1
4.1. Introduction........................................................................................................4-1
4.2. Accessing the Menu System ..............................................................................4-1
4.3. Selecting Screen Background Colors ................................................................4-2
4.4. Selecting Message Font Types...........................................................................4-2
4.5. Turning on/off Screen Sleep Mode.....................................................................4-3
4.5.1. Introduction ..............................................................................................4-3
4.5.2. Turning Sleep Mode on ............................................................................4-3
4.5.3. Setting Times to Reduced Brightness Levels ......................................4-4
4.6. Selecting Frequencies for Second Receiver.......................................................4-4
4.7. Turning on/off Keypress Beep ...........................................................................4-5
4.8. Selecting and Rejecting Transmitters...............................................................4-6
4.8.1. Introduction .............................................................................................4-6
4.8.2. Setting Procedure ...................................................................................4-6
4.9. Selecting and Rejecting Message Types............................................................4-8
4.9.1. Introduction.............................................................................................4-8
4.9.2. Setting Procedure..................................................................................4-8
4.10. Searching Memory for Stored Messages......................................................... 4-11
4.11. Selecting Output Messages .............................................................................4-12

AE–1800 Instruction Manual
Index
4.11.1. Introduction ............................................................................................4-12
4.11.2. Outpu t t ing Live NAVTEX Messages ................................................4-13
4.11.3. Outputting All Stored Messages .......................................................4-14
4.11.4. Outputting NAVTEX Messages of Specific Receiver ....................4-15
4.11.5. Outputting NAVTEX Messages of Specific Station ......................4-16
4.11.6. Outputting NAVTEX Messages of Specific Message Type...........4-17
4.11.7. Outputting All Displayed NAVTEX Messages ...............................4-18
4.11.8. Outputting Specific NAVTEX Message...........................................4-19
4.12. Setting Output Ports .......................................................................................4-20
4.12.1. Introduction ..........................................................................................4-20
4.12.2. Enabling / Disabling I / O Ports .............................................................4-20
4.12.3. Selecting Communications Protocols ...........................................4-22
4.12.4. Selecting Bit Formats and Data Transfer Rates ......................4-23
4.13. Performing Self–Diagnostic Tests ..................................................................4-26
4.13.1. Introduction ............................................................................................4-26
4.13.2. Activating Self–Diagnostic Test Function.........................................4-26
4.13.3. Checking Test Results .............................................................................4-27
4.14. Turning on/off Message Alarms.......................................................................4-28
4.15. Resetting the System......................................................................................4-29
5. User–Level Troubleshooting .....................................................................5-1
5.1. Power–Up Problems...........................................................................................5-1
5.2. No Message Reception .......................................................................................5-2
5.3. Message Storage Problems................................................................................5-4
5.4. Poor Reception ...................................................................................................5-5
5.5. Blank Message Screen.......................................................................................5-6
5.6. Uncontrollable Screen Brightness.....................................................................5-6
5.7. No Beep from Keypress .....................................................................................5-6
5.8. No Response from Keypress ..............................................................................5-7
5.9. No Message Alarm Indication ...........................................................................5-7
5.10. No Message Alarm Output ................................................................................5-8
5.11. No External Outputs .........................................................................................5-8
5.12. External Control Problem .................................................................................5-9
6. User–Level Maintenance Instructions ................................................6-1
6.1. Maintenance on the Equipment Cabinet ..........................................................6-1
6.2. Maintenance on Electrical Connections............................................................6-1
6.3. Maintenance on The Active Antenna Unit........................................................6-2

AE–1800 Instruction Manual
Index
6.4. Self–Diagnostic Tests.........................................................................................6-2
6.5. Recommended Spare Parts................................................................................6-3
7. Installation ............................................................................................7-1
7.1. Receiver Cabinet Installation............................................................................7-1
7.1.1. General Precautions ...............................................................................7-1
7.1.2. Mounting the Receiver Cabinet..................................................................7-1
7.2. Antenna Installation..........................................................................................7-3
7.2.1. Installation Site Requirements ..................................................................7-3
7.2.2. Precautions for Cabling ..............................................................................7-3
7.3. Electrical Connections .......................................................................................7-5
7.3.1. Introduction ..............................................................................................7-5
7.3.2. Connector Pin Assignments and Connections ....................................7-7
7.4. INS Port Data and Command Sentences........................................................7-15
7.4.1. Received NAVTEX Sentence Format .................................................7-15
7.4.2. Controlling Receiver Operation via INS (RS–422) Port ...............7-17
7.4.3. Checking Current Settings via INS (RS–422) Port.......................7-18
7.4.4. Alarm Output Sentence Formats.......................................................7-19
7.4.5. Alarm Acknowledgement .....................................................................7-20
7.4.6. Proprietary Sentence (Switching 2nd Receiver Frequency ) ........7-20
8. Summarized Theory of Operation ........................................................8-1
8.1. What is NAVTEX?..............................................................................................8-1
8.2. Operating Frequencies ......................................................................................8-1
8.3. Service Area........................................................................................................8-1
8.4. Error Correction.................................................................................................8-1
8.5. NAVTEX Receiver – General.............................................................................8-2
8.6. The AE–1800 NAVTEX Receiver ......................................................................8-2
8.7. Operating Principle of AE–1800........................................................................8-3
9. Specifications .........................................................................................9-1
10. List of Alarms ......................................................................................10-1
10.1. Message Alarms ...............................................................................................10-1
10.2. Operational Alarms..........................................................................................10-1
11. List of Abbreviations ........................................................................... 11-1
12. User Settings To Be Stored in Non–Volatile Memory ............................12-1
13. List of Components To Be Shipped .........................................................13-1

AE–1800 Instruction Manual
Typical NAVTEX Message Screen
1. Typical NAVTEX Message Screen
1.1. Introduction
The illustration below represents a typical NAVTEX message screen, showing a new
message received on the first (518 kHz) receiver. A similar screen will show up when
the equipment is switched to receive a second receiver (490 kHz or 4209.5 kHz) message.
A brief description of on–screen indications is given below and in the following pages.
Figure 1-1 Typical NAVTEX Message Screen (First Receiver Page)
①Indication of Receiver in Use to Display Current Messages
･1ST RCVR: First receiver, 518 kHz
･2ND RCVR1: Second receiver, 490 kHz or 2ND RCVR2:4209.5 kHz
The two receivers can be switched by pressing or by means of a software
command from an IBS/INS terminal via the rear panel RS–422 connector (INS
port). See paragraph 7.4 for details.
②Message No. and Total No. of Messages Stored
The message number of the currently displayed message along with the total
number of stored messages is indicated in the following format:
Examples:
・12/12: Message #12 (newest message) of 12 messages stored
・1/12: Message #1 (oldest message ) of 12 messages stored
( continued on next page )
1ST RCVR MSG (12/12)   STANDBY
JD13 INEW MESSAGEIIALARM!II
011400 UTC JAN
POLISH SAR INFO 003
SOUTHEASTERN BALTIC
FISHING VESSEL OF UNIDENTIFIED REGISTRY
IS ON FIRE AND IS IN DANGER OF SINKING IN
POSITION 55–22.23N 14–40.37E.
ALL SHIPS IN THE VICINITY ARE URGENTLY
REQUESTED TO RUSH TO THE SITE AND OFFER
ASSISTANCE.
NNNN
STORED (CER= 00%)
MORE NEW MSG LEFT !
①②③④
⑤
⑥
⑨
⑩
⑬
⑦
⑧
⑪
⑫

AE–1800 Instruction Manual
Typical NAVTEX Message Screen
1. Typical NAVTEX Message Screen ( continued – 2/6 )
1.1. Introduction (
continued – 2 /5 )
③Message Scrolling Keys
The keys that can be used to manually scroll messages across the current screen
are indicated.
・ : Line–by–line scrolling by pressing /
・: Message–by–message scrolling by pressing
/

NOTE: When a type–D message (SAR, piracy and armed robbery information) is
received on either the first or second receiver, automatic scrolling will be disabled until
the user acknowledges the
message with

or with a software command from an
IBS/INS terminal via the rear–panel
RS–422 connector. See paragraph 7.4 for details.
④Receiver Operating Status Indication
The current status of receiver operation is indicated here.
・ABORTED: The receiver has failed to lock onto the current transmission,
due, for example, to weak signal level or noise interference.
No message will be displayed or stored.
NOTE: Signal propagation conditions change greatly with time.
You might not be able to receive a signal in the daytime that can
be received at night; this is normal and should not be considered
as a sign of receiver malfunction.
・ACQUIRING: The receiver is currently in the process of locking onto the
start of the current message transmission.
・LOCKED: The receiver has locked onto current NAVTEX transmission,
allowing a message to be received. As soon as the equipmet
starts receiving the message, this indication will be replaced
by RCVNG MSG.
・RCVNG MSG: The receiver is properly receiving a message after locking
onto current transmission. This blinking indication will stay
until the end–of–message code NNNN (⑩) is received.
NOTE: Whether to display or output the message to external
devices depends on the character error rate
(CER, ⑫) and on
the selection/rejection settings to be made via the procedure in
paragraph 4.8.
・STANDBY: The receiver is idling, waiting for a NAVTEX message
transmission to begin. Most stations transmit messages every
4 hours.
⑤Operating Status Line
The current status of receiver operation, text scroll keys, etc. are indicated here.
Examples:
・1ST RCVR MSG: Message received on the first receiver is currently displayed.
・2ND RCVR MSG: Message received on the second receiver (490 or 4209.5 kHz)
is currently displayed.
・ : Message can be scrolled line by line by pressing /.
・STANDBY: Receiver is idling, waiting for a NAVTEX message
transmission. See ④above for details.
(
continued on next page )

AE–1800 Instruction Manual
Typical NAVTEX Message Screen
1. Typical NAVTEX Message Screen ( continued – 3/6 )
1.1. Introduction (
continued – 3/5 )
⑥Message Identification (Message ID)
The ID of the currently displayed message is shown here. A red–colored ID
represents a warning message. A message ID consists of the following elements:
station ID, message type, and message serial number, as in the following example.
Figure 1-2 NAVTEX Message ID Format – Example
*1:
ID of the transmitter from which the message was received .
Examples: J in NAVAREA Ⅰ : Gislövshammar, Sweden
F in NAVAREA Ⅳ: Cape Cod /Boston, U.S.
I
in NAVAREA Ⅱ: Las Palmas, Spain
*2:
Type (category) of this message ( subject indicator)
Examples: A: Navigational warnings
B: Weather warnings
D:
Search and rescue, piracy and armed robbery information
*3:
Serial number of this message
Each message within the same category group is allocated a serial number between
00 and 99 by each transmitter. A message with number 00 is always received on
each transmission regardless of rejection settings, and will be displayed and stored
in memory.
⑦Alarm Tag IIALARM!III
This tag represents a visual alarm and is turned on when a NAVTEX message of
one of the following types has been received.
･Type–A Message: Navigational warning ( initially disabled)
･Type–B Message: Weather warning (initially disabled)
･Type–D Message: Search and rescue, piracy and armed robbery information. All text
characters will be displayed in red to distinguish it from other
type alarm messages.
･Type–L Message: Additional navigational warning (initially disabled)
NOTE: When a type–D message has
been received, an audible alarm will
also be turned on, beeping at approx.
1–second intervals. To silence the
alarm sound, press
. A second
keypress resets the alarm
and
removes the alarm tag.
The alarm for the message types A, B and L is initially disabled. It can be enabled
via SYSTEM MENU – 9:TURN ON/OFF MESSAGE ALARM.See paragraph 4.14 for details.
(
continued on next page )
Silencing the audible alarm constitutes
your acknowledgement of the current
alarm message.
< CAUTION
>
J D 1 3
*3Message serial number
(
B3&B4characters)
*2Message Type
(
B2character)
*1Transmitter ID
(
B1character)

AE–1800 Instruction Manual
Typical NAVTEX Message Screen
1. Typical NAVTEX Message Screen ( continued – 4/6 )
1.1. Introduction (
continued – 4 / 5 )
⑧New Message Tag IINEW MESSAGEII
This indication ( tag) shows that the currently displayed NAVTEX text is a new
message that you have not yet read or acknowledged.
To acknowledge it, simply press or , turning the tag off.
If two or more new messages have been left unread, the following caution message
will be displayed at the screen bottom, prompting you to read them. Press 
again to display, or scroll the text up to, the next one by pressing /.
The NEW MESSAGE tag for the current message will be automatically removed 24
hours after its reception, if it is left unacknowledged ( i.e. if is not pressed).
⑨NAVTEX Message
If message text exceeds the screen display area, you can scroll it line–by–line by
pressing /. Holding down either key accelerates the scroll.
To read other messages, press /( for message–by–message scrolling).
Holding down either key accelerates the scroll.
Type–D messages (SAR, piracy and armed robbery information) will be displayed
in red. A new type–D message will remain fixed on screen until:
･it is acknowledged by pressing or by means of a *1software command
through an INS/IBS terminal interfaced to the rear panel RS–422 connector, or
･another new type–D message is received.
*1:
See paragraph 7.4.5 for details.
NOTE: Forced carriage return 
When the number of characters in a line exceeds 40, an internally generated carriage return
symbol, shown above, will be automatically inserted in the 40th character position to divide the
last word, forcing the rest of the characters in the word to shift to the top of the next line. This
symbol will be replaced by an underscore ( _ )
(hex 5F ) when it is printed or output to an IBS/ INS
device via the RS–422 port.
⑩End–of–Message Indication NNNN
The appearance of these four successive Ncharacters indicates the end of the
currently displayed NAVTEX message.
NOTE: Some messages including those from Chinese stations, end with NN (2 Ns)
instead of NNNN (4 Ns), in which case, the equipment will consider that the
transmission has not ended properly, and will not, therefore, display and store such a
message, or will append it to a new message, if received within a specified period of time,
and display the two messages combined. The RS–232C port (printer port) may be set to
output such messages. See paragraph 4.9 for setting instructions.
(
continued on next page )
MORE NEW MSG LEFT !

AE–1800 Instruction Manual
Typical NAVTEX Message Screen
1. Typical NAVTEX Message Screen ( continued – 5/6 )
1.1. Introduction(
continued – 5/5 )
⑪Indication of Message Storage Status
This indication shows whether or not the displayed NAVTEX message has been
stored in the internal non–volatile memory.
･*1STORED: The message has been stored.
When message reception has been completed with a character error rate (CER,⑫)
of 33% or less, the received NAVTEX message together with its ID will be displayed
and stored in memory, making it possible to recall it onto the screen at a later time.
If the same message is received with a lower CER on the next transmission, the
previously stored message will be replaced with the new one. However, if the first
message was received with a CER of 4% or less, message replacement will not take
place on subsequent reception with a lower CER.
When the CER exceeds 33%, the message and its ID will not be displayed and will
not be stored in memory, allowing a retransmission of the same message to be
displayed and stored.
*1:
If the message selection/rejection settings are made so that a particular message
type is rejected from storage, this indication will not be displayed regardless of a
CER
being smaller than 33%. See paragraph 4.9 for the related setting instructions.
⑫Character Error Rate (CER) Indication
CER is the percentage ratio of the total number of corrupt characters represented
by asterisks (*) to the total number of characters received in a message, including
control codes (sync. signal, carriage returns, line feeds, letter/numeral shift, etc.).
If a message is received with a CER equal to or greater than 33%, the message will
not be displayed and stored in memory, allowing the same message to be received
again on its next transmission. No CER reading will be available on the current
transmission.
See paragraph
⑪for more information on CER.
⑬Message Prompt Line
This line indicates the receiver’s response for the user’s keypress or displays
prompts related to reception of new or alarm NAVTEX messages on the first or
second receiver, or related to message storage, like the examples below.
･ALARM MESSAGE RECEIVED ON 2ND RCVR
･MORE UNREAD ALARM
*2MSG LEFT
･2ND
*3RCVR RECEIVED NEW MSG
･MORE NEW MSG LEFT
･STORAGE LIMIT IS REACHED
･MEMORY FULL !
*4[CLR] TO *5 ACKNLG.
*2MSG = MESSAGE, *3RCVR = RECEIVER
*4[CLR] = *5ACKNLG = ACKNOWLEDGE

AE–1800 Instruction Manual
Typical NAVTEX Message Screen
1. Typical NAVTEX Message Screen ( continued – 5/5 )
1.2. Indication of Reception and Storage of New NAVTEX Message
●Indicating Reception of New Message – First Receiver
The equipment visually indicates the reception of a new NAVTEX message by
attaching a tag (iNEW MESSAGEi) to the message ID, as in the example below.
The tag will be turned off 24 hours after reception or when you press .
Figure 1-3 First Receiver Receiving New NAVTEX Message – Example
●Indicating Reception of New Message – Second Receiver
When the first receiver message screen is currently showing, the reception of a new
message on the second receiver is indicated with message “ 2ND RCVR RECEIVED
NEW MSG” blinking in the prompt line at the screen bottom, as in the example
below. To read it, switch to the second receiver page by pressing .
Figure 1-4 Indication of New Message Reception on Second Receiver – Example
●Indicating Successful Storage of New Message
When a new NAVTEX message has been received with a character error rate (CER)
of 33% or less, the message will be displayed and stored in non–volatile memory
together with its ID; this condition is displayed with indication “ STORED” at the
end of the message together with its CER reading, as in the example above.
If the CER exceeds 33%, the currently received message will not be stored and will
not be displayed. No CER reading will be available.
..................................................
NNNN STORED
(
CER= 00%
)
2ND RCVR RECEI
V
ED NEW MSG
This message blinks .
NA28 INEW MESSAGEI
CCGD5 BNW 328–06
NJ – COASTAL – SURFACE AND SUB–SURFACE
DATA BUOY DEPLOYMENT
1. 60 SUBSURFACE AND 2 SURFACE MOORINGS
WILL BE DEPLOYED ON LINES EXTENDING FROM
39–09.6N, 073–22.05W TO 38–55.56N, 072–50.76W
AND OUT TO ･････････････････････････････････
･･････････････････････････････････････････････
･･････････････････････････････････････････････
｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡｡
NNNN STORED (CER= 00%)
Tag indicating reception of new message
Message ID
End
–
of
–
message indication
Successful storage indication
Character error readout

AE–1800 Instruction Manual
Control Panel Functions
2. Control Panel Functions
The figure below shows the control panel of the equipment. A summary description of
the functions the keys provides is given below and in the following pages.
Figure 2-1 Control Panel
①Screen Brightness Key 
Repeated pressing of this key adjusts the screen brightness in a total of 8 steps
including a completely dark level. The last used level is stored in memory. The
brightness level returns to its maximum on next power–up when the equipment is
switched off with the level set to its minimum. See paragraph 4.5 for related
information.
②Power Key
– 1/2
Figure 2-2 Opening Message – Example
This key turns the unit on/off. A
first keypress turns it on,
displaying an opening message
like the example at right for
approximately five seconds.
Figure 2-3 Power–Off Countdown Window
Keep on pressing the key until all
five bars have disappeared, and
then release it to completely
switch the unit off. This delayed
action helps prevent an
accidental shutoff and resultant
loss of data.
Releasing the key with at least one countdown bar showing cancels the power–off
sequence.
(
continued on next page )





②④⑥⑧⑩⑫⑭⑯⑰
①③⑤⑦⑨⑪⑬⑮
To turn the unit off, press and
hold down for 2–3 seconds
until a power–off countdown
window shows
up as illustrated
at right, indicating that a
power–off sequence has started.
SHUTTING DOWN NAVTEX RECEIVER
WAIT !– – – – –
Countdown bars
WELCOME TO NAVTEX RECEIVER
SOFTWARE VER. 1.0 REV_1.1A1
DATE OCT 06, 2007
V
ersion and date information is an example.

AE–1800 Instruction Manual
Control Panel Functions
2. Control Panel Functions ( continued – 2/12 )
②Power Key
– 2/2
After the unit is switched on, the opening message window will be replaced with
another window listing the current settings of receiver control parameters, as in the
example below.
Figure 2-4 Current Settings of Receiver Control Parameters – Example
The above list will stay on for approximately 20 seconds before the message screen
shows up, replacing it automatically.
To turn the list off immediately, press or .
③Keypad Dimmer Key 
Pressing this key adjusts the keypad backlighting level in a total of 8 steps
including a completely switched–off level.
The last used level will be stored in memory. When the equipment is switched off
with the level at its minimum, the keypad will be lit at the highest level at next
power–up time.
④Audible Monitor Key 
Pressing this key allows you to audibly monitor the reception of a NAVTEX
transmission. To monitor the sound continuously, hold down the key. As soon as it is
released, the audible output is turned off.
(
continued on next page )
CURRENT SETTINGS
1:FIRST RECEIVER:
REJECTED STATIONS:
REJECTED MESSAGE TYPES: G I M
NO P Q R S T U W X Y
2:SECOND RECEIVER:
REJECTED STATIONS:
REJECTED MESSAGE TYPES: G I M
NO P Q R S T U W X Y
3:KEYPRESS BEEP: ON
4:DISABLED MSG ALARMS: A B L
5: RECEIVING MSG OUTPUT: OFF
6:2ND RECEIVER FREQ.: 490KHZ
7:DISPLAY SLEEP MODE: 5MIN./ 30MIN.
IPRESS [CLR]OR [ENT]TO START.
Blinks in reverse video.

AE–1800 Instruction Manual
Control Panel Functions
2. Control Panel Functions ( continued – 3/12 )
⑤Screen Page Key 
Pressing this key switches the message screen between the first receiver screen
page and the second receiver screen page.
For example, if the current screen is currently showing the first receiver page (i.e.
518 kHz NAVTEX message display), a first keypress changes the display to show
the second receiver page (i.e. 490 kHz/4209.5 kHz message display). A second press
changes it back to the first receiver page. See paragraph 3.5 for more details.
⑥Alarm Stop Key 
The equipment will alarm you audibly through a built–in buzzer and visually by
turning on an alarm tag ( iALARM!I ) in reverse video on the message screen upon
reception of an important NAVTEX warning (type–D message, for example). A
type–D message text will be displayed in red. See paragraph 3.7 for more details.
Pressing this key silences the
audible alarm. A second key–
press removes the alarm tag,
resetting the alarm. Observe the
CAUTION at right.
If other types of warning messages (e.g. type–A messages) were received in addition
to a D–type message, pressing the key silences the audible alarm for all warnings
at a time.
A new type–D message received on either the first receiver or second receiver will
remain fixed on screen and will not automatically scroll until:
･this key is pressed *1twice to acknowledge it,
･the user remotely *2acknowledges it from an IBS/ INS terminal connected to the
rear–panel RS–422 connector (INS port), or
･another new type–D message has been received on either receiver.
If more alarm messages are left unread in memory, a next alarm message will be
displayed after the above keypress. However, no audible alarm will be available.
*1:
A first keypress turns off the alarm sound only.
*2:
See paragraph 7.4 for information on the command format .
⑦Up Key

･When a NAVTEX message is being displayed, pressing this key scrolls the
message screen downward one line at a time, allowing you to view message lines
hidden beyond the screen’s upper text display limit. When the newest message
(e.g. 200/200) is reached, a further keypress displays the oldest one (e.g. 1/200).
Holding down the key accelerates text scrolling.
･When a menu is displayed, pressing this key selects vertically listed options
upward. Press after highlighting the desired option.
(
continued on next page )
Silencing the audible alarm constitutes
your acknowledgement of the current
alarm message/condition.
< CAUTION
>

AE–1800 Instruction Manual
Control Panel Functions
2. Control Panel Functions ( continued – 4/12 )
⑧Left Key 
･When a NAVTEX message is being displayed, a single press of this key scrolls the
message text by one message forward timewise, displaying a newer message.
･Holding down the key accelerates the scroll.
When the screen is showing the newest message (e.g. 200/200), a further
keypress returns you to the oldest message (e.g. 1/200).
･When a currently displayed menu has horizontally listed options, pressing this
key selects (i.e. highlights) those options in a leftward direction. Be sure to press
after highlighting the desired option.
⑨Enter Key

･When a NAVTEX message is being displayed, pressing this key displays the
newest message (e.g. 200/200).
･When a menu is being displayed, pressing this key:
- completes the selection of a desired option,
- executes the function selected or,
- finalizes the current setting.
⑩Down Key

･When a NAVTEX message is being displayed, pressing this key scrolls the
message screen upward one line at a time, allowing you to view message lines
hidden beyond the lower text display limit of the screen.
･When the screen is showing the oldest message (e.g. 1/200), further keypress
returns you to the newest message (e.g. 200/200).
･Holding down the key accelerates the scrolling.
･When a menu is being displayed, pressing this key selects (highlights) vertically
listed options downward. Be sure to press after highlighting the desired
option.
( continued on next page )

AE–1800 Instruction Manual
Control Panel Functions
2. Control Panel Functions ( continued – 5 /12 )
⑪Message/Station Selection Key – 1/2
･When the screen is showing a NAVTEX message, pressing this key displays a
summary list of the transmitter IDs and message types that are currently
selected as in the example below so that the equipment displays and stores
messages of the selected types from the selected transmitters.
Figure 2-5 List of Currently Selected Stations and Message Types – Example
All transmitters and most of major message types are initially selected so that
the equipment will display and store those selected types of messages from all
stations in the coverage area.
A particular station or a particular message type can be rejected from display or
storage via the menu system. Detailed instructions are given in paragraph 4.8.
→SYSTEM MENU →4:MAKE SEL/ REJ SETTING →1/2/3 →1/2 →
To turn off the above lists, press .
NOTE: Message types A (navigational warning), B ( meteorological warning), D (SAR,
piracy and armed robbery information) and L ( additional navigational warning) are
always selected for storage in memory and output to the I / O ports, and cannot be
rejected due to the relevant IMO resolutions and IEC requirements.
(
continued on next page )
MEM. SELECTED STATIONS:
A B C D E F G H I J K L M
N O P Q R S T U VW X Y Z
MEM. SELECTED MESSAGES:
A B C D E F H J K L
VZ
< FIRST RECEIVER >
MEM. SELECTED STATIONS:
A B C D E F G HIJ K L M
N O P Q R S T U V W X Y Z
MEM. SELECTED MESSAGES:
A B C D E F H J K L
V Z
< SECOND RECEIVER 1>
MEM: to be stored in memory
SECOND RECEIVER 1:490 kHz
SECOND RECEIVER 2:4209.5 kHz

AE–1800 Instruction Manual
Control Panel Functions
2. Control Panel Functions ( continued – 6/12 )
⑪Selection/Station Key
– 2/2
･When option “4:MAKE SEL/REJ SETTING” on the SYSTEM MENU is currently
accessed for selection/rejection settings, this key selects the station or message
type you specify for display and storage, and/or output to the I/O ports (RS–232C,
RS–422 and I/O DATA connectors). An example of station selecting procedure is
illustrated below.
Currently selected stations (SL) are shown in green. Rejected stations (RJ) are
in red.
Using
/and /
, highlight first the ID of the station of which
messages you wish to display, store, and/or output to the I/O ports, and then,
specify the target device ( ME for memory, PR for RS–232C & I/O DATA, IN for
RS–422). To select the currently rejected (RJ) setting on each device, press .
See paragraph 4.8 for details.
Figure 2-6 Selecting Stations – Example
(
continued on next page )
Station C is
currently rejected from display and storage (ME),
and from output to printer (PR). Its messages are to be output
to the INS (IN) terminal alone. To select it to display and store
its messages, press after specifying ME using
/
.
SYSTEM MENU
4:MAKE SEL/REJ SETTING
1:SYNCHRONIZE BOTH RECEIVERS
2:FIRST RECEIVER (518KHZ)
3:SECOND RECEIVER
2:FIRST RECEIVER
1:STATIONSI
2:MESSAGES
ME PR IN
A: SL SL SL
B: SL SL SL
C: RJ RJ SL
D: SL SL SL
E: SL SL SL
F: SL SL SL
G: SL SL SL
H: SL SL SL
I: SL SL SL
ME PR IN
J: SL SL SL
K: SL SL SL
L: SL SL SL
M: SL SL SL
N: SL SL SL
O: SL SL SL
P: SL SL SL
Q: SL SL SL
R: SL SL SL
ME PR IN
S: SL SL SL
T: SL SL SL
U: SL SL SL
V: SL SL SL
W: SL SL SL
X: SL SL SL
Y: SL SL SL
Z: SL SL SL
1: STATIONS
(
MEmor
y
PRinter INs
)
Target Devices:
ME: memory
PR: printer port (RS–232C)
IN: INS port (RS–422)
