Allen-Bradley 22-COMM-E FRN 1.xxx User manual

EtherNet/IP
Adapter
22-COMM-E
FRN 1.xxx
User Manual

Important User Information
Solid state equipment has operational characteristics differing from those of
electromechanical equipment. “Safety Guidelines for the Application, Installation
and Maintenance of Solid State Controls” (Publication SGI-1.1 available from
your local Rockwell Automation Sales Office or online at http://www.ab.com/
manuals/gi) describes some important differences between solid state equipment
and hard-wired electromechanical devices. Because of this difference, and also
because of the wide variety of uses for solid state equipment, all persons
responsible for applying this equipment must satisfy themselves that each intended
application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or
consequential damages resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative
purposes. Because of the many variables and requirements associated with any
particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of
information, circuits, equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written
permission of Rockwell Automation, Inc. is prohibited.
Throughout this manual we use notes to make you aware of safety considerations.
Attentions help you:
•identify a hazard
•avoid the hazard
•recognize the consequences
Important: Identifies information that is especially important for successful
application and understanding of the product.
ControlFLASH, DriveExplorer, DriveTools, DriveExecutive, PLC-5, SCANport, and SLC are trademarks of Rockwell
Automation, Inc.
Allen-Bradley, PowerFlex, and ControlLogix are registered trademarks of Rockwell Automation, Inc.
RSLinx, RSLogix, and RSNetWorx are trademarks of Rockwell Software.
Ethernet is a trademark of Digital Equipment Corporation, Intel Corporation, and Xerox Corporation.
Netscape and Netscape Navigator are registered trademarks of the Netscape Communications Corporation.
Windows, Windows CE, Windows NT, and Microsoft are either registered trademarks or trademarks of Microsoft Corporation.
!
ATTENTION: Identifies information about practices or circumstances
that can lead to personal injury or death, property damage, or economic
loss.
Shock Hazard labels may be located on or inside the drive to alert
people that dangerous voltage may be present.

Summary of Changes
The information below summarizes the changes made to this manual
since its first release (December 2003) of the EtherNet/IP adapter FRN
1.xxx:
Description of Changes Page(s)
Corrected the values in the Input Size and Output Size columns in
Table 4.A.
4-6

S-ii Summary of Changes

Table of Contents
Preface About This Manual
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-1
Conventions Used in this Manual . . . . . . . . . . . . . . . . . . . . . P-2
Rockwell Automation Support. . . . . . . . . . . . . . . . . . . . . . . . P-2
Chapter 1 Getting Started
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Compatible Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Required Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Modes of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Chapter 2 Installing the Adapter
Preparing for an Installation. . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Setting Operating Mode and Web Pages Switches . . . . . . . . 2-1
Connecting the Adapter to the Network . . . . . . . . . . . . . . . . 2-3
Connecting the Adapter to the Drive . . . . . . . . . . . . . . . . . . . 2-4
Applying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Commissioning the Adapter. . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Chapter 3 Configuring the Adapter
Configuration Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Using the PowerFlex 4-Class HIM . . . . . . . . . . . . . . . . . . . . 3-2
Using BOOTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Setting the IP Address, Subnet Mask, and Gateway Address 3-5
Setting the Data Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Setting the I/O Configuration. . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Setting a Fault Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Setting Web Features Access . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Resetting the Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Viewing the Adapter Configuration . . . . . . . . . . . . . . . . . . . 3-12
Chapter 4 Configuring the Scanner or Bridge
Example Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Adding a Bridge or Scanner to the I/O Configuration . . . . . . 4-2
Adding the Adapter and Drive to the I/O Configuration . . . . 4-4
Saving the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

ii Table of Contents
Chapter 5 Using I/O Messaging
About I/O Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Understanding the I/O Image. . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Using Logic Command/Status . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Using Reference/Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Example Ladder Logic Program . . . . . . . . . . . . . . . . . . . . . . 5-3
Chapter 6 Using Explicit Messaging
About Explicit Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Formatting Explicit Messages . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Performing Explicit Messages . . . . . . . . . . . . . . . . . . . . . . . . 6-4
About the Example Explicit Messages . . . . . . . . . . . . . . . . . 6-5
Example Get Attribute Single Message . . . . . . . . . . . . . . . . . 6-6
Example Set Attribute Single Message . . . . . . . . . . . . . . . . . 6-8
Chapter 7 Using Multi-Drive Mode
Single Mode vs. Multi-Drive Mode . . . . . . . . . . . . . . . . . . . . 7-1
System Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Understanding the I/O Image. . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Configuring the RS-485 Network . . . . . . . . . . . . . . . . . . . . . 7-5
Multi-Drive Ladder Logic Program Example . . . . . . . . . . . . 7-6
ControlLogix Example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Multi-Drive Mode Explicit Messaging . . . . . . . . . . . . . . . . 7-20
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-22
Chapter 8 Troubleshooting
Locating the Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . 8-1
PORT Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
MOD Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Net A Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Net B Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Adapter Diagnostic Items in Single Drive Mode . . . . . . . . . 8-5
Adapter Diagnostic Items in Multi-Drive Mode . . . . . . . . . . 8-7
Viewing and Clearing Events. . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Chapter 9 Viewing the Adapter’s Web Pages
Accessing the Adapter’s Web Home Page . . . . . . . . . . . . . . . 9-1
Process Display Pop-up Windows . . . . . . . . . . . . . . . . . . . . . 9-6
TCP/IP Configuration Web Page . . . . . . . . . . . . . . . . . . . . . . 9-7
Configure E-mail Notification Web Page . . . . . . . . . . . . . . . 9-8
Configure Process Display Web Page . . . . . . . . . . . . . . . . . 9-10
DSI Device Information Pages. . . . . . . . . . . . . . . . . . . . . . . 9-11

Table of Contents iii
Appendix A Specifications
Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Appendix B Adapter Parameters
About Parameter Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Parameter List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Appendix C EtherNet/IP Objects
Identity Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
Assembly Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Register Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6
Parameter Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9
Parameter Group Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . C-13
PCCC Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-15
DPI Device Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-21
DPI Parameter Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-24
DPI Fault Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-28
DPI Diagnostic Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-30
TCP/IP Interface Object. . . . . . . . . . . . . . . . . . . . . . . . . . . . C-32
Ethernet Link Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-34
Appendix D Logic Command/Status Words
PowerFlex 4 and PowerFlex 40 Drives . . . . . . . . . . . . . . . . D-1
Glossary
Index

iv Table of Contents

Preface
About This Manual
Documentation can be obtained online at http://www.ab.com/manuals.
Topic Page
Related Documentation P-1
Conventions Used in this Manual P-2
Rockwell Automation Support P-2
Related Documentation
For: Refer to: Publication
EtherNet/IP EtherNet/IP Planning and Installation Manual
EtherNet/IP Performance and Application Guide
ENET-IN001…
ENET-AP001…
DriveExplorer™ http://www.ab.com/drives/driveexplorer, and
DriveExplorer Online Help (installed with the software)
—
DriveTools™ SP http://www.ab.com/drives/drivetools, and
DriveTools SP Online Help (installed with the software)
—
HIM HIM Quick Reference 22HIM-QR001…
PowerFlex®4 Drive PowerFlex 4 User Manual
PowerFlex 4 Quick Start
22A-UM001…
22A-QS001…
PowerFlex®40 Drive PowerFlex 40 User Manual
PowerFlex 40 Quick Start
22B-UM001…
22B-QS001…
RSLinx™ Getting Results with RSLinx Guide
Online help (installed with the software)
LINX-GR001…
RSLogix™ 5 RSLogix 5 Getting Results Guide
Online help (installed with the software)
LG5-GR001…
RSLogix™ 500 RSLogix 500 Getting Results Guide
Online help (installed with the software)
LG500-GR001
…
RSLogix™ 5000 RSLogix 5000 Getting Results Guide
Online help (installed with the software)
9399-RLD300G
R
RSNetWorx™ for
EtherNet/IP
RSNetWorx for EtherNet/IP Getting Results Guide
Online help (installed with the software)
ENET-GR001…
ControlLogix™ and
1756-ENBT or
1756-ENET/B
ControlLogix EtherNet Bridge Module User Manual
ControlLogix EtherNet Communications Module User Manual
1756-UM050…
1756-UM051…

P-2 About This Manual
The following conventions are used throughout this manual:
•Parameter names are shown in the format Parameter xx - [*]. The xx
represents the parameter number. The * represents the parameter
name. For example Parameter 01 - [Mode].
•Menu commands are shown in bold type face and follow the format
Menu > Command. For example, if you read “Select File > Open,”
you should click the File menu and then click the Open command.
•The firmware release is displayed as FRN X.xxx. The “FRN”
signifies Firmware Release Number. The “X” is the major release
number. The “xxx” is the minor update number.
•RSNetWorx for EtherNet/IP (version 4.01), RSLinx (version 2.40),
and RSLogix5000 (version 11) were used for the screen shots in this
manual. Different versions of the software may differ in appearance
and procedures.
•This manual provides information about the 22-COMM-E EtherNet/
IP adapter and using it with PowerFlex 40 drives. The adapter can be
used with other products that support an internal DSI adapter. Refer to
the documentation for your product for specific information about
how it works with the adapter.
Rockwell Automation, Inc. offers support services worldwide, with over
75 sales/support offices, over 500 authorized distributors, and over 250
authorized systems integrators located through the United States alone.
In addition, Rockwell Automation, Inc. representatives are in every
major country in the world.
Local Product Support
Contact your local Rockwell Automation, Inc. representative for:
•Sales and order support
•Product technical training
•Warranty support
•Support service agreements.
Conventions Used in this Manual
Rockwell Automation Support

About This Manual P-3
Technical Product Assistance
If you need to contact Rockwell Automation, Inc. for technical
assistance, please review the information in Chapter 8,Troubleshooting
first. If you still have problems, then call your local Rockwell
Automation, Inc. representative.
86$OOHQ%UDGOH\'ULYHV7HFKQLFDO6XSSRUW
(PDLO VXSSRUW#GULYHVUDURFNZHOOFRP
7HO 
)D[ 
2QOLQH ZZZDEFRPVXSSRUWDEGULYHV
8.&XVWRPHU6XSSRUW&HQWHU
(PDLO HVXSSRUW#UDURFNZHOOFRP
7HO 
)D[ 
*HUPDQ\&XVWRPHU6HUYLFH&HQWHU
(PDLO UDJHUPDQ\FVF#UDURFNZHOOFRP
7HO 
)D[ 

P-4 About This Manual
Notes:

Chapter 1
Getting Started
The 22-COMM-E EtherNet/IP adapter is a communication option
intended for installation into a PowerFlex 40 drive. It can also be used
with other Allen-Bradley products that support an internal DSI adapter.
The Multi-Drive feature (Chapter 7) also provides a means for
PowerFlex 4 drives and other DSI Hosts to connect to EtherNet/IP.
Figure 1.1 Components of the Adapter
Topic Page Topic Page
Components 1-1 Safety Precautions 1-4
Features 1-2 Quick Start 1-5
Compatible Products 1-3 Modes of Operation 1-6
Required Equipment 1-3
Components
Item Part Description
➊Status
Indicators
Four LEDs that indicate the status of the Ethernet connection,
DSI, and the adapter. Refer to Chapter 8,Troubleshooting.
➋DSI Connector A 20-pin, single-row shrouded male header. An Internal Interface
cable is connected to this connector and a connector on the drive.
➌Ethernet
Connector
An RJ-45 connector for the Ethernet cable. The connector is
CAT-5 compliant to ensure reliable data transfer on 100Base-TX
Ethernet connections.
➍Operating Mode
Switch and Web
Pages Switch
Selects Single or Multi-Drive mode of operation, and enables or
disables the adapter web pages. Refer to Chapter 2,Setting
Operating Mode and Web Pages Switches.
➊
➌
➋
➍
LEDs are on bottom side of adapter board

1-2 Getting Started
The EtherNet/IP adapter features the following:
•The adapter is mounted in the PowerFlex 40 drive. It receives the
required power from the drive.
•A switch lets you select between Single or Multi-Drive mode of
operation. In Single mode (default), the adapter represents a single
drive on one node. In Multi-Drive mode, the adapter represents up to 5
drives on one node.
•A switch lets you enable or disable (default) the adapter web pages.
•A number of configuration tools can be used to configure the adapter
and connected drive. The tools include an external PowerFlex 4-Class
HIM (22-HIM-*), network software such as RSNetWorx for
EtherNet/IP, or drive-configuration software such as DriveExplorer
(version 3.01 or higher) or DriveExecutive (version 3.01 or higher). In
addition, you can use a BOOTP server to configure the network
features on the adapter (for example, the IP address).
•Status indicators report the status of the drive communications,
adapter, and network.
•I/O, including Logic Command/Reference, may be configured for
your application using a parameter.
•Explicit Messages are supported.
•User-defined fault actions determine how the adapter and PowerFlex
drive respond to communication disruptions on the network and
controllers in idle mode.
•Each adapter has Web pages that display information about the
adapter, the connected drive, and other DSI devices connected to the
drive. The adapter can also be configured to send e-mail messages to
desired addresses when selected drive faults occur and/or are cleared,
and/or when the adapter takes a communication or idle fault action.
Features

Getting Started 1-3
The EtherNet/IP adapter is compatible with Allen-Bradley PowerFlex
Component Class drives and other products that support an internal DSI
adapter. At the time of publication, compatible products include:
•PowerFlex 40 drives
The Multi-Drive feature (Chapter 7) also provides a means for
PowerFlex 4 drives and other DSI Hosts to connect to EtherNet/IP.
Equipment Shipped with the Adapter
When you unpack the adapter, verify that the package includes:
User-Supplied Equipment
To install and configure the EtherNet/IP adapter, you must supply:
Phillips is a registered trademark of the Phillips Screw Company.
Compatible Products
Required Equipment
❑One EtherNet/IP adapter
❑A 15.24 cm (6 in.) Internal Interface Cable
❑This manual
❑A small flathead or Phillips®screwdriver
❑Ethernet cable (refer to the EtherNet/IP Media Planning and
Installation Manual, Publication No. ENET-IN001…, for details)
❑Configuration tool, such as:
– PowerFlex 4-Class HIM (22-HIM-*)
– DriveExplorer (version 3.01 or higher)
– DriveExecutive (version 3.01 or higher)
– RSNetWorx for EtherNet/IP
– BOOTP Server (version 2.1 or higher) (network setup only)
❑A PC connection to the EtherNet/IP network.
❑Controller configuration software
(Examples: RSLogix5, RSLogix500, or RSLogix 5000)

1-4 Getting Started
Please read the following safety precautions carefully.
Safety Precautions
!
ATTENTION: Risk of injury or death exists. The PowerFlex drive
may contain high voltages that can cause injury or death. Remove all
power from the PowerFlex drive, and then verify power has been
removed before installing or removing an EtherNet/IP adapter.
!
ATTENTION: Risk of injury or equipment damage exists. Only
personnel familiar with drive and power products and the associated
machinery should plan or implement the installation, start-up,
configuration, and subsequent maintenance of the product using an
EtherNet/IP adapter. Failure to comply may result in injury and/or
equipment damage.
!
ATTENTION: Risk of equipment damage exists. The EtherNet/IP
adapter contains ESD (Electrostatic Discharge) sensitive parts that can
be damaged if you do not follow ESD control procedures. Static control
precautions are required when handling the adapter. If you are
unfamiliar with static control procedures, refer to Guarding Against
Electrostatic Damage, Publication 8000-4.5.2.
!
ATTENTION: Risk of injury or equipment damage exists. If the
EtherNet/IP adapter is transmitting control I/O to the drive, the drive
may fault when you reset the adapter. Determine how your drive will
respond before resetting an adapter.
!
ATTENTION: Risk of injury or equipment damage exists. Parameters
18 - [Comm Flt Action] and 19 - [Idle Flt Action] let you determine the
action of the adapter and connected PowerFlex drive if communications
are disrupted. By default, these parameters fault the drive. You can set
these parameters so that the drive continues to run. Precautions should be
taken to ensure that the settings of these parameters do not create a risk
of injury or equipment damage. When commissioning the drive, verify
that your system responds correctly to various situations (for example, a
disconnected cable or a faulted controller).
!
ATTENTION: Hazard of injury or equipment damage exists. When a
system is configured for the first time, there may be unintended or
incorrect machine motion. Disconnect the motor from the machine or
process during initial system testing.
!
ATTENTION: Hazard of injury or equipment damage exists. The
examples in this publication are intended solely for purposes of
example. There are many variables and requirements with any
application. Rockwell Automation, Inc. does not assume responsibility
or liability (to include intellectual property liability) for actual use of
the examples shown in this publication.

Getting Started 1-5
This section is provided to help experienced users quickly start using the
EtherNet/IP adapter. If you are unsure how to complete a step, refer to
the referenced chapter.
Quick Start
Step Refer to . . .
1 Review the safety precautions for the adapter. Throughout This
Manual
2 Verify that the PowerFlex drive is properly installed. Drive User Manual
3 Install the adapter.
Verify that the PowerFlex drive is not powered. Then, connect
the adapter to the network using an Ethernet cable and to the
drive using the Internal Interface cable. Use the captive screw
to secure and ground the adapter to the drive.
Chapter 2,
Installing the
Adapter
4 Apply power to the adapter.
The adapter receives power from the drive. Apply power to
the drive. The status indicators should be green. If they flash
red, there is a problem. Refer to Chapter 8,Troubleshooting.
Chapter 2,
Installing the
Adapter
5 Configure the adapter for your application.
Set the following parameters for the adapter as required by
your application:
•IP address, subnet mask, and gateway address
•Data rate
•I/O configuration
•Fault actions
Chapter 3,
Configuring the
Adapter
6 Create a ladder logic program.
Use a programming tool such as RSLogix to create a ladder
logic program that enables you to:
•Control the adapter and connected drive using I/O.
•Monitor or configure the drive using Explicit Messages.
Chapter 4,
Configuring the
Scanner or Bridge
Chapter 5,
Using I/O Messaging
Chapter 6,
Using Explicit
Messaging

1-6 Getting Started
The adapter uses four status indicators to report its operating status. They
can be viewed on the adapter or through the drive cover. See
Figure 1.2.
Figure 1.2 Status Indicators (location on drive may vary)
Modes of Operation
Item Status
Indicator
Status (1)
(1) If all status indicators are off, the adapter is not receiving power. Refer to Chapter 2,
Installing the Adapter, for instructions on installing the adapter.
If any other conditions occur, refer to Chapter 8,Troubleshooting.
Description
➊PORT Green Normal Operation. The adapter is properly connected and
is communicating with the drive.
Flashing
Green
Normal Operation. The adapter is in the process of
establishing a connection to the drive. This status
indicator will turn solid green or red.
➋MOD Green Normal Operation. The adapter is operational and is
transferring I/O data.
Flashing
Green
Normal Operation. The adapter is operational but is not
transferring I/O data.
➌NET A Green Normal Operation. The adapter is properly connected and
communicating on the network.
Flashing
Green
Normal Operation. The adapter is properly connected but
is not communicating with any devices on the network.
➍NET B Flashing
Green
Normal Operation. The adapter is properly connected and
is transmitting data packets on the network.
Off Normal Operation. The adapter is not transmitting data
packets.
➊
➋
➌
➍
➌
➍
➊
➋
Bottom side
of adapter board

Chapter 2
Installing the Adapter
Chapter 2 provides instructions for installing the adapter in a
PowerFlex 40 drive.
Before installing the EtherNet/IP adapter:
•Read the EtherNet/IP Performance and Application Guide,
Publication ENET-AP001…, and the EtherNet/IP Media Planning and
Installation Manual, Publication ENET-IN001….
•Verify that you have all required equipment. Refer to Chapter 1,
Getting Started.
Important: To guard against device malfunction, use a grounding wrist
strap when installing the EtherNet/IP adapter.
Before installing the adapter, you must set its Operating Mode Switch
for Single or Multi-Drive operation. To use the adapter web pages, the
Web Pages Switch must be set to its “Enable Web” position.
Important: New settings are recognized only when power is applied to
the adapter, or the adapter is reset. If you change a setting,
cycle power or reset the adapter.
Topic Page
Preparing for an Installation 2-1
Setting Operating Mode and Web Pages Switches 2-1
Connecting the Adapter to the Network 2-3
Connecting the Adapter to the Drive 2-4
Applying Power 2-6
Commissioning the Adapter 2-6
Preparing for an Installation
Setting Operating Mode and Web Pages Switches

2-2 Installing the Adapter
1. Set the Operating Mode Switch (SW1) for Single or Multi-Drive
operation (see Figure 2.1 and setting descriptions below). For
complete details on Multi-Drive mode operation, see Chapter 7,
Using Multi-Drive Mode.
Figure 2.1 Setting Single/Multi-Drive Operation and Web Page Enable Switches
2. Set the Web Pages Switch (SW2) to enable or disable the adapter web
pages (see Figure 2.1 and setting descriptions below). By default, the
adapter web pages are disabled. For complete details on the adapter
web pages, see Chapter 9,Viewing the Adapter’s Web Pages.
!
ATTENTION: Risk of equipment damage exists. The EtherNet/IP
adapter contains ESD (Electrostatic Discharge) sensitive parts that can
be damaged if you do not follow ESD control procedures. Static control
precautions are required when handling the adapter. If you are
unfamiliar with static control procedures, refer to Guarding Against
Electrostatic Damage, Publication 8000-4.5.2.
SW1 Setting Description
Down position
(DN = Closed = 0)
Sets the adapter for Single drive mode (default setting) using a
single drive connection.
Important: In this mode, connections to multiple drives must be
removed since all powered and connected hosts will respond to
any message sent by the adapter.
Up position
(UP = Open = 1)
Sets the adapter for Multi-Drive operation mode using up to 5
different drives. DSI peripherals (22-HIM-*, 22-SCM-*, etc.) do
not operate with the adapter in this mode.
SW2 Setting Description
Down position
(DN = Closed = 0)
Disables the adapter web pages (default setting).
Up position
(UP = Open = 1)
Enables the adapter web pages.
2
1
OPERATING
MODE SWITCH
Single-Drive
Operation
Position
Multi-Drive
Operation
Position
Disable Web
Position
Enable Web
Position
WEB PAGES
SWITCH
