Allnet ALL9600T User manual

AV Extender
ALL9600T ALL9600R
User's Manual
One-Port AV Transmitter : ALL9600T
One-Port AV Receiver : ALL9600R
(C) 2006 ALLNET, All Rights Reserved

User’s Manual
2
One-Port AV Transmitter : ALL9600T
One-Port AV Receiver : ALL9600R

3
TABLE OF CONTENTS
Introduction
Key Features
Panel Description
Installation and Operation
Specication
Order Information
Remarks
4
5
7
9
12
13
14

User’s Manual
4
/ Introduction
ALL9600 is a broadcast system to transmit AV signal (Audio + VGA) over
Cat5/5e/6 cable, it can reach the distance up to 300 meters and by stacking
more system Transceivers, the whole system can extend AV signal up to
900 meters.
You can broadcast the AV signal from PC, KVM switch, matrix AV switcher,
or use optional TV Box or converter to connect DVD or other multimedia
output devices. The video quality can be adjusted very easily from the
FOCUS and GAIN Control in the Receiver. Take the advantage of UTP
cable, ALL9600 can simplify the installation, extend the AV signal, and
centralize the multimedia server.
For single port unit, you can fix the unit very easily through its magnetic
pad and optional metal plate; for multiple port units, you can use the rack
mounting kit to lock your device in an industrial cabinet. ALL9600 is a
perfect extension solution for projector, plasma TV, LCD TV, LCD monitor,
HDTV, and CRT, as well as in the area of Digital Signage broadcasting.

5
/ Key Features
1. ALL9600 can send VGA and Audio signal from Transmitter over single
Cat5/5e/6 cable, and broadcast AV signal in Receiver. The standard
maximum broadcasting distance is 300 meters.
2. Remote and local monitors and speakers can broadcast simultaneously
3. Use Cat5 Enhance UTP cable (350MHz bandwidth) for best video quality
4. Receiver build in video GAIN and FOCUS control to adjust the video
quality.
5. Software free, pure hardware design, support Plug & Play
6. Support VGA, SVGA, XGA, TFT_LCD, LCD TV, PDP, Projector with
DDC2B function
7. Transmitter and Receiver build with LEDs to indicate system status
8. Stackable capacity to expand the AV broadcasting
9. Provides magnetic pad and attachable metal plate for single-port unit to
ease the installation
10. One-Port Transmitter ALL9600T:
(1) Built in one set of AV inputs (VGA + Audio)
(2) Built in one set of AV outputs (VGA + Audio) to monitor the AV signal
broadcasted
(3) Built in one RJ-45 port for system output which can be connected by
Cat5/5e/6 cable and send signal to System Receiver
(4) Take the power from USB or optional power adaptor

User’s Manual
6
11. Receiver ALL9600R::
(1) Receive AV signal through RJ45 port, and with video GAIN
and FOCUS control, you can adjust the video quality, the maximum
supported extended VGA resolution and distance up to
2048x1536@300m
(2) Built in one set of AV output (VGA + Audio) to monitor the AV signal

7
/ Panel Description
1. ALL9600T Single-Port AV Transmitter
2. ALL9600R Single-Port AV Receiver
❶
❷ ❸ ❹ ❺
❻ ❼
❽
❶ Power Indicator
❷ Power Jack
❸ VGA+Audio Output
❹ VGA+Audio+USB Power Input
❺ RJ-45 AV Output
❻ H. Sync Activity
❼ V. Sync Activity
❽ Magnetic Pad
❶
❷ ❸ ❹ ❺
❻ ❼
❽
❶ Power Indicator
❷ Power Jack
❸ VGA+Audio Output
❹ Video Control
❺ RJ-45 AV Output
❻ H. Sync Activity
❼ V. Sync Activity
❽ Magnetic Pad

User’s Manual
8
3. Cable and Accessories
CBK1510AU 3-in-1 cable for ALL9600T

9
/ Installation and Operation
1. ALL9600T Single-Port Transmitter Installation:
(1) Site Selection: In your rst time installation, place Transmitter near the
PC or AV devices (Audio and Video outputs); you can use magnetic
pad to attach the unit on metal plane (Ex. PC / Server Enclosure) or
use attachable rack mounting kit to fix the unit on selected area by
screw or nail.
Unit attached with Rack Mounting Kit and the Rack Mounting Kit
(2) Connecting Monitor and Speaker: Take a 3-in-1 cable (VGA + Audio
+ USB Power) to connect the signal from your AV device to the
“VGA+AUDIO IN” port of Transmitter box and then connect monitor and
speaker to the “VGA OUT” and “AUDIO” ports. The Transmitter can
take the power through the USB port or if you are using DVD Player
or other device without USB port, you can plug optional power adaptor
(AC7.5V, 1A ).
Installation Diagram of System Transmitter ALL9600T
VGA Audio USB
One-Port Transmitter
3-in-1 Cable

User’s Manual
10
(3) Function Test: Turn on your AV device, the POWER LED should turn
on green to indicate the POWER ON status and the LEDs above RJ-45
will blink before VGA signal is turned ON and remain ON after VGA
signal is turned ON.
2. Receiver ALL9600R installation and UTP Connection
(1) Site Selection: Please place Receiver in an appropriate place and have
the UTP cable settled for later connection.
(2) Power Up: Plug power adapter to the Receiver and connect monitor
and speaker to the VGA OUT and AUDIO port. The power LED will
turn on green to indicate the POWER ON status.
(3) Selection of UTP Cable: For best VGA resolution, please use Cat5
Enhanced cable (350MHz bandwidth) for connection, please note that
the maximum extended length of one section should not exceed 300
meters. The connector must be made by 568B/568B type.
The EIA/TIA denation of 568B in the pin assignment is
(1) orange white, (2) orange, (3) green white, (4) blue,
(5) blue white, (6) green, (7) brown white, and (8) brown
1 2 3 4 5 6 7 8
JACK POSITION
PAIR 1PAIR 2 PAIR 4
PAIR 3

11
(4) Connect UTP Cable: Plug two ends of UTP cable to Transmitter and
Receiver’sRJ45 UTP link ports, the Receiver’s connected monitor
and speaker should work now. You can adjust the FOCUS and GAIN
control of Receiver to have the best VGA display.
(5) Function Test: After above installation, you will be able to broadcast the
AV signal to Receiver’s connected monitor and speaker.
(6) Problem and Solving: If you find unstable image or audio problems
after installation, please confirm following list or contact your direct
vendor for further assistance:
a. Check if PC’s VGA resolution and frequency over the limit of monitor
display, if so, please change the VGA configuration from Windows
Control panel.
b. Try to connect Monitor and speaker directly to a PC, and ensure the
basic function of these devices.
c. When using LCD or same type monitor, there might have some image
offset or blinking, please adjust the position, clock or phase of the
LCD monitor, or simply press Auto Adjust / Tune to have a better
image solution.
3. Other Integration and Application
Please contact your local dealer or vender for further information.
One-Port Transmitter One-Port Receiver
VGA output Devices
Projector PDP LCD CRT
Use Cat5e cable
Max : 300M
VGA Audio USB
3-in-1 Cable
Installation Diagram of Receiver ALL9600R

User’s Manual
12
/ Specification
Spec AV Transceiver AV Receiver
Model ALL9600T ALL9600R
Description 1 Port Transmitter 1 Port Receiver
AV INPUT AV x 1 RJ45 x 1
AV OUTPUT AV x 1, RJ45 x1 AV x 1
Video CTRL -Video Gain and Focus
LED Two Color LEDs
Video Quality Maximum VGA Resolution and Distance : 2048 x 1536@300m
Dimension (LxWxH) 62 x113 x 29
Power Consumption USB DV5V Power or AC 7.5V 250mA DC 7.5V, 250mA
Environmental Condition • Operation Temp.: 0~50˚C • Storage Temp.: -20~60˚C • Humidity: 10~90%

13
/ Order Information
Order Details Part Number Remark
One-Port ALL9600 AV Transmitter ALL9600T AVU Cable x 1,
Rack-mount Kit x 1
One-Port ALL9600 AV Receiver ALL9600R With AC7.5V Power Adaptor x 1,
Rack-mount Kit x 1

User’s Manual
14
/ Remarks
(1) Before operating this system, please read operation manual carefully.
(2) Please use correct power adapter and use high quality cable for optimum
broadcasting.
(3) To prevent potential power damage, please don’t use 2 -wire extension
cord and ensure AC outlets at relative devices on the same electronic
phase and have correct grounding.
(4) Limited Warranty :
A. In no events shall the direct vendor’s liability for direct or indirect,
special, incidental or consequential damages, loss of profit, loss of
business, or financial loss which may be caused by the use of the
product exceeds the price paid for the product.
B. The direct vendor makes no warranty or representation, expressed
or implied with respect to the contents or use of this documentation,
and especially disclaims its quality, performance, merchantability, or
tness for any particular purpose.
C. The direct vendor also reserves the right to revise or update the
product or documentation without obligation to notify any user of such
revisions or updates. For further information, please contact your
direct vendor.

15

(C) 2006 ALLNET, All Rights Reserved
