XNV- 770BT
XNV-770BT AV Receiver with TomTom® navigation
INTEGRATED NAVIGATION FROM TOMTOM ®
The Sony ® XNV - 770BT A/V Receiver with Navigation features TomTom ® navigation and
delivers incredible audio and video picture quality. TomTom is the only company to
incorporate real world, real - time feedback, providing the most accurate maps available.
7 ” TOUCH SCREEN DISPLAY
High - resolution TFT (WVGA) 7 ” touch screen display that will inform and entertain you,
making everything easier to control with gesture command and on - screen touch
buttons. Separate audio and video power supply circuits provide added clarity.
PRELOADED MAPS OF US & CANADA
TomTom ® navigation provides the most accurate maps with over 1 million more miles
of road in the US than other GPS brands.
1 YEAR FREE MAP UPDATES
Map updates ensure that the digital map content remains completely up - to - date.
Access codes are provided for (4) verified US and Canada map updates for the first year.
USB 1 - WIRE CONNECTIVITY
Connect, charge, and control your iPod ® , iPhone ® , Walkman ® player or other
compatible USB devices via the USB 1 - Wire on the rear of the unit. You can also view
metadata like song title and artist on the front display.
INTEGRATED BLUETOOTH ® TECHNOLOGY
Taking calls and enjoying streaming audio has never been easier with the XNV - 770BT
A/V Receiver with Navigation featuring Bluetooth ® technology . Connect compatible
devices and easily choose between Hands Free and Phone Book Access or Audio
Streaming.
PLAYS DVDS/CDS AND DIGITAL FILES
The XNV - 770BT A/V Receiver with Navigation accepts just about every digital format
you ’ d want on the road. The XNV - 770BT can playback CD or DVD and
MP3/WMA/AAC/JPEG/MP4 (Simple Profile) CODEC files .
The Sony ® XNV - 770BT A/V Receiver with Navigation delivers incredible
audio and video picture quality and integrates navigation from TomTom ® .
With the most accurate maps and over 1 million more miles of road in the
US than others, plus features like USB 1 - Wire connectivity and Bluetooth ®
technology , you’re ready for the road trip of a lifetime and your daily
commute.
7
7
5
2
2
5
6
6
1
1
5
6

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/26/2011
XNV- 770BT
XNV-770BT AV Receiver with TomTom® navigation
Specifications
Convenience Features
CD Text Display: CD/MP3/WMA/AAC data
displayed
On - Screen Clock: 12H
DimmerAdjust: Selectable Auto/on/off
KeyIllumination: White Key Illumination
Video Features
ColorSystem: PAL / NTSC / SECAM / M - PAL
General
Color: Black
Audio
PreoutImpedance: 220 ohms
PreoutVoltage: 4 volt
S/NRatio: Audio Power: CEA2006 S/N 80
dBA
FrequencyResponse: DVD / CD: 10 - 20,000
Hz
Wow and Flutter: Below measurable limit
StationPreset(s): 18 FM / 12 AM
Digital - to - AnalogConverter: 24bit
Tuner Frequency Range: FM: Tuner
Frequency Range(MHz): 87.5 - 107.9
AM: Tuner Frequency Range(kHz): 530 -
1710
TunerType: SSIR - EXA with RDS
VolumeControl: Tel/Nav Attenuation
Circuitry
Band: AM / FM
Signal - to - Noise Ratio (dB): DVD/CD Player:
120dB
Format(s)Supported:
MP3/WMA/AAC/JPEG/MP4/XviD files
Equalizer: EQ7: 7 band EQ with +/ - 6 dB
adjustment at: 63, 160, 400, 1000, 2500,
6300 and 16000 Hz
Convenience
TiltRange: 0 - 45 ° mounting angle
Display
Technology: TFT (WVGA)
AspectRatio: 17:9
TextDisplayed: Source, artist, track,
playback time, menu and clock
Amplifier Section
SpeakerImpedance: 4 - 8 Ohms
Max power output: 52 watts x 4 at 4 ohms
Tuner
FM Usable Sensitivity: 10 dBf
Selectivity: 75 dB at 400 kHz
S/NRatio: 70 dB (mono)
FrequencyResponse: FM: 20 - 15,000 Hz
StereoSeparation: 40 dB at 1 KHz
Power
OutputPower: 52W x4 Watts Max Power -
CEA2006 Standard Power Output: 17
Watts RMS per channel into 4 Ohms, 4
channels driven from 20 Hz to 20 kHz with
less than 1% THD+N.
CurrentDrain: 5 - 7 amps
InputVoltage: 12 V DC car battery
(negative ground)
1
Inputs and Outputs
RCA Audio Output(s): Front, Rear, and
Subwoofer RCA pre - amp outputs
Digital Audio Input(s): - Ability to use all
forms of USB devices may vary as not all
devices are compatible.
- This unit can be connected to the
following iPods. Update your iPod to the
latest software before you use it.
- iPod Nano 1st generation*
- iPod Nano 2nd generation (aluminum)
- iPod Nano 3rd generation (video)
- iPod 5th generation (video)*
- iPod Classic
- iPod Touch
- iPhone
- This unit is compliant with MSC (Mass
Storage Class) and MTP (Media Transfer
Protocol) type USB devices compliant
with the USB standard.
- This unit cannot recognize USB devices
via a USB hub.
- If you have any questions or problems
concerning your unit that are not
covered in the owners manual, consult
your nearest Sony dealer.
USBPort(s): Rear USB - Full Speed
AntennaTerminal(s): AM/FM Antenna
Input Terminal
12V Trigger Output(s): Power antenna
Amplifier turn on
RemoteJack: Optional wired remote
terminal
Audio/VideoInput(s): AUX1 audio/video
AUX2 audio/video
rear camera with reverse input trigger
AudioIn: Rear Aux in with variable level
Rear USB input
Sony Bus terminal
InfraredPort: Wireless remote
Dimensions
Weight: 5 lb. 14 oz. (2.7 kg)
Measurements: 7.125 x 4 x 7.5" (w/h/d)
178 x 100 x 189 mm (w/h/d)
Wireless Connectivity
Compatible Bluetooth ® Profiles: A2DP
(Advanced Audio Distribution Profile)1.2
AVRCP (Audio Video Remote Control
Profile)1.3
HFP (Handsfree Profile)1.5
OPP (Object Push Profile)
PBAP (Phone Book Access Profile)
FrequencyBand: 2.4 GHz band (2.400 -
2.4835 GHz)
MaximumRange: Line of sight approx. 10M
(33ft)
ModulationMethod: FHSS
Output: Bluetooth Standard Power Class2
(Max. +4 dBm)
WirelessConnectivity: Bluetooth Standard
version 2.0
Supplied Accessories
Supplied Wireless Card Remote (RM - X170)
Parts for Installation and Connections (1
set)
HF microphone (XA - MC10)
USB connection cable for iPod (RC - 200IPV)
CD - ROM (application disc)
Parts for enabling navigation functions (1
set)
Optional Accessories
Aux - in selector: XA - 300
iPod ® video cable: RC - 202IPV
HD Radio™tuner: XT - 100HD
Rear View Camera: XA - R800C
Mobile Monitor: XVM - B62
Color: Black
UPC Code: 027242808836
1.Notallfilesmayplaybackduetofilevariations.Copy - protectedACC -
LC files not supported.
2.CompatiblewithiPod ® with video, iPod Classic ® , iPod nano ®1st
through 5th gen., iPod Touch ® 1st & 2nd gen., iPhone ® , iPhone3G,
andiPhone3GS.Passengercontrolnotavailable for iPod nano 1st gen.
oriPodwithvideo.
3. Requires satellite radio tuner and service subscription, sold separately.
4. Requires XT - 100HDHDRadio™ tuner, sold separately.
5.InteroperabilityandcompatibilityamongBluetooth ®devicesvary.
6.RequiresInternetradio - enabledsmartphoneor devicewith
Bluetooth® streamingcapability,USB1 - wire,or1/8 ” mini connection.
7. Viewable area measured diagonally.
8. Feature available in the US and Canada only.
9.Feature only available in the US.
©2010Sony Electronics Inc.Allrights reserved.Reproductionin whole or
inpartwithout written permission isprohibited.Sony,Walkman and the
Sonylogoaretrademarks of Sony. iPodandiPhoneare trademarks of
Apple,Inc.Bluetooth is a trademarkofBluetoothSIG. ©2010TomTom
N.V., The Netherlands. TomTom ® andthetwohandslogo, among others,
aretrademarksownedbyTomTomN.V. or one of its subsidiaries. Please
seewww.tomtom.com/legalfor the limitedwarrantyandend user
licenseagreementapplyingto this product. Map data ©2010TeleAtlas
N.V.Allother trademarksaretrademarks oftheirrespective owners.
Features and specifications are subject to change without notice. Non -
metricweightsandmeasuresareapproximateandmayvary.
