Alpha Fan HANI-5B/36 LED User manual

Model : HANI-5B/36 LED
Version: SG/2022 V1

Power Supply Connection & Circuit Diagram
4 - 8
13
8 - 9
10 - 11
11
12
1 - 2
3
Transmitter Learning Process & Function
Warning
Installation and maintenance work shall only be performed by qualified persons, familiar with local
code and regulation, and experienced with this type of appliance.
All field wiring must be installed in accordance with the national wiring regulation.
Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing
wiring work according to the wiring diagram.
The unit must be GROUNDED to prevent possible hazard due to insulation failure.
The earth wire is approximately 60mm longer than safety wire. This is to ensure at the event
whereby the suspension system fails, the (L) and (N) wire will break leaving the fan remain earthed
to prevent electrocution.
Tighten the blade firmly using a screw driver.
Blades that are detached from the unit during operation will cause serious injuries and property
damages.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliances.
Confirm that the power supply has been switched OFF before installing or servicing the unit. Ensure
that the blade is fully static before doing any maintenance work.
The appliance must be permanently connected to the electricity supply through a double pole switch
having a contact separation of at least 3mm in all poles.
STOP using the ceiling fan when any abnormality or failure occurs.
If unusual oscillating movement is observed, immediately stop using the ceiling fan and contact the
manufacturer, its service agent or suitably qualified persons.

2
CAUTION
Please take note of the following important points when installing.
The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a
sufficient strength to withstand 4 times the weight of the ceiling fan.
The mounting of the suspension system shall be performed by the manufacturer, its service agent or
suitably qualified persons.
The fan is to be installed so that the blades are more than 2.5m above the floor.
Safety cord should not be longer than the earthing conductor.
Should failure of the suspension system occur, the supporting of the fan must not rely on the earthing
conductor. The earthing terminal in the fan assembly should be such that should any part of the
suspension system fall off, the body of the fan assembly shall effectively earthed.
Ensure that the unit’s panel is closed after service or installation.
Unsecured panels will cause the unit to operate noisily.
Sharp edges and coil surfaces are potential locations which may cause injury hazards. Avoid
from being in contact with these places.
Before turning off the power supply set the remote controller’s ON/OFF switch to the “OFF”
position.
If this is not done, the unit’s fans will start turning automatically when power resumes, posing a hazard
to service personnel or the user.
Do not operate any heating apparatus too close to the ceiling fan unit or use in room where mineral oil,
oil vapour or oil steam exist, this may cause plastic part to melt or deform as a result of excessive heat
or chemical reaction.
Ensure the colour of wires of the outdoor unit and the terminal markings are same to the indoors
respectively.
Don’t use joined and twisted wires for incoming power supply.
Do not place any object in the path of the blades. Avoid raising objects or your arms near the ceiling
fan.
The fan suspension system and blade screw tightening shall be examined yearly.
Replacement of parts of the safety suspension system device shall be performed by the manufacturer,
its service agent or suitably qualified persons.
Torque value for screw/bolts for securing primary suspension system for motor is 2Nm.
Avoid the ceiling fan unit from exposing to direct sunlight, this may cause degradation of plastic
material as a result of excessive heat and UV radiation.
3
SAFETY PRECAUTION
Blade x 5
Canopy &
Canopy Cover
Lamp Shade
LED light Kit
Notch Ball
Mounting Bracket
Receiver
Motor Assembly
Fan Rod Coupling Cover
Wall Screw x 2
Battery x 2
AAA
AAA
Transmitter &
Holder x 1
1
2
3
4
5
6
78
Expansion
Screw x 4 Expansion ‘J’ x 1 Blade Screw x 11 Light Kit Screw x 4 Bolt x 2

4
Step 1
a. Route all the wires & Safety Wire from the Motor through the Fan Rod.
b. Fix the Fan Rod to the Motor Assembly with Bolt, Washer, Nut and tighten them firmly then insert
the Clevis Pin. Tighten the Fan Rod Support Screw.
c. Assemble the Coupling Cover, Canopy Cover, Canopy and the Notch Ball through the Fan Rod.
Expansion ‘J’ Hook
Expansion Screw
Mounting Bracket
Nut
IMPORTANT : THE EXPANSION SCREWS, EXPANSION ‘J’ HOOK AND NUT MUST
BE TIGHTENED UNTIL SNUG.
Step 2
a. Drill the holes for 4 Expansion Screws and 1 Expansion ‘J’ Hook provided to the concrete
ceiling.
b. Align the slotted holes in the mounting bracket with the expansion screws and secure
with the washer and nuts
5
Step 3 -
a. Raise the fan and place the ball into the Mounting Bracket.
b. Align the notch on the Notch Ball with the indent in the mounting bracket
until you hear the notch pop into place.
c. Hook the Safety Wire onto the expension ‘J’ hook.
Indent
Expansion
‘J’
Notch
Notch
Ball
Mounting Bracket
Safety Wire
Coupling
Cover
Downrod
Canopy
Canopy
Cover
Notch
Ball
Earth
Wire
Safety
Wire
The diagram below shows the assembly of wires
through downrod
Insulating
Sleeve
Current Carrying Wires
Locking
Pin
Cross
Bolt
Locking
Nut
Motor
Shaft
Insulating
Sleeve
Safety
Cord
Earth
Wire
a. b. c.

Step 4 -
a. Connect the Connectors from Fan and Receiver.
b. Connect the wires from the Receiver to House’s Supply Wire.
c. Connect Earth Wire to House Supply Earth Terminal.
67
Step 8
a. Route the LED Wire from Motor throught the Light Kit
b. Install the LED Light Kit on Motor with Light Kit Screw.
c. Connect LED connector from Motor onto LED Light Kit.
d. Install Lamp Shade by twisting in
Light Kit Connectionc.
a.
b.
Install Lamp Shaded.
Step 7
a. Install the Blades on Motor with Screw.
b. Two pieces blade screw and washer for each fan blade.
IMPORTANT : Assemble the Fan Blades only after the ceiling fan is mounted on the bracket.
Step 5
a. Insert the receiver into the canopy and store all wire neatly.
b. Loosen (do not remove) the two screws on the mounting bracket. Slide the canopy up to mounting
bracket and place the key hole on the canopy over the screw on the mounting bracket, turn the canopy
until it locks.
c. Align the holes on the canopy with mounting bracket and secure with the two sets of screws until snug.
d. Install the canopy cover on to the canopy.
a. d.b. & c.
White
Yellow
Grey
White
Yellow
Grey
House Supply Wires
Brown (L)
Blue (N) Green/Yellow(E)
Orange
Blue
Orange
Blue Green/Yellow(E)
Green/Yellow(E)
Brown (L)
Blue (N)
a.
b.
c.

The receiver & transmitter is pre-programmed in factory. If you wish to control 2 or more
fans using 1 transmitter, the below steps are required.
DO NOT PRESS ANY OTHER BUTTON DURING THIS PROCESS
Step 1
a) Insert the 2 pcs of batteries (provided) into transmitter.
b) Turn on the power supply (wall switch) to the fan.
c) Within 30 sec, press and hold the “LEARN” button for 3 sec. Once the receiver has
detected the frequency, transmitter will “Beep Beep” twice.
Programming process is completed and fan is ready to use.
If the fan is not responding to the transmitter, repeat Step 1b.
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO
DIMMER SWITCH OR REGULATOR.
Press and hold
for 3 sec
Transmitter
89
Forward Reverse
Anti-clockwise or
clockwise rotation.
Fan Speed
1 - Lowest speed
8 - Highest speed
1
2
3
4
5
6
78
Function of Forward & Reverse
Fan must be turned on and rotating.
Press and hold Forward/Reverse button for 3 sec fan will slow down and then change direction
(approx. 15 sec). When the fan is slowing down to change direction, the Fan Speed function is disabled
until direction has been changed.
The transmitter & receiver is incorporated with last memory function. This function stores your last setting
in memory and the next time you turn on the fan, fan will operate as the last setting.
Power
Turn off fan
Natural Wind
Fan speed changes within
its range creating gentle
sea-breeze effect
Timer On
1h - Fan turns on after 1 hour
3h - Fan turns on after 3 hours
6h - Fan turns on after 6 hours
8h - Fan turns on after 8 hours
Light
On/Off & LED light
colour selection -
Warm, Daylight & White
Step 9
Below shows a complete installation diagram.
Forward
Fan rotates anti-clockwise blowing
the air downwards creating the
wind chill effect. Suitable for hot
weather condition.
Reverse
Fan rotates clockwise drawing the air towards
the ceiling circulating the warm air downwards.
This function works best at low speed.
Suitable for air-conditioned condition.

10 11
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO DIMMER
SWITCH OR REGULATOR.
DC
Motor
ANTW
N LED+
Blue
Grey
Yellow
White
Earth (Green/Yellow)
Earth (Green/Yellow)
Brown
Neutral (Blue)
Live (Brown)
Green/Yellow
MAIN PCB
LED-
L
E
V
U
Power Supply
220V-240V - 50Hz
LED
20W
Orange
Orange
Blue
Blue
220V-240V~ 50Hz
Dimmer SwitchRegulator
Due to the fan’s natural movement, connections mayget loose after a period of usage.
to ensure a proper safety usage. inspect the suspension system and tighten all
connections every 6 months.
Cleaning
Cleaning your fan periodically will prolong its new appearance. Basic cleaning procedures
are as follows:
1. Use only lukewarm water. Do not use detergent. corrosive or acidic solution.
2. Damp the cloth lightly. Use only soft or lint-free cloth to clean the fan. Rought fabric will
scratch the fan surface.
3. To cover small scratches, apply a light coat of shoe polish over it.
4. There is no need to oil the fan.
Double Pole
Switch
Single Pole
Switch
Earth
220-240V~ 50Hz
Power Supply

12
Alpha Sales & Services Pte. Ltd. (200709461 R)
50, Ubi Avenue 3, #02-16/17, Frontier, Singapore 408866.
Tel : [phone] Fax : [phone]
Website : www.alphasingapore.com Email : [email protected]
If you need any technical assistance or faulty report, please contact our customer
service centre at :
Model
No. of Blades
Fan Width
Motor RPM
Voltage
Motor Wattage
LED Wattage
Nett Weight
HANI-5B/36 LED
5
914mm (36”)
90 - 220
220 - 240V~ 50Hz
5W - 35W
20W
5kg
13
280mm
(11”)
200mm
(7.9”)
HANI-5B/36 LED 914mm (36”)
More than 2.5m (8’ 2”)
More than 1m
