ALLPOWER APGG6000C User manual

6000W Generator
Topi c Page
3ytnarraWdetimiL
5senilediuGytefaS
6snoituacerPlareneG
Battery 15
Assembly 16
Spark Plug Service 22
Operation 17
Inspection, Cleaning, Maintenance and Storage 23
Installation 29
Compliance 31
Specifications 32
33gnitsiLstraPlareneG
2

6000W Generator

5
Owner’s Manual
Safety Guidelines - Definitions
This manual contains important information that you need to know and
understand in order to protect YOUR SAFETY and to PREVENT
EQUIPMENTPROBLEMS.Thefollowingsymbolshelpyourecognizethis
information. Please read the manual and pay attention to these sections.
Save These Important Safety Instructions!
Readandunderstandallofthesesafetyinstructions.Be
sure to retain them for future use.
WARNING! WARNINGS INDICATE A CERTAINTY OR STRONG
POSSIBILITYOFPERSONALINJURYORDEATHIF
INSTRUCTIONS ARE NOT FOLLOWED.
CAUTION: CAUTIONS INDICATE A POSSIBILITY OF
EQUIPMENT DAMAGE IF INSTRUCTIONS ARE NOT
FOLLOWED.
NOTE: NOTES GIVE HELPFUL INFORMATION
WARNING! IMPROPER OPERATION OR MAINTENANCE
OFTHISPRODUCTCOULDRESULTINSERIOUSINJURY
AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL
WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING
THIS EQUIPMENT. WHEN USING AIR TOOLS, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE
THERISKOFPERSONALINJURY.

6
6000WGenerator
WARNING! THE EXHAUST CONTAINS POISONOUS CARBON MONOXIDE
GAS THAT CAN CAUSE LOSS OF CONSCIOUSNESS AND MAY LEAD TO
DEATH.
Gasoline and Oil
This product requiresoil and fuel. Attempting to start the enginewithout oilwill ruin
the engine and void the warranty. Work in well ventilated area. Keep cigarettes,
flames or sparks away fromthe work area or wheregasoline is stored.
WARNING! GASOLINE IS EXTREMELY FLAMMABLE AND IS EXPLOSIVE
UNDER CERTAIN CONDITIONS. KEEP OUT OF REACH OF CHILDREN.
• Gasoline fuel and fumes are flammable and potentially explosive. Use proper fuel storage and
handling procedures. Always have multiple ABC class fire extinguishers nearby.
General Precautions
WARNING! FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN
SEVERE INJURY OR DEATH.
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS CAN ALSO
RESULT IN DAMAGE TO THE TOOL AND/OR THE ITEM YOU ARE WORKING
ON.
DANGER
CARBON MONOXIDE
Using a generator indoors WILL KILL YOU IN MINUTES.
Generator exhaust contains high levels of carbon monoxide (CO), a poisonous gas you cannot
see or smell. If you can smell the generator exhaust, you are breathing CO. But even If you
cannot smell the exhaust, you could be breathing CO.
· NEVER use a generator inside homes, garages, crawlspaces, or other partly enclosed areas.
Deadly levels of carbon monoxide can build up in these areas. Using a fan or opening windows
and doors does NOT supply enough fresh air.
· ONLY use a generator outdoors and far away from open windows, doors, and vents. These
openings can pull in generator exhaust.
Even when you use a generator correctly, CO may leak into the home. ALWAYS use a battery-
powered or battery-backup CO alarm in the home.
If you start to feel sick, dizzy, or weak after the generator has been running, move to fresh air
RIGHT AWAY. See a doctor. You could have carbon monoxide poisoning.
• Keepthegenerator and surrounding area clean at alltimes.

Owner’s Manual
7
General Precautions (cont’d)
Gasoline and Oil (cont’d)
• Do not smoke, or allow sparks, flames or other sources of ignition around the engine and fuel
tank. Fuel vapors are explosive.
• Keep grounded conductive objects, such as tools, away from exposed, live electrical parts and
connections to avoid sparking or arcing. These events could ignite fumes or vapors.
• Do not refill the fuel tankwhile the engine is running or whilethe engine is still hot. Do not
operatethe generator withknown leaks in the fuelsystem
• Excessive buildup of unburned fuel gases in the exhaust system can create a potentially
explosive condition. This buildup can occur after repeated failed start attempts, valve testing, or
hot engine shutdown. If this occurs, open exhaust system drainplugs, if equipped, and allow the
gases to dissipate before attempting to restart the generator.
• Use only engine manufacturer recommended fuel and oil.
Hot Components
WARNING! ENGINE AND EXHAUST SYSTEM PARTS BECOME VERY
HOT AND REMAIN HOT FOR SOME TIME AFTER THE ENGINE IS RUN. WEAR
INSULATED GLOVES OR WAIT UNTILTHE ENGINE AND EXHAUST SYSTEM
HAVE COOLED BEFORE HANDLINGTHESE PARTS.
Power Output
Thisgenerator is not designed to power sensitive electronicequipment (including computers
and medical devices) without the addition of an approved line conditioner, which is sold separately.
CAUTION: ATTEMPTING TO POWER SENSITIVE ELECTRONIC EQUIPMENT
WITHOUT THE USE OF AN APPROVED LINE CONDITIONER MAY CAUSE
DAMAGE TO THE EQUIPMENT. ALL-POWER IS NOT RESPONSIBLE
FOR ANY DIRECT OR INDIRECT DAMAGE CAUSED BY FAILURE TO USE AN
APPROVED LINE CONDITIONER.
• Fuel or oil spills must be cleaned up immediately. Dispose of fluids and cleaning materials as per
any local, state, or federal codes and regulations. Store oily rags in a covered metal container.
• Never storefuel or other flammable materials near the generator.
Fuel:
Fuel capacity is 6.6 US gallons(25 L). Use regular
unleaded gasoline with a minium octane rating of 90.
Oil:
Oil capacity is 1.16 qt(1.1 L)

8
6000WGenerator
General Precautions (cont’d)
Work Area
• Keep your work area clean and welllit. Cluttered benches and dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust.Generators create sparkswhich may ignite thedust or fumes.
• Keep bystanders, children, and visitors away while operating a generator. Provide barriers or
shields as needed.
Electrical Safety
• Grounded tools must be plugged into an outlet properlyinstalledand
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify theplug in any way. Do not use any adapter
plugs.
• Grounding provides a low-resistance path to carry electricity away from the
user in the event of an electrical malfunction.
• Double insulated tools are equipped with a polarized plug where one blade is wider than the
other. This plug fits in a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized outlet.
Do not change theplug in any way. Doubleinsulation eliminates the need for the three-wire
grounded power cord and grounded power supply system.
• Avoid body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerators.
There is an increasedrisk of electric shock if your body is grounded.
• Do not expose generator to rain or wet conditions. Water entering a generator will increase the
risk of electricshock.
• Do not abuse the power cord. Keep power cords away from heat, oil, sharp edges, or moving
parts. Replace damaged power cordsimmediately. Damaged power cords increase the risk of
electric shock.
• When operating a power tool outside, use an outdoor extension cord marked “W-A” or “W”.
These extension cords are rated for outdoor use, and reduce the risk of electricshock.

9
Owner’s Manual
General Precautions (cont’d)
Electrical Safety (cont’d)
• All connections and conduits from the generator to the load must only be installed by trained and
licensed electricians, and in compliance with allrelevantlocal,state,andfederalelectrical
codes and standards, and other regulations where applicable.
• The generator must be earth-grounded for fixed installations in accordance with all relevant
electricalcodesandstandardsbeforeoperation.
•Donotattempttoconnectordisconnectloadconnectionswhilestandinginwater,oronwetor
soggy ground.
•Donottouchelectricallyenergizedpartsofthegeneratorandinterconnectingcablesor
conductorswithanypartofthebody,orwithanynon-insulatedconductiveobject.
•Connectthegeneratoronlytoaloadorelectricalsystem(120volt)thatiscompatiblewiththe
electrical characteristics and rated capacities of the generator.
• Before servicing equipment powered by the generator, disconnect the equipment from its power
input.
•Keepallelectricalequipmentcleananddry.Replaceanywiringwheretheinsulationiscracked,
cut abraded or otherwise degraded. Replace terminals that are worn, discolored, or corroded.
Keep terminals clean and tight.
• Insulate all connections and disconnected wires.
•Guardagainstelectricshock.Preventbodycontactwithgroundedsurfacessuchaspipes,
radiators, ranges, and refrigerator enclosures.
Personal Safety
•Stayalert.Watchwhatyouaredoing,andusecommonsensewhenoperatingagenerator.Do
notusegeneratorwhiletiredorundertheinfluenceofdrugs,alcohol,ormedication.Amoment
of inattention while operating generators may result in serious personal injury.
•Dressproperly.Donotwearlooseclothingorjewelry.Containlonghair.Keepyourhair,clothing,
andglovesawayfrommovingparts.Looseclothes,jewelry,orlonghaircanbecaughtin
moving parts.

6000WGenerator
General Precautions (cont’d)
Personal Safety (cont’d)
• Avoid accidental starting. Make sure the power switch is in its “OFF” position, and disconnect
the sparkplugwirewhen not in use.
• Remove adjusting keys or wrenches before turning the generator on. A wrench or a key that is
left attached to a rotating part of thegenerator may result in personalinjury.
• Do not overreach. Keep proper footing and balance at all times.
• Use safety equipment. Always wear eye protection. Wear ANSI approved safety impact eye
goggles. Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for
appropriate conditions.
• Do not force the generator. Use the correct generator for your application. The correct generator
willdothejob better and safer at the rate for which it is designed.
• Do not use the generator if the power switch does not turn it on or off. Any generator that cannot
be controlledwiththe power switch is dangerous and must be replaced.
Generator Use andCare
Make sure the power switch is in its “OFF” position and disconnect the spark plugwire before
making any adjustment, changing accessories, or storing thegenerator. Such preventive safety
measures reduce the risk of starting thegenerator accidentally.
Store idle generators out of reach of children and other untrained persons. Generators are
dangerous in the hands of untrained users.
Maintain generators with care. Do not use damaged generator. Tag damaged generators “Do not
use” until repaired.
Check for misalignment or binding of moving parts, breakage of parts, and any other condition that
may affect the generator’s operation. If damaged, have the generator serviced before using. Many
accidents are caused by poorlymaintainedgenerators.
Use only accessories that are recommended by the manufacturer for your model. Accessories that
may be suitable for one generator may become hazardous when used on another generator.
10

Owner’s Manual
General Precautions (cont’d)
Servicing
Maintain labels and name plates on the generator and engine. These carry important information.
If unreadable or missing, contact our service center toll free at 888-896-6881 immediately for a
replacement.
Generator service must be performed only qualified repair personnel. Service or maintenance
performed by unqualified personnel could result in a risk of injury.
Whenservicingagenerator,useonlyidenticalreplacementparts.Followallappropriate
instructions in this manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
Heart Pacemakers
WARNING!PEOPLEWITHPACEMAKERSSHOULDCONSULTTHEIR
PHYSICIAN(S) BEFORE USING THIS PRODUCT. ELECTROMAGNETIC
FIELDS IN CLOSE PROXIMITY TO A HEART PACEMAKER COULD CAUSE
INTERFERENCE TO OR FAILURE OF THE PACEMAKER.
Installation
• Ensure installation meets all applicable safety, and local and national electrical codes. Have
installation performed by a qualified, licensed electrician and building contractor.
• All electrical work, including the earth-ground connection, should be completed by a licensed
electrician.
•Anyseparatefuelstorageorgeneratorsupplyfacilitymustbebuiltorinstalledinfullcompliance
withallrelevantlocal,state,andfederalregulations.
11

12
6000WGenerator
General Precautions (cont’d)
Installation (cont’d)
• If the generator is installed outdoors, it must be weatherproofed and should be soundproofed. It
should not be run outdoors without protection to the generator and wiring conduit.
• The generator weighs 100 lbs (approx). Two or more peopleshould assistwhen moving or lifting
thisproduct. Never lift the generator using the engine or alternatorlifting lugs. Connect lifting
equipment to the frame of the generator
• Beforelifting the generator, ensure the lift rigging and supporting structure are in good
condition, and are rated to lift such a load.
• Keep all personnel away fromthe suspended generator during relocating.
• The supporting floor/ground surface should be level and strong enough to safely hold the weight
of the generator. If the floor/grounded surface is not level, strong cross members should be
placed under the full length of the generator frame at its low side.
• For trailerinstallation, the generatorshould be mounted on the center point of the trailer, over
the wheels. The trailer must be capable of supporting the weight of the generator and all
contents (tools, etc.)
• Install sound-and weather-proofing only when it is not raining or snowing to avoid trapping
moisture withinthegenerator’s area.
Mechanical
• Always make sure the power switch is in its “OFF” position. Disconnect the spark plugwire, and
allow the engine to completely cool before carrying out maintenance.
• Check for damaged parts. Before using the generator, any part that appears damagedshould
be carefully checked to determine that it will operateproperly and perform its intended function.
Check for alignment and binding of moving parts, any broken parts or mountingfixtures,and any
other condition that may affect proper operation technician.
• The generator is designed with guards for protection from moving parts. In any case, care must
still be taken to protect personnel and equipment from other mechanical hazards when working
around the generator.

Owner’s Manual
General Precautions (cont’d)
Mechanical (cont’d)
• Do not operate the generator with safety guards removed. While the generator is running, do not
attempttoreacharoundthesafetyguardformaintenanceoranyotherreason.
•Keephands,arms,longhair,looseclothing,andjewelryawayfrommovingparts.Beawarethat
when engine parts are moving fast they cannot be seen clearly.
•Keepaccessdoorsonenclosuresclosedandlockedwhenaccessisnotrequired.
• When working on or around the generator always wear protective clothing including ANSI
approvedsafetygloves,safetyeyegoggles,andsafetyhat.
•Donotalteroradjustanypartofthegeneratorthatisassembledandsuppliedbythe
manufacturer.
• Always follow and complete scheduled engine and generator maintenance.
Chemicals
•Avoidcontactwithhotfuel,oil,exhaustfumes,andhotsolidsurfaces.
•Avoidbodycontactwithfuels,oils,andlubricants used in the generator. If swallowed, seek
medical treatment immediately. Do not induce vomiting if fuel is swallowed. For skin contact,
immediately wash with soap and water. For eye contact, immediately flush eyes with clean water
and seek medical attention.
Noise
• Prolonged exposure to noise levels above 68 DBA is hazardous to hearing. Always wear ANSI
approved ear protection when operating or working around the generator when it is running.
13

6000WGenerator
General Precautions (cont’d)
Extension Cord
If an extension cord (not included) is used, make sure to use only UL approved cords having the
correct gauge and length according to the following table:
Cord LengthsNameplate Amps (@ full load)
0 - 5 16 16 12 12
5.1 - 8 16 14 10 -
8.1 - 12 14 12 - -
12.1 - 15 12 10 - -
15 - 20 10 10 - -
14
0 ft.- 50 ft. 50 ft.-100 ft. 100 ft.-150 ft. 150 ft.-200 ft.
AWG AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG
AWG

Owner’s Manual
15
Battery
This product does not need a battery.

6000WGenerator
16
Assembly
Unpacking
1. Remove the generator andloose parts box from thecarton.
2. Compare the accessory with the inventory list below.
Loose Parts (Wheel kit and handle)
Checkall loose parts against the following list. Contact your dealertoll free at 888.896.6881
if any of the loose parts shown are not included with your generator
Hardware Check:
Your Hardware Kit should include:
1) Two Handles with bolts, nuts, pin with chain and brackets
2) One axle shaft with bolts and nuts
3) Two washers
4) Two cotterpins
5) One generator leg with bolts and nuts
6) Two wheels
3
4
2
5
1
6

17
Owner’s Manual
Operation
NOTE: THE PARTS LISTED ABOVE ARE HELPFUL FOR LOCATING THE
CONTROLS MENTIONED BELOW.
CAUTION: PRIOR TO FIRST USING THE GENERATOR, THE ENGINE MUST BE
FILLED WITH OIL OF A HIGH QUALITY SAE 10W-30 GRADE ENGINE OIL.
TO DO SO, UNSCREW AND REMOVE THE ENGINE’S OIL DIPSTICK LOCATED
AT THE BOTTOM OF THE ENGINE CRANKCASE. FILL THE ENGINE’S
CRANKCASE UNTIL THE OIL LEVEL IS LEVEL WITH THE UPPER MARKED
LINE ON THE DIPSTICK. THEN SCREW THE DIPSTICK BACK INTO
THE OIL FILL HOLE.
Before Starting the Generator
1. Check that the engine power switch is in its
Fuel tank capacity:25L(6.6 gallons)
Choke lever
Air Filter
Recoil Starter
Oil Plug
Handel
Control Panel
Fuel Tank
“OFF” position.
2. Beforethe first use, remove the fuel
tank cap and fill the fuel tank with unleaded
gasoline. When fueling, be sure that the
fuelstrainer is in place. Replace the fuel
tank cap. Thereafter, check the engine’s
fuelgauge for the amount of unleaded
gasoline in the fuel tank. If necessary,
refill the fuel tankwithunleaded gasoline;
the generator must be turned off and
cooled down before refilling the fuel tank.
Use gasoline with a pump octane rating of 90 or higher.
We recommend unleaded gasoling because it produces
fewer engine and spark plug deposits and extends
exhaust system life.
Never use stale or contaminated gasoline or oil/gasoline
mixture. Avoid getting dirt or water in the fuel tank.

18
Operation (cont’d)
Starting
1. Turn the engine switch to the “RUN” position.
The engine switch enables and disables the ignition
system.
STOP: To stop the engine
RUN: To run the engine
2. The fuel valve is located under the fuel tank . When
the valve lever is in the ON position, fuel is allowed
to flow from the fuel tank to the carburetor. Be sur
to return the fuel valve lever to the OFF position after
stopping the engine.
3. To start a cold engine, move the choke lever to the
“Start” position. To restart a warm engine, leave the
choke lever in the “RUN” position.
The choke lever opens and closes the choke valve in
the carburetor.
The “Start” position enriches the fuel mixture from
starting a cold engine.
The “RUN” position provides the correct fuel mixture
for operation after starting, and for restarting a warm
engine.
6000WGenerator
STOP
RUN
Choke Lever
(“Start position”)
ON
OFF

19
Operation (cont’d)
Starting
Stopping Engine
4. Operate the Recoil Starter:
Pull the starter grip lightly until you feel resistance,
then pull briskly. Return the starter grip gently.
Pulling the starter grip operates the recoil starter to
crank the engine
5. If the choke has been moved to the “Start”
position to start the engine, gradually move it to the
“Run” position as the engine warms up.
1. Turn the engine switch to the “Stop” position.
2. Turn the fuel valve lever to the OFF position.
When the engine is not in use, leave the fuel valve in
the OFF position to prevent carburetor flooding and to
reduce the possibility of fuel leakage.
STOP
Owner’s Manual
Starter Grip
“Run” Position
ON
OFF

20
Operation (cont’d)
Powering 120 Volt AC Tools And Equipment:
1. Prior to powering tools and equipment, make sure the generator’s rated voltage, and amperage
capacity (120 V AC @ 41.7 AMPs) is adequate to supply all electrical loads that the unit will
power. If powering exceeds the generator’s capacity, it may be necessary to group one or more
of the toolsand/or equipment for connection to a separategenerator.
CAUTION: ATTEMPTING TO POWER SENSITIVE ELECTRONIC EQUIPMENT
WITHOUT THE USE OF AN APPROVED LINE CONDITIONER MAY CAUSE
DAMAGE TO THE EQUIPMENT. ALL-POWER IS NOT RESPONSIBLE FOR
ANY DIRECT OR INDIRECT DAMAGE CAUSED BY FAILURE TO USE AN
APPROVED LINE CONDITIONER.
2. Once the generator is running, simply connect the power cords of 120 volt AC powered
tools and equipment into the 120 volt AC dual outlets.
NOTE:THEGENERATORFEATURESAN AC NON-FUSETHERMAL PROTECTOR
TOPROTECTTHE AC CIRCUITIN CASEOFAN OVERLOAD.SHOULD
AN OVERLOADOCCUR,THEBREAKERWILL POP.
3.Disconnect all electrical powered tools and equipment from the generator’s 120 volt AC
duel outlets.
4.After the engine and generator have completely cooled, store generator in a safe,clean,dry
location (if not already installed).
6000WGenerator
