Preface
Introduction
This manual describes how to install, configure, and troubleshoot the 1784-PKTX and
-PKTXD network interface cards. Throughout the manual, we refer to this product as the
PKTxcard. When one card differs from the other, this document individually calls out the
cards by name.
Contents of Your Package
With this package you should receive:
•one 1784-PKTxnetwork interface card
•one 1784-PKTxNetwork Interface Card User Manual, publication
1784-UM527B-EN-P
If you are missing any of these pieces, contact your Allen-Bradley distributor.
Abbreviations
Throughout this manual, we abbreviate some terms. Use this table to become familiar with
our terminology.
This is the abbreviation for
BIOS Basic Input/Output System
ESD Electrostatic Discharge
IRQ Interrupt Request
ISA Industry-Standard Architecture
NIC Network Interface Card
ORB Outside Retaining Bracket
PCI Peripheral Component Interconnect
PC Personal Computer
RIO Remote I/O

2Preface
Publication 1784-UM527B-EN-P - October 2003
Conventions
We use these conventions in this manual:
•Screen displays and prompts are shown as
Press ENTER to continue with the installation
•Text that you type is shown as:
a:\install c
•Keys that you press look like this:
•Other actions to be performed are show as:
Click on the Memory tab.
Enter

Preface 3
Publication 1784-UM527B-EN-P - October 2003
Environment and Enclosure
Preventing Electrostatic Discharge
ATTENTION This equipment is intended for use in a Pollution Degree 2 industrial
environment, in overvoltage Category II applications (as defined in IEC
publication 60664-1), at altitudes up to 2000 meters without derating.
This equipment is considered Group 1, Class A industrial equipment
according to IEC/CISPR Publication 11. Without appropriate
precautions, there may be potential difficulties ensuring electromagnetic
compatibility in other environments due to conducted as well as radiated
disturbance.
This equipment is supplied as “open type” equipment. It must be
mounted within an enclosure that is suitably designed for those specific
environmental conditions that will be present and appropriately designed
to prevent personal injury resulting from accessibility to live parts. The
interior of the enclosure must be accessible only by the use of a tool.
Subsequent sections of this publication may contain additional
information regarding specific enclosure type ratings that are required to
comply with certain product safety certifications.
NOTE: See NEMA Standards publication 250 and IEC publication
60529, as applicable, for explanations of the degrees of protection
provided by different types of enclosure. Also, see the appropriate
sections in this publication, as well as the Allen-Bradley publication
1770-4.1 (“Industrial Automation Wiring and Grounding Guidelines”),
for additional installation requirements pertaining to this equipment.
ATTENTION This equipment is sensitive to electrostatic discharge, which can cause
internal damage and affect normal operation. Follow these guidelines
when you handle this equipment:
•Touch a grounded object to discharge potential static.
•Wear an approved grounding wriststrap.
•Do not touch connectors or pins on component boards.
•Do not touch circuit components inside the equipment.
•If available, use a static-safe workstation.
•When not in use, store the equipment in appropriate static-safe
packaging.

4Preface
Publication 1784-UM527B-EN-P - October 2003
North American Hazardous Location Approval
The following information applies when
operating this equipment in hazardous locations:
Informations sur l’utilisation de cet équipement
en environnements dangereux:
Products marked “CL I, DIV 2, GP A, B, C, D” are
suitable for use in Class I Division 2 Groups A, B, C, D,
Hazardous Locations and nonhazardous locations only.
Each product is supplied with markings on the rating
nameplate indicating the hazardous location
temperature code. When combining products within a
system, the most adverse temperature code (lowest
“T” number) may be used to help determine the overall
temperature code of the system. Combinations of
equipment in your system are subject to investigation
by the local Authority Having Jurisdiction at the time
of installation.
Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne
conviennent qu’à une utilisation en environnements
de Classe I Division 2 Groupes A, B, C, D dangereux et
non dangereux. Chaque produit est livré avec des
marquages sur sa plaque d’identification qui
indiquent le code de température pour les
environnements dangereux. Lorsque plusieurs
produits sont combinés dans un système, le code de
température le plus défavorable (code de température
le plus faible) peut être utilisé pour déterminer le
code de température global du système. Les
combinaisons d’équipements dans le système sont
sujettes à inspection par les autorités locales
qualifiées au moment de l’installation.
WARNING EXPLOSION HAZARD
•Do not disconnect
equipment unless power
has been removed or the
area is known to be
nonhazardous.
•Do not disconnect
connections to this
equipment unless power
has been removed or the
area is known to be
nonhazardous. Secure any
external connections that
mate to this equipment by
using screws, sliding
latches, threaded
connectors, or other
means provided with this
product.
•Substitution of
components may impair
suitability for Class I,
Division 2.
•If this product contains
batteries, they must only
be changed in an area
known to be
nonhazardous.
AVERTISSEMENT RISQUE D’EXPLOSION
•Couper le courant ou
s’assurer que
l’environnement est
classé non dangereux
avant de débrancher
l'équipement.
•Couper le courant ou
s'assurer que
l’environnement est
classé non dangereux
avant de débrancher les
connecteurs. Fixer tous
les connecteurs
externes reliés à cet
équipement à l'aide de
vis, loquets coulissants,
connecteurs filetés ou
autres moyens fournis
avec ce produit.
•La substitution de
composants peut rendre
cet équipement
inadapté à une
utilisation en
environnement de
Classe I, Division 2.
•S’assurer que
l’environnement est
classé non dangereux
avant de changer les
piles.

Publication 1784-UM527B-EN-P - October 2003
Table of Contents
Chapter 1
Introducing the Network Interface Cards
How the 1784-PKTx Card Operates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Chapter 2
Configuring the PKTx Hardware
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Interrupt Request Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Base Memory Address Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Setting a Base Memory Address Jumper . . . . . . . . . . . . . . . . . . . . . . 2-2
Using Multiple PKTx Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Planning Jumper Settings for Multiple Cards . . . . . . . . . . . . . . . . . . . 2-4
What to Do Next . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Chapter 3
Installing the Card and the Drivers
Accessing the PCI Bus Slots and Installing the Card . . . . . . . . . . . . . . . . . 3-1
Installing the Plug and Play Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
What to Do Next . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Chapter 4
Connecting the Network Interface Card
1784-PKTX Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
1784-PKTXD Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Connecting to DH+ Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Connecting the Card to
an Original PLC-5 Programmable Controller . . . . . . . . . . . . . . . . . . . 4-5
Connecting the Card to an Enhanced PLC-5 Processor. . . . . . . . . . . 4-7
Terminating the Last Node . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Connecting the Card Using Custom Cabling for DH+ . . . . . . . . . . 4-8
Connecting the Card via a DH-485 Network. . . . . . . . . . . . . . . . . . . . . . . 4-8
Connecting the Card to a Single SLC Processor on DH-485. . . . . . . 4-9
Terminating the Last Node . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Connecting to Remote I/O Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11

ii Table of Contents
Publication 1784-UM527B-EN-P - October 2003
Interpreting the Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
What to Do Next . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Appendix A
Specifications
Index

Publication 1784-UM527B-EN-P - October 2003
Chapter 1
Introducing the Network Interface Cards
Rockwell Automation 1784-PKTxfamily PCI cards connect PCs to PLC controllers on Data
Highway Plus (DH+) or SLC processors on DH-485 networks for easy programming and
data acquisition. I/O scanner functionality is also available in the cards so they can be used
with soft-control or embedded-control engines. And, because these cards incorporate the
Universal PCI Card Standard, they are compatible with almost any PC. If general
programming, configuration, and monitoring capabilities via an industrial or desktop PC are
required, these cards are a necessity.
Your 1784-PKTxnetwork interface card (cat. nos. 1784-PKTX and 1784-PKTXD) is a PCI
(Peripheral Component Interconnect) universal card that must be inserted into a PCI bus
slot. A universal card can be placed into a PCI bus slot that is keyed for either 3.3 Volt or 5
Volt signalling. This card may also be placed in a 64-bit slot, although it will not use the
extended 64-bit operation. Table 1.1 outlines features supported by the PKTxcards.
Table 1.1 Features supported by PKTxcards
KTxcard
catalog #
# of
channels
Active node
on these
networks
Remote I/O
scanner
capability?
1784-PKTX 1DH+ or
DH-485 yes
1784-PKTXD 2DH+ and/or
DH-485!yes
!Available only on channel 1

1-2 Introducing the Network Interface Cards
Publication 1784-UM527B-EN-P - October 2003
Compatibility
You need a PCI-compatible personal computer. Table 1.2 outlines operating systems and
drivers that support the PKTxcards.
Table 1.2 Operating Systems and drivers supporting the PKTxcards
How the 1784-PKTxCard Operates
The 1784-PKTX and -PKTXD cards:
•communicate with nodes on Data Highway Plus networks, including PLC-5®,
PLC-5/250, and SLC 5/04 processors, and SLC 5/01,
SLC 5/02, and SLC5/03 processors (only via 1785-KA5)
•communicate with SLCprocessors on DH-485 networks
•communicate to DH+ and Remote I/O via SoftLogix-5
•communicate to ControlLogix through a 1756-DHRIO module
•act as a remote I/O scanner
The 1784-PKTxperforms data transmission, management, and local network diagnostics.
The interface to the host processor is through a board-resident dual-port memory.
Rockwell Automation RSLinx interface software manages data transmission and reception
through dual-port memory.
The PCI BIOS on your computer automatically assigns the PKTxcard’s IRQ and base
memory address (one for each channel). If your card has two channels, both channels share
the same IRQ.
Windows 98 or later Other operating system
DH+ Included with RSLinx Write your own driver using
1784-DP4
DH-485 Included with RSLinx Same as DH+
Remote I/O Write your own driver using
6001-RIO - RIO Tool Kit
Write your own driver using
6001-RIO - RIO Tool Kit

Publication 1784-UM527B-EN-P - October 2003
Chapter 2
Configuring the PKTxHardware
Introduction
The 1784-PKTxcard is a PCI bus card, compliant with the PCI Bus Specification Revision
2.3. This card was developed with Plug and Play functionality, as defined in Revision 1.0A of
the Plug and Play BIOS Specification. Because of this, PKTxcards do not require the use of
switches or jumpers to configure their specific interrupt request levels (IRQ) and base
memory address values. These configurations are automatically assigned to the PKTxcard by
the PCI BIOS when the computer is powered-up. The configurations are stored in the PCI
configuration registers. These values may be retrieved by application software used to
communicate with the PKTxcard.
Interrupt Request Assignment
The PCI BIOS automatically assigns the PKTxcard an IRQ. Because of this, each time you
add or remove cards and restart your computer, the BIOS may assign a different IRQ to each
card. You should check the IRQ assignment each time you start your system. Most
application software will verify this assignment for you. If you’re using RSLinx, its Plug and
Play driver verifies the IRQ.
Base Memory Address Values
Although the assignment of the IRQ and base memory address values is automatic, and does
not require user intervention, there is one jumper on the PKTxcard that is used to restrict the
range of values that can be assigned to the base memory address by the PCI BIOS. This
jumper is called the Base Memory Address jumper, and its default position is set to 32 bit.
If you are not using Microsoft Windows 95 or later, you may have to set this jumper. See
Figure 2.1 on page 2-2.

2-2 Configuring the PKTx Hardware
Publication 1784-UM527B-EN-P - October 2003
Figure 2.1 Overview of the jumpers on the PKTxcard
Setting a Base Memory Address Jumper
The host computer and the PKTxcard exchange data via a dual-port interface. The dual-port
requires 4 Kbytes of memory. This 4 Kbyte block of memory begins at the base memory
address assigned to the card by the PCI BIOS when the computer is started.
Under MS-DOS, Windows 3.1 and Windows for Workgroups, the base memory address of
PC cards should fall within the range of 0 and 1 Megabyte of PC memory. For the newer
Windows operating systems, this restriction is no longer required, and the base memory
address should be located anywhere in the PC memory space.
The Base Memory Address jumper (JP2) forces the PCI BIOS to assign the base memory
address to one of two address ranges, as shown in the table below. You should select the
jumper position based on the operating system running on your PC.
Card ID Jumper (JP3)
Base Memory
Jumper (JP2)

Configuring the PKTx Hardware 2-3
Publication 1784-UM527B-EN-P - October 2003
When looking directly at the 1784-PKTxcard, the Base Memory Address jumper looks like:
Using Multiple PKTx Cards
It is possible to have more than one PKTxcard within your system. You can have up to four
cards functioning at the same time. There are two jumpers that can be set to establish unique
identification between the PKTxcards. The position and combination of the two jumpers
allow each card to be uniquely recognized by any application software.
The default position, card ID 0, has both jumpers in place.
32BIT
1MEG
32BIT
1MEG
This is a jumper that is not covered.
This is a jumper that has the 32bit position for
Windows 95 (or later) covered.
40022

2-4 Configuring the PKTx Hardware
Publication 1784-UM527B-EN-P - October 2003
Planning Jumper Settings for Multiple Cards
Located on each PKTxcard is a set of jumpers with markings that indicate how each jumper
can be set. These jumpers are identified as JP3. It is important to coordinate the setting of
these jumpers so that each card can be recognized by the system. Figure 2.2 and the table
below show possible combinations of jumper settings that can be used if you have a total of
four cards.
Figure 2.2 Examples of covered/open jumpers for all four card IDs
What to Do Next
Chapter 3 tells you how to install a PKTxcard into your computer.
Card ID JP3
0CID0 and CID1 covered
1CID0 open, CID1 covered
2CID0 covered, CID1 open
3CID0 and CID1 open
Key
Indicates the jumper is openIndicates the jumper is covered
JP3
card ID 1card ID 0 card ID 3
CID0
CID0
CID0
CID1
CID1
CID1
card ID 2
CID0
CID1

Publication 1784-UM527B-EN-P - October 2003
Chapter 3
Installing the Card and the Drivers
You’ve set the jumpers; now you’re ready to place the PKTxcard inside your computer and
install the plug-n-play drivers.
Accessing the PCI Bus Slots and Installing the Card
To install the PKTxcard, you must have access to the computer’s PCI bus. Install the card
according to your computer manufacturer’s instructions.
ATTENTION Before you can install the PKTxcard, you need to verify that the
appropriate jumpers have been set. Refer to chapter 2, Configuring the
PKTxHardware, for more information.
WARNING If you install or remove the communications card with power applied
to this module, an electrical arc can occur. This could cause an
explosion in hazardous location installations.
IMPORTANT If you disconnect the ac power from the computer, you lose the chassis
ground. Electrostatic damage (ESD) protection is lost.

3-2 Installing the Card and the Drivers
Publication 1784-UM527B-EN-P - October 2003
Installing the Plug and Play Drivers
Following these instructions to install your Plug and Play (PnP) drivers:
1. Upon startup, Microsoft Windows should detect the PKTX card and start the ‘New
Hardware Wizard’. Click Next.
2. Insert your RSLinx CD into your CD-ROM drive (if it auto-starts, Exit the RSLinx
installation).
3. When prompted by the New Hardware Wizard, select ‘Search for a suitable driver...’
and click Next.
4. When the ‘Locate Driver Files’ screen appears, select ‘Specify a location’ and click
Next.
5. When prompted to specify the location, browse to ‘D:\RSLinx\PnP_Drivers’
(where D: is the CD-ROM drive with your RSLinx CD).
6. Follow decision table below:
7. Click OK.
The screen should indicate the driver has been found.
8. Click Next.
You should get a message that Windows has successfully added the PKTX. If not
successful, call Rockwell Technical support at 440-646-5800 (if you have an
appropriate support contract) or submit a request at http://support.rockwellautomation.com.
9. Click Finish.
What to Do Next
Chapter 4 explains how to connect the PKTxcard to various networks and devices.
If your operating system is browse to and select file
Microsoft Windows XP or 2000 Win2K\1784-PKTX(D) pktx2000.inf
Microsoft Windows 9x Win9x\1784-PKTX(D) rsipktx.inf

Publication 1784-UM527B-EN-P - October 2003
Chapter 4
Connecting the Network Interface Card
You can connect the PKTxcard to these networks:
•DH+
•DH-485
•Remote I/O
The purpose of this chapter is to explain:
•what cables can be used to connect to the various networks
•other information needed to connect to a network
•the meanings of the status LEDs
WARNING If you connect or disconnect the communications cable with power
applied to this module or any device on the network, an electrical arc
can occur. This could cause an explosion in hazardous location
installations.

4-2 Connecting the Network Interface Card
Publication 1784-UM527B-EN-P - October 2003
1784-PKTX Connections
Remote I/O
DH+
1 Clear
2 Shield
3 Blue
1 Blue
2 Shield
3 Clear
6 Termination Resistance
5 Channel A
4 Channel B
3 Signal Ground
2 Shield/Drain
1 Earth Ground
DH-485
40024

Connecting the Network Interface Card 4-3
Publication 1784-UM527B-EN-P - October 2003
1784-PKTXD Connections
Remote I/O
DH+
1 Clear
2 Shield
3 Blue
1 Blue
2 Shield
3 Clear
Remote I/O
DH+
1 Clear
2 Shield
3 Blue
1 Blue
2 Shield
3 Clear
6 Termination Resistance
5 Channel A
4 Channel B
3 Signal Ground
2 Shield/Drain
1 Earth Ground
DH-485
40025

4-4 Connecting the Network Interface Card
Publication 1784-UM527B-EN-P - October 2003
Before You Begin
Before you make the connections, make sure you have the correct cable.
The 1784-PKTX, -PKTXD card ships with 82Ωand 150Ωresistors and with the
DH+/remote I/O and DH-485 mating connectors.
For additional cable information, see these Allen-Bradley publications:
WARNING If you connect or disconnect the communications cable with power
applied to this module or any device on the network, an electrical arc
can occur. This could cause an explosion in hazardous location
installations.
For connections to: Use this cable: And these termination
resistors:
Network Cable (build your own)
Remote I/O 1770-CD !"
Belden #9463
82Ωor 150Ω
DH+ 1770-CD !"
Belden #9463
150Ωfor 57.6K bits/sec
150Ωfor 115.2K bits/sec
82Ωfor 230.4K bits/sec
DH-485 Belden #3106A !$ not needed
Point-to-point Cable (prefabricated)
Original PLC-5 1784-CP12 not needed
SLC 5/04 processors
(direct DH+ connection)
Enhanced PLC-5
SLC 5
1756-DHRIO
1784-CP13 (DH+) not needed
SLC family processors
(direct DH-485 connection)
1784-CP14 (DH-485 not needed
!Cables used for construction of custom cables
$Mating Connector: A-B PN 941999-06 or Phoenix Order No. 1849406
"Mating Connector: A-B PN 941999-03 or Phoenix Order No. 1849396
Publication Title Publication Number
1784-CP12 Cable Packing Data 1784-2.41
1784-CP13 Cable Packing Data 1784-2.44
1784-CP14 Cable Packing Data 1784-2.45
