ALORAIR Cleanshield HEPA 550 User manual

Cleanshield HEPA 550
Owner's Manual
READ AND SAVE THESE INSTRUCTIONS
Seaira Global LLC
14021 NC Highway 50 Surf City, NC 28445
910-660-0962
[email protected]

AIR SCRUBBER
--1
WARNING!
Please note that the CleanShield 550 should only be used with parts approved by AlorAir. The use of
unauthorized parts or alterations to the machine could void your warranty. Contact an approved distributor
for further assistance.
To Avoid the Risk of Fire or Electric Shock:
• Unit must be electrically grounded.
• Insert 3-prong plug directly into outlet with Ground Fault Circuit Interrupting device.
• Do not use an adapter with this unit.
• Do not use the unit in standing water.
• If electrical parts get wet, they must be dried prior to use.
The CleanShield HEPA 550 is a convenient filtration system that cleans the air. The 550 uses an
effective blend of air flow and advanced filtration to expel airborne particles like mold spores,
dust, pollen, and pet dander. The CleanShield is ideal for for restoration jobs, including water,
sewage, and fire.
INTRODUCTION
SPECIAL FEATURES
Daisy-Chain Capability
Using the auxillary outlet on the control panel, you can link up to 3 units together, creating a
maximum airfow 1650 CFM. You can also daisy-chain the machines when they are stacked
vertically (limit of 2 units).
Multi-Positional
The CleanShield HEPA 550 can be operated in the vertical postion, as well as, when
stacked vertically (up to 2 units). When storing, the machines can be stacked horizontally to
save space.
HOW IT WORKS
1. When set to maxiumum airflow, the 550 draws air through two types of filters- a pre-filter and
a HEPA filter.
2. The first phase of filtration, the prefilter, catches the large particles, while the second phase
of filtration, the HEPA filter, catches smaller particles, down to 0.3 microns.
IDENTIFICATION
Congratulations on purchasing a CleanShield 550 air scrubber. In order to take advantage of
the warranty plan, be sure to note the serial number and date of purchase.
Serial Number:
Date of Purchase:

AIR SCRUBBER
-2-
Vertical,
upright
position
Retaining Clips
(4 on base & 4 on side)
Inlet panel,
removable
Inlet
(ductable,12")
Removable
foam cap
(with cap leash)
Control Panel Handle
Latches (4 total)
Outlet
KEY FEATURES
Removable Intake Panel
The CleanShield 550 is equipped with a removable panel on the intake side of the machine. The
removable panel is quite useful in remediation applications, so you can draw air out the room and
create more negative pressure (use a manometer to monitor air pressure). To use panel:
1. Lift latches to remove the panel.
2. Install the machine outside the containment area to draw air out.
3. Cut a hole in the containment plastic that is the size of the unit’s inlet.
4. Insert the inlet into plastic and seal the circumference tightly with duct tape.

AIR SCRUBBER
SETUP
1. Place the CleanShield HEPA 550 so that it is in the upright, vertical position.
2. Plug the machine into a standard 115 volt outlet. Note: Each unit needs 3 amps to operate.
3. Power the unit on and adjust the speed by turning the variable speed control. The maximum
speed is 550 CFM and the minimum speed is 270 CFM.
4. The CleanShield 550 can be operated in the vertical or horizontal postion, depending on
the exact situation. At this point, adjust the machine to the optimal position.
THE CONTROL PANEL
INSTRUCTIONS
--3
Circuit Breaker Switch
Variable Speed Control
Auxiliary Outlet
Variable Speed Control
The Variable Speed Control is used to adjust the power of the machine. Turn the knob in a
clockwise direction, to increase the speed from minimum to maximum.The minimum speed
setting is located immediately under the OFF button. You can switch to minimum speed by
turning the knob counterclockwise.
Auxiliary Outlet
If more air filtration is necessary for a space, you can “daisy chain” or link up to 3 CleanShield
550’s to the same outlet. There is a maximum amperage of 12 when the units are turned off, a
maxium of 9 amps when the units are turned on. Other equipment can be plugged into the same
outlet as the CleanShield as long as it doesn’t go above the max amperage.
Circuit Breaker Switch
The Circuit Breaker Switch protects the unit if there are more than 12 amps of electricity passing
the circuit. If this occurs, the switch will cut off the power to the unit.

--4
AIR SCRUBBER
WARNING
AIR SCRUBBER
WARNING!
CHANGING THE FILTERS
1. Loosen the 4 locks that hold the filter board in place.
2. Slide out the filter panel board.
3. Remove the used filters and replace with new filters.
• Always wear approved protective gear when changing the filters.
• Filters should be changed after each remediation job.
• If the indicator light is on, always change the HEPA filter.
Water Damage
In this application, the CleanShield should be placed in the center of the affected area. The air
scrubber will draw in the air, filter it, then blow out the newly cleaned air. To begin the process,
simply turn on the scrubber and it will start cleaning the air. Keep in mind that if you are working
in a large area or one divided by walls, you may need several air scrubbers to effectively clean
the air.
Odor Control
The CleanShield 550, when used with the optional activated carbon filter (P/N:), is excellent at
odor control, as well. Simply place the carbon filter in the pre-filter slot and it will capture a wide
variety of odor-causing gas molecules, such as volatile organic compounds (VOC’s), smoke,
soot, and paint fumes.
Other Uses
The CleanShield is also useful in many other applications including mold remediation, fire
damage, dust control, and sewage remediation.
Breathing Hazard
• When using the CleanShield HEPA 550 in a containment area, always turn off power to open combus-
tion appliances, such as firelaces, furnaces, water heaters, and HVAC systems, to avoid the risk of
backdrafting carbon monoxide fumes.
• If the Filter Change Light illuminates during the remediation process, immediately change the HEPA
filter.
Tipping Hazard
• Use caution when stacking units,
• Do not stack more than 2 units on top of each other.
• Falling equipment could cause bodily harm.
APPLICATIONS

- -5
AIR SCRUBBER
•Always unplug the unit prior to performing any maintenance.
• Check the power cord for damage (fraying, cuts, etc.) before use.
• Verify that the GFCI outlet is working by powering on the machine and pressing the red
GFCI test button. If the outlet is working, the “reset” button will pop up. To operate, press the
reset button again.
•To avoid electric shock, never use a water hose or pressure washer to clean the electrical
components.
• Check the pre-filter prior to operating the machine to ensure it is not clogged. If there is any
sign of air flow restriction change the filter.
• Make sure the unit is dry prior to installing clean filters.
• When using the CleanShield for remediation purposes, replace both filters at the same time
and always clean machine in between jobs. This will help prevent cross contamination.
SAFETY NOTES
WARRANTY
All warranty benefits apply to the original owner only. Warranty cannot be transferred or assigned.
1 Year (from date of purchase): Seaira Global warrants the machine will operate free of defects in workmanship and
materials. At it’s discretion, Seaira will repair or replace any malfunctioning components, free of charge (excluding trans-
portation costs)
Customer Responsibilities: In order to take advantage of the warranty service, the customer must do the following:
1. Customer must provide normal care and maintenance (including, but not limited to cleaning filters)
2. Removal and re-installation of unit is the sole responsibility of owner.
3. If customer cannot return unit to certified repair center, all costs associated with shipment are borne by the customer.
In addition, all ancillary charges related to freight shipments, including but not limited to palletizing, wrapping, labeling,
and pickup are associated with customer.
4. If shipped, customer is responsible for all risk of loss or damage.
Warranty Procedure:
1. Customer must mail in warranty registration card to Seaira Global. If no card is submitted, warranty period will begin
the day the shipment left the warehouse. Please be sure to record serial # and date of installation. You will need this
information to receive an RA number.
2. If warranty service is necessary, customer must contact Seaira Global Tech Support by phone [phone] to
receive a Return Authorization (RA number).
3. Once an RA has been issued, it is the customer’s job to bring the unit to a certified repair center. If this is not an option,
shipping will be arranged to bring the unit back to the Seaira warehouse (at the expense of the customer).
4. After the unit has been received by Seaira (whether at a repair center or the warehouse), an initial inspection will be
completed, if it is determined to be an invalid warranty claim (see exclusions below), unit will be only be completed after
receiving payment from customer for all associated costs.
5. If unit is defective, the necessary parts will be repaired or replaced and the unit will be available for pickup at certified
repair center or returned via freight shipment (at customer’s expense). Keep in mind that work is only done during normal
working hours. After being repaired, all units are required to go through a rigorous testing process prior to being returned
to customer.
6. Once a part is repaired and the dehumidifier is returned, the original warranty period still applies (no extensions).

- -6
AIR SCRUBBER
Warranty Exclusions:
DAMAGE DUE TO THE FOLLOWING IS NOT covered under warranty
1. Acts of Nature- including but not limited to:
flooding
fire
water damage
hurricane/storm damage
2. IMPROPER USAGE- Including but not limited to:
misuse, abuse, or tampering whether intentional or accidental
improper installation or design
improper voltage
lack of normal care
failure to follow instructions
3. Corrosion
4. Freezing
5. any additional costs due to changes in laws or building codes
6. freight charges
7. any costs due to lost profit or delay
8. damage to property
9. cause beyond control
10. consumable parts, including but not limited to:
filters
batteries
power cords
valves
switches
rubber parts
11. direct, indirect, collateral or inconsequential damages of any kind
THE WARRANTIES AND LIABILITIES SET FORTHARE IN LIEU OFALL OTHER WARRANTIES EXPRESSED
OR IMPLIED, IN LAW OR IN FACT, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
PARTICULAR PURPOSE. SEAIRA Global’s total li- ability, regardless of nature of claim shall not exceed original purchase
price of the product. If a product or component is replaced while under warranty, the applicable warranty period shall not be
extended beyond the original warranty time period.
The foregoing shall constitute the total liability of seller in the case of defective performance of all or any of the
equipment or services provided to Buyer. Buyer agrees to accept and hereby accepts the foregoing as the sole and exclu-
sive remedy for any breach or alleged breach of warranty by Seller.
Any dishonesty or fraud in connection with SEAIRA GLOBAL warranty thoroughly voids all warranty policies.
SEAIRA Global expressly reserves the right to pursue legal action in the event of dishonesty, fraud, or attempted fraud.
