Allied Vision MANTA User manual

GigE VISION CAMERAS
Manta
Technical Manual
V7.7.0
Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2016-Dec-16

Manta at a glance
2Manta Technical Manual V7.7.0
Manta at a glance
Manta cameras have a Gigabit Ethernet (GigE) interface and work with Gigabit
Ethernet hardware and cable lengths up to 100 m. Manta cameras are GigE Vision®
V1.2 and GenICam Standard Feature Naming Convention (SFNC) V1.2.1 compliant.
Applied standards
GigE Vision® The GigE Vision standard is an interface standard for digital machine vision
cameras administered by the Automated Imaging Association (AIA) that is widely
supported in the machine vision industry. In contrast, Gigabit Ethernet is the
network GigE Vision is built upon.
GenICam™ GenICam is a machine vision standard hosted by the European Machine Vision
Association (EMVA). The aim of GenICam is to provide a generic configuration
interface for cameras and devices independent of the used interface technology
(i.e., GigE Vision, USB3 Vision, DCAM IEEE 1394, Camera Link). This approach
enables proper interoperability between GenICam compliant hardware and
software solutions without the need for customization.
The GenICam standard consists of multiple modules that specify tasks to be solved.
Allied Vision cameras and software make use of these modules, like the Standard
Feature Naming Convention (SFNC) that standardizes feature names and types via
an XML file or the transport layer interface (GenTL) that is used to grab images.
What else do you need?
Content URL
Camera data sheets
GigE Installation Manual
GigE Features Reference
Modular Concept
3D CAD STEP files
Software and firmware downloads
https://www.alliedvision.com/en/support/
technical-documentation/manta-
documentation.html
Technical papers and knowledge base https://www.alliedvision.com/en/support/
technical-papers-knowledge-base.html
Read this manual carefully
Learn how to protect your camera from damage and fully understand its functions.

Contact us
3Manta Technical Manual V7.7.0
Contact us
Connect with Allied Vision by function
https://www.alliedvision.com/en/meta-header/contact.html
Find an Allied Vision office or distribution partner
https://www.alliedvision.com/en/about-us/where-we-are.html
Email
[email protected]
[e-mail]
Sales offices
Europe, Middle East, and Africa: [phone]
UK, Ireland, Nordic countries: [phone]
France: [phone]
North and South America: +1 (877) USA-1394
Asia-Pacific: [phone]
China: [phone]
Headquarters
Allied Vision Technologies GmbH
Taschenweg 2a, 07646 Stadtroda, Germany
Tel: [phone]
Fax: [phone]
President/CEO: Frank Grube
Registration Office: AG Jena HRB 208962
Tax ID: DE 184383113

Contents
4Manta Technical Manual V7.7.0
Contents
Manta at a glance 2
Applied standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What else do you need? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Contact us 3
Document history and conventions 9
Document history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Manual conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Styles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Safety and regulations 18
General safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Regulations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Board level models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
European Economic Area requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
FCC – Class B Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Industry Canada Equipment Standard for Digital Equipment (ICES) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Life support applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Other legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installation and hardware 23
Configuring the host computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installing the Ethernet adapter driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Optional: Modifying Ethernet adapter IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Ethernet adapter driver settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Enabling jumbo packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Connecting your camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Downloading camera drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Powering up the camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connecting to host application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Specifications 28
Notes on specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Frame memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Resolution and ROI frame rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Sensor tap mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Absolute quantum efficiency plots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Spectral response plots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Manta G-031B, G-031C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Contents
5Manta Technical Manual V7.7.0
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Manta G-032B, G-032C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Manta G-033B, G-033C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Manta G-046B, G-046C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Manta G-125B, G-125C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Manta G-145B, G-145C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
ROI frame rate for 30 fps variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Manta G-145B NIR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Increase of relative response. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Manta G-146B, G-146C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Manta G-201B, G-201C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
ROI frame rate for 30 fps variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Manta G-223B, G-223B NIR, G-223C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Manta G-235B, G-235C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Manta G-282B, G-282C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Manta G-283B, G-283C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Contents
6Manta Technical Manual V7.7.0
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Manta G-319B, G-319C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Manta G-419B, G-419B NIR, G-419C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Manta G-504B, G-504C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Manta G-505B, G-505C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Manta G-507B, G-507C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Manta G-609B, G-609C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Manta G-895B, G-895C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Manta G-917B, G-917C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Manta G-1236B, G-1236C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Absolute QE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Spectral response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
ROI frame rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Camera feature comparison. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Mechanical dimensions 125
Tripod adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Camera dimensions (type A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Manta standard housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Manta angled-head housings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Manta board level variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
C-Mount cross section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
CS-Mount cross section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Camera dimensions (type B) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Contents
7Manta Technical Manual V7.7.0
Manta standard housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Manta angled-head housings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Manta board level variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
C-Mount cross section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
CS-Mount cross section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Sensor position accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Filter and lenses 156
Camera lenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Manta G-031B, G-031C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Manta G-032B, G-032C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Manta G-033B, G-033C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Manta G-046B, G-046C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Manta G-125B, G-125C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Manta G-145B, G-145C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Manta G-145B NIR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Manta G-146B, G-146C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Manta G-201B, G-201C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Manta G-223B, G-223B NIR, G-223C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Manta G-235B, G-235C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Manta G-282B, G-282C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Manta G-283B, G-283C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Manta G-319B, G-319C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Manta G-419B, G-419B NIR, G-419C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Manta G-504B, G-504C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Manta G-505B, G-505C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Manta G-507B, G-507C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Manta G-609B, G-609C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Manta G-895B, G-895C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Manta G-917B, G-917C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Manta G-1236B, G-1236C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
IR cut filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Camera interfaces 168
Back panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Gigabit Ethernet interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Camera I/O connector pin assignment (including PoE). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Input block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Output block diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Video iris output description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Control signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Input block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Input/output pin control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Output signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Trigger timing concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Trigger definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Image data flow 182

Contents
8Manta Technical Manual V7.7.0
Manta models with CCD sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Manta models with CMOS sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Color interpolation (Bayer demosaicing). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Cleaning optical components 189
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Keep optical components clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Identifying impurities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Locating impurities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Materials for cleaning optical components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Cleaning Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Firmware update 196
Appendix 201
Mechanical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Back panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Camera I/O connector pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Index 210

Manta Technical Manual V7.7.0 9
Document history and conventions
This chapter includes:
• Document history
• Layout styles and symbols used in this manual

Document history and conventions
10Manta Technical Manual V7.7.0
Document history
Version Date Remarks
V2.0.3 2010-Apr-15 New manual release status
V3.0.0 2010-Jun-09 Added new models: Manta G-046B, G-046C, G-145B, G-145B-30fps, G-145C,
G-145C-30fps, G-146B, G-146C, G-201B, G-201B-30fps, G-201C, G-201C-30fps
Added spectral sensitivity note
Added image memory size table
Added ROI frame rate data for the following models: Manta G-046B, G-046C,
G-145B, G-145C, G-146B, G-146C, G-201B, G-201C
With the new firmware version 01.40, due to a bug all Manta models have only
12-bit in the data path (even if the ADC delivers 14-bit).
Due to a repaired bug in FPGA and microcontroller, the StreamHoldCapacity
changed: Manta G-032B, G-032C from 49 frames to 99 frames, Manta G-125B,
G-125C from 12 frames to 25 frames.
RGBA24 and BGRA24 are not supported
Manta board level cameras have now a cooling plate.
V4.0.0 2010-Oct-25 Added note that description of status LEDs can be found in Manta Hardware
Installation Guide.
Changed file format from Adobe FrameMaker FM7 to FM9
Added Manta G-033B, G-033C (Sony ICX414) and G-504B, G-504C (Sony ICX655)
V4.0.1 2011-Jan-05 Changed tripod drawing: added dimensions of three big holes (M6 and UNC 1/4-
20).
In specifications tables color pixel formats: inserted Mono8. Added note, that
Raw8, Raw16 displayed in some viewers means the same as Bayer8, Bayer16.
Changed GigE Vision V1.0 to V1.2 in all specification tables.
Table 1: Document history

Document history and conventions
11Manta Technical Manual V7.7.0
V4.1.0 2011-Jun-24 Added PoE information including:
• Power requirements, power consumption and regulations for PoE models.
• Note about PoE capable cameras
• PoE cameras < 220 g (without lens)
Corrected frame rate formulas for Manta G-033, G-504:
• C-Mount/CS-Mount not adjustable, for modifications contact Customer Care
and send camera to Allied Vision Technologies
Manta board level:
• Manta board level: deleted (PWR output on demand) at Pin2
Removed the Firmware update chapter (see Knowledge Base at Allied Vision
Technologies Website: search for GigE Firmware Update Application Note)
Revised data path block diagram.
Added 30 fps variant: Manta G-145B-30fps, G-145C-30fps and G-201B-30fps,
G-201C-30fps
Added Mono12Packed for monochrome cameras and Bayer12Packed for color
cameras.
Added the following camera controls: Chunk Data, EventControls,
StreamFramerateConstrain, FrameStartTriggerOverlap,
PayloadSize, NonImagePayloadSize, SyncInGlitchFilter, AutoIris,
Gamma correction, LUT
Manta G-145-30fps and G-201-30fps (non PoE)
• ... have same I/O pin assignment (input circuits and voltage range), power
LED and upside down PoE plug as PoE models
Manta G-145B, G-145C-30fps and G-201B, G-201C-30fps non-PoE behave like PoE
cameras.
V5.0.0 2012-May-15 Error found in Document history V3.0.0 by Validation Team:
• RGBA24 and BGRA24 should be named RGBA32 and BGRA32
• Added RGBA32 and BGRA32 color formats (except Manta G-201B/C-30fps)
• Added frame rate diagrams
Initial commercial release: Manta G-145B NIR
New Sony ICX618 sensors for Manta G-031B, G-031C
Added focal length 4.0 mm in the focal length vs field of view table for the Manta
G-125.
Initial commercial release: Manta G-031B, G-031C
Same main board for all Manta models:
From serial number 503323258 on all Manta models including PoE and board
level versions contain the same main board.
Revised non-PoE drawings and new board level PoE drawings
Revised PoE descriptions regarding IEEE 802.3af and IEEE 802.3at:
• See note in Gigabit Ethernet port (Manta PoE models can source power from
IEEE 802.3af (100 MBit/s and 1000 MBit/s) and from IEEE 802.3at compliant
power sourcing equipment (PSE) such as switches injectors or NICs.)
Version Date Remarks
Table 1: Document history (continued)

Document history and conventions
12Manta Technical Manual V7.7.0
V5.0.0
[continued]
2012-May-15
[continued]
New CAD drawings with Pin3 = Video Type Auto Iris Out
Frame memory
• Manta G-032B, G-032C: changed from 49 to 99 frames
• Manta G-033B, G-033C: changed from 88 to 99 frames
• Manta G-046B, G-046C: changed from 35 to 70 frames
• Manta G-125B, G-125C: changed from 12 to 25 frames
• Manta G-145B, G-145C: changed from 10 to 22 frames
• Manta G-145B-30fps, G-145C-30fps: changed from 10 to 22 frames
• Manta G-146B, G-146C: changed from 10 to 22 frames
• Manta G-201B, G-201C: changed from 8 to 16 frames
• Manta G-201B-30fps, G-201C-30fps: changed from 8 to 16 frames
Added frame rates for ROI height = 720
• Manta G-125B, G-125C ROI frame rate
IR cut filter:
• Changed IR cut filter to type Jenofilt 217
V6.0.1 2013-Mar-20 Initial commercial release: Manta G-223B, G223C, G-282B, G282C, G-283B,
G283C, G-609B, G-609C, G-917B, G-917C
These models are called Manta type B, since there are some differences to the
other models that are called Manta type A (specifications, housing, data path,
features).
New tripod adapter, new CAD drawings with LEDs on top of the connector
In Specifications chapter, the pixel formats are listed both for PvAPI and Vimba
(GenICam V1.0).
Added Video iris output description chapter
I/O pin assignment: 10 mA on outputs 1 and 2 (not 20 mA)
Manta G-031B, G-031C: External trigger delay.
Corrected the mass (200 g) of Manta type A cameras Manta G-031B, G-031C,
G-032B, G-032C, G-033B, G-032C, G-046B, G-046C, G-125B, G-125C, G-145B,
G-145C, G-146B, G-146C, G-201B, G-201C, G-504B, G-504C
PoE models: compliant with Power over Ethernet IEEE 802.3at/IEEE 802.3af
Deleted the Manual Overview chapter, Deleted Frame Rate Comparison of all
Manta cameras
New date format: year-month-day
V7.0.0 2013-Aug-30 Initial commercial release: Manta G-419B, G-419C
• CMOSIS CMV4000 CMOS sensor
As of this version, the document refers to Vimba SDK (not PvAPI)
Changed cable recommendation to Category 6 or higher
Manta G-145B, G-145C (including 30 fps variants): changed framerate
Camera interfaces chapter: added input/output block diagrams and the status
LED description
Changed miminum exposure times of Manta G-223B, G-223B NIR, G-223C,
G-419B, G-419B NIR, G-419C
Changed ROI frame rates of Manta G-145B-30fps, G-145C-30fps
Version Date Remarks
Table 1: Document history (continued)

Document history and conventions
13Manta Technical Manual V7.7.0
V7.0.1 2013-Sep-30 Added Camera cleaning
Changed maximum frame rates and gain range, added burst mode for Manta
G-223B, G-223B NIR, G-223C, G-419B, G-419B NIR, G-419C
Added a feature of Manta type B cameras (Manta G-223B, G-223C, G-282B,
G-282C, G-283B, G-283C, G-609B, G-609C, G-917B, G-917C):
• Temperature monitoring
Added ReverseX feature in Camera features
Added Manta angled-head housings (type B)
Updated maximum gain values for Manta G-283B, G-283C, G-917B, G-917C
Updated minimum exposure time for Manta G-145B, G-145B-30fps, G-145C,
G-145C-30fps
Updated the frame rate vs. height plots
Updated links to the GigE Installation Manual through out this manual
V7.0.2 2014-May-08 Updated camera block diagrams
Updated drawings for Manta type A board level (non-PoE): dimensions and
Manta type A board level (PoE): dimensions
Updated spectral sensitivity plots
Updated the note on StreamHoldCapacity in Specifications and Frame
memory sections
Added section Exceptions for non-PoE Manta cameras up to serial number
503323258
Updated available color pixel formats for Manta G-223B, G-223B NIR, G-223C,
G-419B, G-419B NIR, G-419C
Updated optional accessories in the Specifications chapter
Added section Manta standard board level variants (type B)
Added Hirose cable information
Updated exposure time values for Manta G-145B, G-145B-30fps, G-145B NIR,
G-145C, G-145C-30fps, G-223B, G-223B NIR, G-223C, G-282B, G-282C, G-283B, G-
283C
Corrected frame rate formula for Manta G-145B NIR
V7.0.3 2014-Jun-09 Added trigger latency and jitter values in the Specifications chapter
Updated and rearranged Specifications chapter
Added Camera feature comparison section
Preliminary Manta type B angled-head and board level variant information
removed from the document until samples are available
Version Date Remarks
Table 1: Document history (continued)

Document history and conventions
14Manta Technical Manual V7.7.0
V7.1.0 2014-Oct-07 Updated the following in the Specifications chapter
• Trigger latency and jitter values
•DecimationX/DecimationY control descriptions changed to GenICam
factor style
Added BufferHandlingControl and StreamInformation in Camera
features section, applicable for Vimba v1.3 or higher
Updated Camera features section
Initial commercial release: Manta G-235B, G-235C, G-505B, G-505C
• Sony IMX174 CMOS sensor (G-235) & Sony ICX625 CCD sensor (G-505)
• Specifications, Camera lens information, Description of data path, ROI frame
rate information
Added the following sections:
• Manta CMOS angled-head housings (type B)
• Manta CMOS board level variants (type B)
• Cross section: CS-Mount (type B)
V7.2.0 2015-Mar-20 Updated Allied Vision logo
Replaced references of AVT and Allied Vision Technologies to Allied Vision
Updated links to new Allied Vision website
Renamed Description of data path chapter to Camera data path
V7.3.0 2015-Nov-02 Updated mass of all Manta type B cameras as per Product Change Notification
2015-03-02.
Changed the technical manual layout.
Changed chapter name from ‘Camera data path’ to Image data flow and updated
the figures.
Changed chapter name from ‘Camera dimensions’ to Mechanical dimensions.
Merged the ‘Resolution and ROI frame rates’ chapter into Specifications chapter.
Added Manta at a glance section
Added General safety notes section
Updated Manta type B mechanical drawings
Added Legislation section in Safety and legislation chapter to replace ‘Legal
notice’ and ‘Conformity’ sections
Moved ‘Sensor position accuracy’ section from Appendix to ‘Mechanical
dimensions’ chapter and deleted ‘Appendix’
Added Camera features comparison section in Specifications chapter to replace
‘Camera smart features’ and ‘Camera features’ sections
Added Cross section: C-Mount and CS-Mount section to replace ‘Cross section:
C-Mount’ and ‘Cross section: CS-Mount’ sections
Added Cleaning optical components chapter to replace ‘Camera cleaning’ and
updated information
Added Contact us section to replace ‘Contacting Allied Vision’ section
Version Date Remarks
Table 1: Document history (continued)

Document history and conventions
15Manta Technical Manual V7.7.0
V7.4.0 2016-July-08 Initial commercial release: Manta G-319B, G-319C, G-507B, G-507C
• Sony IMX265 CMOS sensor (G-319) & Sony IMX267 CMOS sensor (G-507)
• Specifications, absolute QE, spectral response, ROI frame rate information,
camera lens information, data path
Added spectral response plots for select camera models
Updated specification tables to be consistent with the information on the product
web pages
Added Trigger over Ethernet Action Commands feature for supported models. For
more information see the GigE Features Reference.
Updated frame rate plots
Updated feature list for Manta 223B, G-223B NIR, G-223C, G235B, G-235C,
G-419B, G-419B NIR, G-419C
Added installation chapter
Various other minor enhancements and corrections
Added REACH (EC 1907/2006) certification statement to regulations section
Updated Manta type B CCD monochrome and color image flow diagram
Updated image flow diagrams for Manta type B cameras (CCD and CMOS)
Updated absolute QE plots for Manta G-282, G-283, G-505, G-609, G-917
V7.5.0 2016-Aug-16 New features for Manta G-282, G-283, G-505, G-609, G-917:
• One-tap/dual-tap switchability
• Trigger over Ethernet (ToE) Action Commands feature
•DeviceUserID is now accessible via the Vimba user interface
New features and changes for Manta G-505B, G-505C:
• Binning: changed the maximum value for BinningX and BinningY to 4
•ReverseX
Added optical filter information to specification tables
Various other minor enhancements and corrections
V7.6.0 2016-Nov-25 Initial commercial release: Manta G-895B, G-895C
• Sony IMX267 CMOS sensor
• Specifications, absolute QE, spectral response, ROI frame rate information,
camera lens information, data path
Updated board level camera regulatory statement
Updated missing values in specification tables
Updated absolute QE plot ands added spectral response plot for Manta G-032
Corrected reported errors
V7.7.0 2016-Dec-16 Initial commercial release: Manta G-1236B, G-1236C
• Sony IMX304 CMOS sensor
• Specifications, absolute QE, spectral response, ROI frame rate information,
camera lens information, data path
Added ReverseX to the following Manta Type A monochrome models: Manta
G-031B, G-033B, G-046, G-125B, G-146B, G-201B, G-504B.
Various other minor enhancements and corrections
Version Date Remarks
Table 1: Document history (continued)

Document history and conventions
16Manta Technical Manual V7.7.0
Manual conventions
To give this manual an easily understood layout and to emphasize important
information, the following typographical styles and symbols that are used.
Styles
Symbols
Style Function Example
Bold Program names, UI elements, highlighting
important things
bold
Italics Publication names, UI non-interactive elements Italics
Courier New Code listings, feature names Input
Courier New
Italics
Feature options Mode
Blue Cross references, web page links, email links Link
Safety Note
Note to prevent physical injury.
Possible material damage
This symbol addresses important information to avoid material damage; however,
is not related to physical injury.
Damage to the camera by electrostatic discharge (ESD)
This symbol addresses important information to avoid material damage by ESD.
Safety-related instructions to avoid malfunctions
This symbol indicates important or specific instructions or procedures that are
related to product safety. You have to follow these instructions to avoid
malfunctions.
Practical hint
This symbol highlights a practical hint that helps to better understand the camera‘s
features and functions, and to make better use of it.

Document history and conventions
17Manta Technical Manual V7.7.0
Further information available online
This symbol highlights URLs for further information. The URL itself is shown in blue.
Example:
https://www.alliedvision.com
i

Manta Technical Manual V7.7.0 18
§
Safety and regulations
This chapter includes:
• General safety notes for Manta cameras
• Information about the legal requirements and
restrictions for Manta cameras based on current
and relevant regulations
• Particular emphasis has been given to regulations
of the European Economic Area (CE, RoHS,
REACH, WEEE) as well as regulations of the
United States of America (FCC) and Canada (ICES)

Safety and regulations
19Manta Technical Manual V7.7.0
General safety notes
Avoid damage to the camera by ESD
Inadequate protection of the camera from ESD can damage the camera
permanently. Read the safety instructions and ESD warnings in the GigE
Installation Manual.
Do not operate the camera beyond the environmental specifications
See environmental specifications limits in the Specifications section of this
document. Special care must be taken to maintain a reasonable operating
temperature. If the camera is operated in temperatures higher than the specified
range, the camera should be mounted on a heat sink.
Verify all external connections
Verify all external connections in terms of voltage levels, power requirements,
voltage polarity, and signal integrity prior to powering the device.
Do not disassemble the camera housing
This camera contains sensitive internal components. The warranty is void if the
camera is disassembled.
Keep shipping material
Poor packaging of the product may cause damage during shipping.
Cleaning optical components
This product can be damaged by some volatile cleaning agents. Avoid cleaning the
image sensor unless absolutely necessary. See instructions on optics cleaning in
this document.
Allied Vision can clean your camera as a service for you, if necessary. For more
information, contact Allied Vision support at https://www.alliedvision.com/en/
support/contact-support-and-repair.html.

Safety and regulations
20Manta Technical Manual V7.7.0
Regulations
Board level models
Board level models are designed for integration and are delivered without housing
on customer's request. Because housing design is critical to the electromagnetic
compatibility (EMC) of a camera, no CE, FCC, or ICES certification tests regarding
electromagnetic interference have been performed for board level models. Users
who design board level models into their systems should perform appropriate
testing regarding EMC after the product design is completed.
RoHS, REACH, and WEEE are still applicable to these models.
European Economic Area requirements
CE and RoHS
Allied Vision Technologies declares under its sole responsibility that all standard
cameras of the Manta family to which this declaration relates are in conformity
with the following standard(s) or other normative document(s):
• CE, following the provisions of 2004/108/EC directive
• RoHS (2011/65/EU)
REACH
Allied Vision Technologies products are in compliance with the Regulation (EC) No
1907/2006 REACH.
WEEE
This product must be disposed of in compliance with the directive 2002/96/EC on
waste electrical and electronic equipment (WEEE).
FCC – Class B Device
For customers in the U.S.A.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a residential environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interferences will not occur in a particular
installation. If the equipment does cause harmful interference to radio or
television reception, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Use a different line outlet for the receiver.
• Consult a radio or TV technician for help.
