Alpha Communications PENTHA GB2 User manual

Description of the monitor when receiving a call and during communication.
4
*
( )
Answering a call from the door panel.
When a call is received, the monitor(s) will play a melody and show the door panel image on the
master monitor without alerting the visitor. The monitor automatically takes a photo or records a
video (MicroSD card required for video). To answer a call, press option on the master monitor
screen or the logo on the front of any slave monitor in the apartment (unless the 'display
image in call' function is activated on the slave monitor, in which case, option must be pressed).
If the monitor is a PENTHAGB2/H with icon on the front, make sure that the hearing aid is 15 and
25 cm away from the monitor to ensure maximum audio quality during communication with the door
panel.
Communication will last for 90 seconds or until option on the screen is pressed.
To open door 1 or 2, press option / on screen during the communication or call processes:
one press will enable the lock release for 5 seconds.
To open door 1, press the door release option on screen during the communication or call
processes: one press will activate the lock release for 5 seconds.
*
( )
PENTHA MONITORG 2B
PENTHA ONITORMG 2B
AWD256 REV. 11/2017
QUICK GUIDE
www.alphacommunications.com
50121914
Camera
Door Messages Media Call Log
Intercom Divert
to Phone Light Call Options
14:14
Mon .
05 / 06 / 2017
To open door 2, press the door release option on screen during the communication or call
processes: one press will activate the lock release for 5 seconds.
00:30 -1PL
Call/communication time elapsed.
Door panel that made the call.
Enable lock release 1.
Start communication.
End call/communication.
Record
Door enabled.2
Photo or video capture enabled
(MicroSD card required for video recording).
Communication enabled.
2
Door 1 enabled.
1
Take photo or record video manually.
Video recording (MicroSD card required).
Enable lock release 2.
12
00:30 -1PL
1
2
Screen settings, monitor volume, activating
the light, CCTV camera picture selection
(DQ-CAM-GB2 module required).
Start communication.
End call/communication.
Enable lock release 1.
Take photo or record video manually.
Video recording (MicroSD card required).
Enable lock release 2.
Screen settings, monitor volume, activating
the light, CCTV camera picture selection
(DQ-CAM-GB2 module required).

2
SAFETY PRECAUTIONS
-Hands-free monitor.
-7” TFT colour screen.
-Monitor with simple installation (non-polarised 2 wire BUS).
-Touch screen for access and selection of menu functions.
-User menu.
-Installer menu.
-Screen, volume and control settings menu.
-Capacitive menu access and (slave monitor only) start/stop communication button.
-Monitor status light.
-'Divert call' mode LED.
-'Do not disturb' mode LED.
-DIP switches for setting the monitor address (call code) and end of line.
-Always disconnect the power supply before making modifications to the device.
-The fitting and handling of these devices must be carried out by .authorised personnel
-The wiring must run at least 40 cm away from any other wiring.
-Do not overtighten the screws on the connector.
-Install the monitor in a dry protected location free from the risk of dripping or splashing water.
-Do not place in humid, dusty or smoky locations, or near sources of heat.
-Before connecting the device to the mains, check the connections between the door panel, power
supply, distributors and monitors.
-Always follow the instructions contained in this manual.
CHARACTERISTICS
SYSTEM OPERATION
-To make a call, the visitor must press the button of the apartment; an audible sound indicates that
the call is being made and LED will turn on. If vocal synthesis is enabled, a 'Call is in progress'
message appears indicating that a call is being made. At this moment, the apartment's monitors
receive the call. If another apartment is called by mistake, press the button for the correct
apartment and the first call will be cancelled.
-The call lasts for 40 seconds and, when received, the image appears on the master monitor
without the visitor knowing. : the image appears on the monitor (with code 0House kit application
'apartment 1' or monitor with code 16 if the call is in 'apartment 2') when receiving the call without
the visitor being alerted.
If the call is not answered within 40 seconds, LED will turn off and the channel will be freed.
-To establish communication, press option on the screen of the master monitor or
the logo on the front of any slave monitor in the apartment (unless the 'display image in
call' function is enabled on the slave monitor, in which case, option must be pressed), and
LED on the door panel will illuminate. If the monitor is a PENTHA GB2/H with icon on the
front, make sure that the hearing aid is 15 and 25 cm away from the monitor to ensure maximum
audio quality during communication with the door panel.
-Communication will last for one and a half minutes or until option on the monitor screen is
pressed. When communication has finished, LEDs and will turn off and the channel will be
freed. If vocal synthesis is enabled, a 'Communication is finished' message will indicate that the
call is over.
-To open door 1 or 2, press option / on the monitor screen during the call or communication
processes: one press will activate the lock release for 5 seconds and LED will also illuminate
for 5 seconds. If vocal synthesis is enabled, a 'Door Opened!' message will be indicated on the
door panel.
*
( )
3
DESCRIPTION OF THE MONITOR
Monitor code setup:
*
( )
INSTALLATION OF THE MONITOR
1.60m
x4 30
Screws supplied with
the embedding box.
Surf eac Embedding boxLocation
*
( )
*
( )
1 2 3
ON
E mpl : 0 +0+ 4+0+16 = 20xa e
Switch nº: 1 2 3 4 5
Value when ON: 1 2 4 8 16
Table of values DIP
4 5 6
DIP 6: Configures the end of line. Leave in the ON position in monitors
where the video cable terminates. Others set to OFF.
DIP 1 to DIP 5: Sets the monitor address (addresses 0 to 31).
The switches set to OFF have a zero value.
The values of the switches set to ON are shown in the table below.
The monitor code is the sum of the values of the switches set to ON.
2-apartment kit: Monitor code 16 is the last,
DIP 6 of the end of line to ON.
1
( )
PENTHA MONITORG 2B
a. Microphone.
b. Monitor status light and capacitive menu access (in
standby) / slave monitor communication start button.
c. Communication with hearing aids (PENTHA GB2/H).
Sets the hearing aid switch to T-mode.
d. Speaker.
e. 7”TFT colour screen.
f. 'Do not disturb' mode LED.
g.'Divert call' mode LED.
h. Vertical wiring entry.
i. Connector fixings.
j. Con ector.n
k. DIP switch.
l. Bus connection terminals.
'Divert call' mode LED:
Off: 'Divert call' mode disabled.
On: 'Divert call' mode enabled.
LED :S
k
l
i
j
PENTHA
CODE 0
APARTMENT 1
CODE 0 CODE 16
APARTMENT 1
1-apartment kit 2-apartment kit
APARTMENT 2
1
( )
PENTHA PENTHA
e
1 2 3
ON DIP
4 5 6
h
i
h
*
( )
Building
PENTHA MONITORG 2B
d
a
c
MicroSD card
(Max. 16GB
Class 10)
g
f
'Do not disturb' mode LED:
Off: 'Do not disturb' mode disabled.
On: 'Do not disturb' mode enabled.
1 2
b
Monitor status light:
Standby: Light fixed (low intensity).
Call: Light blinking.
Communication: Light fixed.
Missed call: Low and variable intensity light.
