Alnico 8 Series Manual

Alnico 8 Series RAID Subsystem
Hardware Installation Guide
Version 1.3
10/02/2009

Hardware Installation Guide
Copyright ©2008-2009
This guide and any accompanying software and firmware are copyrighted. No
parts of this publication may be reproduced, stored on a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopy,
recording, or otherwise, without prior written consent except for copies retained
by the purchaser for backup purposes.
All rights Reserved- Printed in Taiwan.
Notice
We make no warranties with respect to this documentation either express or
implied and provide it "as it". This includes but is not limited to any implied
warranties of merchantability and fitness for a particular purpose. The
information in this document is subject to change without notice. We assume no
responsibility for any errors that may appear in this document.
The manufacturer shall not be liable for any damage, or for the loss of
information resulting from the performance or use of the information contained
herein
Trademarks
Product names used herein are for identification purposes only and may be the
trademarks of their respective companies. All trademarks or registered
trademarks are properties of their respective owners.
ii

Hardware Installation Guide
R
R
Re
e
eg
g
gu
u
ul
l
la
a
at
t
to
o
or
r
ry
y
y
i
i
in
n
nf
f
fo
o
or
r
rm
m
ma
a
at
t
ti
i
io
o
on
n
n
For Europe
This drive is in conformity with the EMC directive.
Federal Communications Commission (FCC)
Statement
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules.
Those limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antennas.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circlet different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning:
A shielded-type power cord is required in order to meet FCC emission limits and
also to prevent interference to the nearby radio and television reception. It is
essential that only the supplied power cord be used.
Use only shielded cables to connect I/O devices to this equipment.
You are cautioned that changes or modifications not expressly approved by the
party responsible for compliance could void your authority to operate the
equipment.
iii

Hardware Installation Guide
e
A
A
Ab
b
bo
o
ou
u
ut
t
t
T
T
Th
h
hi
i
is
s
s
H
H
Ha
a
ar
r
rd
d
dw
w
wa
a
ar
r
re
e
I
I
In
n
ns
s
st
t
ta
a
al
l
ll
l
la
a
at
t
ti
i
io
o
on
n
n
G
G
Gu
u
ui
i
id
d
de
e
e
Welcome to Hardware Installation Guide. This guide is designed to be used as
step-by-step instructions for installation of your subsystem, and covers
everything you need to know in learning how to operation, troubleshooting and
future upgrades. For the detail about how to configure your subsystem, please
refer to the Software Operation manual.
S
S
Sy
y
ym
m
mb
b
bo
o
ol
l
ls
s
s
i
i
in
n
n
T
T
Te
e
ex
x
xt
t
t
These symbols may be found in the text of this guide. They have the following
meanings.
Caution
This icons indicates that failure to follow directions could result in
personal injury, damage to your equipment or loss of information.
Note
This icon presents commentary, sidelights, or interesting points of
information .
Important terms, commands and programs are put in Boldface font.
Screen text is given in screen font.
iv

Hardware Installation Guide
Contents
ABOUT THIS HARDWARE INSTALLATION GUIDE..................................IV
SYMBOLS IN TEXT................................................................................IV
CONTENTS.............................................................................................V
CHAPTER 1. INTRODUCTION .............................................................1
MODEL VARIATIONS ............................................................................. 1
FEATURES ............................................................................................. 2
Front Panel Overview.....................................................................3
Rear Panel Overview......................................................................5
CHAPTER 2. INSTALLATION.............................................................10
UNPACKING &CHECKING THE EQUIPMENT......................................... 10
WHAT ELSE YOU NEED ........................................................................ 11
ESD PRECAUTION............................................................................... 11
INSTALLING HARD DISKS ..................................................................... 12
INSTALL THE ALNICO RAID SUBSYSTEM IN A RACK .......................... 13
SYSTEM CONNECTION......................................................................... 15
CONNECTION TO ALNICO 8RAID SUBSYSTEM WITH SAS JBODS...... 15
TURNING ON FOR THE FIRST TIME........................................................ 17
TURNING OFF ...................................................................................... 18
CHAPTER 3. TROUBLE SHOOTING.................................................19
REPLACE THE CONTROLLER ................................................................ 19
REPLACING /UPGRADING DIMM....................................................... 20
Specifications:...............................................................................20
Installing DIMM...........................................................................21
HOT SWAPPING TO REPLACE THE FAN MODULE.................................. 22
HOT SWAPPING TO REPLACE THE POWER MODULE............................. 23
APPENDIX A ..........................................................................................24
CONNECTORS ..............................................................................24
APPENDIX B...........................................................................................26
BATTERY BACKUP MODULE (BBM)..............................................26
BBM Components.........................................................................26
BBM Specifications.......................................................................26
Installation....................................................................................26
v

Hardware Installation Guide
Battery Backup Capacity...............................................................27
Operation.......................................................................................28
Removing the Battery Backup Module ..........................................28
APPENDIX C. SPECIFICATIONS .............................................29
SPECIFICATIONS...................................................................................29
vi

Chapter 1. Introduction
C
Ch ha ap pt te er r 1 1. . I IN NT TR RO OD DU UC CT TI IO ON N
T
T
Th
h
hi
i
is
s
s
c
ch
h
ha
a
ap
pt
t
te
e
er
r
r
i
i
in
n
nt
t
tr
r
ro
o
od
d
du
u
uc
c
ce
e
es
s
s
t
t
th
h
he
e
e
f
f
fe
e
ea
a
at
t
tu
ur
r
re
e
es
s
s
a
a
an
n
nd
d
d
c
c
ca
a
ap
p
pa
a
ab
b
bi
i
il
l
li
i
it
t
ti
i
ie
e
es
s
s
o
o
of
f
f
A
A
Al
l
ln
n
ni
i
ic
c
co
o
o
cpu
s
s
se
e
er
r
ri
i
ie
es
s
s
R
R
RA
A
AI
I
ID
D
D
s
s
su
u
ub
b
bs
s
sy
y
ys
s
st
t
te
e
em
m
ms
s
s.
.
.
e
Y
Y
Yo
o
ou
u
u
w
w
wi
i
il
l
ll
l
l
f
f
fi
i
in
n
nd
d
d:
:
:
Ö
Ö
Örl
A
A
A
f
f
fu
u
ul
l
ll
l
l
i
i
in
n
nt
t
tr
r
ro
o
od
d
du
u
uc
c
ct
t
ti
i
io
o
on
n
n
t
t
to
o
o
y
y
yo
o
ou
u
ur
r
A
A
Al
ln
n
ni
i
ic
c
co
o
o
R
R
RA
A
AI
I
ID
D
D
s
s
su
u
ub
b
bs
s
sy
y
ys
s
st
t
te
e
em
m
m.
.
.
Ö
Ö
Ö
D
D
De
e
et
t
ta
a
ai
i
il
l
ls
s
s
o
o
of
f
f
k
k
ke
e
ey
y
y
f
f
fe
e
ea
a
at
t
tu
u
ur
r
re
e
es
s
s
a
a
an
n
nd
d
d
s
s
su
u
up
p
pp
p
pl
l
li
i
ie
e
ed
d
d
a
a
ac
c
cc
c
ce
e
es
s
ss
s
so
o
or
r
ri
i
ie
e
es
s
s.
.
.
M
M
Mo
o
od
d
de
e
el
l
l
V
V
Va
a
ar
r
ri
i
ia
a
at
t
ti
i
io
o
on
n
ns
s
s
There are ten available models in Alnico 8 RAID storage subsystem series;
which utilize dual 4Gb Fibre / dual miniSAS/ dual 1Gb Ethernet as Host
interface per controller, each with 12, 16, or 24 device bays. .
Model Name Host Interface Device bays Controller Numbers
AL-8241F-S 2 x 4Gbps FC 24 bays 1
AL-8241F-D 4 x 4Gbps FC 24 bays 2
AL-8241S-S 2 x miniSAS 24 bays 1
AL-8241S-D 4 x miniSAS 24 bays 2
AL-8161F-S 2 x 4Gbps FC 16 bays 1
AL-8161F-D 4 x 4Gbps FC 16 bays 2
AL-8161S-S 2 x miniSAS 16 bays 1
AL-8161S-D 4 x miniSAS 16 bays 2
AL-8121F 2 x 4Gbps FC 12 bays 1
AL-8121S 2 x miniSAS 12 bays 1
1

Hardware Installation Guide
Before the Alnico SAS\SATA MUX board is available, onlySAS hard
drives can be installed in the Alnico redundant controller
subsystem.
F
F
Fe
e
ea
a
at
t
tu
u
ur
r
re
e
es
s
s
The Alnico Series RAID Subsystem is designed to meet today’s high volume,
performance storage requirements from rapidly changing business environment.
It provides a maximum data protection and exceptional performance in a
storage subsystem. Target usage ranges are set from small business to
departmental and corporate server needs. The RAID SYSTEM is designed for
easy integration, smooth data expansion and server migration.
The Alnico 8 series supports the following features:
RAID Levels : 0, 1,1E, 3, 5, 6, 50, 60 & JBOD.
Multiple RAID selection.
Online RAID level/stripe size migration.
Online Array roaming.
Hot Spare Disk / Pass through Disk support.
Disk Scurbbing/Array verify scheduling.
Max 122 SAS devices.
Max 128 LUNs ( volumeset ) per controller.
Online capacity expansion and RAID level migration simultaneously.
Online Volume Set growth
Support spin down drivers when not in use to extend service
life( MAID).
Instant availability and background initialization.
Automatic drive insertion / removal detection and rebuilding.
2

Chapter 1. Introduction
Understanding the Alnico RAID subsystem
Front Panel Overview
LCD Module
Function keys. ( ENT, ESC, Scroll up, Scroll Down )
Keys Descriptions
Up Arrow To scroll upward through the menu items
Down Arrow To scroll downward through the menu items
(ENT ) Enter To confirm a selected item
(ESC) ESC To exit a sub-menu and return to previous menu.
Driver Bay numbering convention
The enclosure bay numbering convention is shown in following figure. A bay is
designed to house a single 1.0-inch high, 3,5-inch hard disk drive in his carrier
module.
3

Hardware Installation Guide
AL-8241F / AL-8241S
AL-8161F / AL-8161S
AL-8121F / AL-8121S
Drive Bay
4

Chapter 1. Introduction
Rear Panel Overview
AL-8241F Fibre-SAS/SATA RAID SUBSYSTEM
AL-8241S SAS-SAS/SATA RAID SUBSYSTEM
Fibre-SAS/SATA RAID SUBSYSTEM: 1. FC CH 1
5

Hardware Installation Guide
2. FC CH 0
SAS-SAS/SATA RAID SUBSYSTEM: 1. SAS CH 1
2. SAS CH 0
3. SAS Expand Port
4. Console
5. Terminal
6. LAN port
7. Controller Box 1 (The default first controller location)
8. Controller Box 2
9. FAN failure indicator (Rear / Front)
10. FAN Module /FAN Module 1
11. FAN Module /FAN Module 1 latch
12. Power Switch
13. FAN failure indicator (Rear / Front)
14. FAN Module 2
15. FAN Module 2 latch
16. AC inlet 1 & Ltch
17. Power Module 1
18. AC inlet 2 & Latch
19. Power Module 2
20. AC inlet 3 & Latch
21. Power Module 3
6

Chapter 1. Introduction
AL-8161F Fibre-SAS/SATA RAID SUBSYSTEM
AL-8161S SAS-SAS/SATA RAID SUBSYSTEM
Fibre-SAS/SATA RAID SUBSYSTEM: 1. FC CH 1
2. FC CH 0
SAS-SAS/SATA RAID SUBSYSTEM: 1. SAS CH 1
2. SAS CH 0
7

Hardware Installation Guide
3. SAS Expand Port
4. Console
5. Terminal
6. LAN port
7. Controller Box 1 (The default first controller location)
8. Controller Box 2
9. FAN failure indicator (Rear / Front)
10. FAN Module /FAN Module 1
11. FAN Module /FAN Module 1 latch
12. Power Switch
13. FAN failure indicator (Rear / Front)
14. FAN Module 2
15. FAN Module 2 latch
16. AC inlet 1 & Ltch
17. Power Module 1
18. AC inlet 2 & Latch
19. Power Module 2
AL-8121F Fibre-SAS/SATA RAID SUBSYSTEM
8

Chapter 1. Introduction
AL-8121S SAS-SAS/SATA RAID SUBSYSTEM
1. LAN port
2. Terminal
3. Console
4. SAS Expand Port
Fibre-SAS/SATA RAID SUBSYSTEM: 5. FC CH 1
6. FC CH 0
SAS-SAS/SATA RAID SUBSYSTEM: 5. SAS CH 1
6. SAS CH 0
7. FAN Module /FAN Module 1 latch
8. FAN Module /FAN Module 1
9. FAN failure indicator (Rear / Front)
10. Power Module 1
11. Power Module 2
12. AC inlet 1 & Latch
13. AC inlet 2 & Latch
14. Power Switch
9

Hardware Installation Guide
C
Ch ha ap pt te er r 2 2. . I IN NS ST TA AL LL LA AT TI IO ON N
This chapter presents:
Ö
Ö
Ö
I
I
In
n
ns
s
st
t
tr
r
ru
u
uc
c
ct
t
ti
i
io
o
on
n
ns
s
s
o
o
on
n
n
u
u
un
n
np
p
pa
a
ac
c
ck
k
ki
i
in
n
ng
g
g
&
&
&
c
c
ch
h
he
e
ec
c
ck
k
ki
i
in
n
ng
g
g
t
t
th
h
he
e
e
e
e
eq
q
qu
u
ui
i
ip
p
pm
m
me
e
en
n
nt
t
t
Ö
Ö
Ö
I
I
In
n
ns
s
st
t
tr
r
ru
u
uc
c
ct
t
ti
i
io
o
on
n
ns
s
s
o
o
on
n
n
h
h
ho
o
ow
w
w
t
t
to
o
o
i
i
in
n
ns
s
st
t
ta
a
al
l
ll
l
l
H
H
Ha
a
ar
r
rd
d
d
d
d
di
i
is
s
sk
k
k
d
d
dr
r
ri
i
iv
v
ve
e
e
Ö
Ö
Ö
I
I
In
n
ns
s
st
t
tr
r
ru
u
uc
c
ct
t
ti
i
io
o
on
n
ns
s
s
o
o
on
n
n
h
h
ho
o
ow
w
w
t
t
to
o
o
i
i
in
n
ns
s
st
t
ta
a
al
l
ll
l
l
A
A
Al
l
ln
n
ni
i
ic
c
co
o
o
R
R
RA
A
AI
I
ID
D
D
i
i
in
n
n
a
a
a
R
R
Ra
a
ac
c
ck
k
k.
.
.
Ö
Ö
Ö
I
I
In
n
ns
s
st
t
tr
r
ru
u
uc
c
ct
t
ti
i
io
o
on
n
ns
s
s
o
o
on
n
n
h
h
ho
o
ow
w
w
t
t
to
o
o
c
c
co
o
on
n
nn
n
ne
e
ec
c
ct
t
t
A
A
Al
l
ln
n
ni
i
ic
c
co
o
o
R
R
RA
A
AI
I
ID
D
D.
.
.
U
U
Un
n
np
p
pa
a
ac
c
ck
k
ki
i
in
n
ng
g
g
&
&
&
c
c
ch
h
he
e
ec
c
ck
k
ki
i
in
n
ng
g
g
t
th
h
he
e
e
E
E
Eq
q
qu
u
ui
i
ip
p
pm
m
me
e
en
n
nt
t
t
t
Before unpacking the Alnico RAID subsystem, prepare a clean, stable surface
to put on the contents of Alnico 8 RAID shipping container. Altogether, you
should find following items in the package:
Alnico 8 Fibre to SAS/SATA RAID Subsystem :
zAlnico RAID subsystem x1
zCD-ROM x 1 ( Includes Hardware Installation Guide, Software operation
Manual & HTTP Proxy Server utility for Web browser-based
Configuration).
zSerial cable x1
zPower Cord x 2 (AL-8161 and AL-8121), Power Cord x 3 ( AL-8241)
zSAS cable ( SFF-8088 ) x 1 ( for SAS model only) per controller
zSpare Fan x 1
zSpare Drive Bay x 1
zRails for Rack
zMounting screws (bag) ×1
10

Chapter 2. Installation
Alnico 8 SAS to SAS/SATA RAID Subsystem :
zAlnico RAID subsystem x1
zCD-ROM x 1 ( Includes Hardware Installation
zGuide, Software operation Manual & HTTP Proxy Server utility for Web
browser-based Configuration).
zSerial cable x1
zPower Cord x 2 (AL-8161 and AL-8121), Power Cord x 3 ( AL-8241)
zSpare Fan x 1
zSAS cable ( SFF-8088 ) x 1 per controller ( For SAS model only)
zSpare Drive Bay x 1
zRails for Rack
zMounting screws (bag) ×1
To avoid the unmatched connector type between the Fibre HBA in the Host
computer and Alnico RAID, Alnico RAID doesn’t include the Fibre cable
with the standard shipping.
W
W
Wh
h
ha
at
t
t
e
e
el
l
ls
s
se
e
e
y
y
yo
o
ou
u
u
n
n
ne
e
ee
e
ed
d
d
a
zHard disk drives (different RAID levels requires different numbers of HDDs.
Refer to Software Operation manual for more detail information.
zHost computer with SCSI or Fibre interface.
zDedicated terminal or PC with third party communication software that
supports ANSI terminal emulation (required for viewing Monitor Utility)
E
E
ES
S
SD
D
D
P
P
Pr
r
re
e
ec
c
ca
a
au
u
ut
t
ti
i
io
o
on
n
n
Use a suitable anti-static wrist or ankle strap and observe all conventional ESD
precaution when handle Alnico RAID’s modules and components. Avoid contact
with backplane components and module connectors.
11

Hardware Installation Guide
s
I
I
In
n
ns
s
st
t
ta
a
al
l
ll
l
li
i
in
n
ng
g
g
h
h
ha
a
ar
r
rd
d
d
d
d
di
i
is
sk
k
ks
s
s
The Alnico RAID series includes 16 hot swappable drive bays. The following
sections describe how to install disks into Alnico RAID subsystems.
Loading Hard Disk to the drive bay.
1. Put HDD into the bay.
2. Fasten all 4 screws to mount HDD in
the bay and make sure the HDD is
properly tightened.
Place drive bays back into the system
1. Slide in drive bay, make sure the
handle is open fully.
2. Close the handle to engage the drive
bay into the slot.
The hard drives in a RAID array should match in size and speed. All drives in
any array should be identical models with the same firmware versions. RAID
arrays can use any size drive, however the smallest drive will determine the
size of the array.
1. Only use the screws offered with AlnicoRAID subsystem. Longer screws
might cause the drive damage.
2. All the drive bays ( with or without hard drive) must be placed in the
Alnico subsystem. Alnico’s cooling system is designed with full of drive
bays. Missing drive bays might cause the subsystem damage.
12

Chapter 2. Installation
I
I
In
n
ns
s
st
t
ta
a
al
l
ll
l
l
T
T
Th
h
he
e
e
A
A
Al
l
ln
n
ni
i
ic
c
co
o
o
R
R
RA
A
AI
I
ID
D
D
s
s
su
u
ub
b
bs
s
sy
y
ys
s
st
t
te
e
em
m
m
i
i
in
n
n
a
a
a
R
R
Ra
a
ac
c
ck
k
k
You are shipped one rackmounting kit for each Alnico subsystem that you intend
to rackmount. Alnico subsystem is designed for installation into a
industry-standard 19-inch rackmount cabinet. Following the use of this section
for installing the Alnico subsystem into a Rack
Install the Slide Rails
1. Combine Left slide rail and rear slide rail.
2. Measure the depth of the rack enclosure, then fasten 4 of P4*8M screws
into M4 Locking nuts to fix the length.
3. Use T5*8M screws and PW14 washer to install the left slide on Front and
rear Posts of Rack as Figure 1.
4. repeat procedure 1 ~ 3 to install the right Slide into the Rack.
Figure 1.
Place the Alnico Subsystem into the rack
1. Lift the subsystem enclosure and slide it slowly and gently along the slide rail
into the rack as Figure 2.
13

Hardware Installation Guide
Figure 2.
2. Fasten two M5 screws through the chassis ears in the front side of the
chassis to secure the Alnico subsystem in the rack as Figure 3.
Figure 3.
The Alnico subsystem is heavy, two person are required to move the system
in the procedure.
14
