ALIBI ALI-AV3 User manual

1
ALI-AV3_PQ
7/30/15
© 2015 Observint Technologies. All rights reserved.
Step 1. Installation
1. Install and setup you HD video recorder in accordance with the manufacturer recommended procedure.
2. Install the HD video camera in accordance with manufacturer recommended procedure.
3. Route Cat 5e or Cat 6 UTP cable between the camera and the video recorder. Use high quality CAT5e UTP or CAT6 UTP cable. Do not
route the cable near devices that product electromagnetic radiation, such as microwave ovens, mobile phone equipment, radio
equipment or high voltage power cables.
4. Install RJ-45 connectors at both end of UTP cable in accordance with the diagram shown below.
RJ-45 Jack
Pin Color (Function)
1W-O: White-Orange X
2 O: Orange X
3W-G: White-Green Power -
4BL: Blue Power +
5W-BL: White-Blue Power -
6 G: Green Power +
7W-BR: White-Brown Video +
8BR: Brown Video -
5. Connect the balun for the camera end to the camera, and then to the UTP cable.
6. Connect the balun for the HD video recorder end to the UTP cable, and then to the HD video recorder and the power supply.
7. Apply power to the power supply.
ALI-AV3 HD Video/Power Balun
Quick Start Guide
The ALI-AV3 HD Video / Power Baluns adapt HD-CVI/TVI/AHD video signals on coax and 12/24 V power to an RJ-45 connectorized interface
for transmission across standard Cat 5e/6 UTP cable. These baluns are ideal for transmitting power to and video signals from an HD video
camera and an HD video recorder through Ethernet cable instead of more expensive RG-6 coax/power cable. Features include:
• Transmit HD-CVI/TVI/AHD video and power over one CAT5e/6 UTP cable
• Includes 2 units: 1 x RJ-45 to BNC with DC power plug, 1 x RJ-45 to BNC with DC power jack
• Carries 300 mA at 12 Vdc / 24 Vac up to 655 ft
• Built-in ESD, EFT (impulse noise) and transient protection
• Easy installation
RJ-45 to Cat 5e/6To camera To recorderDC power plug DC power jack
Balun for camera end Balun for HD video recorder end
NOTE Some voltage loss occurs when transmitting power through Cat 5e/6 cable. Adjust the supply power appropriately to ensure that the voltage
level and current at the camera is within its specied operating range. See Tables 1 - 3 on Pg 2.
Cat 5e/6 UTP cable
Balun for camera end Balun for
HD video recorder end
Power supply
HD video camera
BNC RJ-45RJ-45 BNC
DC power plug
HD video recorder
Typical ALI-AV3 application DC power jack
www.observint.com

2www.observint.com
Table 4. Specications
Balun Balun for camera end Balun for HD video recorder end
Video Input / Output Terminals BNC x 1 (1 Vp-p, 75 Ohm)
Video Output / Input Terminals RJ-45 x 1 (100 Ohm )
Power DC plug DC jack
Bandwidth 50 Hz ~ 60 MHz ( -3 dB )
Transmission Distance HD-CVI / AHD: 980 ft, HD-TVI: 820 ft
ESD protection 30 KV (air), 15 KV (contact); IEC 61000-4-2 compliant
EFT protection 40 A (5/50 ns); IEC 61000-4-4 compliant
Lightning protection 2 A (8/20 μs); IEC 61000-4-5 compliant
Surge Protection Attack Time < 1 nS
Environmental Specications Operation: 32 ~ 131˚F (0 ~ 55˚C), Storage: -4 ~ 185˚F (-20 ~ 85˚C), Humidity: up to 95%
Dimension 2.72 × .98 ×.81 in (69 ×25 ×20.7 mm) + 4 72 in (120 mm) pigtail cable
Weight 1.59 oz (45 g)
Table 1. Power output voltage
Cable Power supply
voltage
Camera power
consumption TVI camera distance AHD, HD-CVI camera
distance
Power output
voltage
Cat 5e
12 Vdc
200 mA 490 ft 490 ft 10.2 Vdc
300 mA 325 ft 325 ft 10.2 Vdc
24 Vdc / 24 Vac
200 mA 820 ft 980 ft 22.6 V
300 mA 655 ft -- 21 V
Table 2. Voltage drop vs. cable length (24 AWG)
Voltage 12 Vdc 15 Vdc 24 Vdc
Distance 160 ft 325 ft 980 ft 160 ft 325 ft 980 ft 1970 ft 160 ft 325 ft 980 ft 1970 ft
Current 2 pair 2 pair 2 pair 2 pair 2 pair 2 pair 2 pair 2 pair 2 pair 2 pair 2 pair
50 mA 11.7 11.3 10.6 14.7 14.3 13.6 12 23.8 23.5 22.4 21.2
100 mA 11.5 10.8 9.2 14.5 13.8 12.2 -- 23.4 23.1 21.1 18.7
150 mA 11.2 10.4 -- 14.2 13.4 11.1 -- 23.2 22.6 20 16.1
200 mA 11 9.9 -- 14 12.9 -- -- 22.9 22 18.1 13.5
250 mA 10.7 9.4 -- 13.7 12.4 -- -- 22.6 21.6 17.4 11.1
300 mA 10.5 -- -- 13.5 12 -- -- 22.4 21.2 16.1 --
350 mA 10.3 -- -- 13.3 11.7 -- -- 22.1 20.6 15 --
400 mA 10 -- -- 13 11.2 -- -- 21.8 20.1 13.9 --
450 mA 9.6 -- -- 12.7 10.7 -- -- 21.6 19.6 12.7 --
500 mA 9.2 -- -- 12.4 -- -- -- 21.3 19.1 11.3 --
Table 3. 24 Vac power/distance chart (Cat 5 - 24 AWG UTP cable)
Current over 2 pair Range
100 mA 980 ft
300 mA 325 ft
1000 mA 98 ft
