Allied GC2450 User manual

GC2450 / GC2450C
Allied Vision Technologies Canada Inc.
101-3750 North Fraser Way
Burnaby, BC
V5J 5E9 / Canada
Technical Manual
700037A
Updated August 27, 2010

GC2450 Technical Manual Page ii
Table of Contents
Table of Contents .......................................................................................................... ii
Introduction ............................................................................................................ 1
Precautions.............................................................................................................. 1
Warranty ................................................................................................................. 1
Specifications .......................................................................................................... 2
Supported Features ................................................................................................... 3
Mechanical .............................................................................................................. 4
Connections............................................................................................................. 5
Cleaning the Sensor................................................................................................... 9
Adjusting the C-mount ..............................................................................................10
Camera Installation ..................................................................................................11
System Optimization.................................................................................................16
Trouble Shooting .....................................................................................................18
Addendum..................................................................................................................21
GC IO Schematic.......................................................................................................22
Isolated Trigger Schematic.........................................................................................23
Non-isolated Trigger Schematic ..................................................................................24
Video Iris Schematic .................................................................................................25
Trigger Timing Diagram .............................................................................................26
Notes on Triggering ..................................................................................................27

GC2450 Technical Manual Page iii
Legal notice
For customers in the U.S.A.
(FCC Compliance Information)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. However there is no guarantee
that interferences will not occur in a particular installation. Operation of this equipment in a residential environment is likely to
cause harmful interference.
You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this
equipment. The shielded interface cable recommended in this manual must be used with this equipment in order to comply with the
limits for a computing device pursuant to Subpart B of Part 15 of FCC Rules.
For customers in Canada
This digital apparatus complies with the Class A limits for radio noise emissions set out in the Radio Interference Regulations.
Pour utilisateurs au Canada
Cet appareil numérique est conforme aux normes classe A pour bruits radioélectriques, spécifiées dans le Règlement sur le
brouillage radioélectrique.
Life support applications
These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can
reasonably be expected to result in personal injury. Allied Vision Technologies customers using or selling these products for use in
such applications do so at their own risk and agree to fully indemnify Allied Vision Technologies for any damages resulting from
such improper use or sale.
Trademarks
Unless stated otherwise, all trademarks appearing in this document are the property of Allied Vision Technologies and are fully
protected by law.
Warranty
The information provided by Allied Vision Technologies is supplied without any guarantees or warranty whatsoever, be it specific or
implicit. Also excluded are all implicit warranties concerning the negotiability, the suitability for specific applications or the non-
breaking of laws and patents. Even if we assume that the information supplied to us is accurate, errors and inaccuracy may still
occur.
Copyright
All text, pictures and graphics are protected by copyright and other laws protecting intellectual property. It is not permitted to copy
or modify them for trade use or transfer, nor may they be used on web sites.
Allied Vision Technologies Canada Inc. 1/2010
All rights reserved.

GC2450 Technical Manual Page iv
Contacting Allied Vision Technologies
• Technical information:
http://www.alliedvisiontec.com
• Support:
[email protected]
Allied Vision Technologies GmbH (Headquarters)
Taschenweg 2a
07646 Stadtroda, Germany
Tel.: [phone]
Fax.: [phone]
e-mail: [email protected]
Allied Vision Technologies Canada Inc.
101-3750 North Fraser Way
Burnaby, BC, V5J 5E9, Canada
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
Allied Vision Technologies Inc.
38 Washington Street
Newburyport, MA 01950, USA
Toll Free number +1-877-USA-1394
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]

GC2450 Technical Manual Page 1
Introduction
The GC2450 series of cameras are 5 megapixel, 15 frames per second, Gigabit Ethernet cameras
based on the Sony ICX625ALA and ICX625AQA, Super HAD CCD sensors.
Precautions
READ INSTALLATION GUIDE CAREFULLY.
This document contains specific information which is necessary for the correct operation and
treatment of this product.
DO NOT OPEN THE CAMERA. WARRANTY IS VOID IF CAMERA IS OPENED.
This camera contains sensitive components which can be damaged if handled incorrectly.
KEEP SHIPPING MATERIAL.
Poor packaging of this product can cause damage during shipping.
VERIFY ALL EXTERNAL CONNECTIONS.
Verify all external connections in terms of voltage levels, power requirements, voltage polarity,
and signal integrity prior to powering this device.
CLEANING.
This product can be damaged by some volatile cleaning agents. Avoid cleaning the image sensor
unless absolutely necessary. Please see instructions on sensor cleaning in this document.
DO NOT EXCEED ENVIRONMENTAL SPECIFICATIONS.
See environmental specifications limits in the Specifications section of this document.
Warranty
AVT provides a 2 year warranty which covers the replacement and repair of all AVT parts which are
found to be defective in the normal use of this product. AVT will not warranty parts which have
been damaged through the obvious misuse of this product.

GC2450 Technical Manual Page 2
Specifications
Sensor Type Sony ICX625ALA CCD (ICX625AQA for color)
Sensor Shutter Type Progressive Interline
Image Resolution 2448 x 2050 pixels
Pixel Size 3.45μm x 3.45μm
Optical Forma
t
2/3 inch
Lens Moun
t
C-mount with adjustable back focus
Color Sensor Filter Pattern
†
Bayer
Full Resolution Frame Rate 15.1 fps
Frame Rate (1900 x 1080 ROI) 24.6 fps
I/O 1 isolated input/output, 1 non-isolated input/output,
1 RS-232 input/output
Power Requirements Less than 3.8W
††
(5V to 16V)
†††
Digitization 12 Bits
Trigger latency* 2us for non-isolated I/O, 10us for isolated I/O
Trigger Jitter* ±20ns for non-isolated I/O, ±0.5us for isolated I/O
Tpd* 10ns for non-isolated I/O, 1.3us for isolated I/O
Operating Temperature 0 to 40 Celsius***
Operating Humidity 20 to 80% non-condensing
Size 33mm (height) x 46mm (width) x 59mm (length)
Weigh
t
106g
Hardware Interface Standard IEEE 802.3 1000BASE-T, 100BASE-TX
Software Interface Standard GigE Vision Standard 1.0
Regulator
y
CE, FCC, RoHS
† Applies to GC2450C only.
†† Power consumption will increase with reduced ROI imaging and color interpolation.
††† Nominal operating voltage is 12V. Cameras have been tested at 12V.
* See Notes on Triggering in the Addendum.
***DUE TO THE SMALL PACKAGING AND HIGH SPEED OF THE GC CAMERAS, SPECIAL CARE IS REQUIRED TO
MAINTAIN A REASONABLE OPERATING TEMPERATURE. IF THE CAMERA IS TO BE OPERATED IN A WARM
ENVIRONMENT, IT IS SUGGESTED THAT THE CAMERA BE MOUNTED ON A HEAT SINK SUCH AS A METAL BRACKET
AND THAT THERE IS SUFFICIENT AIR FLOW.

GC2450 Technical Manual Page 3
Supported Features
Imaging Modes free-running, external trigger, fixed rate, software trigger
Fixed Rate Control 0.001 fps to maximum frame rate
External Trigger Delay 0 to 60 seconds in 1 microsecond increments
External Trigger Even
t
rising edge, falling edge, any edge, level high, level low
Exposure Time 25 microseconds to 60 seconds in 1 microsecond increments
Gain 0 to 24dB
Region of Interest (ROI) independent x and y control with 1 pixel resolution
Horizontal Binning 1 to 8 pixels
Vertical Binning 1 to 14 rows
Pixel Formats Mono8*, Mono16*, Bayer8, Bayer 16
Sync Out Modes trigger ready, trigger input, exposing, readout, imaging, strobe, GPO
*On monochrome versions only.

GC2450 Technical Manual Page 4
Mechanical
Figure 1. GC SERIES mechanical dimensions.

GC2450 Technical Manual Page 5
Connections
Figure 2. GC SERIES connection diagram.
4
2
3
1

GC2450 Technical Manual Page 6
Item 1: GIGABIT ETHERNET PORT
This port conforms to the IEEE 802.3 1000BASE-T standard for Gigabit Ethernet over copper. It is
recommended that CAT5E or CAT6 compatible cabling and connectors be used for best
performance. Cable lengths up to 100m are supported.
Item 2: General Purpose I/O PORT
1
2
3
57
6
4
8
9
10
11 12
PIN FUNCTION
1Power Ground
212V Power
3Sync Input 1 - isolated
4Sync Output 1 - isolated
5Isolated Ground
6Video Iris
7 DNC
8RS-232 TXD
9RS-232 RXD
10 Signal Ground
11 Sync Input 2 – non-isolated
Figure 3. General Purpose I/O Pin out. Camera
rear view. 12 Sync Output 2 – non-isolated
The General Purpose I/O port uses a Hirose HR10A-10R-12PB connector on the camera side. The
mating cable connector is Hirose HR10A-10P-12S. This connector can be purchased from AVT or
from http://www.digikey.com.
See Addendum for more detail.
DO NOT EXCEED 5.5V ON SIGNAL INPUTS UNLESS OTHERWISE INDICATED. SYNC INPUT 1
CAN BE DRIVEN FROM A HIGHER VOLTAGE IF A CURRENT LIMITING RESISTOR IS USED TO
LIMIT THE CURRENT TO LESS THAN 10 MILLIAMPS.
12V Power and Power Ground
To operate the camera 12V Power with suitable current capacity (see specifications) must be
provided on Pin 2 and the Power Ground on Pin 1.
A cable assembly providing this power can be ordered from AVT (AVT P/N 02-8003A for North
America or AVT P/N 02-8004A for a Universal supply).

GC2450 Technical Manual Page 7
Sync Input 1 and Sync Input 2
These input signals allow the camera to be synchronized to some external event. The camera can
be programmed to trigger on the rising edge, falling edge, both edges or level of this signal. The
camera can also be programmed to capture an image at some programmable delay time after the
trigger event.
Sync Input 1 is isolated and should be used in noisy environments to prevent false triggering due
to ground loop noise. Sync Input 2 is non-isolated and can be used when a faster trigger is
required and when environmental noise is not a problem.
Sync Output 1 and Sync Output 2
These signals only function as outputs and can be configured as follows:
Exposing Corresponds to when camera is
integrating light.
Trigger Ready Indicates when the camera will accept a
trigger signal.
Trigger Inpu
t
A relay of the trigger input signal used to
“daisy chain” the trigger signal for
multiple cameras.
Readou
t
Valid when camera is reading out data.
Imaging Valid when camera is exposing or reading
out.
Strobe Programmable pulse based on one of the
above events.
GPO User programmable binary output.
Any of the above signals can be set for active high or active low.
Sync Output 1 will require a pull up resistor of greater than 1Kohm to the user’s 5V logic supply.
Sync Output 1 is isolated and should be used in noisy environments. Sync Output 2 is non-isolated
and can be used when environmental noise is not a problem and when faster response is required.
RS-232 RXD and RS-232 TXD
These signals are RS-232 compatible. These signals allow communication from the host system via
the Ethernet port to a peripheral device connected to the camera. Note that these signals are not
isolated and therefore careful attention should be used when designing cabling in noisy
environments.

GC2450 Technical Manual Page 8
Isolated Ground
Isolated Ground must be connected to the user’s external circuit ground if Sync Input 1 or Sync
Output 1 is to be used.
Signal Ground
Signal Ground must be connected to the user’s external circuit ground if Sync Input 2 or Sync
Output 2 is to be used or if the RS-232 port is to be used. Note that Signal Ground is common with
Power Ground however it is good practice to provide a separate ground connection for power and
signaling when designing the cabling.
Video Iris
This signal can be used to drive the video input of a video iris lens. See Addendum.
DNC
These signals are reserved for future use and should be left disconnected.
Item 3: Status LED 1
LED COLOR STATUS
Solid Orange Ethernet link established.
Flashing Orange Ethernet activity.
Item 4: Status LED 2
LED COLOR STATUS
Solid Green Normal operation.
Flashing once per second Boot up pending
3 quick flashes once per
second.
Camera fault.

GC2450 Technical Manual Page 9
Cleaning the Sensor
DO NOT CONTACT CLEAN SENSOR UNLESS ABSOLUTELY NECESSARY.
Identifying Debris
Debris on the image sensor or optical components will appear as a darkened area or smudge on the
image that does not move as the camera is moved. Do not confuse this with a pixel defect which
will appear as a distinct point.
Locating Debris
Before attempting to clean the image sensor, it is important to first determine that the problem is
due to debris on the sensor window. To do this you should be viewing a uniform image, such as a
piece of paper, with the camera. Debris will appear as a dark spot or dark region that does not
move as the camera is moved. To determine that the debris is not on the camera lens, rotate the
lens independent of the camera. If the spot moves as the lens moves, then the object is on the
lens -not on the image sensor- and therefore cleaning is not required. If the camera has an IR
filter, then rotate the IR filter. If the object moves then the particle is on the IR filter not the
sensor. If this is the case remove the IR filter carefully using a small flat head screw driver. Clean
both sides of the IR filter using the same techniques as explained below for the sensor window.
DO NOT TOUCH ANY OPTICS WITH FINGERS. OIL FROM FINGERS CAN DAMAGE FRAGILE
OPTICAL COATINGS.
Cleaning with Air
If it is determined that debris is on the sensor window, then remove the camera lens, and blow the
sensor window directly with clean compressed air. If canned air is used, do not shake or tilt the
can prior to blowing the sensor. View a live image with the camera after blowing. If the debris is
still there, repeat this process. Repeat the process a number of times with increased intensity until
it is determined that the particulate cannot be dislodged. If this is the case then proceed to the
contact cleaning technique.
Contact Cleaning
Only use this method as a last resort. Use 99% laboratory quality isopropyl alcohol and clean
cotton swabs. Dampen the swab in the alcohol and gently wipe the sensor in a single stroke. Do
not reuse the same swab. Do not wipe the sensor if the sensor and swab are both dry. You must
wipe the sensor quickly after immersion in the alcohol, or glue from the swab will contaminate the
sensor window. Repeat this process until the debris is gone. If this process fails to remove the
debris, then contact AVT.

GC2450 Technical Manual Page 10
Adjusting the C-mount
LOCKING RING
C-MOUNT RING
Figure 4. Camera Front View.
THE C-MOUNT IS ADJUSTED AT THE FACTORY AND SHOULD NOT REQUIRE ADJUSTING.
If for some reason, the C-mount requires adjustment, use the following method.
Loosen Locking Ring
Use an adjustable wrench to loosen locking ring. Be careful not to scratch the camera. When the
locking ring is loose, unthread the ring a few turns from the camera face. A wrench suitable for this
procedure can be provided by AVT (P/N 11-0048A).
Image to Infinity
Use a c-mount compatible lens that allows an infinity focus. Set the lens to infinity and image a
distant object. The distance required will depend on the lens used but typically 30 to 50 feet
should suffice. Make sure the lens is firmly threaded onto the c-mount ring. Rotate the lens and c-
mount ring until the image is focused. Carefully tighten locking ring. Recheck focus.

GC2450 Technical Manual Page 11
Camera Installation
Computer Interface
The Prosilica GC cameras will work with any Ethernet network card; however AVT strongly
recommends using Gigabit Ethernet components that support Jumbo Frames. A Jumbo Frame is
loosely defined as a frame size greater than 1500 bytes however typical Jumbo Frames are around
9000 bytes. Frame size is the number of bytes per packet and the larger the frame size, the less the
computer CPU will be loaded due to the processing of incoming packets.
There are many Gigabit Ethernet cards available which will support Jumbo Frames. The following
examples have been verified to work well with the Prosilica GC cameras:
•Intel PRO/1000
•D-Link DGE-550T
•SMC EZ Card 1000
Gigabit Ethernet cards supporting this feature can also be purchased with the camera (AVT P/N 02-
3002A).

GC2450 Technical Manual Page 12
Gigabit Ethernet Setup for Windows
oInstall network card in computer.
oBoot the PC and cancel the “Found new Hardware Wizard” window that may appear when
Windows detects the new card.
oInstall the driver that came with the network card.
oOnce the driver is installed, open the Network Connections Dialog as follows: From the
Windows desktop select start, then select Control Panel, then double click on the Network
Connections icon. Double click the relevant network card listed or right-click the relevant
network card and select Properties. This will open the properties window for your network
card. See Figure 5.
Figure 5. Network card main properties window.

GC2450 Technical Manual Page 13
oSelect the Internet Protocol (TCP/IP) check box and then select Properties. See Figure 6.
Network card TCP/IP address.. Select the Use the following IP address and enter an IP
address of 169. 254. x. y, where xand ycan be any number. Press the TAB key after entering
the IP address and the subnet mask will automatically be entered. The subnet mask is 255.
255. 0. 0. Click OK to save changes. Note that if Windows reports a conflict with the above IP
address, simply repeat the above steps and change the last digit of the IP address to a different
value.
Figure 6. Network card TCP/IP address.

GC2450 Technical Manual Page 14
Figure 7. Turn off Firewall.
oReturn to the Gige Local Properties window as in Figure 5. Select the Advanced tab as in
Figure 7 and disable the Firewall for this device. Click OK to save changes.
Gigabit Ethernet Cabling
All Gigabit Ethernet cabling and connectors should be CAT5E or CAT6 compatible. Cable lengths
must not exceed 100 meters.
Power Connection
The camera requires a 12V DC power supply that can source a minimum of 500 mA of current. See
the Connections section of this document for more information.

GC2450 Technical Manual Page 15
Installing GigE Viewer for Testing
oThe latest Viewer software can be downloaded from
http://www.alliedvisiontec.com/us/support.html.
oRun the GigE Viewer Installer.exe. This will install the Prosilica GC Digital Camera drivers as
well as the GigE Viewer application program.
oPlug in the Prosilica GC camera via the Gigabit Ethernet port. Plug in the power connection.
Verify that the Status LED 2 is a solid green. Run the GigE Viewer Application. It will take a few
seconds for the camera to be recognized. If the camera does not appear in the Viewer list after
approximately 10 seconds then try disconnecting and reconnecting the power. If it still does
not appear restart the viewer. If it still does not appear, see the Trouble Shooting section of
this document.
oSee Figure 8. Select the wrench icon to change camera settings. Change the PacketSize to a
value of 1500. Select the eye icon to image. The camera should now be imaging. If the
camera is not imaging, see the Trouble Shooting section of this document. Note that the
PacketSize can be set to 8228 if the network card has been optimized to support jumbo frames.
oSee the System Optimization Section to maximize the performance of your system.
Figure 8. GigE Viewer application window.

GC2450 Technical Manual Page 16
System Optimization
oOpen the Network Connections Dialog as follows: From the Windows desktop select start, then
select Control Panel, then double click on the Network Connections icon. Double click the
relevant network card listed or right-click the relevant network card and select Properties.
This will open the properties window for your network card. See Figure 9.
Figure 9. Network card main properties window.
oFrom the Properties window select Configure then select the Advanced tab. See Figure 10.
