PREFACE
Thank you for purchasing an ALL POWER AMERICA generator. This manual covers operation and maintenance of the 2000 watt digital
generator. All information in this publication is based on the latest product information available at the time of approval for printing. ALL POWER AMERICA LLC reserves the right to make changes at any time without notice and without incurring any obligation. No part of this publication may be reproduced without written permission. This manual should be considered a permanent part of the generator and should remain with it if it is resold. Pay special attention to statements preceded by the following words;
Indicates a strong possibility of severe personal injury or death if instructions are not followed. Indicates a possibility of personal injury or equipment damage if instructions are not followed.
NOTE: Gives helpful information. If a problem should arise, or if you have any questions about the generator, consult an authorized ALL POWER AMERICA dealer.
This generator is designed to give safe and dependable service if operated according to instructions. Read and understand the Owner's Manual before operating the gen- erator. Failure to do so could result in personal injury or equipment damage.
The illustration may vary according to the type.
WARNING
CAUTION
WARNING
1. SAFETY INSTRUCTIONS 2. SAFETY LABEL LOCATIONS 3. COMPONENT IDENTIFICATION 4. PRE-OPERATION CHECK 5. STARTING THE ENGINE High altitude operation 6. GENERATOR USE 7. STOPPING THE ENGINE 8. MAINTENANCE 9. TRANSPORTING/STORAGE 10. TROUBLESHOOTING 11. SPECIFICATIONS 12. ELECTRICAL WIRING DIAGRAM 13. LIGHT KIT
CONTENTS
1 3 5 9
13 16 17 24 26 31 33 35 36 37

1. SAFETY INSTRUCTIONS
To ensure safe operation
WARNING
This generator is designed to give safe and depend-
Read and understand the Owner's Manual before op- erating the generator. Failure to do so could result in
WARNING WARNING
able service if operated according to instructions.
personal injury or equipment damage.
Exhaust gas contains poisonous carbon monoxide. Never run the generator in an enclosed area. Be sure to provide adequate ventilation.
The muffler becomes very hot during operation and
remains hot for a while after stopping the engine.
Be careful not to touch the muffler while it is hot. Let the engine cool before storing the generator indoors. The engine exhaust system will be heated during
operation and remain hot immediately after stopping the engine.
To prevent scalding, pay attention to the warning marks
attached to the generator.
WARNING
SAFETY INSTRUCTIONS To ensure safe operation --
Gasoline is extremely flammable and explosive under certain conditions.
Refuel in a well ventilated area with the engine stopped.
Keep away from cigarette, smoke and sparks when refueling the
generator, Always refuel in a well-ventilated location.
Wipe up spilled gasoline at once.
WARNING
Connections for standby power to a building's
electrical system must be made by a qualified electrician and must comply with all applicable laws and electrical codes. Improper connections can allow electrical current from the generator to back feed into the utility lines. Such back feed may electrocute utility company workers or others who contact the lines during a power outage, and when utility power is restored, the generator may explode, burn, or cause fires in the building's electrical system.
WARNING
Always make a pre-operation inspection (page 9) before you start the
engine. You may prevent an accident or equipment damage.
Place the generator at least 1m(3ft) away from buildings or other
equipment during operation.
Operate the generator on a level surface. if the generator is tiled, fuel
spillage may result.
Know how to stop the generator quickly and understand operation of all
the controls. Never permit anyone to operate the generator without proper instructions.
Keep children and pets away from the generator when it is in operation. Keep away from rotating parts while the generator is running.
The generator is a potential source of electrical shocks when misused; do
not operate with wet hands.
Do not operate the generator in rain or snow and do not let it get wet.

2. SAFETY LABEL LOCATIONS
These lables warn you potential hazards that can cause serious injury. Read the labels and safety notes and precautions described in manual carefully. If a label is lost or becomes unreadable, contact your ALL POWER AMERICA
dealer for a replacement.
CHOKE LEVER
OIL ALERT
ENGINE SWITCH
HOT CAUTION
SAFETY CAUTION

3. COMPONENT IDENTIFICATION
Record the frame serial number in the space below. You will need this serial number when ordering pars. Frame serial number:
ENGINE SWITCH
FUEL CAP VENT LEVER
CHOKE LEVER
FUEL FILLER CAP
MAINTENANCE COVER
CONTROL PANEL
STARTER GRIP
Frame serial number
SPARK PLUG MAINTENANCE COVER
MUFFLER
Control panel E type
OIL ALERT INDICATOR LIGHT
SMART-THROTTLE SWITCH
OUTPUT INDICATOR LIGHT
OVERLOAD INDICATOR LIGHT
DC RECEPTACLE
GROUND TERMINAL
DC CIRCUIT PROTECTOR
AC RECEPTACLE

A type (120V) Aus type J type A type (240V)
AC RECEPTACLE AC RECEPTACLE
AC RECEPTACLE
AC RECEPTACLE
Smart throttle Engine speed is kept at idle automatically when the electrical appliance is disconnected and it returns to the proper speed to power of the electrical load when electrical appliance is connected. This position is recommended to minimize the fuel consumption while in operation.
WARNING
Smart throttle system does not operate effectively, if the electrical appliance requires the momentary electric power. When high electrical loads are connected simultaneously, turn the Smart- throttle switch to the OFF position to reduce voltage vibration. In DC operation, turn the Smart-throttle switch to the OFF position.
OFF: Smart-throttle system does not operate. Engine speed is kept over rated speed.
ON
OFF
OFF
ON

4. PRE-OPERATION CHECK
WARNING
Use high-detergent, premium quality 4-stroke engine oil, certified to meet or exceed U.S. automobile manufacturer's requirements for API Service Classification SG, SF. Select the appropriate viscosity for the average temperature in your area. Loosen the cover screw and remove the left side maintenance cover. Remove the oil filler cap, and wipe the dipstick with a clean rag. Check the oil level by inserting the dipstick in the filler hole without screwing it in. If the oil level is below the end of the dipstick, refill the recommended oil up to the top of the oil filler neck.
1. Check the engine oil level.
WARNING
Using nondetergent oil or 2-stroke engine oil could shorten the engine's service
life.
Running the engine with insufficient oil can cause serious engine damage.
Be sure to check the generator on a level surface with the engine stopped.
WARNING
NOTE: The Oil Alert System will automatically stop the engine before the oil level falls below the safe limit. However, to avoid the inconvenience of an unexpected shutdown, it is still advisable to visually inspect the oil level regularly.
OIL FILLER HOLE
WARNING
Gasoline is extremely flammable and is explosive under certain conditions. Refuel in a well-ventilated area with the engine stopped. Do not smoke or
allow flames or sparks in the area where the engine is refueled or where gasoline is stored.
Do not overfill the fuel tank (there should be no fuel above the upper limit mark).
After refueling, make sure the tank cap is closed properly and securely.
Be careful not to spill fuel when refueling. Spilled fuel or fuel vapor may ignite,
If any fuel is spilled, make sure the area is dry before starting the engine.
Avoid repeated or prolonged contact with skin or breathing of vapor. KEEP
OUT OF REACH OF CHILDREN.
2. Check the fuel level. Use automotive gasoline (Unleaded or lowleaded is preferred to minimize combustion chamber deposits). If the fuel level is low, refuel the fuel tank until the level increased to the specified mark. Never use an oil/gasoline mixture or dirty gasoline. Avoid getting dirt, dust or water in the fuel tank. After refueling, tighten the fuel filler cap seurely.
UPPER LEVEL
OIL FILLER CAP
AMBIENT TEMPERATURE
SAE Viscosity Grades
10W
20W
20
30
40
-20- -10 0 10 20 30 40
0 20 40 60 80 100 F
SINGLE VISCOSITY MULTI VISCOSITY

Gasolines containing alcohol If you decide to use a gasoline containing alcohol (gasohol), be sure it's octane rating is as high as that recommended by ALL POWER AMERICA. The two types of gasohol contain either ethanol or methanol. Do not use gasohol that contains more than 10% ethanol.
Do not use gasoline containing methanol (methyl or wood alcohol) that does not also contain cosolvents and corrosion inhibitors for methanol. Never use gasoline containing more than 5% methanol, even if it has cosolvents and corrosion inhibitors.
Fuel tank capacity: 3.7 liter
UPPER LIMIT MARK
NOTE
Fuel system damage or engine performance problems resulting from the use of fuels that contain alcohol is not covered under the warranty. ALL POWER AMERICA cannot endorse the use of fuels containing methanol since evidence of their suitability is as yet incomplete. Before buying fuel from an unfamiliar station, try to find out if the fuel contains alcohol, if it does, confirm the type and percentage of alcohol used. If you notice any undersirable operating symptoms while using a gasoline that contains alcohol, or one that you think contains alcohol, replace it by a gasoline that you know does not contain alcohol.
FUEL FILLER CAP
OPEN
3. Check the air cleaner. Check the air cleaner element to be sure it is clean and in good condition. Loosen the cover screw and remove the left side maintenance cover. Press the latch tab on the top of the air cleaner body, remove the air cleaner cover, check the element. Clean or replace the element if necessary.
CAUTION
Never run the engine without the air cleaner. Rapid engine wear will result from contaminants, such as dust and dirt, being drawn through the carburetor, into the engine.
AIR CLEANER ELEMENTS
AIR CLEANER BODY
AIR CLEANER COVER
AIR CLEANER COVER SCREW
MAINTENANCE COVER
MAINTENANCE COVER SCREW

5. STARTING THE ENGINE
Before starting the engine, disconnect any load from the AC receptacle. 1.Turn the fuel cap lever fully clockwise to the ON position. NOTE: Turn the fuel cap vent lever to the OFF position when transporting the generator.
FUEL CAP VENTLEVER
ENGINE SWITCH
2.Turn the engine switch to the ON position.
ON
ON OFF
ON
4. Pull the starter grip until resistance is felt, the pull the starter grip briskly toward the
arrow as shown below.
3. Move the choke lever to the START position. NOTE: Do not use the choke when the engine is warm or the air temperature is high.
CAUTION
Do not allow the starter grip to snap back, Return it slowly by hand.
STARTER GRIP
CHOKE LEVER
START
START

5.Move the choke lever to the RUN position after the engine warms up.
NOTE
If the engine stops and will not restart, check the engine oil level before troubelshooting in other areas.
High altitude operation At high altitude, the standard carburetor air-fuel mixture will be excessively rich. Performance will decrease, and fuel consumption will increase. High altitude performance can be improved by installing a smaller diameter main fuel jet in the carburetor and readjusting the pilot screws. If you always operate the generator at altitudes higher than 1,500 m (5,000 feet) above sea level, have your authorized ALL POWER AMERICA service center perform these carburetor modifications. Even with suitable carburetor jetting, engine horsepower will decrease approximately 3.5% for each 300m (1,000 feet) increase in altitude. The affect of altitude on the horsepower will be greater than this if no carburetor modification is made.
CAUTION
Operation of the generator at an altitude lower than the carburetor is jetted for may result in reduced performance, overheating, and serious engine damage caused by an excessively lean air/fuel mixture.

6. GENERATOR USE
WARNING
To prevent electrical shock from faulty appliances, the generator should be
grounded. Connect a length of heavy wire between the generator's ground teminal and an external ground source.
Connections for standby power to a building's electrical system must be made
by a qualified electrician and must comply with all applicable laws and electri- cal codes. Improper connections can allow electrical current from the generator to backfeed into the utility lines. Such backfeed may electrocute utility company workers or others who contact the lines during a power outage, and when utility power is restored, the generator may explode, burn, or cause fires in the building's electrical system.
Be sure to ground the generator when the connected equipment is grounded.
GROUND MARK
GROUND TERMINAL
CAUTION
Do not exceed the rated power. The total wattage of all appliances connected must be considered. Do not exceed the current limit specified for any one receptacle. Do not connect the generator to a household circuit. This could cause the damage to the generator or to electrical appliances in the house. Do not modify or use the generator for other purpose than it is intended for. Also observe the following when using the generator. Do not connect an extension to exhaust pipe. When an extension cable is required, be sure to use a rubber sheathed flexible cable (IEC 245 or equivalent).
2
Limit length of extension cables; 60m for cables of 1.5mm and 100m for
2
cables of 2.5mm . Long extension cables will reduce usable power due to resistance in the extension cable. Keep the generator away from other electric cables or wires such as commercial power supply lines.
NOTE
The DC receptacle can be used while the AC power is in use. If you use both at the same time, be sure not to exceed the total power for AC and DC. Most appliance motors require more than their rated wattage for start-up.

AC applications 1. Start the engine and make sure the output indicator light (green) flash. 2.Confirm that the appliance to be used is switched off, and plug in the appliance.
PLUG
CAUTION
Substantial overloading that continuously lights the overload indicator light (red) may damage the generator. Marginal overloading that temporarily lights the overload indicator light (red) may shorten the service life of the generator. Be sure that all appliances are in good working order before connecting them to the generator. If an appliance begins to operate abnormally, becomes sluggish, or stops suddenly, turn off the generator engine switch immediately. Then disconnect the appliance, and examine it for signs of malfunction.
OUTPUT INDICATOR LIGHT
OVERLOAD INDICATOR LIGHT
Output and Overload Indicators The output indicator light (green) will remain flash during normal operating conditions. If the generator is overloaded (in excess of 1.6KVA), or if there is a short in the connected appliance, the output indicator light (green) will go OFF, the overload indicator light (red) will go ON and current to the connected appliance will be shut off. Stop the engine if the overload indicator light (red) comes ON and investigate the overload source
Before connecting an appliance to the generator, check that it is in good order, and
that its electrical rating does not exceed that of the generator. Then connect the power cord of the appliance, and start the engine.
NOTE
When an electric motor is started, both the overload indicator light (red) and the output indicator light (green) may go on simultaneously. This is normal,if the red overload indicator light goes off after about four (4) seconds. If the red overload indicator light stays on, consult your local generator dealer.
OUTPUT INDICATOR LIGHT (GREEN) OVERLOAD INDICATOR LIGHT (RED)
3. In order to acquire both the best effect and the maximum service life of the generator. Usually, the new generator should run 20 hours under 50% load, the generator may reach the best performance.

DC application The DC receptacle may be used for charging 12 volt automotive-type batteries only. The zero load voltage is 15V-30V.
NOTE
In DC operation, turn the Smart-throttle switch to the OFF position.
1. Connect the charging cables to the DC receptacle of the generator and then to the ba- ttery terminals.
WARNING
To prevent the possibility of creating a spark near the battery, connect charging
cable first to the generator, then to the battery. Disconnect cable first at the battery.
Before connecting charging cables to a battery that is installed in a vehicle,
disconnect the vehicles grounded battery cable. Reconnect the vehicle's grounded battery cable after the charging cables are removed. This procedure will prevent the possibility of a short circuit and sparks if you make accidental contact between a battery terminal and the vehicle's frame or body.
CAUTION
Do not attempt to start an automobile engine with the generator still connected to the battery. The generator may be damaged. Connect the positive battery terminal to the positive charging cord. Do not re- verse the charging cables, or serious damage to the generator and/or battery may occur.
WARNING
The battery gives off explosive gases; keep spark, flames and cigarettes away.
Provide adequate ventilation when charging.
The battery contains sulfuric acid (electrolyte). Contact with skin or eyes may
cause severe burns. Wear protective clothing and a face shield.
-If electrolyte gets on your skin, flush with water. -If electrolyte gets in your eyes, flush with water for at least 15 minutes and call
a physician.
Electrolyte is poisonous. -If swallowed, drink large quantities of water or milk and follow with milk of
magnesia or vegetable oil and call a physician.
KEEP OUT OF REACH OF CHILDREN.
2. Start the engine
NOTE
The DC receptacle may be used while the AC power is in use. An overloaded DC circuit will trip the DC circuit protector. If this happens, wait
a few minutes before pushing in the circuit protector to resume operation.
ON OFF
CHARGING CABLE (SOLD SEPARATELY)
DC CIRCUIT PROTECTOR

Oil alert system The oil alert system is designed to prevent engine damage caused by an insufficient amount of oil in the crankcase. Before the oil level in the crankcase falls below a safe limit, the oil alert system will automatically shut down the engine(the engine switch will remain in the ON position). If the oil alert system shuts down the engine, the oil alert indicator light(red) will come on when you operate the starter, and the engine will not run. If this occurs, add engine oil.
OIL ALERT INDICATOR LIGHT (red)
7. STOPPING THE ENGINE
To stop the engine in an emergency, turn the engine switch to the OFF position. IN NORMAL USE: 1.Switch off the connected equipment and pull the inserted plug out. 2.Turn the engine switch to the OFF position
PLUG
ENGINE SWITCH
ON OFF
OFF

3. Allow the engine to cool well, and turn the fuel cap lever fully counterclockwise to the
OFF position.
FUEL CAP LEVER
CAUTION
Be sure both the fuel cap lever and the engine switch are in "OFF" position when stopping, transporting and/or storing the generator.
8. MAINTENANCE
The purpose of the maintenance and adjustment schedule is to keep the generator in the best operating condition. Inspect or service as scheduled in the table below.
WARNING
Shut off the engine before performing any maintenance. If the engine must be
run, make sure the area is well ventilated. The exhaust contains poisonous carbon monoxide gas.
CAUTION
Use genuine ALL POWER AMERICA parts or their equivalent. The use of re- placement parts which are not of equivalent quality may damage the generator.
NOTE: (1) Service more frequently when used in dusty areas.
(2) These items should be serviced by your servicing dealer, unless you have the proper tools and
are mechanically proficient. Refer to shop manual for service procedures.
(3) For commercial use, log hours of operation to determine proper maintenance intervals.
ITEM Perform at every indicated month or operating hour interval, which- ever comes first.
REGULAR SERVICE PERIOD(3)
Fuel line Check
Check level Change Check
Clean
Check-adjust Replace Clean Check-adjust Clean
Engine oil
Air cleaner
Spark plug Combustion chamber Valve clearance Fuel tank and filter
EVERY
YEAR
OR
200 HRS
EACH
USE
FIRST
MONTH
OR
20HRS
EVERY 3
MONTHS
OR
50HRS
EVERY 6
MONTHS
OR
100 HRS
(1)
Every 300Hrs. (2)
(2)
(2)
Every 2 years (Replace if necessary) (2)
Maintenance Schedule
OFF

1. CHANGING OIL Drain the oil while the engine is still warm to assure rapid and complete draining.
1. Loosen the cover screw and remove the left side maintenance cover. 2. Remove the oil filler cap. 3. Drain dirty oil into a container thoroughly. 4. Refill with the recommended oil, and check the oil level. 5. Reinstall the left side maintenance cover and tighten the cover screw securely. Engine oil capacity: 0.4L (0.42USQT, 0.35LMQT)
Make sure to turn the engine switch and the fuel cap vent lever OFF before
draining.
CAUTION
Wash your hands with soap and water after handing used oil.
NOTE
Please dispose of used motor oil in a manner that is compatible with the environment. We suggest you take it in a sealed container to your local service station for reclamation. Do not throw it in the trash or pour it on the ground.
2. AIR CLEANER SERVICE A dirty air cleaner will restrict air flow to the carburetor. To prevent carburetor malfunc- tion, service the air cleaner regularly. Service more frequently when operating the generator in extremely dirty areas.
1. Loosen the cover screw and remove the left side maintenance cover. 2. Remove the air cleaner cover. 3. Wash the element in a non-flammable or high flash point solvent and dry it thoroughly. 4. Soak the element in clean engine oil and squeeze out the excess oil. 5. Reinstall the main and outer air cleaner elements and the air cleaner cover. Tighten
the cover screw securely. 6. Reinstall the maintenance cover and tighten the cover screw securely.
WARNING
Do not use gasoline or low flash point solvents for cleaning. They are
flammable and explosive under certain conditions.
CAUTION
Never run the generator without the air cleaner, otherwise rapid engine wear
may result.
OIL FILLER CAP
OIL FILLER HOLE
UPPER LEVEL
ELEMENT
AIR CLEANER
COVER SCREW
AIR CLEANER COVER
MAINTENANCE COVER
MAINTENANCE COVER SCREW
MAINTENANCE
COVER SCREW
MAINTENANCE COVER
AIR CLEANER
BODY
AIR CLEANER ELEMENTS

3. SPARK PLUG SERVICE RECOMMENTDED SPARK PLUG: A7RTC To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. 1. Remove the spark plug maintenance cover 2. Remove the spark plug cap. 3. Clean any dirt from around the spark plug base. 4. Use the wrench to remove the spark plug.
SPARK PLUG MAINTENANCE COVER
SPARK PLUG CAP
5. Visually inspect the spark plug. Discard it if the insulator is cracked or chipped. Clean the spark plug with a wire brush if it is to be reused. 6. Measure the plug gap with a feeler gauge. The gap should be 0.6~0.7mm (0.024-0.028in). Correct as necessary by carefully bend- ing the side electrode. 7. Install the spark plug carefully, by hand, to avoid cross-threading. 8. After a new spark plug has been seated by hand, it should be tightened 1/2 turn with a wrench to compress its washer. If a used plug is being reinstalled, it should only require 1/8 to 1/4 turn after being seated. 9. Reinstall the spark plug cap on the spark plug securely. 10. Reinstall the spark plug maintenance cover.
CAUTION
The spark plug must be securely tightened. An improperly tightened plug can become very hot and possibly damage the generator. Never use a spark plug with an improper heat range. Never use a spark plug without damping resistance, or it will cause no AC output.
HANDLE BAR
PLUG WRENCH
0.6-0.7mm (0.024-0.028 in)

9. TRANSPORTING STORAGE
To prevent fuel spillage when transporting or during temporary storage, the generator should be secured upright in its normal operating position, with the engine switch OFF. The fuel cap vent lever is turned counterclockwise to the OFF position. Allow the engine to cool well before turning the fuel cap vent lever to the OFF position.
WARNING
When transporting the generator:
Do not overfill the tank (there should be no fuel in the filler neck). Do not operate the generator while it is on a vehicle. Take the generator off the
vehicle and use it in a well ventilated place.
Avoid a place exposed to direct sunlight when putting the generator on a
vehicle. If the generator is left in an enclosed vehicle for many hours, high temperature inside the vehicle could cause fuel to vaporize resulting in a possible explosion.
Do not drive on a rough road for an extended period with the generator on
board. If you must transport the generator on board. If you must transport the generator on a rough road, drain the fuel from the generator beforehand.
Before storing the unit for an extended period: 1. Be sure the storage area is free of excessive humidity and dust. 2. Drain the fuel.
WARNING
Gasoline is extremely flammable and explosive under certain conditions. Do not smoke or allow flames or sparks in the area.
SCREW DRIVER
a. Drain all gasoline from the fuel tank into an approved gasoline container. b. Turn the engine switch ON, and loosen the carburetor drain screw and drain the
gasoline from the carburetor into a suitable container.
c. With the drain screw loosened remove the spark plug cap, and pull the starter grip 3
to 4 times to drain the gasoline from the fuel pump.
d. Turn the engine switch to the OFF position, and tighten the drain screw securely.
e. Reinstall the spark plug cap on the spark plug securely. 3. Change the engine oil . 4. Remove the spark plug and pour about a tablespoon of clean engine oil into the
cylinder. Crank the engine several revolutions to distribute the oil, then reinstall the spark plug.
5. Slowly pull the starter grip until resistance is felt. At this point, the piston is coming up
on its compression stroke and both the intake and exhaust valves are closed. Storing the engine in this position will help to protect it from internal corrosion.
Starter grip

10. TROUBLESHOOTING
To check: 1) Remove the spark plug cap and clean any dirt from around the spark plug. 2) Remove the spark plug and install the spark plug in the plug cap. 3) Set the plug side electrode on the cylinder head to ground. 4) Pull the recoil starter, sparks should jump across the gap.
When the engine will not start:
Is there fuel in the tank?
NO
Refuel the fuel tank
YES
Is the engine switch on? Turn the engine switch on. Is the enough oil in the engine? Add the recommended oil.
Is there a spark from the spark plug?
Replace the spark plug.
Take the generator to an
authorized dealer.
Still no spark
YES YES
NO NO
NO
Be sure there is no spilled
fuel around the spark plug. Spilled fuel may ignite.
WARNING
If the engine still does not start, take the generator to an authorized dealer.
No electricity at the DC receptacle:
Appliance does not operate:
Is the output indicator light ON?
Is the overload in- dicator light ON?
Take the generator to an authorized dealer.
Check the electrical appli- ance or equipment for any defects.
Take the generator to an authorized dealer.
Replace the electrical
appliance or equipment
Take the electrical appli-
ance or equipment to an electrical shop for repair
Stop and restart the engine.
Take the generator to an authorized dealer.
Turn the DC circuit protector on.
Is DC circuit protect on? NO
YES
DEFECTS
NO DEFECTS
NO
NO
YES
YES

11. SPECIFICATIONS 12. ELECTRICAL WIRING DIAGRAM
DC output
DC voltage Electric circuit breaker No. of Phase
12V-8.3A (Charge with automotive-type batteries only)
Available
Single phase
SPECIFICATIONS
Model 2000 Digital Generator
Rated frequency (Hz) Rated voltage (V) Rated current (A) Rated speed (rpm) Rated output (kVA) Max output (kVA)
50
230
7.0
5000
1.6 2.0
60
120/240 13.3/6.7
Engine
Model Type 2000 Digital Generator
Type Displacement(cc) Rated power (kW) Rated rotation speed (rpm) Ignition system Spark plug Starting system Fuel
.
Fuel consumption (g /kW h) Lube oil
Single cylinder, 4 stroke, vertical, air-cooled, OHV, gasoline engine
105
2.2/5000
5000
T. C. I
A7RTC
Recoil starter
Automotive unleaded gasoline
630
SAE 10W30 (above CC grade)
Fuel tank capacity (L) Continuous running time (hr) (at rated output) Noise level(zero load~ full load) [dB(A)/7m] Overall dimension (L W H) [mm(in)]
3.7 3.0
56 64
Dry weight [kg(lbs)] 22 (48.4)
to 23.5 (51.7)
KGE2000Tc: 549 291 405 (21.61 11.46 15.94)
Charging winding
Blue
Blue
Graz rectifier
Brown
Black
Main winding
Yellow
Green
Red
Black
Green
Black
Subsidary winding
Purple
Yellow/Green
27V winding
Shutdown switch
Yellow/Green
Red
Yellow
Triggering winding
Low oil level switch
Yellow
Yellow/Green
Ignition
coil
Spark plug
Output indicator
Overload indicator
Low oil pressure indicator
Black
Blue
White
Brown
Gray
Red
Green
Yellow/Green
Yellow
Orange
Inverter unit
Yellow
Blue
Pink
Orange
Step motor
Red
Red
Red
Black
Green
Red Smart-throttle
