Alinco DJ-A46 User manual
A1.131218
ALINCO, INC.
Yodoyabashi Dai-bldg 13F
4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan
Phone: +81-6-7636-2362 Fax: +81-6-6208-3802
http://www.alinco.com
E-mail:[email protected]
Copyright Alinco, lnc. PS0804/FNEH-NB
Printed in China
UHF FM Transceiver 8 PMR446 channels.
Use of this device is authorized in all EU and EFTA
member states (CH/ICE/LI/NOR).
Thank you for purchasing your new Alinco transceiver. Please read this manual
carefully before using the product to ensure full performance, and keep this
manual for future reference as it contains information on after-sales service.
In case addendum or errata sheets are included with this product, please read
those materials and keep them together with this instruction manual for future
reference.
Instruction Manual
PRIVATE MOBILE RADIO
DJ-A46
DJ-A46
PRIVATE MOBILE RADIO
Introduction
Thank you very much for purchasing this excellent Alinco transceiver. Our products are ranked among the
nest in the world. This radio has been manufactured with state of the art technology and it has been tested
carefully at our factory. It is designed to operate to your satisfaction for many years under normal use.
Please read this manual completely from the rst page to the last, to learn all the functions the
product offers. It is important to note that some of the operations may be explained in relation
to information in previous chapters. By reading just one part of the manual, you may risk not
understanding the complete explanation of the function.
Before transmitting
There are many radio stations operating in proximity to the frequency ranges this product covers. Be
careful not to cause interference when transmitting around such radio stations.
■ Lightning
Any person is not safe outdoor during thunderstorm and lightning. This condition is getting worse if
somebody keeps a hand-held radio; chances of being hit by lightning are doubled since lightning may
hit a radio antenna as well. At this time, there is no hand-held radio having any kind of protection against
lightning current (which is higher than 10 kA.). Note also that no car provides adequate protection of its
passengers or drivers against lightning as well. Therefore, Alinco will not take responsibility for any danger
associated with using its hand-held radios outdoor or inside the car during lightning.
■ About IP54 rating / Dust and splash resistant
About IP54 rating
5: Dust protected / Ingress of dust is not entirely prevented, but it must not enter in sufcient quantity to
interfere with the satisfactory operation of the equipment; complete protection against contact.
4: Splashing water / Water splashing against the enclosure from any direction shall have no harmful effect.
Test duration: 5 minutes / Water volume: 10 litters per minute / Pressure: 80~100 kN/m².
The IP54 designation provides for limited dust and splash proong of the radio per specied above. This
compatibility is factory guaranteed for a period of one year provided all the jack covers are securely in
place, any accessories connected must be specied genuine Alinco accessories and the radio has not
been disassembled by the customer. The factory has tested and made the equipment compatible to IP54
certication during engineering. However, please understand that this equipment is NOT certied IP54
compliant but is designed to remain operational when used in hard conditions and is in no way stating
that you should attempt to wash the radio for cleaning. Warranty will not cover radios that are water/dust
damage due to negligence or misuse of the product.
The warranty period of dust and splash resistance is the same as the period of the product warranty.
■ Covering ranges
You may expect a range of approx 1.5km/1 miles or more at high-power when located on a at, noise-free
place like on a beach. However, it may vary drastically depending on how to wear and carry the radios,
surrounding locations/conditions and static noise levels (below or near power transmission lines), etc. In
urban areas with many buildings or inside a building, such covering range will become drastically short
even to several tens of meters.
■ 128 PC-programmable channels(16ch x 8groups)
■ Li-Ion battery pack and stand-charger as standard accessories
■ Voice Compander(Reduce Noise & enhance audio clarity)
■ Inversion Scramble
■ Sub-tone(CTCSS/DCS) Encode/Decode
■ VOX built-in(An optional earphone-microphone is necessary)
Features
Conformity Symbols
Tested to comply MIL-STD-810G
-Shock: Method 514.6/I,IV -Vibration: Method 516.6/I
Alert
Environment and condition of use
Use of this product may be prohibited or illegal outside of your country. Be informed in advance when you
travel.
It is recommended that you check local trafc regulations regarding the use of a radio equipment while
driving. Some countries prohibit or apply restrictions for the operation of radios and mobile-phones while
driving.
Do not use this product in close proximity to other electronic devices, especially medical ones. It may cause
interference to those devices.
Keep the radio out of the reach of children.
In case a liquid leaks from the product, do not touch it. It may damage your skin. Rinse with plenty of cold
water if the liquid contacted your skin.
Never operate this product in facilities where radio products are prohibited for use such as aboard aircraft,
in airports, in ports, within or near the operating area of business wireless stations or their relay stations.
The manufacturer declines any responsibilities against loss of life and/or a property due to a failure of this
product when used to perform important tasks like life-guarding, surveillance, and rescue.
Do not use multiple radios in very close proximity. It may cause interference and/or damage to the
product(s).
Risk of explosion if battery is replaced with an incorrect type. Dispose of, or recycle used batteries
according to your local regulations.
Handling this product
The manufacturer declines any responsibilities against loss of life and property due to a failure of this product
when used with or as a part of a device made by third parties.
Use of third party accessory may result in damage to this product. It will void our warranty for repair.
Be sure to reduce the audio output level to minimum before using an earphone or a headset. Excessive audio
may damage hearing.
Do not open the unit without permission or instruction from the manufacturer. Unauthorized modication or
repair may result in electric shock, re and/or malfunction and voids warranty.
Do not operate this product in a wet place such as in a shower room. It may result in electric shock, re and/
or malfunction, This product is splash-proof but not a complete water-proof.
Do not place the product in a container carrying conductive materials, such as water or metal in close
proximity. A short-circuit to the product may result in electric shock, re and/or malfunction.
About chargers
Do not use adapters other than having the specified voltage. It may result in electric shock, fire and/or
malfunction, Never turn on the radio while charging.
Do not plug multiple devices using an adapter into a single wall outlet. It may result in overheating and/or re.
Do not handle adapter with a wet hand. It may result in electric shock.
Securely plug the adapter into the wall outlet. Insecure installation may result in short-circuit, electronic shock
and/or re.
Do not use the adapter if the plug or socket contacts are dirty. Overheating and/or short-circuiting may result
in re, electric shock and/or damage to the product.
In case of emergency
In case of the following situation(s), please turn off the product, switch off the source of power,
then remove or unplug the power-cord. Please contact your local dealer of this product for service
and assistance. Do not use the product until the trouble is resolved. Do not try to troubleshoot the
problem by yourself.
When a strange sound, smoke and / or strange odor comes out of the product.●
When the product is dropped or the case is broken or cracked.●
When a liquid penetrated inside.●
When a power cord (including DC cables, AC cables and adapters) is damaged.●
For your safety, turn off then remove all related AC lines to the product and its accessories from the wall outlet
if a thunderstorm is likely.
Maintenance
Do not open the unit and its accessories. Please consult with your local dealer of this product for service and
assistance
About transceiver
Alert
Environment and condition of use
Do not use the product in proximity to a TV or a radio. It may cause interference or receive interference.
Do not install in a humid, dusty or insufciently ventilated place. It may result in electric shock, re and/or
malfunction.
Do not install in an unstable or vibrating position. It may result in electric shock, re and/or malfunction when/
if the product falls to the ground.
Do not install the product in proximity to a source of heat and humidity such as a heater or a stove. Avoid
placing the unit in direct sunlight.
Be cautious of a dew formation. Please completely dry the product before use when it happens.
Be cautious of the whip antenna when carried in your shirt-pocket etc. It may make contact with your eye and
cause injury.
Do not connect devices other than specified ones to the jacks and ports on the product. It may result in
damage to the devices.
Turn off and remove the power source (AC cable, DC cable, battery, cigar cable, charger adapter etc.) from
the product when the product is not in use for extended period of time or in case of maintenance.
Never pull the cord alone when you unplug AC cable form the wall outlet.
Use a clean, dry cloth to wipe off dirt and condensation from the surface of the product. Never use thinner or
benzene for cleaning.
Check with your local waste ofcials for details on recycling or proper disposal of the electronics product,
battery-packs and accessories in your area.
PC PROGRAMMING
NOTE: The utility software may be available to distributors/dealers only. USB programming cable is required. The
manufacturer will not release the software to unauthorized party so please contact your dealer for details.
Professional
FM Transceiver I
STANDARD ACCESSORIES/OPTIONAL ACCESSORIES............................................... 1
Standard Accessories .........................................................................................................................1
BATTERY INFORMATION.................................................................................................. 2
Charging Operation.............................................................................................................................2
Battery Charger Type..........................................................................................................................2
Notice for Charging Battery.................................................................................................................2
How to Charge the battery pack .........................................................................................................4
How to Store the Battery.....................................................................................................................6
PREPARATION................................................................................................................... 7
Installing / Removing the Battery ........................................................................................................7
Installing / Removing the Belt Clip ......................................................................................................7
Accessories ........................................................................................................................................8
Installing/ Removing the Hand Strap ..................................................................................................8
GETTING ACQUAINTED.................................................................................................... 9
Indicator Status and Beep ..................................................................................................................11
[PF1] & [PF2] Key Default...................................................................................................................11
BASIC OPERATIONS......................................................................................................... 12
Switch on / off Transceiver..................................................................................................................12
Adjusting Volume ................................................................................................................................ 12
Channel Selection...............................................................................................................................12
TABLE OF CONTENTS
Professional
FM Transceiver
II
Group Selection ..................................................................................................................................13
Receiving ............................................................................................................................................13
Transmitting ........................................................................................................................................13
Emergency Alarm Function.................................................................................................................14
Resetting.............................................................................................................................................14
ADVANCED OPERATIONS( [PF1] & [PF2] KEY )............................................................. 15
Monitor ................................................................................................................................................15
Momentary Monitor ............................................................................................................................. 15
Temporary Deletion of the Interfering Channel from scanning............................................................15
Squelch Levels Enquiry ......................................................................................................................15
Squelch Levels Setup .........................................................................................................................16
Scan....................................................................................................................................................16
Scramble Setup ..................................................................................................................................16
Squelch off ..........................................................................................................................................16
Temporary Squelch off .......................................................................................................................16
Whisper...............................................................................................................................................17
Voice Compander (Reduce Noise & Enhance Audio Clarity).............................................................. 17
Battery Capacity Enquiry ....................................................................................................................17
Current Channel Enquiry ....................................................................................................................17
PRESET OPERATIONS( FUNCTION SETUP ).................................................................. 18
TABLE OF CONTENTS
Professional
FM Transceiver III
CTCSS / DCS Encode / Decode.........................................................................................................18
Busy Channel Lockout ........................................................................................................................18
Signaling Relations Setup...................................................................................................................18
Channel Scan Skip .............................................................................................................................19
TX OFF ...............................................................................................................................................19
Battery Save Setup .............................................................................................................................19
Time-out Timer....................................................................................................................................19
Time-Out Timer Pre-Alarm ..................................................................................................................19
TOT Re-transmitting Time Setup ........................................................................................................20
Voice Operated Transmission (VOX: An optional earphone-microphone is necessary)..................... 20
Channel Selector Knob Lockout ......................................................................................................... 20
Priority Scan Setup .............................................................................................................................20
OPTIONAL ACCESSORIES ............................................................................................... 2 1
RECOMMENDED INSTALLATION OF EARPHONE MICROPHONE ................................. 22
TECHNICAL SPECIFICATIONS......................................................................................... 23
DJ-A46 TECHNICAL SPECIFICATIONS ............................................................................................23
TROUBLE SHOOTING GUIDE........................................................................................... 24
ATTACHED CHARTS ......................................................................................................... 26
Preset Channel Frequency Chart (Reset won't delete these channels) .............................................26
TABLE OF CONTENTS
Professional
FM Transceiver
1
STANDARD ACCESSORIES
Li-ion Battery Pack Charger AC Adaptor Belt Clip
Instruction
Manual
Hand Strap
Standard Accessories
NOTE: Accessories may differ depending on the version you have purchased. Please contact your local
dealer for details of standard accessories and the warranty-policy before purchase.
Professional
FM Transceiver 2
BATTERY INFORMATION
Charging Operation
The battery is not charged at the factory, so please charge it before use.
Charge the battery for the rst time after purchase or extended storage (more than 2 months) may
not bring the battery to its normal operating capacity. After repeating fully charge / discharge cycle,
the operating capacity will reach the best performance. The battery life is over when its operating
time decreases even though it is fully and correctly charged and it must be replace to new one.
Battery Charger Type
Please use Alinco's designated charger, other models may cause explosion. After installing the
battery pack, if the radio displays low battery with red ashing lamp or voice prompt, please charge
the battery.
Notice for Charging Battery
Do not shortcircuit the charger. Never attempt to remove the casing from the battery, otherwise▼
the warranty is void and you risk serious damage to yourself and properties.
The ambient temperature should be between 5▼℃and 40℃while charging. Charging outside
this range may not charge the battery.
Always switch OFF the transceiver before charging. Otherwise, it may not charge correctly.▼
To avoid interfering the charging procedure, please do not cut off the power or take out the▼
battery during charging.
Do not recharge the battery if it is already fully charged. This may shorten the life of the battery▼
or damage the battery.
Do not charge the battery or transceiver when wet. Dry it before charging to avoid danger.▼
Professional
FM Transceiver
3
BATTERY INFORMATION
Risk of explosion, generation of heat or leak of chemicals inside if the battery is replaced by an▼
incorrect type or reverse polarity. Use always the recommended types of batteries in this manual
only.
The battery pack isn't fully charged when shipped. It must be charged before use.▼
Charging should be conducted in a temperature range of +5ºC to +40ºC (+41ºF to +104ºF).▼
Don't modify, dismantle, incinerate or immerse the battery pack in the water as this can be▼
dangerous.
Never short-circuit the battery pack terminals, as this can cause damage to the equipment or lead▼
to heating of the battery which may cause burns.
Unnecessary prolonged charging (overcharging) can deteriorate battery performance.▼
The battery pack should be stored in a dry place where temperature is in -10ºC to+45ºC (-14ºF to▼
+113ºF) range. Temperatures outside this range can cause the battery liquid to leak. Exposure to
prolonged high humidity can cause corrosion of metal components.
Battery-packs are a consuming part. When its operating time becomes considerably short after a▼
normal charge, please consider that the pack is exhausted and replace it with a new one.
The battery pack is recyclable. Check with your local waste ofcials for details on recycling options ▼
or proper disposal in your area.
Use specied genuine chargers only to charge battery packs. Use of other chargers may cause ▼
damage to products, you and your property.
Never carry battery packs together with conductive articles such as metals in a same bag to▼
prevent from short-circuiting. Put the packs only in nylon bags to carry them safely.
Caution:
Professional
FM Transceiver 4
BATTERY INFORMATION
How to Charge the battery pack
1.Plug the AC adaptor into the AC outlet, then plug into
the DC jack, the indicator lights orange for 1 second
and goes out---waits to charge.
2.Slide the battery or transceiver with battery into the
charger; make sure the battery terminals are in contact
with the charging terminals. LED turns into twinkling
RED---pre-charging begins.
3.Pre-charging for about 5 minutes, LED stop blinking
then charging begins.
4.It takes up to 4 hours to fully charge the battery, and LED
turns to green when the charge is complete.
Warning: Never charge while the radio is turned on. When turned on, the charger can't detect the
charging voltage properly and LED fails to indicate charge status correctly.
5. LED Indicator:
STATUS self-examine
when power on (No battery) Pre-charging Charge
normally Fully Charged Trouble
LED Orange
(for 1 second) None Red blinks
for 5 minutes Red Green Red blinks
alternatively
Ac Input
Professional
FM Transceiver
5
BATTERY INFORMATION
NOTE:
▲ Trouble means battery heating, short-circuit or charger malfunction. Remove the battery pack from
the charger immediately and contact to your local dealer for services.
▲ The max trickle pre-charging time is 30 minutes. In case the red indicator continues to blink longer,
please stop charging and consult with your local dealer for services.
▲ It is known that Li-Ion battery packs heat up over 400℃ by itself when kept in a temperature of over
80℃ for extended period of time. Although the packs are protected against overheating with a protective
circuit, never leave the battery packs in a car or similar locations in hot seasons.
▲ Li-ion packs may deteriorate by over 30% regardless of conditions after 3 years. This is a nature of
Li-ion pack and not a defect of the product.
▲ The charger is to charge the battery pack only. It is not an AC adapter to operate the radio. Never
attempt to transmit the radio with using the charger as it will cause the damage to the charger and a
repair/replace may become necessary.
▲ The charge should be conducted in an ambient temperature with a minimum proper air-conditioning
in an extremely hot or cold seasons.
▲ Try charging the battery pack only when having trouble charging with the radio.In case the radio may
have troubles,the charge can't be conducted properly.If the battery pack can be charged alone, please
take the radio to your local dealer for services.
Professional
FM Transceiver 6
BATTERY INFORMATION
How to Store the Battery
1.The battery should be kept in the status of 50% discharge when storing.
2.Remove the battery pack from the radio and keep it in a cool, dry place.
3.Keep away from source of heat and direct sunlight.
Note: Incorrect storage will damage both the battery pack and the radio. Please always remove the
battery pack from the radio when not in use.
Table of contents
Other Alinco Two-way Radio manuals
