ALK Nokia N70 User manual

Quickstart Guide
Satellite Navigation
for Nokia N70
CoPilot Live. Local knowledge, everywhere
CoPilot Live. Local knowledge, everywhere
www.alk.eu.com
Copyright ©2005 ALK Technologies, All rights reserved
symbian booklet 050406_new 5/4/06 12:04 Page 1

CoPilot Satellite Navigation Kit
CoPilot Satellite Navigation Kit for Nokia N70
Your CoPilot kit contains the following:
*Only included in CoPilot Bluetooth kits.
RS-MMC memory
cardpre-loaded
with maps
1xinstallation CD
2 x data CDs
Product
key card
QuickstartGuide
Satellite Navigation
for Nokia N70
CoPilot Live. Local knowledge, everywhere
Bluetooth
receiver*
Car charger*
and car mount*
Quickstart
guide
CoPilot Satellite Navigation Kit
iCoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
CoPilot Customer Support Helpline
Call a member of our Customer Support team for professional
and friendly support on CoPilot.
Our helpline is open Monday to Friday between 09:00 and
17:00 hours.
Online Support
Please email [email protected] for answers to your
CoPilot support related queries and questions.
Alternatively, visit the support section at www.alk.eu.com
to register and activate your CoPilot.
Our FAQs section provides answers to customers’ most
frequent requests to help you get started and make the
most out of CoPilot today.
CoPilot Customer Support
Telephone [phone]
Customer Support
24
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 2

Getting Started 1
Keys and User Interface 2
Unique Product Key Code Entry 3
License Activation 4
Bluetooth GPS Receiver Set-up 5
CoPilot Welcome Menu 7
Navigating to a Destination 8
nEntering an Address 8
Navigating to a Point of Interest 9
nPOI Alerts 9
How to Change Driving Views 10
Navigation Modes 11
Advanced Routing Settings 12
Advanced Features 13
CoPilot Live Services 14
nLive Traffic 16
nLive Location Tracking 18
nLive Messaging 19
nLive Destination Sending 20
Trouble Shooting 21
Help 23
CoPilot Customer Support 24
Contents
ii
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
Contents
CoPilot has a help function, which provides you with instructions
and information about setting up and using the software.
Select Welcome > Help (or Options > Help).
User Guide
Read the user guide to get familiar with CoPilot.
The user guide provides important safety information, detailed
instructions for setting up your CoPilot, comprehensive
information on downloading and transferring map data for
European, USA and Australian upgrades.
Learn how to use the advanced navigation features in CoPilot
and setup Live Communications to enjoy real time traffic, Live
tracking and messaging - plus much more.
Help
Help
23 CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 3

Getting Started
1CoPilot Live 6 Symbian S60
Setting up your Nokia N70
Set up your Nokia N70 following the instructions supplied
with the phone's manual.
Please ensure your phone's battery is fully charged.
Set the correct date and time on your Nokia N70 for
optimum performance.
CoPilot Live Satellite Navigation on your Nokia N70
CoPilot is preloaded on the RS-MMC memory card.
To start using CoPilot Live on your Nokia N70, simply insert
the memorycardinto your phone.
Once the card is inserted, press the Menu key to open the
main menu of the Nokia N70.
Using the scroll key cursors, browse to ‘My Own’ and open
the folder.
The CoPilot icon will be displayed within the ‘My Own’ folder.
Highlight and select the ‘CoPilot’ icon to startCoPilot.
Getting Started
Customer Support Helpline
([phone]
Trouble Shooting
22
QIam having trouble obtaining a GPS signal
If you can’t get a GPS signal after setting up your receiver,
ensure that your Bluetooth GPS receiver is switched on,
charged-up and working properly by switching off and on.
Green and blue lights will appear if the GPS receiver is fully
charged.
QCoPilot did not find the address that I entered
If a specific address is not within the CoPilot database, try
using the ‘Map’ option from the ‘Select Stop’ screen.
(This enables you to pin point anywhere on the map and
add it to your itinerary.)
Trouble Shooting
i
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 4

Nokia N70 Keys
Power key
Left selection key
Right selection key
5-way scroll key
Menu key
Clear key
Memorycardslot
CoPilot User Interface
Next turn arrow
Route ahead highlighted
Driver’s current position
Distance to next turn
Options menu
GPS status indicator
Live services indicator
7
6
5
4
3
2
1
Keys and User Interface
2
Keys and User Interface
7
23
1
4
5
6
7
6
5
4
3
2
1
4
1
2
3
5
6
7
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
Trouble Shooting
21 CoPilot Live 6 Symbian S60
QIam experiencing problems switching on
Bluetooth
Close CoPilot by selecting ‘Exit’ from the menu.
Switch your phone off and then on again using the power
button.
RestartCoPilot and select Welcome > GPS > Options > Turn
On Bluetooth.
Q‘No devices found’ in search for GPS
Close CoPilot by selecting ‘Exit’ from the menu.
Ensurethat your Bluetooth GPS receiver is switched-on,
charged-up and working properly.
Please switch the GPS receiver off and on. Green and blue
lights will appear if the GPS receiver is fully charged and
working properly.
RestartCoPilot and select ‘GPS’ from the CoPilot Welcome
screen.
Press ‘Options’, and select ‘Search for GPS’.
Your Bluetooth receiver should appear with the name
BTGPS xxxx xxxx.
Trouble Shooting
i
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 5

Product Key Code
3CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
The first time you run CoPilot on your phone you will be
prompted to enter your product key.
Please scratch off the silver panel on your product key card to
reveal your unique product key code.
Carefully input your unique 25 digit product key code. Press
'Next'.
Unique Product Key Code Entry
Live Destination Sending
20
Send new destinations to the driver
People can even send new destinations to the driver from the
http://live.alk.eu.com website which the driver can either
accept or reject at the touch of a button.
If the driver accepts the new locations they are automatically
added straight into the driver’s itinerary.
If a new destination is rejected then the itinerary remains
unchanged and the driver continues as planned.
Live Destination Sending
Live website
Live destination sent to
driver’s Nokia N70
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 6

License Activation
4
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
You will need to activate
your CoPilot license within 3
days of installation.
Press ‘Options’ and select
one of the three activation
methods:
1. Automatic
Press ‘Next’.
Enter your email address
and press ‘Next’. CoPilot
will automatically connect
to the Internet using the
GPRS/3G capabilities of
the Nokia N70.
‘License activated success-
fully’ will be displayed,
press ‘Done’ and continue.
2. Manual
Using a PC/laptop
connected to the
Internet, visit
http://activate.alk.com
Type in your Product Key
and the License Number
displayed on-screen, then
enter your email address
and press ‘Submit’ to receive
your activation code.
Press ‘Next’. Enter the
activation code into your
phone and press ‘Done’.
‘License activated success-
fully’ will be displayed,
press ‘Done’ and continue.
3. Telephone
Please select your location
from the Menu.
Call the CoPilot Customer
Supportteam.
You will need to provide
your Product Key and the
License Number displayed
on-screen to receive your
activation code.
Enter the activation code
into your phone and press
‘Done’.
‘License activated success-
fully’ will be displayed,
press ‘Done’ and continue.
License Activation
Live Messaging
19 CoPilot Live 6 Symbian S60
Real-time messaging
People can also send messages to your phone while tracking
your location on a map from the http://live.alk.eu.com website.
Messages will appear on the driver’s Nokia N70’s screen.
Simple timed-out responses are displayed and allow the driver
to respond at the touch of a button to avoid driver distraction.
Live Messaging
Live website
Live Message on driver’s
Nokia N70
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 7

Bluetooth Set-up
Bluetooth GPS Receiver Set-up
CoPilot uses Global Positioning Satellites (GPS) to locate your
position on a map and to provide turn-by-turn guidance to a
destination.
It is essential that you pair the Bluetooth GPS receiver with
your phone to obtain a GPS fix so you can enjoy satellite
navigation on your Nokia N70.
Switch on your Bluetooth GPS receiver.
When prompted to switch on Bluetooth on your device,
choose ‘Yes’. Please check that Bluetooth is automatically
turned on.
Create a name for your phone. Press ‘OK’.
Press ‘Options’, and select ‘Search for GPS’. A list of
Bluetooth devices will be displayed. Select the Bluetooth
device starting with ‘BTGPS xxxxx’.
Check that a GPS Signal is Found. Press ‘Done’.
You arenow ready to enter a destination and start
navigating.
5CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
You can invite people to track your current location on a map
via the Internet in real-time.
Simply login to your CoPilot Live account. Select Live Setup >
Invites. In the Updating List screen, press Options > New.
In the New Invitation screen, please enter the name and email
address of the person you wish to invite to track your location.
Type in a message and press ‘Done’.
Aweb tracking email hyperlink will be sent to the person’s
PC/laptop, therefore enabling them to track your location
on a map and monitor your estimated time of arrival to a
destination.
Live Location Tracking
Live Location Tracking
18
CoPilot Live 6 Symbian S60
Driver’s current
position
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 8

Bluetooth Set-up
6
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
GPS performance hints and tips
CoPilot uses the Bluetooth GPS receiver to enable you to obtain
aGPS fix for CoPilot to calculate your route and provide
navigation guidance.
The first time you use the GPS receiver it may take several
minutes to determine your position.
There is no GPS signal inside buildings, tunnels, garages, multi-
storey and basement car parks.
When using the GPS receiver for a journey, please ensure that
it is fully charged and mounted securely with a clear line of
sight to the sky e.g. by placing on a vehicle dashboard.
Scrolling GPS status indicator
Good GPS reception
Fair GPS reception
No GPS reception
Note: If you need to re-bond your Bluetooth receiver
with your Nokia N70, please select Welcome > GPS >
Options > Turn On Bluetooth.
You will then need to search for your Bluetooth device
by pressing Options > Search for GPS. Select the
Bluetooth device starting with BTGPS xxxxx. Press ‘Done’.
Traffic Incident Indicators
Press ‘9’ to see a list of all current incidents. In the Traffic
screen, highlight an incident and select Options > Details.
You can make an informed decision about whether you
would prefer to:
Ignore the alertand and continue to drive along your
planned route through the traffic congestion
Avoid the traffic incident by allowing CoPilot to automatically
re-route you around it.
*+Traffic availability subject to country and varies by region. An additional
traffic subscription may be required. Additonal costs can be incurred for
mobile data charges, prices will vary according to mobile network operator.
Live Traffic
Traffic
Jam
Accident Road
Construction
General
Incident
Weather
Live Traffic
17 CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 9

CoPilot Welcome Menu
Take a look at the CoPilot Welcome Screen
The Welcome screen is displayed, either when you first launch
CoPilot, or by selecting the Options left hand soft key > Help
>Welcome.
Once you are there, you’ll discover on-screen step by step
address entry for navigating to a destination; real-time traffic
information; Live location tracking and messaging plus lots
more.
CoPilot Welcome Menu
7CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
T-Mobile customers receive a complimentary 24 month
subscription to real-time traffic information*+.
Traffic incidents are reported in real-time into CoPilot using
the phone’s mobile Internet connection.
How to set-up Traffic Reports
To receive alerts for traffic incidents reported along your
planned route select, Settings > Live > Traffic. In the ‘Traffic
Settings’ screen, set the options as specified below:
Using Live Traffic
In Guidance Mode, press Options > Traffic > Check Route.
CoPilot Live will alertyou when traffic incidents are reported
on your road ahead by displaying a yellow traffic warning
indicator in its maps and itinerary.
Enable Traffic - Yes
Automatically Check for Traffic - Yes
Live Traffic
Live Traffic
16
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 10

Navigating to a destination
8
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
Select ‘Going To’ from the
Welcome screen.
You can enter a destination
using a street Address,
Favourites, Intersection,
Points of Interest, a person
listed in your Contacts or
simply by picking a stop from
the map.
Entering an Address
Select ‘Add a Stop’ from the
‘Going To’ screen. Press the
‘Address’ icon. Using the
mobile phone keypad,
complete the House Number,
Street Name, Town or Postal
Code address fields for a
destination, press ‘Done’.
The destinations entered
for your journey will be
displayed in the ‘Going To’
screen.
You can check the destination
on a map to ensure that it
is the correct location by
pressing Options > Actions >
Map.
Tip: For quick address entry,
just type in a full UK postcode,
press ‘Done’.
CoPilot will display a list of
matches. If an exact match is
not found, a cross street,
nearby address or a street in
anearby city will be displayed.
You can enter multiple
destinations and optimise
your journey by pressing
Options > Actions > Optimise
Stops.
Once you have finished
entering your complete
itinerary,press ‘Drive’.
Navigating to a Destination
Note: CoPiLot Live real-time information services requires
aconnection to the mobile Internet via GPRS or 3G.
Usage of Live Services may incur additional mobile data
charges.
Please contact your mobile network operator regarding
your mobile phone service.
Step 2 - How to set-up Live Communications on your phone
To enjoy CoPilot Live real-time information services on your
Nokia N70, please follow the steps below:
1. From the CoPilot Welcome menu, select ‘Live Setup’.
2. Press the ‘Login’ button. In the Login screen, please select
Live Messaging > On. Press ‘OK’.
3. Enter a screen name of your choice, followed by the
account name and password created in step 1.4 overleaf.
4. Press ‘Back’.
Stay connected and enjoy the drive with CoPilot Live!
NB: You will have to exit and re-startCoPilot for these
settings to take effect.
CoPilot Live Services
15 CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:04 Page 11

Navigating to a POI
9CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
Points of Interest (POIs) are important, useful and popular
locations. You can use CoPilot to locate and navigate to any
one of thousands of Points of Interest.
POIs are listed by category and type to assist your search.
To search for a POI, select a ‘Category’ and ‘Type’, then enter
a‘Town/Postal Code’ and ‘Country’. Press ‘Done’.
Select the desired location from the list of matches displayed,
press ‘Drive’.
POI Alerts
Report and view POIs (by desired category) for any journey on
amap while driving, select Options > Settings > POI Alerts >
On, then define the Category and Type for your search.
Navigating to a Point of Interest
POI category
and type
selection
POI matches POI map
preview
POI entered as
destination
POI alert on
Nokia N70
In addition to voice guided turn-by-turn satellite navigation,
CoPilot offers a range of real time information services to
make your journey safer and easier.
Live Traffic
Live Location Tracking
Live Messaging
Live Destination Sending
Get connected
Step 1 - How to create a CoPilot Live Web Account
To use CoPilot Live services, you will first need to create an user
account on CoPilot’s Live website:
1. Connect your PC/Laptop to the Internet.
2. Browse to the http://live.alk.eu.com website.
3. In the login screen click on “create your new account here”.
4. Enter an easy to remember account name and password for
your account.
5. Complete your name and email address details.
6. Select a time zone, followed be a region for your account
based on the country your CoPilot license is registered.
7. Click on “Submit”.
CoPilot Live Services
CoPilot Live Services
14
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:05 Page 12

Driving Views
10
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
CoPilot has six different driving views which can be accessed
by pressing Options > View.
Driver Safety
Driver Safety is the default view, which displays a simple turn
instruction arrow with concise next turninstructions.
An auto-zoom map will appear as you
approach a turnor if your speed is below
10 mph.
This is the recommended view for safe
driving as it's designed to display the
information you need at a glance with
minimum driver distraction.
How to Change Driving Views
Driver
Safety
Next
Turn
Where
Am I
Next
Stop
3D
Itinerary
Optimise stops
CoPilot can work out the best way around multiple destinations
for journeys that require you to stop/pass through various
locations.
Simply enter the destinations in the ‘Going To’ screen. To optimise
your stops select Options > Actions > Optimise Stops.
The destinations entered for your journey will be displayed in
the ‘Going To’ screen, press ‘Drive’.
Taking the strain out of night driving
Trust your CoPilot to guide you to the door at night - safely
and in comfort. CoPilot’s night mode uses the time set on
your Nokia N70 to automatically display night time 2D or 3D
maps to reduce glareand eye strain while driving using
CoPilot at night.
To set-up night mode, select Options > Settings > Map > Map
Colors > Automatic.
Advanced Features
2D
view
3D
view
Advanced Features
13 CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:05 Page 13

CoPilot has 3 navigation modes, accessed by selecting
Options > Mode.
1) Guidance Mode provides spoken and on-screen driving
directions plus other information relevant to your journey
such as Estimated Time of Arrival (ETA), road name of the
next turn and the distance to turn.
2) Planning Mode lets you plan your journey in advance.
Simply key in a destination and view the itinerary and
detailed street maps of any location - wherever you are.
3) Walking Mode lets you find the way on foot using your
mobile. CoPilot displays a straight line 'as the crow flies' to
your destination at all times and indicates the straight line
distance to that location.
Navigation Modes
Navigation Modes
11 CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
CoPilot Live is packed with powerful features to help you
reach your destination easily.
London congestion zone warnings
If you are driving in London, you can set up CoPilot to alert
you when your destination approaches/passes through the
London Congestion Zone. You will have the option to either
drive through the charging zone or re-route around it.
To set-up London Congestion Zone alerts, select:
Options > Settings > Routing > Cong. Zone Warning > On
Toll road avoidance
You can set CoPilot to calculate routes which avoid/use toll
roads by selecting, Options > Settings > Routing > Avoid Tolls
To define how CoPilot handles toll roads, choose one the
3options:
Always Avoid
Use If Necessary
No Restriction
Defining your routing
Define whether you would prefer CoPilot to calculate
quickest or shortest routes by selecting, Options > Settings >
Routing > Routing Type.
Advanced Routing Settings
Advanced Routing Settings
12
CoPilot Live 6 Symbian S60
Customer Support Helpline
([phone]
symbian booklet 050406_new 5/4/06 12:05 Page 14
