Muse Art Table
Assembly Instructions
Tools required for assembly
1.) 3/8” Ratchet Wrench
2.) 3” extension
3.) 1/2” socket
4.) Standard Screwdriver (at head)
Hardware Components
Wood Pedestal Components
6ea. 4-1/2” Hex
Bolts
10ea. Flat Washers
2ea Top Supports
2ea Middle Supports
2ea Bottom Supports
1ea Stretcher
Phone [phone]
www.alliedmanufacturing.com
4ea. 2-3/4” Hex
Bolts
6ea. Dowel Nuts
4ea. Glides

End Pedestal Assembly
Table Top Assembly
1.) Glides should be pre-installed in bottom supports
2.) Fasten bottom support and top support to middle support
(ensure extended slot in middle support is closer to the top support.)
3.) Install top and bottom support using 4-1/2 hex bolts with washers.
e bolt with washer is placed through the hole in the supports to egage
the dowel nuts,. e dowel nuts are positioned in round countersunk
holes in the middle support with the slotted side facing out. e screw-
driver is used to rotate the dowel nut so the hex bolt can engage the
thread.
4.) Repeat this procedure for the other end pedestal
1.) Fasten the stretcher to the two end pedestal assem-
blies using 4-1/2” hex bolts, washers, and Dowel Nuts.
2.) e dowel nuts are positioned in round countersunk
holes in the stretcher with the slotted side facing out.
e screwdriver is used to rotate the dowel nut so the
hex bolt can engage the thread.
3.) Do not completely tighten the hex bolts at this time
1.) Place the table top face down on a clean surface to avoid scratching
the top surface.
2.) Place the pedestal assembly upside down on the table top. Line up
the holes in the top support with the holes in the table top.
3.) Fasten the pedestal assembly to the top using the 2-3/4” hex bolts
with washers through the top support ito the table top. Do not tighten
the hex bolts completely at this time.
4.) Tighten the two bolts connecting the stretcher to the end pedestals.
5.) Tighten the four bolts connecting the pedestal assembly to the table
top.
6.) Assembly is complete. Turn the table upright for use.
