Alpha Fan TWF10-DC User manual

Model : TWF10-DC
TOWER FAN
Version: 2021 V1

SAFETY PRECAUTION
IMPORTANT : PLEASE READ BEFORE USING THE APPLIANCE. SAFETY PRECAUTION SHOULD BE
FOLLOWED TO REDUCE THE RISK OF FIRE ELECTRICAL SHOCK AND PERSONAL INJURY.
1. Unplug the Power Cord during installation, cleaning or relocation of appliance.
2. Do not modify the length of the Power Cord.
3. Do not use the appliance if the Power Cord or Plug is damaged, or the power socket is loose.
4. Repairing/servicing of the appliance must be carried out by authorized and qualified electricians only.
5. If the Power Cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified person to avoid a hazard.
6. Do not touch the appliance and Plug when your hands are wet.
7. Do not expose the appliance to dripping or splashing water or objects filled with water, such as vase.
8. Do not use the appliance near the gas stove, any fire source, unusually humid or high temperature, oil soot
with a lots of metal powder, objects that may be drawn to fan, such as drapes or curtain and outdoor.
9. Do not insert hands or fingers into the appliance, or movable parts.
10. Place the appliance on a stable and level surface.
11. Do not hang or mount appliance on wall or ceiling.
12. Do not operate or use when appliance housing is damaged.
13. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
14. Ensure that the fan is switched off from the supply mains before removing the guard.
This appliance is designed to use only those parts supplied with this appliance and/or accessories designated
specifically for use with this appliance. Using parts and/or accessories not designated for use with this
appliance could result in personal injury or property damage.
PARTS & ACCESSORIES
WARNING
1
Plug
Rear Case
Rear Grille
Remote Control
Control Panel
1
Display Panel
2
3Air Outlet Grille
4
5Front Case
7Chassis
6
TIMER
z
MODE

IMPORTANT : BEFORE PERFORMING ANY CLEANING & MAINTENANCE WORK, UNPLUG
APPLIANCE FROM THE SUPPLY SOCKET.
1. Install Chassis
Align the Mark 1 on Chassis with the Mark 1 on Body.
Mark 1 on the Chassis
Mark 1 on Body
Rotate the Body towards Mark 2 on Chassis until it is lock with “Click” sound. If this step is
done correctly, the Body will attach firmly to the Chassis.
2. Disassemble Chassis
Turn over the Body, press the lock Clasp on Chassis towards arrow direction - Mark 1, rotate
towards Mark 2 direction to remove Chassis from Body.
2
Clasp
Base
INSTALLATION METHOD

OPERATION
3
CONTROL PANEL
POWER - ON or OFF Tower Fan.
OSCILLATION - Auto horizontal direction.
TIMER - On timer setting for 0.5 hr to 12 hr.
- Off timer setting for 0.5 hr to 12 hr.
FAN SPEED - Increase fan speed.
FAN SPEED - Decrease fan speed.
Timer OSC.
OSC.
Timer
OFF Timer - Turn on the power and select a fan speed. Press button to select the
desire setting. Press or to set the hours and press to confirm.
ON Timer - On standby mode, press button to select the desire setting. Press
or to set the hours and press to confirm.
To check on the remaining time, press button.
To cancel timer setting, press and hold button for 3 sec.
Timer
Timer
Timer
Timer
Timer
Timer

OPERATION
4
DISPLAY PANEL
REMOTE CONTROL FUNCTION
Function Mode
SILENT - Operate in speed 1.
NORMAL - 12 fan speed selections.
OSCILLATION - Oscillation function activated.
Timer
Mode Setting
Oscillation
On/Off
Increase Fan Speed
Decrease Fan Speed
SLEEP - Gradually reduces fan speed every 1hr till speed 1.
NATURAL - Fan speed changes within its range creating gentle sea-breeze effect.
1 - fan speed changes within speed 1 - 3 range.
2 - fan speed changes within speed 5 - 7 range.
3 - fan speed changes within speed 7 - 10 range
4 - fan speed changes within speed 9 - 12 range.
TIMER - Timer function activated.
TIMER
OSC.
MODE

5
If you need any technical assistance or faulty report, please contact our customer service centre at :
Malaysia
Alpha Home Appliances Sdn. Bhd. (390258-H)
Head Office : 6, Jalan Sungai Kayu 32/37, Berjaya Park, Sect 32, 40460 Shah Alam, Selangor.
Tel : [phone] Fax : [phone]
Website : www.alphamalaysia.com Email : [email protected]
Johor : 71, Jalan Molek 3/10, Taman Molek, 81100 Johor Bahru.
Tel : [phone] / 4933 Fax : [phone]
Melaka : 19, 19-1 & 19-2, Jalan KSB 11, Taman Kota Syahbandar, 75200 Melaka.
Tel : [phone] / 2399 Fax : [phone]
Perak : 16, Jalan Tasek Timur, Taman Tasek Indra, 31400 Ipoh, Perak.
Tel : [phone] Fax : [phone]
Penang : 28 Jalan Icon City, Icon City, 14000 Bukit Mertajam, Pulau Pinang.
Tel : [phone] / 2066 / 2566 Fax : [phone]
Pahang : A131, Jalan Dato Wong Ah Jang, Taman Liza, 25100 Kuantan, Pahang.
Tel : [phone] Fax : [phone]
Singapore
Alpha Sales & Services Pte. Ltd. (200709461 R)
50, Ubi Avenue 3, #02-16/17, Frontier, Singapore 408866.
Tel : [phone] Fax : [phone]
Website : www.alphasingapore.com Email : [email protected]
CUSTOMER SERVICE CENTRE
1. Use only lukewarm water and mild detergent to clean the appliance. Do not use corrosive or
acidic solution.
2. Use soft or lint-free cloth to clean the appliance. Rough fabric will scratch the surface.
3. To clean between the louvers, use pipe cleaner, flexible dust wand, vacuum cleaner or compressed
air to gently remove dust.
4. DO NOT wet or immerse the appliance, motor, switch, power cord and plug in water.
This electric product is in accordance with the relevant safety requirements.
Repairs should only be carried out by qualified persons using original spare parts, otherwise this
may result in considerable danger to the user.
Please contact the Customer Service Centre (below contact list) after sale services if any.
TECHNICAL SPECIFICATIONS
MAINTENANCE
Model
Voltage
Wattage
Noise Level
Nett Weight
TWF10-DC
220V-240V~ 50Hz
35W
≤63dB
6.80Kg
