Allen-Bradley ControlNet 1786-BNC2TNC User manual

Publication 1786-IN002A-US-P - May 2000
Installation Instructions
ControlNet Coax BNC2TNC
Adapter
Catalog Number 1786-BNC2TNC
What’s in This Document
Use this document as a guide when you install a ControlNet™ BNC2TNC Adapter.
Topic: Page:
Important User Information 2
European Communities (EC) Directive Compliance 3
Verify Your Package Contents 4
Why Use the 1786-BNC2TNC Coax Adapter 4
Select a Location to Install the Adapter 5
Install the Connector 6
Rockwell Automation Support 8
Specifications 9
Certifications 9
IMPORTANT For information on how to plan and install your
ControlNet cable system, see the ControlNet Coax
Media System Planning and Installation Manual,
publication 1786-6.2.1 and the ControlNet Ex Media
Planning and Installation Manual, 1797-6.2.1.

4ControlNet Coax BNC2TNC Adapter
Publication 1786-IN002A-US-P - May 2000
Verify Your Package Contents
Be certain that you have these items before you discard any packing material.
Why Use the 1786-BNC2TNC Coax Adapter
Use the BNC2TNC Coax adapter to connect a BNC coax cable segment to a TNC
coax cable segment. With the adapter you can:
•isolate a segment
•install the adapter in a cabinet
•install the adapter in a wall
If an item is missing or incorrect, contact your distributor or sales office.
D ring
lock washer
nut
adapter
BNC TNC

ControlNet Coax BNC2TNC Adapter 7
Publication 1786-IN002A-US-P - May 2000
4. Attach cables according to your network topology.
ATTENTION
!
Do not over tighten the hardware. You can damage the
adapter if you over tighten the hardware. Apply the torque at
0.2-0.4 N-m (1-2 ft.-lbs). Only use the hardware that we
provide with the BNC2TNC connector. If you substitute
hardware, we cannot guarantee the integrity of your network.
1786-RPA 1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
1786-RPA 1786-RPCD
REPEATERDUALCOPPER MODULE
1786-RPCD
Sealed
ControlNet
Media
TNC
T-tap
BNC
TNC
To Node
Enclosure
Standard ControlNet Media
Outside Enclosure
Standard Controlnet Media
Inside Enclosure
BNC
TNC
Harsh Environment
FLEX I/O FLEX I/O FLEX I/O FLEX I/O
ACN FLEX I/O
BNC
TNC
Sealed
ControlNet
Media
TNC
T-tap
IP67
Device
42347
Use only the hardware that we
provide with the connector. They are
the proper design and if you use
other hardware it can diminish the
integrity of your connection.

ControlNet Coax BNC2TNC Adapter 9
Publication 1786-IN002A-US-P - May 2000
Specifications
The following table lists the specifications for the ControlNet BNC2TNC Adapter.
Environmental Specifications
Operating temperature -0 to 60°C (32 to 140°F)
Storage temperature -40 to 85°C (-40 to 185°F)
Relative humidity 5 to 95% noncondensing
Certifications
IP67 truck/tap connection When adapter is wired and locked on:
Class 1 Division 2
