Algo 8039 User manual

8039 SIP Video Intercom (FW version 2.0.1)
8039 SIP Video Intercom
FW Version 2.0.1
Installation & Configuration
Order Codes
8039 SIP Video Intercom
Document 90-00075
11/27/2019
Page 1
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Table of Contents
IMPORTANT SAFETY INFORMATION......................................................................................................3
OVERVIEW................................................................................................................................................. 6
INTRODUCTION................................................................................................... 6
WHAT’S NEW (COMPARED TO THE PREVIOUS FIRMWARE V1.5)........................................6
SETUP AND INSTALLATION.....................................................................................................................
GETTING STARTED - QUICK INSTALL & TEST...............................................................
INSTALLATION.................................................................................................... 8
PROGRAMMING AND CONFIGURATION........................................................................8
WIRING CONNECTIONS.......................................................................................... 9
WEB INTERFACE STATUS AND LOGIN.................................................................................................11
WEB INTERFACE LOGIN.......................................................................................11
STATUS..........................................................................................................12
STATUS TAB – VIDEO.........................................................................................12
WEB INTERFACE BASIC SETTINGS......................................................................................................13
BASIC SETTINGS TAB – SIP..................................................................................13
BASIC SETTINGS TAB – FEATURES..........................................................................14
BASIC SETTINGS TAB – VIDEO...............................................................................16
BASIC SETTINGS TAB – KEYPAD............................................................................19
BASIC SETTINGS TAB – DOOR CONTROL..................................................................21
BASIC SETTINGS TAB – MULTICAST........................................................................23
WEB INTERFACE ADVANCED SETTINGS.............................................................................................26
ADVANCED SETTINGS TAB - NETWORK....................................................................26
ADVANCED SETTINGS TAB – ADMIN........................................................................28
ADVANCED SETTINGS TAB – TIME..........................................................................30
ADVANCED SETTINGS TAB – PROVISIONING..............................................................31
ADVANCED SETTINGS TAB – TONES........................................................................33
ADVANCED SETTINGS TAB – ADVANCED AUDIO..........................................................34
ADVANCED SETTINGS TAB – ADVANCED SIP.............................................................35
ADVANCED SETTINGS TAB – ADVANCED MULTICAST....................................................3
WEB INTERFACE SYSTEM..................................................................................................................... 39
SYSTEM TAB - MAINTENANCE...............................................................................39
UPGRADE 8039 SIP VIDEO INTERCOM FIRMWARE......................................................40
SYSTEM – SYSTEM LOG.......................................................................................40
SPECIFICATIONS..................................................................................................................................... 41
8061 IP RELAY CONTROLLER............................................................................................................... 42
TYPICAL 8039/8061 SETUP..................................................................................................................... 43
POE AND RELAY CONNECTIONS ON BACK OF 8061 IP RELAY CONTROLLER:......................43
CONFIGURING THE 8061........................................................................................................................ 44
FCC COMPLIANCE STATEMENT............................................................................................................45
Document 90-00075
11/27/2019
Page 2
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Important Safety Information
Important Safety Information
This product is powered y a certified limited power source (LPS), Power over
Ethernet (PoE); through CAT5 or CAT6 connection wiring to an IEEE 802.3af
compliant network PoE switch. The product is intended for installation indoors or
on outdoor perimeter of a uilding. If used in an outdoor environment, additional
protective measures must e taken according to the installation manual. All wiring
connections to the product must e in the same uilding. If the product is installed
eyond the uilding perimeter or used in an inter- uilding application, the wiring
connections must e protected against over voltage / transient. Algo recommends
that this product e installed y a qualified electrician.
If you are una le to understand the English language safety information then
please contact Algo y email for assistance efore attempting an installation
[email protected].
Consignes de Sécurité Importantes
Ce produit est alimenté par une source d’alimentation limitée certifiée
(alimentation par Ethernet); des câ les de catégorie 5 et 6 joignent un
commutateur réseau à alimentation par Ethernet homologué IEEE 802.3af. Le
produit est conçu pour être installé à l’intérieur ou dans une zone adjacente à un
édifice; selon le manuel d’installation, des mesures de sécurité additionnelles
s’avèrent alors nécessaires. Tout le câ lage rattaché au produit doit se trouver
dans le même édifice. Si le produit est installé au-delà du périmètre de l’édifice ou
utilisé pour plusieurs édifices, le câ lage doit être protégé des surtensions
transitoires. Algo recommande qu’un électricien qualifié se charge de l’installation
de ce produit.
Si vous ne pouvez comprendre les consignes de sécurité en anglais, veuillez
communiquer avec Algo par courriel avant d’entreprendre l’installation au
[email protected].
Información de Seguridad Importante
Este producto funciona con una fuente de alimentación limitada (Limited Power
Source, LPS) certificada, Alimentación a través de Ethernet (Power over Ethernet,
PoE); mediante un ca le de conexión CAT5 o CAT6 a un conmutador de red con
PoE en cumplimiento con IEEE 802.3af. El producto se de e instalar en lugares
cerrados o en el perímetro de un edificio al aire li re. Si se utiliza en un am iente
al aire li re, se de en tomar medidas de protección adicionales de acuerdo con el
Document 90-00075
11/27/2019
Page 3
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
manual de instalación. Todas las conexiones ca leadas al producto de en estar
en el mismo edificio. Si el producto se instala fuera del perímetro del edificio o se
utiliza en una aplicación en varios edificios, las conexiones ca leadas se de en
proteger contra so retensión o corriente transitoria. Algo recomienda que la
instalación de este producto la realice un electricista calificado.
Si usted no puede comprender la información de seguridad en inglés,
comuníquese con Algo por correo electrónico para o tener asistencia antes de
intentar instalarlo: [email protected].
Wichtige Sicherheitsinformationen
Dieses Produkt wird durch eine zertifizierte Stromquelle mit egrenzter Leistung
(LPS – Limited Power Source) etrie en. Die Stromversorgung erfolgt ü er
Ethernet (PoE – Power over Ethernet). Dies geschieht durch eine Cat-5-
Ver indung oder eine Cat-6-Ver indung zu einer IEEE 802.3af-konformen
Ethernet-Netzwerkweiche. Das Produkt wurde konzipiert für die Installation
innerhal eines Ge äudes oder außerhal eines Ge äudes. Bei der Anwendung
außerhal eines Ge äudes müssen zusätzliche Schutzmaßnahmen gemäß der
Ge rauchsanweisung durchgeführt werden. Alle Ka elver indungen zum Produkt
müssen im sel en Ge äude estehen. Wenn das Produkt jenseits des Ge äudes
oder für mehrere Ge äude genutzt wird, müssen die Ka elver indungen vor
Ü erspannung und Spannungssprüngen geschützt werden. Algo empfiehlt das
Produkt von einem qualifizierten Elektriker installieren zu lassenv.
Sollten Sie die englischen Sicherheitsinformationen nicht verstehen, kontaktieren
Sie itte Algo per Email evor Sie mit der Installation eginnen, um Unterstützung
zu erhalten. Algo kann unter der folgenden E-Mail-Adresse erreicht werden:
[email protected].
安全须知
本产品由认证的受限电源（LPS），以太网供电（PoE），通过 CAT5 或 CAT6 路
联接至 IEEE 802.3af 兼容的 PoE 网络交换机供电。本产品适用于室内或建筑物周边
安装。如用于室外环境，必须按照安装手册采用附加的保护措施。所有联接本产品
的 路必须源自同一建筑物。本产品如需用于超出建筑物周边范围或跨建筑物的安
装， 路联接部分必须有过压和瞬态保护。Algo 建议本产品由专业电工安装。
如果您对理解英文版安全须知有问题，安装前请通过电子邮件和 Algo 联
系，[email protected]。
Document 90-00075
11/27/2019
Page 4
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
EMERGENCY COMMUNICATION
If used in an emergency communication application, the 8039 SIP Video Intercom
should e routinely tested. SNMP supervision is recommended for assurance of
proper operation. Contact Algo for other methods of operational assurance
including the use of the integrated microphone for automated “sound to air”
acoustic testing.
WET OR OUTDOOR ENVIRONMENTS
The 8039 SIP Video Intercom is intended for indoor or outdoor locations and may
e su jected to spray or weather, provided the rear wiring cavity is properly sealed
to prevent water ingress.
Gaskets included with the 8039 SIP Video Intercom may e effective against water
ingress on some, ut not all surfaces in which case additional protective measures
must e taken such as a perimeter sealant.
CAT5 or CAT6 connection wiring to an IEEE 802.3af compliant network PoE
switch must not leave the building perimeter without adequate lightning
protection.
When the Intercom is connected to wiring that exits the building, there is
potential risk of lightning induced electrical surges or high voltages from
fault conditions. To reduce risk, outdoor wiring should be protected by Earth
grounded conduit whenever possible. Relay input and output connections
must not leave the building perimeter without adequate lightning protection.
Document 90-00075
11/27/2019
Page 5
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Overview
Introduction
The 8039 SIP Video Intercom is ideal for secure usiness entrances, emergency
intercom, and gated entrances. The Algo 8039 provides hands-free intercom
capa ility with video, entrance security with door unlock control, rugged
weatherproof design, and superior audio performance.
Fully compati le with SIP industry standards, the 8039 SIP Video Intercom will
work with most hosted or enterprise SIP- ase servers supporting third-party SIP
endpoints.
The 8039 SIP Video Intercom is configured using central provisioning features or
y accessing a we interface using rowsers such as Google Chrome, Firefox, or
Internet Explorer.
What is Included
•8039 SIP Video Intercom
•Mounting Plate
What is not Included
•Optional 8061 IP Relay Controller
Document 90-00075
11/27/2019
Page 6
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Setup and Installation
Getting Started - Quick Install & Test
This guide provides important safety information which should be read thoroughly
before permanently installing the product.
1. Connect the 8039 SIP Video Intercom to an IEEE 802.3af compliant PoE network
switch. The acklight keypad will turn on. After a out 30 seconds, a eep will signal the
completion of the oot process.
2. After the oot is complete, press the call utton on the 8039 to hear the IP address.
(Once the SIP Server field is populated in the 8039 we interface, the call utton will
contact the preconfigured extension when pressed.) The IP address may also e
discovered y downloading the Algo locator tool to find Algo devices on your network:
www.algosolutions.com/locator
3. Access the 8039 SIP Video Intercom we page y entering the IP address into a
rowser (Chrome, IE, Firefox etc) and login using the default password algo .
4. Enter the IP address for the SIP server into the SIP Domain field under the BASIC
SETTINGS > SIP ta .
5. Enter the SIP Extension, Authentication ID, and Password. Also enter the target Dialing
Extension that the Intercom will call.
Note: The Authentication ID may also be called Username for some SI servers, and in
some cases may be the same as the SI extension.
6. Press the Call Button on the 8039 Intercom, then answer the phone to communicate
over the Intercom. Press the digit 6 on the phone keypad to activate the door control
relay for three seconds (if applica le).
Document 90-00075
11/27/2019
Page 7
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Installation
The 8039 SIP Video Intercom is
weather protected for outdoor
installation. However, if network
ca ling extends eyond the perimeter
of the uilding, then adequate lightning
protection is required to protect the
ca ling and network switch from
lightning surges. No lightning
protection is required y UL or CSA if
the 8039 is located on the outside wall
of a uilding and the wiring is inside
the perimeter of the uilding.
The 8039 is wall and door frame
(mullion) mounta le via the supplied
mounting plate:
Secure the mounting plate to the wall/
mullion door frame via two #8 screws.
Attach the 8039 into the mounting
plate and secure the device in place
with the attached security screw at the
ottom of the mounting plate using the
provided Allen wrench.
Programming and Configuration
The 8039 SIP Video Intercom is configura le using the we interface or
provisioning features.
After oot up, the speaker will eep and the intercom will have o tained an IP
address. If there is no DHCP server the 8039 SIP Video Intercom will default to the
static IP address 192.168.1.111.
Before the 8039 is configured, the call utton on the front can e pressed to play
the IP address over the speaker. (Once the SIP Server field is populated on the
8039 we interface, the call utton will contact the preconfigured extension when
pressed.) The IP address may e discovered y downloading the Algo locator tool
to find Algo devices on your network: www.algosolutions.com/locator
Document 90-00075
11/27/2019
Page 8
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Enter the IP address (e.g 192.168.1.111) into a rowser such as Google Chrome,
Firefox, or Internet Explorer (other than IE9). The we interface should e visi le
and the default password will e algo in lower case letters.
Wiring Connections
Network Connection
The speaker provides a RJ45 jack for network
connection. A ca le run from the switch can e
terminated to a modular jack with connection y patch
cord, or terminated with a RJ45 plug.
PoE (Power over Ethernet) must e 48V 350 mA IEEE
802.3af compliant whether provided y the network
switch or injector.
There are two lights on the Ethernet jack:
Green light: On when Ethernet is working, flickers off
to indicate activity on the port.
Amber light: Off when successful 100M ps link is
esta lished. Typically on only riefly at power up.
Under normal conditions, the Am er light will turn on
immediately after the Ethernet ca le is first connected.
This indicates that PoE power has een successfully
applied. Once the device connects to the network, it
will switch to the Green light instead, which will
typically flicker indicating traffic on the network.
Door Control Relay
Provides oth normally open and normally closed
relay contacts. Note: The 8061 I Relay Controller
can be used as an alternative more secure option
for door opening control, by using a separate relay
from the public-facing intercom.
Serial Control
**Reserved for future use**
Door Sensor (Dry Contact Input)
An external call utton can e connected as a normally open switch. When the
relay is triggered, this will dial the pre-configured “Extension to Dial”.
Document 90-00075
11/27/2019
Page 9
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Backlit Keypad and Call Button
The acklit keypad and call utton will e steady during power up and will flash
during a reset.
If ena led, when making a call, the call utton light will flash rapidly, while the call
is ringing at the far-end phone. Once the call is answered, the flashing will slow
down.
Reset
The 8039 SIP Video Intercom can only e reset during a power up. To return all
the settings to the factory default for the 8039, wait until all the acklit keys start
flashing. Then press and hold the call utton until the call utton acklight
egins a dou le flash pattern. Release the call utton and allow the unit to
complete its oot process. Do not press the call button until all the keys
start flashing.
A reset will set all configuration options to factory default including the password.
Document 90-00075
11/27/2019
Page 10
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Web Interface Status and Login
Web Interface Login
The we interface requires a password which is ‘algo’ y default. This password
can e changed in the Admin ta after logging in the first time.
Web Interface is accessed by entering 8039’s I Address into the web browse.
Important: It is highly recommended to change the default password if the device is
directly connected to a public network.
Document 90-00075
11/27/2019
Page 11
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Status
The device’s Status page will e availa le efore and after log on. The section can
e used to check 8039’s SIP Registration status of the SIP extensions, Call
Status, Proxy Status, Extension to Dial, Door Controller status, and general MAC,
IP, Netmask, and Date/Time information.
The Status page can be hidden when logged out for security purposes under the
Advanced Settings > Admin tab.
Status Tab – Video
The video can e seen in the “Status > Video” ta when the user is not logged in.
A separate video password can also e ena led, to allow users to access the
video, ut not the rest of the device settings. This password can e set in “Basic
Settings > Video” ta , “Session Password” field. Video settings like rightness,
contrast, view (Dewarped or Fisheye) are also availa le in the “Basic Settings >
Video” ta .
Document 90-00075
11/27/2019
Page 12
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Web Interface Basic Settings
Basic Settings Tab – SIP
SIP Server information and Credentials should e o tained from your telephone
system administrator or hosted account provider. After saving the settings, see the
Status ta to confirm the registration was successful.
Important: Any time changes are made to settings in the web interface the ‘Save’
button must be clicked to save the changes.
SIP Domain (Proxy Server)
The IP address (e.g. 192.168.1.111) or domain name (e.g. myserver.com) of the
SIP Server
SIP Extension
Used to register the 8039 on the SIP Server.
Authentication ID
May also e called Username for some SIP servers and in some cases may e
the same as the SIP extension.
Authentication Password
SIP password provided y the system administrator for the SIP account.
Extension to Dial
Enter the phone num er that will e dialed when the call utton is pressed. This
can also e a Hunt Group num er. Ensure that voice mail is not reached.
Document 90-00075
11/27/2019
Page 13
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Note: The “Basic Settings > Keypad” tab offers additional keypad modes like playing
a voice prompt when the call button is pressed and using the keypad to dial
extensions or listed departments.
Basic Settings Tab – Features
Speaker Volume
Select speaker audio level of the 8039 from 1 (lowest) to 10 (highest).
Automatic Gain Control (AGC)
Normalizes the audio level. This ensures audio level heard at the speaker is
always at a consistent level, independent of the phone that is used to answer the
call.
Answer Inbound Call
Allow the 8039 to auto-answer an in ound call. By default, this functionality is
activated.
Document 90-00075
11/27/2019
Page 14
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Answer Tone
Select a tone to e played over the speaker when the intercom answers an
in ound call. Use only Default, or custom uploaded file. The other pre-installed
tone files all contain silence at the end in order to generate ring "cadence" of 6
seconds. This silence will lock the voice path for several seconds at the start of a
call.
Outbound Ring Limit
This feature can e used to set a limit on how long the intercom will ring efore
timing out. If the call is not answered within this time period, the 8039 will go ack
to an idle state.
Ringback Tone
Select an audi le ring ack tone to e played on the 8039 speaker until the call is
answered.
Allow Call Button to End Active Call
If ena led, allows the visitor to end an active call y pressing the call utton.
G. 22 Support
Ena le or disa le the G.722 codec.
Maximum Call Duration
Select the maximum call length. The call will e terminated once the maximum
time is reached. In the event that a call inadvertently reaches voicemail or gets
accidentally left on hold, this setting ensures that the 8039 returns on-hook.
Door Sensor Connector
External call utton can e used as an input to the door sensor connector.
External call utton will function like the call utton on the device.
Document 90-00075
11/27/2019
Page 15
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Basic Settings Tab – Video
Exposure Region
Select an exposure calculation region for optimal image rendering. “Spot” method
calculates exposure ased on the center area of the image. “Full Frame” method
uses the entire image to determine the exposure. “Centre Weighted” uses mainly
the center area and a fraction of the remaining frame to compute the exposure.
Camera View
Camera view can e set to either a “Dewarped” full page view or a circular
“Fisheye”.
White Balance
Select the white alance settings. “Auto” will auto-detect the light levels and auto-
alance the video accordingly. Other alance choices include: Daylight 6500K and
5500K, Fluorescent, and Incandescent.
Document 90-00075
11/27/2019
Page 16
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Brightness
Increase or decrease image rightness either a ove or elow the default value.
Contrast
Increase or decrease image contrast either a ove or elow the default value.
Sharpness
Increase or decrease image sharpness either a ove or elow the default value.
Saturation
Increase or decrease image saturation either a ove or elow the default value.
Powerline Frequency
Choose the local powerline frequency. For example, 60 Hz in North America and
50 Hz in Europe. This allows the device to reduce video flicker when used with
indoor lighting.
Allow PTZ Video via DTMF Control
Use DTMF command to control the we video and H.264 video stream.
Packet Type
Refer to phone specifications to determine est supported packet type (“Single
NAL Unit” or “Fragmentation Unit Type A (FU-A)”). Use ‘Auto’ mode except with
legacy video phones with limited Video SDP negotiation capa ility.
CIF Stream Bitrate
Select the amount of network traffic the device can use.
HD Channel Resolution
Select the video resolution as supported y the video phone that will answer the
calls, 720p (1280x720) or VGA (640x480).
HD Channel Bitrate
Select the amount of network traffic the device can use.
Document 90-00075
11/27/2019
Page 17
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Request Media Bandwidth
Adds andwidth modifiers and attri utes in the SDP offer/answer.
SIP Video Capacity
This controls the video parameters included in the SIP 'Offer' that is sent when the
8039 initiates a call. Select the video capacity as supported y the video phone
that will answer the calls.
SIP Video Stream
This controls the actual video stream sent y the 8039. Use ‘Auto’ mode unless a
manual override is required for compati ility with legacy video phones.
Maximum Browser Sessions
Allows for a limit to e set on the num er of separate rowser sessions that can e
open simultaneously to show the video. The setting can e “Disa led” to turn off
the we video capa ility.
Session Passcode
This allows a separate password to e configured that allows access to only the
“Status > Video” ta .
Document 90-00075
11/27/2019
Page 18
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Basic Settings Tab – Keypad
Dial Mode – Single Number
This mode allows the 8039’s “Call” utton to dial a pre-configured num er, the
“Extension to Dial”. There is also an option to allow all the num er keys on the
keypad to dial this same extension.
Dial Mode – List
This mode allows each of the 10 “num er” keys to dial a different preconfigured
phone num er. For example, 1 for Reception, 2 for Sales, 3 for Shipping, etc.
The Call utton can e configured to play a voice prompt detailing the availa le
options to the visitor. The voice prompt can e uploaded via a custom audio file in
the “Advanced Settings > File Manager” ta .
Dial Mode – Keypad Dial
This mode allows the keypad to e used to dial extensions directly. If an incorrect
num er is dialed y mistake, the “#” key can e pressed to cancel, and the
extension can e dialed again.
Set the “Length of Extension to Dial”, correctly to match the extension length of
your phone system.
The Call utton can e set to “Dial Extension” (e.g. reception) or to “Play Voice
Prompt” giving the visitor instructions and/or summary of main extensions to dial
via the keypad.
Document 90-00075
11/27/2019
Page 19
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]

8039 SIP Video Intercom (FW version 2.0.1)
Warning: Set appropriate permissions on the phone system to ensure that a
malicious visitor cannot use the intercom to dial an external number. Also ensure
that a visitor will not reach voicemail to prevent the call from getting “stuck”
Keypad Backlight
Ena le or disa le the Keypad’s lue acklight.
Call Button Backlight
Ena le or disa le the Call Button’s lue acklight.
Backlight Brightness
Configures the rightness of the Keypad and Call Button acklight if they are
ena led.
Basic Settings Tab – Door Control
The 8039 contains a relay that can e used for Door Control, or it can e used with
the optional 8061 IP Relay Controller (sold separately) for additional door security,
as the 8061 can e located inside the uilding and separate from the pu lic-facing
intercom. This section allows you to configure the 8061 settings (if used), or the
local door relay. For more information a out the 8061, see “8061 IP Relay
Controller” on page 48.
Number of Network Door Controllers
Set up to 4 network door controllers (8061s) to unlock/lock the doors.
Document 90-00075
11/27/2019
Page 20
Algo Communication Products Ltd
4500 Beedie St Burna y BC Canada V5J 5L2
www.algosolutions.com
[phone]
[email protected]
