Paradox HD88 User manual

HD88
720P HD Outdoor Camera
Installation Manual
**Compatible with Insite
GOLD and SWAN Server**
Introduction
The HD88 is an IPX4 outdoor 720P HD camera with built-in
audio, pet immune security motion detector, with Ethernet and
Wi-Fi. It provides up to 30 minutes of internal recording and
comes with a removable rain hood. The BR88 wall bracket is
an optional accessory.
Installing the HD88
If you are installing the HD88 near any reflecting surface, please
note that it may affect the quality of the night vision due to the IR
reflection.
If wall bracket tamper is connected, tamper will automatically be
detected by the camera. Tamper will follow recognition settings set
in the panel.
Unscrew and
remove cover
Lock and Tamper
Drill Out
Holes
Mount back on wall
or bracket
Terminal
Block
Anti-
Tamper
Power Requirements
It is recommended to use the PS25 power supply module that is
capable of powering a maximum of 5 x HD88’s.
HD88 Ethernet Wiring
Connect the HD88 camera with a CAT5e or better cable using
pairs 2 & 3 (pins 1,2,3,6). The maximum cable length is 50 meters.
HD88 Bus Wiring
Connect the PIR with a 4-core 14/0.20 cable or better.
BR88 Wall Bracket Installation
- 1 -

LED is On and
LED is Flashing
HD88 Wiring Table
Creep Zone / Pet Selection
Remove detector assembly.
When selector is UP is Pet Mode.
When selector is DOWN is Creep Zone and there is no Pet
Immunity.
Mounting above 2.4m Pet Immune should be OFF (lever down)
Installation Height:
Pet Immune ON - 2.1m to 2.4m (lever up)
Pet Immune OFF - 2.4m to 2.7m (lever down)
For installations higher than 2.6m tilt the detector down a few
degrees for best detection results. Use of the BR88 bracket is
recommended.
Registration LED Status Indicators
LED Status Indicators
Other than PIR detection, LEDs are active when lock mechanism
is open.
*VOD On/Off LED is controlled by the Master ONLY, using
the Insite GOLD application.
Camera Wire Assignment
Terminals Wire Colour
RX- Solid Orange
RX+ Orange Stripe
TX- Solid Green
TX+ Green Stripe
YYellow
GGreen
B- Black
R+ Red
UP = Pet DOWN = Creep Zone
LED Functionality
HD88 is not connected to a
local network
LED and LED flash
intermittently
HD88 is connected to a local
network but failed to poll the
SWAN Server
HD88 is connected to a local
network and is successfully
polling the SWAN Server
LED is On and
LED is On
LED LED Display
TX Digiplex/Spectra Data TX
Flashing green: Data
transmission
Off: No data
transmission
RX Digiplex/Spectra Data RX
Flashing green: Data
reception
Off: No data reception
Firmware upgrade in
progress
Flashing purple
VOD*Blue on
Power-upFlashing blue
Locate modeFlashing blue
No connection to panel busFlashing red
Bus low powerFlashing red
PIR detection
Red on for 3 seconds
Active Internet
Green on
Active LAN 10/100Mb link
Green on
Network Status
Functionality
-2 -
PIR Wire Assignment
Bracket Wire Assignment
Terminals Wire Colour
TMP Blue
B- Black

HD88 Camera Set Up and Configuration
5Select the WiFi network
that the camera will be
registered to.
6p
Enter
asswor
the
d
Wi
and
Fi
press
continue.
7A
ge
QR
nerated
code
.
will
Present
be
the QR
code to the camera lens.
Ensure tamper is open by
unscrewing screw at the
bottom of the HD88.
8The HD88 WiFi Camera will
then be displayed in the
modules list with a WiFi
symbol next to it. Press
Configure to modify settings.
1Launch the Insite Gold
app 2Select New Installation and then the Create button. 3Type in the Panel Serial
Number, Site ID, Client’s
Email Address.
4To add a WiFi Camera, press
Add WiFi Camera. If you are
not configuring a WiFi
Camera, skip to Step 10.
9Configure your settings
and press Save when
completed.
10 Press Create New Site. A
Site Created message will
appear. The system will send
you an email.
11 Retrieve your email and
click Activate. You will then
be prompted to choose the
type of activation for your
subscription.
12 Your site will then be created
and displayed in the app.
-3 -

PIR Detector Beam Patterns
Top View
Camera View
Side View
Camera View
Technical Specifications
16m
(52’)
100°
110°
1.5m
(3.3’)
1.5m
(3.3’)
3m
(10’)
3m
(10’)
5.5m
(16’)
5.5m
(16’)
10m
(33’)
10m
(33’)
12m
(40’)
12m
(40’)
16m
(52’)
0m
10m
(33’)
5.5m
(16’)
3m
(10’)
1.5m
(3.3’)
16m
(52’)
12m
(40’)
Detector 1 Detector 2 Both Detectors
2.1m
(6.8’)
Image Resolution 1280 x 720
Image Sensor Type 1.4 megapixels, CMOS sensor,
7V/LUX.Sec
Streaming Video 720p H.264 10 FPS
HD Audio 16 bit, 24 KHz sampling rate, 32 Kb/s
mono
Pre-event
recording 3.0 seconds
Internal storage
15 minutes alarm and 15 minutes
Video On Demand (VOD)
File length - 10 sec. 3 min.
PIR Sensor / Lens 2x dual element / Mironel lens
Pet Immune Pets up to 50cm
Voltage Input Nominal: 12VDC, range 9-16VDC
Current
Consumption Max
350mA - IR illumination ON
250mA - IR illumination OFF
Dimensions
(H x W x D) 16.8 x 6.8 x 7.4 cm
Operating
Temperature -40° C to +60° C
Internet Bandwidth Minimum 1 Mb/s UPLOAD
recommended
Installation Height 2.1m - 2.7m
Installation Options Wall or corner mount, BR88 optional
Compatibility EVOHD, EVO192, SP5500, SP6000
and SP7000
Warranty
For complete warranty information on this product, please refer to the Limited Warranty Statement is found on the website:
www.paradox.com/terms or contact your local distributor. Specifications may change without prior notice.
Patents
US, Canadian and international patents may apply. Paradox is a trademark or registered trademark of Paradox Security Systems (Bahamas) Ltd.
-4 -
