Huawei FusionDC1000A Technical specifications

FusionDC1000A Prefabricated All-in-One Data
Center
V100R021C00
Product Description (IT Scenario)
Issue 04
Date 2023-11-10
HUAWEI DIGITAL POWER TECHNOLOGIES CO., LTD.

Copyright © Huawei Digital Power Technologies Co., Ltd. 2023. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Digital Power Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are the property of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei
Digital Power Technologies Co., Ltd. and the customer. All or part of the products, services and features
described in this document may not be within the purchase scope or the usage scope. Unless otherwise
specied in the contract, all statements, information, and recommendations in this document are
provided "AS IS" without warranties, guarantees or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every eort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Digital Power Technologies Co., Ltd.
Address: Huawei Digital Power Antuoshan Headquarters
Futian, Shenzhen 518043
People's Republic of China
Website: https://digitalpower.huawei.com
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. i

About This Document
Purpose
This document describes the FusionDC1000A prefabricated all-in-one data center
(FusionDC1000 for short) solution in terms of its overview, typical application
scenarios, product architecture, and key technical specications, helping readers to
systematically understand the FusionDC1000.
Intended Audience
This document is intended for:
● Sales engineers
● Technical support engineers
● System engineers
Symbol Conventions
The symbols that may be found in this document are dened as follows.
Symbol Description
Indicates a hazard with a high level of risk which, if not
avoided, will result in death or serious injury.
Indicates a hazard with a medium level of risk which, if not
avoided, could result in death or serious injury.
Indicates a hazard with a low level of risk which, if not
avoided, could result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) About This Document
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. ii

Symbol Description
Supplements the important information in the main text.
NOTE is used to address information not related to personal
injury, equipment damage, and environment deterioration.
Change History
Issue Date Description
04 2023-11-10 Added lead-acid batteries and optimized
descriptions.
03 2023-07-20 This issue is the third ocial release.
Optimized the content.
02 2022-12-15 This issue is the second ocial release.
Optimized the content.
01 2021-04-20 This issue is the rst ocial release.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) About This Document
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. iii

Contents
About This Document................................................................................................................ ii
1 Overview....................................................................................................................................1
1.1 Positioning................................................................................................................................................................................. 1
1.2 Features...................................................................................................................................................................................... 1
2 Typical Application Scenarios and Typical Conguration..............................................3
2.1 Application Scenarios of the Prefabricated Data Center........................................................................................... 3
2.2 Typical Conguration............................................................................................................................................................. 4
2.3 Key Technical Specications................................................................................................................................................ 5
3 Structural system.................................................................................................................. 10
3.1 Pre-fab. Module..................................................................................................................................................................... 10
3.2 Pre-fab. Module Thermal Insulation Structure........................................................................................................... 11
3.3 Pre-fab. Module Coating.................................................................................................................................................... 11
3.4 Pre-fab. Module Doors........................................................................................................................................................ 12
3.5 Pre-fab. Module Interior Layout...................................................................................................................................... 13
3.6 Components Inside the Pre-fab. Module...................................................................................................................... 14
3.6.1 Overhead Cable Tray........................................................................................................................................................ 14
3.6.2 Suspended Ceiling............................................................................................................................................................. 15
3.6.3 IT Cabinet............................................................................................................................................................................. 15
3.6.4 Raised Floor......................................................................................................................................................................... 17
3.6.5 Aisle Sliding Door.............................................................................................................................................................. 18
3.6.6 Cabinet Base........................................................................................................................................................................19
3.7 External Ports of the Pre-fab. Module........................................................................................................................... 19
4 Power Supply and Distribution System........................................................................... 22
4.1 Overview.................................................................................................................................................................................. 22
4.2 Integrated UPS....................................................................................................................................................................... 27
4.2.1 Product Structure...............................................................................................................................................................27
4.2.2 Technical Specications................................................................................................................................................... 29
4.3 rPDU.......................................................................................................................................................................................... 32
4.4 SmartLi Cabinet Description............................................................................................................................................. 33
4.5 SmartLi Components........................................................................................................................................................... 34
4.5.1 MDU....................................................................................................................................................................................... 34
4.5.2 Monitoring Interface Unit...............................................................................................................................................35
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) Contents
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. iv

4.5.3 BCU......................................................................................................................................................................................... 37
4.5.4 Battery Module...................................................................................................................................................................39
4.5.5 Carbon Monoxide Gas Sensor....................................................................................................................................... 40
4.5.6 4G Module........................................................................................................................................................................... 42
4.6 Lead-Acid Battery Pack....................................................................................................................................................... 43
4.7 Lead-Acid Battery Cabinet................................................................................................................................................. 44
4.8 Power PDB............................................................................................................................................................................... 44
4.9 AC PDB..................................................................................................................................................................................... 45
5 Cooling System...................................................................................................................... 47
5.1 Overview.................................................................................................................................................................................. 47
5.2 NetCol5000-A025 Smart Cooling Product....................................................................................................................50
5.2.1 Product Composition........................................................................................................................................................ 50
5.2.2 Operating Environment Specications....................................................................................................................... 53
5.2.3 Technical Specications................................................................................................................................................... 55
5.3 Dehumidier........................................................................................................................................................................... 56
5.4 T/H Sensor............................................................................................................................................................................... 57
5.5 Outdoor Unit.......................................................................................................................................................................... 58
5.6 Fan............................................................................................................................................................................................. 60
5.7 Low Temperature Component..........................................................................................................................................61
6 Management System............................................................................................................63
6.1 Overview.................................................................................................................................................................................. 63
6.2 ECC800-Pro............................................................................................................................................................................. 66
6.2.1 Product Conguration......................................................................................................................................................66
6.2.2 Technical Specications................................................................................................................................................... 68
6.2.3 Main Control Module....................................................................................................................................................... 71
6.2.4 PSU......................................................................................................................................................................................... 77
6.3 UIM20A Expansion Module............................................................................................................................................... 79
6.4 Smart ETH Gateway.............................................................................................................................................................82
6.5 AC Actuator.............................................................................................................................................................................83
6.6 Access Actuator..................................................................................................................................................................... 86
6.7 IP Camera................................................................................................................................................................................ 90
6.8 WiFi Module........................................................................................................................................................................... 90
6.9 WLDS900 Water Sensor (BOM Number: 33010352)............................................................................................... 91
6.10 IC Card Reader.....................................................................................................................................................................93
6.11 Door Status Switch............................................................................................................................................................ 94
6.12 Emergency Door Release Button.................................................................................................................................. 95
6.13 Exit Button............................................................................................................................................................................ 96
6.14 Magnetic Lock..................................................................................................................................................................... 96
6.15 Non-Location-Type Water Sensor.................................................................................................................................97
6.16 PAD.......................................................................................................................................................................................... 98
7 Fire Extinguishing System................................................................................................... 99
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) Contents
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. v

7.1 Extinguishant Control Panel (CE)................................................................................................................................. 103
7.2 Extinguishant Control Panel........................................................................................................................................... 104
7.3 Peruorohexanone Automatic Fire Extinguisher..................................................................................................... 104
7.4 Smoke Sensor...................................................................................................................................................................... 105
7.5 Heat Detector...................................................................................................................................................................... 106
7.6 (Optional) ASD....................................................................................................................................................................107
7.7 Emergency Light and Escape Sign................................................................................................................................ 108
7.8 Fire Alarm Bell..................................................................................................................................................................... 109
7.9 Extinguishant Abort Button............................................................................................................................................ 110
7.10 Fire Alarm Horn Strobe.................................................................................................................................................. 110
7.11 Warning Sign..................................................................................................................................................................... 111
8 Surge Protection and Grounding.....................................................................................113
8.1 Surge Protection................................................................................................................................................................. 113
8.2 Grounding............................................................................................................................................................................. 113
9 Integrated Cabling.............................................................................................................. 115
A Acronyms and Abbreviations........................................................................................... 117
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) Contents
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. vi

1 Overview
1.1 Positioning
Huawei has developed the FusionDC1000, a green data center solution, based on
a thorough study on the reform and impact of the cloud computing to traditional
data centers and the practical experience of dozens of global cloud computing
centers. The solution features a exible, hybrid, and modular design to help
customers construct green infrastructure adapting to cloud computing.
The FusionDC1000, foundation for cloud computing in enterprise data centers,
integrates power distribution, monitoring, cooling, racks, cabling, and re
extinguishing. It delivers good waterproof and quakeproof performances. The
FusionDC1000 helps enterprise telecom operators and Internet operators to
rapidly deploy data centers and has unique advantages in the elds of disaster
relief, oil exploitation, survey, and enterprise data for its availability in outdoor
environments.
The FusionDC1000, located at the bottom layer of a data center, provides basic
physical construction for all services in the data center.
1.2 Features
The FusionDC1000 is a small-capacity prefabricated all-in-one data center that
integrates the pre-fab. module mechanical structure, power supply and
distribution system, cooling system, management system, re extinguishing
system, integrated cabling system, and server cabinets. It features high security
and reliability, rapid deployment, low cost, high eciency, and intelligent
management.
High Security and Reliability
● Grounding: The pre-fab. module is properly grounded and resists
electromagnetic interference. Its electromagnetic compatibility (EMC) meets
Class A requirements specied in the CISPR22/EN55022 standard.
● Dustproof and waterproof: The data center uses the pre-fab. module
complying with the International Organization for Standardization (ISO) 668
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) 1 Overview
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 1

standard. The pre-fab. module uses mature welding technologies in the
industry to implement all-round airtight, dustproof, and waterproof
protection.
● Antiseismic: The pre-fab. module meets GR-63-CORE Zone 3 antiseismic
requirements.
● Adaptive to environment: The design of two porches prevents sand from
entering the equipment compartment when doors are open during
maintenance, ensuring that the pre-fab. module applies to various harsh
environments.
● Fireproof: The re extinguishing system is reliable, clean, insulating, and
environment-friendly, and can put out a re eciently and safely without
damaging equipment, thereby ensuring high equipment availability. The re
extinguishing system uses peruorohexanone as the extinguishing agent and
complies with the EU's CE certication.
Rapid Deployment
● Streamlined manufacturing, professional division of labor, and good work
conditions ensure that modules and products of the FusionDC1000 are
produced eciently with strict quality control.
● Infrastructures such as cooling equipment, power supply equipment, and
racks are factory-installed. You only need to provide network cables, power
cables, and water pipes onsite for commissioning.
● System commissioning is completed in factories, and therefore onsite
deployment and equipment room commissioning take less than one week.
Intelligent Management
● Manages the infrastructure of the data center in a central manner.
● Supports O&M using a mobile app and remote unattended operations. Full
WiFi coverage is implemented inside the pre-fab. module using a WiFi
module. WiFi coverage outside the pre-fab. module is implemented using a
customer router gateway.
● Monitors equipment eectively in real time.
● Monitors environments in real time to identify potential risks.
● Provides various methods of collecting and analyzing power consumption
data to realize precision energy eciency analysis. Such data is fundamental
to improving the power usage eectiveness (PUE). You can customize the
data collection and analysis methods.
● Provides a robust security mechanism to protect equipment and ensures a
proper environment.
● Provides standard Simple Network Management Protocol (SNMP) ports to
communicate with third-party network management systems (NMSs).
Intelligent Features
● Local PAD 3D NMS + app view, power supply/cooling 2D link visibility inside
the pre-fab. module.
● Early warning, rack resource automation, management automation, and
cooling/power linkage to eliminate hot spots.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) 1 Overview
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 2

2 Typical Application Scenarios and
Typical Conguration
2.1 Application Scenarios of the Prefabricated Data
Center
The FusionDC1000 is a prefabricated data center, and integrates the UPS, smart
cooling product, and cabinets. It can be put into operation immediately after
connecting to the tap water, power supply, and network.
The FusionDC1000 is focused on fast deployment of outdoor small IT equipment
rooms for carriers and enterprises. It can integrate standard and nonstandard
mainstream IT equipment, supports the 1.2 m cabinet layout.
Table 2-1 Pre-fab. module application scenarios and features
IT Equipment
Room
Energy
Industry
Government Large
Enterprise
Others
● Equipment
room
constructio
n and
modernizat
ion
● Distributed
and mobile
single-
module
deploymen
t
● Distributed
single-
module
deploymen
t
● Areas such
as
wilderness,
mining
areas, and
deserts
● Distributed
single-
module
deploymen
t
● Diverse
environme
nts such as
industrial
parks,
campuses,
and urban
areas
● Primarily
for private
use
● Rapid
deploymen
t
● High
reliability
class
● Distributed
single-
module
deploymen
t
● Suburban
areas
without
equipment
rooms
The FusionDC1000 can be deployed as a small integrated data center (IDC) for
enterprises in diverse environments such as the seaside, industrial parks,
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario)
2 Typical Application Scenarios and Typical
Conguration
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 3

campuses, urban areas, and suburban areas to meet specic application
requirements such as business blowout and capacity expansion.
The FusionDC1000 is the rst choice when a data center needs to be quickly
constructed and deployed due to urgent service requirements.
2.2 Typical Conguration
Table 2-2 Typical conguration
Type System Composition
Cabinet
system
● N+X scenario:
Four 42 U IT cabinets (H x W x D): 2000 mm x 600 mm x 1200
mm
Four 42 U IT cabinets (H x W x D): 2000 mm x 600 mm x 1100
mm
● 2N scenario:
Four 42 U IT cabinets (H x W x D): 2000 mm x 600 mm x 1200
mm
Two 42 U IT cabinets (H x W x D): 2000 mm x 600 mm x 1100
mm
Power
supply
and
distributi
on
system
Integrated UPS, rPDU, power PDB, and SmartLi
Cooling
system
NetCol5000-A025 smart cooling product, remote T/H sensor
Fire
extinguis
hing
system
● CE re extinguishing system: extinguishant control panel, smoke
detector, heat detector, re alarm bell, horn strobe, external horn
strobe, extinguishant abort button, warning sign, electrical
actuator, pneumatic switch, re nozzle, re extinguisher cylinder,
ASD (optional), and emergency light indicator
● Standard (CCC) re extinguishing system: extinguishant control
panel, smoke detector, heat detector, re alarm bell, horn strobe,
emergency light, external horn strobe, extinguishant abort button,
warning sign, electrical actuator, pneumatic switch, re nozzle,
re extinguisher cylinder, ASD (optional), and emergency light
indicator
Monitori
ng
system
ECC800-Pro, smart ETH gateway, smart module actuator, water
sensor, PAD, camera, IC card reader, door status sensor, and magnetic
lock
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario)
2 Typical Application Scenarios and Typical
Conguration
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 4

2.3 Key Technical Specications
Table 2-3 Key technical specications
Conguration N+X-
Norma
l
Temp-
CE
N+X-
Low
Temp-
CE
2N-
Norma
l
Temp-
CE
2N-
Low
Temp-
CE
N+X-
Norma
l
Temp-
CCC
N+X
Low
Temp-
CCC
2N-
Norma
l
Temp-
CCC
2N-
Low
Temp-
CCC
General
specic
ations
Applicabl
e
temperat
ure range
–20°C
to
+55°C
–40°C
to
+45°C
–20°C
to
+55°C
–40°C
to
+45°C
–20°C
to
+55°C
–40°C
to
+45°C
–20°C
to
+55°C
–40°C
to
+45°C
Pre-fab.
module
dimensio
ns
(H x W x
D)
2896 mm x 2438 mm x 12,192 mm
Power
supply
and
distributi
on
architect
ure
N+X 2N N+X 2N
Total
power
54 kW. Derating is required when the temperature is greater than or equal
to 45°C.
Number
of
cabinets
8 6 8 6
Cabinet
specicati
ons (H x
W x D)
4 PCS: 2000 mm
x 600 mm x
1100 mm
4 PCS: 2000 mm
x 600 mm x
1200 mm
2 PCS: 2000 mm
x 600 mm x
1100 mm
4 PCS: 2000 mm
x 600 mm x
1200 mm
4 PCS: 2000 mm
x 600 mm x
1100 mm
4 PCS: 2000 mm
x 600 mm x
1200 mm
2 PCS: 2000 mm
x 600 mm x
1100 mm
4 PCS: 2000 mm
x 600 mm x
1200 mm
NOTE
● 1200 mm deep cabinet: A device with a depth of less than or equal to 750 mm can
be installed. You can move the mounting bar on the front door to install a device
with a depth of 850 mm.
● 1100 mm deep cabinet: A device with a depth of less than or equal to 750 mm can
be installed.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario)
2 Typical Application Scenarios and Typical
Conguration
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 5

Conguration N+X-
Norma
l
Temp-
CE
N+X-
Low
Temp-
CE
2N-
Norma
l
Temp-
CE
2N-
Low
Temp-
CE
N+X-
Norma
l
Temp-
CCC
N+X
Low
Temp-
CCC
2N-
Norma
l
Temp-
CCC
2N-
Low
Temp-
CCC
Backup
time
(lead-
acid
battery)
7 minutes
Backup
time
(lithium
battery)
25 minutes
Power
density
Total power ≤ 54
kW
6 kW/R: 6 PCS
9 kW/R: 2 PCS
Total power ≤ 54
kW
9 kW/R: 6 PCS
Total power ≤ 54
kW
6 kW/R: 6 PCS
9 kW/R: 2 PCS
Total power ≤ 54
kW
9 kW/R: 6 PCS
Environm
ent
corrosion
requirem
ents
Class A, B, or C environment. Class C environments are more than 500 m
away from strong-corrosion environments (seas, garbage dump areas, and
heavy pollution sources, such as a chemical factory).
NOTICE
Class C environments are not supported at a temperature ranging from –40°C to –
20°C.
Quakepro
of level
Complies with GR-63-CORE Zone 3.
Salt spray
corrosion
resistance
The pre-fab. module surface is sprayed with special coating and passes the
1440-hour salt spray test by UL.
Storage
temperat
ure range
–40°C to +70°C [not applicable to batteries (0°C to 40°C) and PADs (–20°C
to +45°C)
Storage
humidity
range
5%–95% RH
Structu
ral
system
Weight Preinstallation weight before delivery: ≤ 14 T; full conguration with
equipment: ≤ 20 T
Aisle
width
Long aisle: 640 mm; cold aisle: 1150 mm; hot aisle: ≥ 510 mm
Cabinet
type
The battery cabinet can slide 200 mm in both directions. Other cabinets are
xed.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario)
2 Typical Application Scenarios and Typical
Conguration
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 6

Conguration N+X-
Norma
l
Temp-
CE
N+X-
Low
Temp-
CE
2N-
Norma
l
Temp-
CE
2N-
Low
Temp-
CE
N+X-
Norma
l
Temp-
CCC
N+X
Low
Temp-
CCC
2N-
Norma
l
Temp-
CCC
2N-
Low
Temp-
CCC
Power
supply
and
distribu
tion
system
Power
system
380 V/400 V/415 V, 50/60 Hz; three-phase four-wire + PE
Input
voltage
range
380/400 V (tolerance: ±15%), 415 V (tolerance: +10%)
Number
of inputs
Two inputs
Input
current
250 A
Model
and
number
of UPSs
UPS5000-E, 1
PCS
UPS5000-E, 2
PCS (1+1
system)
UPS5000-E, 1
PCS
UPS5000-E, 2
PCS (1+1
system)
Power
capacity
≤ 60 kVA
(module 2+1
redundancy)
≤ 60 kVA
(module 2+0
redundancy)
≤ 60 kVA
(module 2+1
redundancy)
≤ 60 kVA
(module 2+0
redundancy)
Total
input
surge
protectio
n
Class B, 8/20 µs, In = 30 kA, Imax = 60 kA
Battery
specicati
ons
SmartLi lithium
battery cabinet
(half-capacity
cabinet 76 Ah,
six battery
modules in one
string) x 1
SmartLi lithium
battery cabinet
(half-capacity
cabinet 760 Ah,
six battery
modules in one
string) x 2
SmartLi lithium
battery cabinet
(half-capacity
cabinet 76 Ah,
six battery
modules in one
string) x 1
SmartLi lithium
battery cabinet
(half-capacity
cabinet 76 Ah,
six battery
modules in one
string) x 2
Lead-acid
battery pack (12
V/9 Ah) x 8
Lead-acid
battery pack (12
V/9 Ah) x 16
Lead-acid
battery pack (12
V/9 Ah) x 8
Lead-acid
battery pack (12
V/9 Ah) x 16
rPDU
type
IEC standard CCC standard
Cooling
system
Cooling
capacity
25 kW @ 37°C, 20% RH/35°C
Redunda
nt
congura
tion
3+1 redundancy
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario)
2 Typical Application Scenarios and Typical
Conguration
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 7

Conguration N+X-
Norma
l
Temp-
CE
N+X-
Low
Temp-
CE
2N-
Norma
l
Temp-
CE
2N-
Low
Temp-
CE
N+X-
Norma
l
Temp-
CCC
N+X
Low
Temp-
CCC
2N-
Norma
l
Temp-
CCC
2N-
Low
Temp-
CCC
Device
dimensio
ns (H x
W x D)
2000 mm x 300 mm x 1100 mm
Compress
or
DC variable-frequency
Refrigera
nt
R410A
Temperat
ure
control
range
18–27°C
Humidity
control
range
20%–80% RH
Thermal
insulation
performa
nce of
the pre-
fab.
module
Overall heat transfer coecient ≤ 0.36 W/(m2 x K)
Fire
extingu
ishing
system
Automati
c gas re
extinguis
hing
system
CE edition CCC edition
Extinguis
hant
FK-5-1-12 in standard conguration
Fireproof
performa
nce
The protection structure uses class A re-resistant rock wool material.
The 100 mm thick rock wool panel can withstand re for 60 minutes.
Monito
ring
system
Pre-fab.
module
access
control
Default IC card door status sensor
Aisle
access
control
Not supported
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario)
2 Typical Application Scenarios and Typical
Conguration
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 8

Conguration N+X-
Norma
l
Temp-
CE
N+X-
Low
Temp-
CE
2N-
Norma
l
Temp-
CE
2N-
Low
Temp-
CE
N+X-
Norma
l
Temp-
CCC
N+X
Low
Temp-
CCC
2N-
Norma
l
Temp-
CCC
2N-
Low
Temp-
CCC
Video
surveillan
ce
Huawei high-denition IP camera
Video
storage
SD card (7-day storage), optional IVS (longer storage and advanced
management as required)
(Optional
) Mobile
O&M
Mobile O&M using mobile phones and PADs
E-mail
(optional
)
An email server can be congured.
NO TICE
● Do not leave the prefabricated data center power o for a long time. If the
data center will be idle for a long time, power the lithium batteries on and
keep them operational for at least two hours every six months. Power the lead-
acid battery cabinets on and keep them operational for at least three hours
every three months.
● The battery storage temperature must be in the range from 0°C to 40°C.
● Batteries can be stored without power-on for a maximum of 90 days. If the
storage period exceeds 90 days, recharge the batteries promptly.
● The PAD storage temperature ranges from –20°C to +45°C.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario)
2 Typical Application Scenarios and Typical
Conguration
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 9

3 Structural system
3.1 Pre-fab. Module
Figure 3-1 Appearance 1
(1) End door (for maintaining outdoor units) (2) Lock rod
(3) Ventilation window for the outdoor unit
compartment
(4) Pre-fab. module feeder windows
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) 3 Structural system
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 10

Figure 3-2 Appearance 2
(1) External horn strobe (2) Card reader (3) End door (main entrance)
(4) Ventilation window (5) Water re extinguishing
pipe
(6) Feeder window
(7) Emergency door (8) External EPO button (9) Ground point
(10) Fire control box
3.2 Pre-fab. Module Thermal Insulation Structure
The pre-fab. module is furnished with a thermal insulation layer composed of steel
plates, bulk rock wool, and rock wool panels.
The pre-fab. module uses the rock wool sandwich panel structure for thermal
insulation. The protection structure uses the 100 mm thick re-retardant level A1
rock wool material, which complies with the GB 8624-2012 design standard and
RoHS environmental protection directive, and meets the requirements for thermal
insulation and re resistance.
3.3 Pre-fab. Module Coating
The current standard pre-fab. module coating solution passes the 1440-hour salt
spray test. According to the ISO12944 standard, the pre-fab. module provides the
VH protection level in C3 and C4 environments.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) 3 Structural system
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 11

3.4 Pre-fab. Module Doors
Figure 3-3 Fireproof door
Table 3-1 Fireproof door technical specications
Fireproof Door End Door (Main
Entrance)
Device Installation
Door/Emergency Door
Fire resistance time 90 min
Width 1100 mm
Net height 2420 mm
IP rating IP65
Door opening angle ≥ 120°, congured with a door closer
Bearing capacity When the door is open, the door, door frame, and
mechanical parts can withstand the door weight and
will not deform permanently within 48 hours with a
static load of 15 kg at any part.
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) 3 Structural system
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 12

Fireproof Door End Door (Main
Entrance)
Device Installation
Door/Emergency Door
Waterproof structure The reproof door uses rubber strips with a
framework and composite adhesive to ensure the
waterproof performance
Door opening mode The door opens in and
out the pre-fab. module.
The door opens in the
pre-fab. module.
3.5 Pre-fab. Module Interior Layout
N+X Scenario
Figure 3-4 Internal layout
(1) Smart cooling product
outdoor unit compartment
(2) IT cabinet (3) Smart cooling product
indoor unit
(4) Cold aisle (5) Hot aisle (6) Integrated UPS
(7) Battery cabinet (8) Entrance room
2N Scenario
Figure 3-5 Internal layout
(1) Smart cooling product
outdoor unit compartment
(2) IT cabinet (3) Smart cooling product
indoor unit
(4) Cold aisle (5) Integrated UPS (6) Hot aisle
(7) Battery cabinet (8) Entrance room
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) 3 Structural system
Issue 04 (2023-11-10) Copyright © Huawei Digital Power Technologies Co., Ltd. 13
