CONTENTS
WARNING
................................................................................
1
SERVICE
CARE
.......................................................................
2
ACCESSORIES
........................................................................
2
INSTALLATION
.......................................................................
3
ATTACHING
THE
TOP
COVER
AND
LOGO
PLATE
......
.4
CONNECTIONS
.....................................................................
5
CONNECTION
CHECK
LIST
................................................
8
SWITCH
SETTINGS
......................................
.
........................
9
SYSTEM
DIAGRAMS
.........................................................
11
SPECIFICATIONS
................................................................
14
WARNING
Points
to
Observe for Safe
Usage
Read
this manual carefully before using
the
system
components.They contain instructions on
how
to
use this
product
in a
safe
and effective manner.
Alpine cannot be responsible for problems
resulting from failure
to
observe the instructions in
this manual.
~WARNING
This
symbol
means
important
instructions.
Failure
to
heed
them
can
result
in
serious
injury
or
death.
DO
NOT
OPERATE
ANY
FUNCTION
THATTAKES YOUR
ATTENTION AWAY
FROM
SAFELY
DRIVING
YOUR
VEHICLE.
Any
function
that
requires
your
prolonged
attention
should
only
be performed after coming
to
a
complete
stop. Always stop
the
vehicle in a safe location before
performing
these functions. Failure
to
do
so
may result in
an
accident.
KEEP THE
VOLUME
AT
A LEVEL WHERE YOU CAN STILL
HEAR OUTSIDE NOISES WHILE
DRIVING.
Excessive
volume
levels
that
obscure sounds such
as
emergency vehicle sirens
or
road warning signals (train
crossings, etc.) can be dangerous and may result in
an
accident.
LISTENING
AT
LOUD
VOLUME
LEVELS
IN
A
CAR
MAY
ALSO
CAUSE
HEARING
DAMAGE.
DO
NOT
DISASSEMBLE OR ALTER.
Doing
so
may result in
an
accident, fire
or
electric shock.
USE THIS PRODUCT FOR
MOBILE
12V
APPLICATIONS.
Use
for
other
than its designed application may result in
fire, electric shock
or
other
injury.
USE THE CORRECT AMPERE RATING
WHEN
REPLACING
FUSES.
Failure
to
do
so
may result in fire
or
electric shock.
DO
NOT
BLOCK VENTS OR RADIATOR PANELS.
Doing
so
may cause heat
to
build
up
inside and may result
in fire.
MAKETHE CORRECT CONNECTIONS.
Failure
to
make
the
proper connections may result in fire or
product
damage.
USE ONLY IN CARS
WITH
A
12
VOLT NEGATIVE
GROUND.
(Check
with
your dealer
if
you are
not
sure.) Failure
to
do
so
may result in fire, etc.
BEFORE WIRING, DISCONNECTTHE CABLE FROM THE
NEGATIVE BATTERY TERMINAL.
Failure
to
do
so
may result in electric shock
or
injury due
to
electrical shorts.
DO
NOT
ALLOW CABLES
TO
BECOME ENTANGLED IN
SURROUNDING OBJECTS.
Arrange wiring and cables in compliance
with
the
manual
to
prevent obstructions when driving. Cables
or
wiring
that
obstruct or hang
up
on places such
as
the
steering
wheel, gear lever, brake pedals, etc. can be extremely
hazardous.
DO
NOT
SPLICE
INTO
ELECTRICAL CABLES.
Never cut away cable insulation
to
supply
power
to
other
equipment. Doing
so
will exceed
the
current carrying
capacity
of
the wire and result in fire or electric shock.
DO
NOT
DAMAGE PIPE OR
WIRING
WHEN
DRILLING
HOLES.
When drilling holes in
the
chassis for installation, take
precautions
so
as
not
to
contact, damage
or
obstruct
pipes, fuel lines, tanks
or
electrical wiring. Failure
to
take
such precautions may result in fire.
1-EN
