Alfa Network APAG04-2 User manual

APAG04-2
2Watt ISM Band 2.4GHz Booster Module
APAG04-2 is a cost-effective, high performance 2.4GHz RF power amplifier
Module using Time Division Duplex (TDD) technology. APAG04-2 can be
installed at indoor or outdoor system to extend wireless connecting distance
and enhance throughput.
Feature
¾Cost-effective PCBA module package
¾Dual band b & g compatible
¾Bi-directional, half-duplex and Auto-Switching(Plug & Play)
¾Compact size and easy for system integration
¾Flexible parameter adjustment per customer request.
Specification

Dimension (unit: mm)
Application: Connecting Booster in a WLAN System
Typical WLAN system diagram with APAG04-2
