ALLEN & HEATH GL3000 User manual

AP2376 ISS 1 1ALLEN & HEATH
FITTING INSTRUCTIONS
Check contents of pack to ensure all parts have been supplied.
1
PARTNO.AB2304
QUANTITY3
SCREW M3X8 HEX
THESE
FITTING
INSTRUCTIONS
PARTNO.AB0102
QUANTITY3
NUT LOCK M3
J
F
PARTNO.s002-103or002-104
QUANTITY1
PARTNO.AB2421
QUANTITY1
SCREW M6X8 SKT HEX
PARTNO.AB2406
QUANTITY1
STUDSLOTTED
PARTNO.AB0335
QUANTITY2
AJUSTABLEFASTENER
PARTNO.AB0336
QUANTITY2
CATCHPLATE
PARTNO.AB2084
QUANTITY10
SCREW6BX5/16
PARTNO.AB0271
QUANTITY4
SCREWM4X10
PARTNO.AB0188
QUANTITY4
NUT LOCK M4
PARTNO.AB2085
QUANTITY6
SREW8BX3/8CSK
B
A
H
LM
CD
E
PARTNO.AA2404
QUANTITY1
BASEBRACKET
N
INTRODUCTION
The GL3000-8M and GL3000-4SM are an 8 channel mono input module and a 4 mono + 4 stereo input
module respectively for fitting to the GL3000 series of consoles. These expander modules allow a
GL3000 console to be expanded up to a maximum of 40 channels.
Please read the following instructions carefully before attempting to fit the module.
GL3000 EXPANDER
8 CHANNEL MONO MODULE
4 MONO + 4 STEREO MODULE
PART NO: GL3000-8M 8 CHANNEL MONO MODULE
PART NO: GL3000-4SM 4 MONO + 4 STEREO MODULE
PARTNO.sAK2365AK2398AK2542
QUANTITY1
IDENTSTRIP
K
G
PARTNO.AB0325
QUANTITY4
STUDM6X38.5
P
PARTNO.AB0062
QUANTITY4
SCREW6ABX3/8

AP2376 ISS 1
2ALLEN & HEATH
EXPANDER POSITIONING
GL3000-816 + Expander
MASTER
9 - 161 - 8 EXPANDER
GL3000-832S + Expander
MASTER
9 - 161 - 8 17 - 24
stereo
25 - 32
EXPANDER
GL3000-824S + Expander
MASTER
1 - 8 17 - 24
stereo
9 - 16 EXPANDER
TOOLS REQUIRED:
The following tools are required to fit the expander module.
1x 3mm Hex key
1x 4mm Hex key
1x 1-point Pozi screwdriver
1x flat point screwdriver
1x long nose pliers
2x 5.5mm AF spanner
2The Expander module must be fitted in the position shown in the diagrams below.

AP2376 ISS 1 3ALLEN & HEATH
4
Ensure you have a good work surface and clear area before starting work. Remove the optional
Meterbridge if fitted. Carefully invert the console and remove base panel.
Remove the side trim from the side of the console that is to have the expander fitted and fix it to
the side of the expander module.
Only technically competent personel should attempt to fit the expander module
Disconnect GL3000 from Power Supply Unit and cables before fitting the module
INSTALLATION
3

AP2376 ISS 1
4ALLEN & HEATH
Attach adjustable fastener 'A' and catchplate 'B'
6
7Screw the 4 plain studs
'G' into the extrusion holes of the console as shown below.
Attach the adjustable fastener 'A' and catchplate 'B' to the front extrusion of the console and
expander using screws 'F' and nuts 'M' . The mounting holes are located under the front armrest
of each unit and are pre-drilled for the adjustable fastener and catchplate.
Attach the second adjustable fastener 'A' and catchplate 'B' to the rear extrusions using 4
screws 'P' in the positions indicated below. Use the dimensions below to position the fixing
screws.
A
B
Attach adjustable fastener 'A' and catchplate 'B'
Expander
Console
G
G
GG
5

AP2376 ISS 1 5ALLEN & HEATH
Expander
Console
'H'
'H'
'C'
'C'
Disconnect the main harness from the end input circuit board on the console. Connect the male
connector on the expander harness to the console main harness. Re-connect the end Input circuit
board with the extra connector on the expander harness.
Attach the base panel Joining bracket 'N' to the console base using screws 'E' .
Place the console base panel onto the console and attach the expander base to the Joining
bracket 'N' using screws 'E' . Then screw the base assembly to the console and expander.
9With the expander module and console securely clamped together, bolt the expander and console
front panels together with bolts 'D' and nuts 'J' using two 5.5mm spanners.
10
Screw the slotted stud 'H' into the top rear extrusion of the console. Slide the expander module
onto the 5 studs and close the 2 adjustable fasteners 'A' over the catchplates 'B' , see Ž& •.
The fasteners can be adjusted to ensure a good join. Screw in the locking screw 'C' into the pre-
tapped hole. Make sure the locking screw 'C' engages with the flat of the slotted stud 'H', see
diagram below.
8
Carefully turn the console the correct way up and fit the new number strips. Refer to the section
'NUMBER STRIP POSITIONING' on the next page for details on fitting the strips to the expanded
console.
13
11
12

AP2376 ISS 1
6ALLEN & HEATH
TESTING THE CONSOLE
The fitting of the expander module is now complete. Before re-plugging the console, apply power and
check for correct operation e.g. mute & PFL LEDs illuminate.
Should you experience any difficulties in fitting this module or have any queries regarding your GL3000
console please contact your ALLEN & HEATH agent. Include the console serial number in any
correspondence.
NUMBERSTRIPPOSITIONING
A complete set of number strips 'K' is supplied with the Expander kit. The existing number strip on
the console can be replaced with the new set. The diagrams below show the combination of strips
to be fitted to the expanded consoles.
MASTER
9 - 161 - 8 EXPANDER
MASTER
1 - 8 17 - 24
stereo
9 - 16 EXPANDER
MASTER
9 - 161 - 8 17 - 24
stereo
25 - 32EXPANDER
GL3000-816 + Expander
GL3000-824S + Expander
GL3000-832S + Expander
cut off numbers 33-40
14
