HIK VISION DS-2CC 2D9T Series User manual

0
HD 1080p Ultra Low-Light
PoC Camera
User Manual
UD02874B-A

1
User Manual
Thank you for purchasing our product. If there are any questions,
or requests, do not hesitate to contact the dealer.
This manual applies to HD 1080p Ultra Low-Light PoC Camera.
This manual may contain several technically incorrect places or
printing errors. The content is subject to change without notice,
and the updates will be added to the new version of this manual.
We will readily improve or update the products or procedures
described in the manual.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
use’s authoity to opeate the euipet.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.

2
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized
European standards listed under EMC Directive
2014/30/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more
information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery
that cannot be disposed of as unsorted municipal
waste in the European Union. See the product
documentation for specific battery information.
The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead
(Pb), or mercury (Hg). For proper recycling, return the battery to
your supplier or to a designated collection point. For more
information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.

3
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The peautio easue is diided ito Waigs ad
Cautios
Warnings: Serious injury or death may occur if any of the
warnings are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
In the use of the product, you must be in strict compliance
with the electrical safety regulations of the nation and region.
Refer to technical specifications for detailed information.
Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 V AC or 12 V DC
according to the IEC60950-1 standard. Refer to technical
specifications for detailed information.
Warnings Follow
these safeguards to
prevent serious injury
or death.
Cautions Follow these
precautions to prevent
potential injury or
material damage.

4
Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
Make sure that the plug is firmly connected to the power
socket.
When the product is mounted on wall or ceiling, the device
shall be firmly fixed.
If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then contact the
service center.
If the product does not work properly, contact your dealer or
the nearest service center. Never attempt to disassemble the
camera yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cautions
Make sure the power supply voltage is correct before using the
camera.
Do not drop the camera or subject it to physical shock.
Do not touch senor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
replace the lens cap to protect the sensor from dirt.
Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.

5
Do not place the camera in extremely hot, cold, dusty or damp
locations, and do not expose it to high electromagnetic
radiation.
To avoid heat accumulation, good ventilation is required for
operating environment.
Keep the camera away from liquid while in use.
While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.

6
1.1 Product Features..................................................................... 8
1.2 Overview of Type I Camera..................................................... 9
1.3 Overview of Type II Camera...................................................10
1.4 Overview of Type III Camera..................................................10
1.5 Overview of Type IV Camera..................................................11
1.6 Overview of Type V Camera...................................................11
2.1 Type I and Type II Camera Installation ...................................12
2.1.1 Ceiling Mounting ...........................................................12
2.1.2 Wall Mounting...............................................................15
2.1.3 In-Ceiling Mounting .......................................................17
2.1.4 In-Ceiling Mounting with Junction Box ..........................18
2.1.5 Mounting with Inclined Base of Type I Camera..............20
2.2 Type III and Type IV Camera Installation ................................21
2.2.1 Ceiling Mounting ...........................................................21
2.2.2 Mounting with Junction Box ..........................................24
2.3 Type V Camera Installation ....................................................26
2.3.1 Ceiling Mounting ...........................................................26
2.3.2 Ceiling Mounting with Junction Box...............................29
2.3.3 Wall Mounting...............................................................30
2.3.4 Mounting with Inclined Base .........................................32
3.1 VIDEO OUT ............................................................................36
3.2 LANGUAGE ............................................................................36
3.3 SET UP ...................................................................................36
3.3.1 SMART FOCUS ...............................................................36

7
3.3.2 SCENE ............................................................................37
3.3.3 LENS ..............................................................................37
3.3.4 EXPOSURE .....................................................................37
3.3.5 BACKLIGHT ....................................................................40
3.3.6 WHITE BALANCE ............................................................43
3.3.7 DAY & NIGHT .................................................................43
3.3.8 SPECIAL..........................................................................44
3.3.9 ADJUST ..........................................................................47
3.3.10 RESET.............................................................................48
3.3.11 EXIT ...............................................................................48

8
Introduction
1.1 Product Features
The camera is applicable for both indoor and outdoor conditions,
and the application scenarios include road, warehouse,
underground parking lot, bar, etc..
The main features are as follows:
High performance CMOS sensor
1080p resolution
Ultra low-light: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR
OSD menu, white balance, auto gain, backlight compensation,
electronic shutter, ect.
2D & 3D DNR
IR cut filter
Semi-auto focus
PoC
Remote parameters configuration and upgrade
External alarm in/out
Note:
Some mode(s) of type II camera is applicable for indoor only.

9
1.2 Overview of Type I Camera
Auxiliary Video
Output
Menu
Button
DIP Switch
Video Cable (CVBS)
Video Cable (TVI)
Power (24 V AC/12 V DC)
Alarm Cable
Bubble
Back Box
ALARM
IN G OUT G
Figure 1. 1 Overview of Type I Camera

10
1.3 Overview of Type II Camera
Menu
Button
Auxiliary Video
Output
DIP Switch
Alarm Cable
Video Cable (CVBS)
Video Cable (TVI)
Power (24 V AC/12 V DC)
Base
Bubble
Base Plate
ALARM
IN G GOUT
Figure 1. 2 Overview of Type II Camera
1.4 Overview of Type III Camera
Bracket
Main
Body
Lens
Video Cable (CVBS)
Video Cable (TVI)
Power Cable (24 V AC/12 V DC)
Alarm Cable
Figure 1. 3 Overview of Type III Camera

11
1.5 Overview of Type IV Camera
Video Cable (CVBS)
Video Cable (TVI)
Power Cable
(DC 12 V )
Switch Cable
Bracket
Main Body
Lens
Figure 1. 4 Overview of Type IV Camera
1.6 Overview of Type V Camera
Enclosure
Main Body
Mounting
Base
Video Cable (CVBS)
Video Cable (TVI)
Power Cable
(DC 12 V )
Switch Cable
Figure 1. 5 Overview of Type V Camera

12
Installation
Before you start:
Make sure that the device in the package is in good condition
and all the assembly parts are included.
Make sure that all the related equipment is power-off during
the installation.
Check the specification of the products for the installation
environment.
Check whether the power supply is matched with your
power output to avoid damage.
Make sure the wall is strong enough to withstand three
times the weight of the camera and the mounting bracket.
If the wall is cement, insert expansion screws before
installing the camera. If the wall is wooden, use self-tapping
screw to secure the camera.
If the product does not function properly, contact your
dealer or the nearest service center. Do not disassemble the
camera for repair or maintenance by yourself.
2.1 Type I and Type II Camera Installation
2.1.1 Ceiling Mounting
Steps:
1. Attach the drill template to the celling.
2. Drill screw holes and the cable hole (optional) on the ceiling
according to the supplied drill template.

13
Note:
Cable hole is required when you adopts ceiling outlet to route
the cables.
Type I Camera：
Type II Camera：
Figure 2. 1 The Drill Template
3. Loosen the screws on the bubble of the dome camera to
remove the bubble and the black liner.
4. Attach the back box of type I camera/base plate of type II
camera to the ceiling and secure them with supplied screws.
Type I Camera：
Type II Camera：
Figure 2. 2 Attach the Back Box/Base Plate

14
Note:
In the supplied screw package, both self-tapping screws and
expansion blots are contained.
If the wall is cement, expansion blots are required to fix the
camera. If the wall is wooden, self-tapping screws are
required.
5. Route the cables through the cable hole or the side opening.
6. Align the camera with the back box/base plate, and tighten
the screws to secure the camera with the back box/base
plate.
Type I Camera：
Type II Camera：
Figure 2. 3 Fix the camera to the Ceiling
7. Connect the corresponding cables, such as power cable and
video cable.
8. Power on the camera to check whether the image on the
monitor is gotten from the optimum angle. If not, adjust the
camera according to the figure below to get an optimum
angle.

15
Type I Camera：
0° to 355°
0° to 355°
0° to 75°
0° to 355°
0° to 340°
0° to 75°
Type II Camera:
Figure 2. 4 3-Axis Adjustment
9. Fit the black liner on the camera and tighten the screws on
the bubble of the dome camera to finish the installation.
2.1.2 Wall Mounting
Note:
You need to purchase a wall mounting bracket separately, if you
adopt the wall mounting.
Steps:
1. Drill 4 screw holes in the wall according to the holes of the
bracket.
2. Attach the bracket to the wall by aligning the 4 screw holes of
the bracket with expansion screws on the wall.
3. Secure the bracket with 4 hex nuts and washers.

16
Type I Camera
Type II Camera
Figure 2. 5 Install Wall Mounting Bracket
4. Refer to step 3 of the 2.1.1 Ceiling Mounting to remove dome
camera’s bubble and the black liner.
5. Attach the back box/base plate of the dome camera to the
wall mounting bracket and secure them with supplied
screws.
Type I Camera
Type II Camera
Figure 2. 6 Attach the Base Plate to the Bracket

17
6. Route the cables through the bracket.
7. Repeat steps 6 to 9 of the 2.1.1 Ceiling Mounting to complete
the installation.
2.1.3 In-Ceiling Mounting
Note:
You need to purchase an in-ceiling mounting bracket separately if
you adopt the in-ceiling mounting.
Steps:
1. Attach the drill template on the ceiling.
2. Drill the screw holes and cable holes (optional) in the ceiling
according to the supplied drill template.
Note:
Cable hole is required when adopting ceiling outlet to route the
cable.
3. Screw the bolts through the mounting bracket by aligning
with the 2 bolt holes. Fit the toggles onto the bolts.
4. Push the two toggles through the two screw holes in the
ceiling. Rotate the bolt till the toggle holds the ceiling tightly.
Figure 2. 7 Install the In-Ceiling Mounting Bracket
5. Route the cables through the cable hole.

18
6. Attach the back box of type I camera/base plate of type II
camera to the in-ceiling mounting bracket with the supplied
screws.
Note:
In the supplied screw package, both self-tapping screws and
expansion blots are contained.
If the wall is cement, expansion blots are required to fix the
camera. If the wall is wooden, self-tapping screws are
required.
Type I Camera：
Type II Camera：
Figure 2. 8 Fix the Camera to the Mount
7. Repeat steps 6 to 9 of the 2.1.1 Ceiling Mounting section to
complete the installation.
2.1.4 In-Ceiling Mounting with Junction Box
Note:
You need to purchase an in-ceiling mounting bracket separately if
you adopt the in-ceiling mounting with the junction box.

19
Steps:
1. Repeat steps 2 to 4 of the 2.1.3 In-Ceiling Mounting section to
secure the in-ceiling mounting bracket (supplied) to the
junction box.
Figure 2. 9 Install the Bracket
2. Connect the corresponding cables, such as power cable and
video cable.
3. Align the camera with the junction box, and tighten the
screws to secure the camera with the junction box.
Type I Camera：
Type II Camera:
Figure 2. 10 Fix the Camera to the Junction Box
