ALLPOWER 1000W 2 Stroke Generator User manual

Item No. APG3004A
www.allpoweramerica.com
HAVE QUESTIONS OR NEED SERVICE
DO NOT RETURN TO STORE!
PLEASE CALL TOLL FREE: 888.896.6881
Please read and save these instructions.
www.allpoweramerica.com

5
8
9
10
10
10
10
11
11
12
13
14
Generator Theory Diagram

APG3004A-A-01-WD GB818-85
Bolt M6x35 (2)
APG3004A-A-02-WD GB97.1-85
Washer Ø6 (3)
APG3004A-A-03-WD F1040001
Handle
APG3004A-A-04-WD F1020200
Sump cover subassembly
APG3004A-A-05-WD F1020300
Filtering net
APG3004A-A-06-WD F1020100
Fuel tank
APG3004A-A-07-WD GB5787-86
Bolt M6x12 (7)
APG3004A-A-08-WD F1020401
Wave washer
APG3004A-A-09-WD F1020402
Screw M3x4 (2)
APG3004A-A-10-WD F1020403
Seal cover
APG3004A-A-11-WD F1020404
Spring clamp (2)
APG3004A-A-12-WD F1020405
Rubber washer Ø8
APG3004A-A-13-WD F1020406
Plastic filter tube
APG3004A-A-14-WD F1020407
Seal
APG3004A-A-15-WD LY63-06100
Carburetor
APG3004A-A-16-WD F1020408
Switch grip
APG3004A-A-17-WD GB900
Double end studs M6x73 (2)
APG3004A-A-18-WD GB6175-86
Nut M14
APG3004A-A-19-WD F1020409
Switch grip cover
APG3004A-A-20-WD F1020410
Special rubber gasket
APG3004A-A-21-WD LY63Fa-06200
Gasket 1
APG3004A-A-22-WD LY63Fa-06200
Pedestal
APG3004A-A-23-WD LY63Fa-06200
Bolt M6x20 (4)
APG3004A-A-24-WD LY63Fa-06200
Reed
APG3004A-A-25-WD LY63Fa-06200
Plate stopper
APG3004A-A-26-WD LY63Fa-06200
Screw M3x10 (4)
APG3004A-A-27-WD GB276/6004
Ball bearing 6004.RS (2)
APG3004A-A-28-WD GB818-85
Screw M6x25 (2)
APG3004A-A-29-WD F1010001
Air cleaner cap
APG3004A-A-30-WD GB1235
Dust seal
APG3004A-A-31-WD GB6175-86
Nut M6 (2)
APG3004A-A-32-WD LY63-01012
Gasket 2
APG3004A-A-33-WD LY64-07300 Spark plug cover
APG3004A-A-34-WD LY63-05006
Steel wire pull rod
APG3004A-A-35-WD LY63-05009
Small tension spring
APG3004A-A-36-WD GB6175-86
Nut M4 (5)
APG3004A-A-37-WD GB5787
Bolt M6x16
APG3004A-A-38-WD F10100100
Air cleaner filter
APG3004A-A-39-WD GB818-85
Screw M4x10 (4)
APG3004A-A-40-WD E-08
Electrical outlet
APG3004A-A-41-WD KCD1
Switch
APG3004A-A-42-WD KGZ-01-1
Rubber cap
APG3004A-A-43-WD LY63-05001
Pin for pole
APG3004A-A-44-WD LY63-05005
Pole
APG3004A-A-45-WD GB97.1-85
Washer Ø4 (3)
APG3004A-A-46-WD GB5787
Bolt M4x30
APG3004A-A-47-WD LY63Fa-07200
Protector
APA PART NO.
PART NO.
DESCRIPTION

APG3004A-A-48-WD GB845-85
Screw ST4x12 (3)
APG3004A-A-49-WD SCP-3.5A
AC Set
APG3004A-A-50-WD F1010004
Plate thrust
APG3004A-A-51-WD GB845-85
Screw ST4x18
APG3004A-A-52-WD CBB61 12 F Condenser 12 F 350V
APG3004A-A-53-WD F1010100
Pedestal air cleaner
APG3004A-A-54-WD E-08-1
Rubber gasket
APG3004A-A-55-WD LY160-0.65-1
Fan assy
APG3004A-A-56-WD LY160-0.65-2
Ball bearing 6202.2RZ
APG3004A-A-57-WD F1020002
Hold of fuel tank
APG3004A-A-58-WD F1050002
Cover left
APG3004A-A-59-WD GB5787
Bolt M6x80 (3)
APG3004A-A-60-WD LY63-01002
Gasket 3
APG3004A-A-61-WD LY63Fa-06101
Rubber fuel tube
APG3004A-A-62-WD LY63-04102
Crankshaft right
APG3004A-A-63-WD LY63-01003
Air intake pipe gasket
APG3004A-A-64-WD LY63-04105
Oil bearing KZK 16 22 11.5
APG3004A-A-65-WD LY63-04103
Crankshaft`s pin
APG3004A-A-66-WD LY63-04101
Crankshaft left
APG3004A-A-67-WD LY63-05102
Centrifugal block (2)
APG3004A-A-68-WD LY63-02103
Centring pin (2)
APG3004A-A-69-WD LY63-05002
Fork for regulator
APG3004A-A-70-WD GB5787
Bolt M6x10 (5)
APG3004A-A-71-WD GB5801-94
Oil bearing KBK 10x14x12.5
APG3004A-A-72-WD LY63Fa-04205
Piston`s pin circlip (2)
APG3004A-A-73-WD LY63-04202
Piston`s pin
APG3004A-A-74-WD ly63-05101
Bracket
APG3004A-A-75-WD LY63-04104
Connecting rod
APG3004A-A-76-WD LY63-04201
Piston
APG3004A-A-77-WD LY63-01006
Gasket for cylinder
APG3004A-A-78-WD GB93-87
Spring washer Ø6 (4)
APG3004A-A-79-WD LY63-04203
Piston`s ring (2)
APG3004A-A-80-WD GB818-85
Screw M3x8 (2)
APG3004A-A-81-WD LY63-05003
Block adjuster
APG3004A-A-82-WD LY63-02102
Crankcase, right
APG3004A-A-83-WD GB893.2
Circlip Ø45
APG3004A-A-84-WD LY63Fa-03201a
Cylinder
APG3004A-A-85-WD LY63-01006
Cylinder head gasket
APG3004A-A-86-WD GB5787
Bolt M6x100 (2)
APG3004A-A-87-WD LY63-07400
Spark plug
APG3004A-A-88-WD LY63-03202
Cylinder head
APG3004A-A-89-WD LY63Fa-08201
Wind diversion
APG3004A-A-90-WD LY63Fa-08202a
Collar (2)
APG3004A-A-91-WD LY63-01008
Oil seal (2)
APG3004A-A-92-WD GB900
Double end studs M6x113 (2)
APG3004A-A-93-WD LY63Fa-01014
Nut M6 (2)
APG3004A-A-94-WD LY160-0.65
Armature
APA PART NO.
PART NO.
DESCRIPTION
6

7
APG3004A-A-95-WD LY160-0.65
Stator
APG3004A-A-96-WD LY63-09000
Muffler weldment assy
APG3004A-A-97-WD LY63-09000
Gasket 5
APG3004A-A-98-WD LY63-09000
Bolt M6x18 (4)
APG3004A-A-99-WD LY63-09000
Gasket 6
APG3004A-A-100-WD LY63-09000
Exhaust pipe assy
APG3004A-A-101-WD GB5787
Bolt M8x140
APG3004A-A-102-WD LY63-00102F2
Pad (2)
APG3004A-A-103-WD LY63Fa-10004 Starting handle
APG3004A-A-104-WD LY63Fa-10101
Starter cover
APG3004A-A-105-WD LY63Fa-10005a Start coil-spring
APG3004A-A-106-WD LY63Fa-10002
Block return
APG3004A-A-107-WD LY63Fa-10001 Starter wheel
APG3004A-A-108-WD LY63Fa-10104
Wheel reinforcement
APG3004A-A-109-WD LY63Fa-10003
Wheel stopper
APG3004A-A-110-WD LY63-10006
Fixing spring
APG3004A-A-111-WD LY63-10007
Rope
APG3004A-A-112-WD LY63-08100
Fly wheel assy
APG3004A-A-113-WD GB6175-86
Nut M10
APG3004A-A-114-WD GB5787
Bolt M6x55 (2)
APG3004A-A-115-WD GB5787
Bolt M6x45 (4)
APG3004A-A-116-WD LY63Fa-07100a Ignition coil
APG3004A-A-117-WD LY63-05007
Spring
APG3004A-A-118-WD LY63-05005
Fixing plate
APG3004A-A-119-WD LY63-05008
Tension spring
APG3004A-A-120-WD LY63-02101
Crankcase, left
APG3004A-A-121-WD GB818-85
Screw M6x40
APG3004A-A-122-WD LY63-01013
Clip
APG3004A-A-123-WD GB818-85
Screw M6x14 (2)
APG3004A-A-124-WD PL220
Indicator
APG3004A-A-125-WD CZ-01
ENG.SW
APG3004A-A-126-WD F1010007
PANEL
APG3004A-A-127-WD SCP-10A
DC RESET
APG3004A-A-128-WD F1050001
Front Cover
APG3004A-A-129-WD GB862.1
FASTEN GASKET
APG3004A-A-130-WD GB5780-86
BOLT M8x20(4)
APG3004A-A-131-WD GB5780-86
BOLT M8x30(2)
APG3004A-A-132-WD GB6175-86
Flange Nut M8(2)
APG3004A-A-133-WD LY160-0.65-3
Pad (2)
APG3004A-A-134-WD LY160-0.65-4
Right side cover
APA PART NO.
PART NO.
DESCRIPTION

44.0 lbs
