CHOICE & FLEXIBILITY
Allied Telesyn’s AT-2700 series of PCI Fast Ethernet
adapters include dedicated copper and fiber versions, as
well as a combination copper/fiber card for mixed cabling
environments.
• AT-2700FX - for fiber only networks requiring
a high-performance Fast Ethernet card.
• AT-2700TX - for copper only networks.
• AT-2700FTX - for environments where 100Mbps
fiber co-exists with 10/100Mbps copper cabling.
This is a common occurrence in networks that
deploy fiber to increase certain segment lengths or
to protect data integrity in high emissions areas such
as manufacturing.By having both 110Mbps fiber and
10/100Mbps copper connectors on a single card,
network administrators need only open a PC case
once and install theAT-2700FTX card.The PC may
then be deployed and re-deployed quickly and cost-
effectively,regardless of the cabling connection.
STANDARD & LOW-PROFILE FORMATS
The AT-2700FX and AT-2700FTX adapters are available
in both traditional and new low-profile PCI formats. The
new low-profile format uses a smaller 2.5" access slot,
rather than the traditional 4.2" slot. Low-profile designs
are being adopted by all the major PC manufacturers in
order to offer smaller desktop systems with expansion
capabilities equivalent to, or better than, previous-
generation systems.
PERFORMANCE
Allied Telesyn PCI bus adapter cards are designed to get
the maximum performance from your PC. By off-loading
almost all of the Fast Ethernet networking functions to
the adapter card, the CPU in a computer is free to run
applications faster.The card also operates in both full and
half-duplex modes, allowing the user to double the per-
formance of the network.
STANDARDS BASED
The AT-2700 series of Fast Ethernet network adapter
cards support Microsoft's latest standards, including
ACPI, OnNow power management and DMI network
management functions. AT-Setup, Allied Telesyn’s user-
friendly installation utility, simplifies installation under
Windows 98, ME, 2000 and XP.
DRIVERS & SUPPORT
Users of Allied Telesyn adapters can find drivers, firmware
updates, other software and documentation at Allied
Telesyn’s web site free of charge, 24 hours a day. Allied
Telesyn’sonlineknowledgebasealsoprovidesaninteractive
tool for identifying solutions to customer’s technical issues.
ABOUT ALLIEDTELESYN
Allied Telesyn leads the world in network technologies
for the access edge. Since the company's inception in
1987, Allied Telesyn has been developing IP-based net-
work products for use in video,voice and data networks
at the metro edge,in education,government agencies and
across the enterprise.AlliedTelesyn's access,aggregation
and core transport technologies range from simple
Ethernet adapters, hubs and media converters to robust
multi-layer Gigabit Ethernet switches and routers, wire-
less systems, DTM and WDM transport solutions for
delivering real-time voice, video and data.AlliedTelesyn's
comprehensive support and professional service pro-
grams are suited to meet the growing demands of today's
switched broadband infrastructures.
SERVICE & SUPPORT
AlliedTelesyn provides value-added support services for
its customers under its Net.CoverSM programs.For more
information on Net.CoverSM support programs available
in your area, contact your Allied Telesyn sales represen-
tative or visit our website. www.alliedtelesyn.com
AT-2700 Series, Fast Ethernet PCI Adapter Cards
KEY FEATURES
Advanced diagnostics
Advanced installation utility
PXE remote
booting available
Traffic and
troubleshooting LEDs
Support for all popular
Operating systems
FaultTolerant driver support
ACPI/Wake On Lan
(WOL) support
Copper and fiber ports
for flexibility (AT2700FTX only)
User guide
ADAPTERS
AT-2700TX,10/100Mbps Fast Ethernet UTP PCI adapter card
AT-2700FX,100Mbps Fast Ethernet fiber PCI adapter card (Low profile card option available)
AT-2700FTX,Fiber Fast Ethernet + UTP Fast Ethernet adapter card (Low profile card option available)

STATUS INDICATORS
UTP Ports:
Link Solid on indicates valid link to hub or switch
Activity Flashing indicates network activity
Speed Solid on indicates 100Mbps operation
Duplex Solid on indicates full duplex operation
PC BUS INTERFACE
Bus Interface PCI Bus 2.1 Compliant
Bus Width 32 bit
Data Transfer mode PCI 2.1 Bus Mastering
Network Mng. Interface DMI 2.0 Support
Power Mng. Interface ACPI
UTP INTERFACE
Connector Shielded RJ-45, MDI
100MBPS FIBER INTERFACE
Connectors ST, SC, MT-RJ or VF-45
Fiber type 62.5/125µM multi-mode fiber
Ouput Power Min -19dB, Typical -16.8dB, Max -14dB
DRIVER SUPPORT
16 bit ODI Netware workstation
32 bit ODI Netware server
NDIS 2.0.1 MSDOS client
NDIS 3.0 miniport Win95 retail
NDIS 4.0 NT 4.0,Win95 OSR2
NDIS 4.0 Fault Tolerance
NDIS 5.0 Win98,Win2000,WinME,WinXP
POWER CHARACTERISTICS
5vDC at 5W (typical)
ENVIRONMENTAL SPECIFICATIONS
Operating Temp. 0°C to 50°C
Relative Humidity 5% to 80% noncondensing
PHYSICAL CHARACTERISTICS
Dimensions 10.7cm x 15.3cm
(4.2” x 6.4”)
half size form factor
Weight 120g (4.2oz)
AT-2700 series low profile cards:
Dimensions 6.5cm x 14.3cm
STANDARDS COMPLIANCE
IEEE 802.3u 10T & 100TX
IEEE 802.3u 100FX
ELECTRICAL/MECHANICAL APPROVALS
FCC class B
VDE class B
CE
USA Headquarters: 19800 North Creek Pkwy, Suite 200, Bothell,WA 98011, USA Tel: [phone] Fax: [phone]
European Headquarters: Via Motta 24, 6830 Chiasso, Switzerland (Corporate) Tel: [phone] Fax: [phone]
(European Sales) Tel: [phone] Fax: [phone]
www.alliedtelesyn.com
© 2003 AlliedTelesyn, Inc. All rights reserved.Information in this document is subject to change without notice.
All company names,logos,and product designs that are trademarks or registered trademarks are the property of their respective owners.
617-00349-00 Rev. D
ORDERING INFORMATION
AT-2700TX
10/100Mbps Autosensing UTP Adapter Card
AT-2700FX/AA
Adapter card with one 100FX connection
AT-2700FX/LP/AA
Low profile adapter card
with one 100FX connection
AT-2700FTX/AA
Adapter card with one 100FX
and one 10/100TX connection
AT-2700FTX/LP/AA
Low profile adapter card with one 100FX
and one 10/100TX connection
Where AA =
ST, SC, MT-RJ or VF-45
20 packs are available for additional savings
AT-2700 Series, Fast Ethernet PCI Adapter Cards
