Alpha Fan AX80-3B/56 User manual

Model : AX80-3B/56
AX80-5B/40
AX80-5B/46
AX80-5B/56
Version: 2022 V1

Power Supply Connection & Circuit Diagram
4 - 6
12
7 - 8
9 - 10
10
11
1 - 2
3
Transmitter Learning Process & Function
Warning
Installation and maintenance work shall only be performed by qualified persons, familiar with local
code and regulation, and experienced with this type of appliance.
All field wiring must be installed in accordance with the national wiring regulation.
Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing
wiring work according to the wiring diagram.
The appliance must be permanently connected to the electricity supply through a double pole
switch having a contact separation of at least 3mm in all poles
The unit must be GROUNDED to prevent possible hazard due to insulation failure.
The earth wire is approximately 60mm longer than safety wire. This is to ensure at the event
whereby the suspension system fails, the (L) and (N) wire will break leaving the fan remain earthed
to prevent electrocution.
Tighten the blade firmly using a screw driver.
Blades that are detached from the unit during operation will cause serious injuries and property
damages.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliances.
Confirm that the power supply has been switched OFF before installing or servicing the unit. Ensure
that the blade is fully static before doing any maintenance work.
STOP using the ceiling fan when any abnormality or failure occurs.
If unusual oscillating movement is observed, immediately stop using the ceiling fan and contact the
manufacturer, its service agent or suitably qualified persons.

SAFETY PRECAUTION
2
CAUTION
Please take note of the following important points when installing.
The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a
sufficient strength to withstand 4 times the weight of the ceiling fan.
The mounting of the suspension system shall be performed by the manufacturer, its service agent
or suitably qualified persons.
The fan is to be installed so that the blades are more than 2.5m above the floor.
Safety cord should not be longer than the earthing conductor.
Should failure of the suspension system occur, the supporting of the fan must not rely on the
earthing conductor. The earthing terminal in the fan assembly should be such that should any part
of the suspension system fall off, the body of the fan assembly shall effectively earthed.
Ensure that the unit’s panel is closed after service or installation.
Unsecured panels will cause the unit to operate noisily.
Sharp edges and coil surfaces are potential locations which may cause injury hazards.
Avoid from being in contact with these places.
Before turning off the power supply set the remote controller’s ON/OFF switch to the “OFF”
position.
If this is not done, the unit’s fans will start turning automatically when power resumes, posing a
hazard to service personnel or the user.
Do not operate any heating apparatus too close to the ceiling fan unit or use in room where mineral
oil, oil vapour or oil steam exist, this may cause plastic part to melt or deform as a result of exces-
sive heat or chemical reaction.
Avoid the ceiling fan unit from exposing to direct sunlight, this may cause degradation of plastic
material as a result of excessive heat and UV radiation.
Ensure the colour of wires of the outdoor unit and the terminal markings are same to the indoors
respectively.
Do not use joined and twisted wires for incoming power supply.
Do not place any object in the path of the blades. Avoid raising objects or your arms near the ceiling
fan.
The fan suspension system and blade screw tightening shall be examined yearly.
Replacement of parts of the safety suspension system device shall be performed by the manufac-
turer, its service agent or suitably qualified persons.
Torque value for screw/bolts for securing primary suspension system for motor is 2Nm.
3
Rubber Pulley Assembly
AX80-3B/56 : Fan Blade x 3
AX80-5B/40 : Fan Blade x 5
AX80-5B/46 : Fan Blade x 5
AX80-5B/56 : Fan Blade x 5
Switch Housing
Motor Assembly with Downrod,
Coupling Cover and Canopy
Blade
Screw
Wall Screw x 2
AAA
AAA
Battery x 2
Receiver
Transmitter &
Holder x 1
1
2
3
4
5
6
78

IMPORTANT : CLEVIS PIN MUST BE INSERTED
TO PREVENT NUT FROM LOOSENING.
a. Fix the Rubber Pulley Assembly to the Downrod
with Bolt, Washer, Nut and tighten them firmly
b. then insert the Clevis Pin.
a. Remove the Bolt, Clevis Pin, Nut, Washer and
Rubber Pulley from the Downrod.
b. Place the Rubber Pulley onto the ceiling hook and
fix back the Bolt, Clevis Pin, Nut and Washer.
Rubber Pulley
Assembly
Bolt
Washer, Nut &
Celvis Pin
Rubber
Pulley
Clevis Pin
Nut
Safety Wire
Washer
Tie the Safety Wire across the hook as shown and
firmly screw the Safety Wire onto the Downrod.
4
a. Install the Blades on Motor with Screw.
b. Install the Switch Housing by twisting in.
IMPORTANT : Assemble the Fan Blades only after the ceiling fan is mounted on the hook.
Step 5
Step 4
5
a. Connect the Connectors from Fan and Receiver.
b. Connect the wires from the receiver to House’s Supply Wire.
c. Connect Earth Wire to House Supply Earth Terminal.
House Supply Wire
White
Yellow
Grey
Brown (L)
Blue (N)
Green/Yellow (E)
Brown (L)
Blue (N)
White
Yellow
Grey
a. 2 x screws for each blade
b. Twist clock-wise to lock
Green/Yellow (E)

6
Step 6
Below shows a complete installation diagram.
Model: AX80-3B/56
Model: AX80-5B/40, AX80-5B/46 & AX80-5B/56
7
TRANSMITTER LEARNING PROCESS
The receiver & transmitter is pre-programmed in factory. If you wish to control 2 or more fans using
1 transmitter, the below steps are required.
DO NOT PRESS ANY OTHER BUTTON DURING THIS PROCESS
Step 1
a. Insert the 2 pcs of batteries (provided) into transmitter.
b. Turn on the power supply (wall switch) to the fan.
c. Within 30 sec, press and hold the “LEARN” button for 3 sec. Once the receiver has detected the frequency,
transmitter will “Beep Beep” twice. Programming process is completed and fan is ready to use.
If the fan is not responding to the transmitter, repeat Step 1b.
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO DIMMER
SWITCH OR REGULATOR.
Press and hold
for 3 sec
Learn
Transmitter
AAA
AAA

8
Function of Forward & Reverse
Fan must be turned on and rotating.
Press and hold Forward/Reverse button for 3 sec fan will slow down and then change direction (approx. 15 sec).
When the fan is slowing down to change direction, the Fan Speed function is disabled
until direction has been changed.
The transmitter & receiver is incorporated with last memory function. This function stores your last setting in
memory and the next time you turn on the fan, fan will operate as the last setting.
Forward Reverse
Anti-clockwise or
clockwise rotation.
Fan Speed
1 - Lowest speed
8 - Highest speed
Power
Turn off fan
Natural Wind
Fan speed changes within
its range creating gentle
sea-breeze effect
Timer On
1h - Fan turns on after 1 hour
3h - Fan turns on after 3 hours
6h - Fan turns on after 6 hours
8h - Fan turns on after 8 hours
1
2
3
4
5
6
78
Forward
Fan rotates anti-clockwise blowing
the air downwards creating the
wind chill effect. Suitable for hot
weather condition.
Reverse
Fan rotates clockwise drawing the air
towards the ceiling circulating the warm
air downwards. This function works best
at low speed. Suitable for air-conditioned
condition.
220-240V~ 50Hz
Power Supply
Double Pole
Switch
Single Pole
Switch
Earth
9
Regulator Dimmer Switch

10
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO DIMMER
SWITCH OR REGULATOR.
DC
Motor
ANTW
N
Blue
Grey
Yellow
White
Neutral (Blue)
Live (Brown)
Earth (Green/Yellow)
Earth (Green/Yellow)
Brown
Green/Yellow
MAIN PCB
L
E
V
U
Power Supply
220V-240V - 50Hz
E
11
Model
No. of Blades
Fan Width
Motor RPM
Voltage
Motor Wattage
Nett Weight
AX80-3B/56
3
1420mm (56”)
90 - 225
220 - 240V~ 50Hz
5W - 40W
6.0kg
AX80-5B/40
5
1015mm (40”)
110 - 260
220 - 240V~ 50Hz
5W - 40W
5.2kg
AX80-5B/46
5
1165mm (46”)
90 - 225
220 - 240V~ 50Hz
5W - 40W
5.8kg
AX80-5B/56
5
56”
80 - 205
220 - 240V~ 50Hz
5W - 45W
6.5kg
510mm
(1’ 8”)
380mm
(1’ 3”)
AX80-3B/56 1420mm (4’ 8”)
AX80-5B/40 1015mm (3’ 4”)
AX80-5B/46 1165mm (3’ 10”)
AX80-5B/56 1420mm (4’ 8”)
More than 2.5m (8’ 2”)
More than 1m

12
