ALFAtron ALF-TPBK70-R User manual
- 1 -
ALF-TPBK70-R
Preface
For optimum performance and safety, please read these instructions
carefully before connecting, operating, or adjusting this product. Please keep
this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
Use of surge protection systems is highly recommended to protect and
extend the life of your equipment.
FCC Statement
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. It has been tested and found
to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause
interference, in which case the user at their own expense will be required to
take whatever measures may be necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture
would void the user’s authority to operate the equipment.
Do not dispose of this product with the normal household waste at the
end of its life cycle. Return it to a collection point for the recycling of
electrical and electronic devices. This is indicated by the symbol on the
product, user manual or packaging. The materials are reusable according
to their markings. By reusing, recycling or other forms of utilisation of old
devices you make an important contribution to the protection of our
environment. Please contact your local authorities for details about
collection points.
- 2 -
ALF-TPBK70-R
1. Introduction
The Alfatron TPBK70-R HDBaseT receiver supports video resolutions up to
4K2K@50/60Hz 4:4:4 from the transmitter over CAT6. It has bi-directional RS-
232 pass-through; audio de-embedding and the RS-232 control signal can
be transmitted up to 131ft / 40m.
Supports local HDMI in with auto switching between HDBT in and local
HDMI in.
2. Features
•Compliant with HDMI 2.0b, HDCP 2.2 and Display Port1.2a
•HDMI input supports 18Gbps video bandwidth.
•HDMI in with auto switching between HDBT in and local
HDMI in
•Video resolution up to 4K2K@50/60Hz 4:4:4.
•HDBaseT output can extend video transmission distance up to 230ft
/ 70m for 1080P@60 or 131ft / 40m for 4K@60 via a single CAT6/6a/7
cable.
•Supports 3D, HDR10 and Dolby Vision
•HDMI audio formats support LPCM, Dolby Digital / Plus / EX, Dolby
True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio,
DSD
•Supports POE function (Receiver to Transmitter only)
- 3 -
ALF-TPBK70-R
3. Specifications
Technical
HDMI Compliance
HDMI 2.0b
HDCP Compliance HDCP 2.2
DP Compliance
Display Port 1.2a
Video Bandwidth
HDMI: 18 Gbps
Video Resolution
480i~1080p50/60Hz, 4Kx2K@24/30Hz, 4k2k@60Hz
Color Space
RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0
Color Depth
8/10/12-bit (1080P@60Hz)
8-bit (4K@60Hz)
HDR Support
HDMI Audio Formats
LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS,
DTS-EX, DTS-96/24, DTS High Res, DTS-HD
Master Audio, DSD
Transmission
Distance
Max distance (1080P): 230ft / 70m over CAT6/6a/7
Max distance (4K): 131ft / 40m over CAT6/6a/7
ESD Protection
Human body model — ±8kV (Air-gap discharge) &
±4kV (Contact discharge)
Connection
Receiver
Inputs: 1x HDMI IN [Type A, 19-pin female]
1x HDBaseT IN [RJ45, 8-pin female]
Outputs: 1x HDMI OUT [Type A, 19-pin female]
1x AUDIO OUT [Phoenix jack]
Controls: 1x RS-232 [3-pin phoenix connector]
1x FW [Micro USB, Update port]
- 4 -
ALF-TPBK70-R
3.1. Receiver Panel
1 Power LED
When the product is powered on, the red LED
indicator will be on.
2
DC 24V
DC 24V power supply port.
3
FW
Firmware update port.
4 HDBaseT IN
Connect to the
HDBaseT OUT port of Transmitter
with a CAT6/6a/7 cable.
5
HDMI OUT
HDMI output port, connect to HDMI display
device.
6 HDMI IN
HDMI input port, connect to HDMI source device.
7 AUDIO OUT
Analog audio output port.
8 RS-232 port
Connect to PC or control system for
bidirectional RS-232 control signal pass-through.
- 5 -
ALF-TPBK70-R
4. Application Example
- 6 -
ALF-TPBK70-R
After-sales Service
Should you experience problems using the Alfatron ALF-TPBK70-R please
note that any transport costs of the equipment to the distributor are
borne by the user during the warranty.
1) Product Limited Warranty: Alfatron warrants that its products will be free
from defects in materials and workmanship for seven years, which starts
from the first day of purchase.
Proof of purchase in the form of a bill of sale or receipted invoice
which is evidence that the unit is within the warranty period must be
presented to obtain warranty service.
2) What the warranty does not cover (servicing available for a fee):
●Warranty expiration.
●The factory-applied serial number has been altered or removed
from the product.
●Damage, deterioration, or malfunction caused by:
●Normal wear and tear.
●Use of supplies or parts not meeting product specifications.
●No certificate or invoice as proof of warranty.
●The product model shown on the warranty card does not match
with the product or if the product had been altered.
●Damage caused by force majeure.
●Servicing is not authorized by Alfatron.
●Any other causes which do not relate to a product defect.
●Delivery, installation or labour charges for installation or setup of the
product.
Technical Support: Contact our after-sales department at
www.alfatronelectronics.com
- 7 -
ALF-TPBK70-R
Warranty
1.1 This limited warranty covers defects in materials and workmanship in
this product.
1.2 Should warranty service be required, proof of purchase must be
presented to the Company. The serial number on the product must
be clearly visible and not have been tampered with in any way
whatsoever.
1.3 This limited warranty does not cover any damage, deterioration or
malfunction resulting from any alteration, modification, improper or
unreasonable use or maintenance, misuse, abuse, accident, neglect,
exposure to excess moisture, fire, improper packing and shipping
(such claims must be presented to the carrier), lightning, power
surges, or other acts of nature. This limited warranty does not cover
any damage, deterioration or malfunction resulting from the
installation or removal of this product from any installation, any
unauthorized tampering with this product, any repairs attempted by
anyone unauthorized by the Company to make such repairs, or any
other cause which does not relate directly to a defect in materials
and/or workmanship of this product. This limited warranty does not
cover equipment enclosures, cables or accessories used in
conjunction with this product.
This limited warranty does not cover the cost of normal maintenance.
Failure of the product due to insufficient or improper maintenance
is not covered.
1.4 The Company does not warrant that the product covered hereby,
including, without limitation, the technology and/or integrated
circuit(s) included in the product, will not become obsolete or that
such items are or will remain compatible with any other product or
technology with which the product may be used.
1.5 Only the original purchaser of this product is covered under this
limited warranty. This limited warranty is not transferable to
subsequent purchasers or owners of this product.
- 8 -
ALF-TPBK70-R
1.6 Unless otherwise specified, the goods are warranted in
accordance with the manufacturer’s product specific warranties
against any defect attributable to faulty workmanship or materials,
fair wear and tear being excluded.
1.7 This limited warranty only covers the cost of faulty goods and does not
include the cost of labor and travel to return the goods to the
Company’s premises.
1.8 In the event of any improper maintenance, repair or service being
carried out by any third persons during the warranty period without
the Company’s written authorization, the limited warranty shall be
void.
1.9 A 7 (seven) year limited warranty is given on the aforesaid product
where used correctly according to the Company’s instructions, and
only with the use of the Company’s components.
1.10 The Company will, at its sole option, provide one of the following
three remedies to whatever extent it shall deem necessary to satisfy
a proper claim under this limited warranty:
1.10.1 Elect to repair or facilitate the repair of any defective parts within a
reasonable period of time, free of any charge for the necessary parts
and labor to complete the repair and restore this product to its proper
operating condition.; or
1.10.2 Replace this product with a direct replacement or with a similar
product deemed by the Company to perform substantially the same
function as the original product; or
1.10.3 Issue a refund of the original purchase price less depreciation to be
determined based on the age of the product at the time remedy is
sought under this limited warranty.
1.11 The Company is not obligated to provide the Customer with a
substitute unit during the limited warranty period or at any time
thereafter.
- 9 -
ALF-TPBK70-R
1.12 If this product is returned to the Company this product must be
insured during shipment, with the insurance and shipping charges
prepaid by the Customer. If this product is returned uninsured, the
Customer assumes all risks of loss or damage during shipment. The
Company will not be responsible for any costs related to the removal
or re-installation of this product from or into any installation. The
Company will not be responsible for any costs related to any setting
up this product, any adjustment of user controls or any programming
required for a specific installation of this product.
1.13 Please be aware that the Company’s products and components have
not been tested with competitor’s products and therefore the Company
cannot warrant products and/or components used in conjunction with
competitor’s products.
1.14 The appropriateness of the goods for the purpose intended is only
warranted to the extent that the goods are used in accordance with the
Company’s installation, classification, and usage instructions.
1.15 Any claim by the Customer which is based on any defect in the quality
or condition of the goods or their failure to correspond with specification
shall be notified in writing to the Company within 7 days of delivery or
(where the defect or failure was not apparent on reasonable inspection
by the Customer) within a reasonable time after discovery of the defect
or failure, but, in any event, within 6 months of delivery.
1.16 If delivery is not refused, and the Customer does not notify the Company
accordingly, the Customer may not reject the goods and the Company
shall have no liability and the Customer shall pay the price as if the
goods had been delivered in accordance with the Agreement.
1.17 THE MAXIMUM LIABILITY OF THE COMPANY UNDER THIS LIMITED
WARRANTY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID FOR
THE PRODUCT.
