Alpine CDE-196DAB User manual

Designed by ALPINE Japan
68-30368Z34-A
EN
DE
FR
ES
IT
SE
NL
RU
PL
RR
FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/PARA USO EN
AUTOMÓVILES/SOLO PER L’UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE AUTO/
ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ/DO UŻYCIA TYLKO W SAMOCHODZIE
•OWNER’S MANUAL
Please read before using this equipment.
•ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa
igenom denna användarhandledning.
•BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
•GEBRUIKERSHANDLEIDING
Lees deze aanwijzingen aandachtig alvorens dit
toestel te gebruiken.
•MODE D’EMPLOI
Veuillez lire avant d’utiliser cet appareil.
•РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
Прочтите настоящее руководство перед
началом использования оборудования.
•MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
•INSTRUKCJA OBSŁUGI
Prosimy zapoznać siç z tą instrukcją przed
przystąpieniem do użytkowania urządzenia.
•ISTRUZIONI PER L’USO
Si prega di leggere prima di utilizzare il
attrezzatura.
ALPINE ELECTRONICS MARKETING, INC.
1-7, Yukigaya-Otsukamachi, Ota-ku,
Tokyo 145-0067, JAPAN
Phone: [phone]
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone [phone]
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany
Phone [phone]
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
www.alpine.co.uk
ALPINE ELECTRONICS France S.A.R.L.
184 allée des Erables
CS 52016 – Villepinte
95 945 Roissy CDG cedex
FRANCE
Phone : + 33(0)1 48 63 89 89
ALPINE ITALIA S.p.A.
Viale Cristoforo Colombo, 8
20090 Trezzano sul Naviglio MI, Italy
Phone [phone]
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone [phone]
CD/DAB RECEIVER WITH ADVANCED BLUETOOTH
CDE-196DAB
DIGITAL MEDIA/DAB RECEIVER WITH ADVANCED BLUETOOTH
UTE-93DAB

3-EN
Contents ENGLISH
Operating Instructions
WARNING
WARNING....................................................... 6
CAUTION ........................................................ 6
PRECAUTIONS ............................................... 6
Getting Started
Accessory List ...............................................................9
Turning Power On and Off.......................................9
Demonstration Function..........................................9
Turning the Demonstration mode Off ............9
Source Selection..........................................................9
Detaching and Attaching the Front Panel .........9
Detaching ..................................................................9
Attaching ................................................................ 10
Initial System Start-Up............................................ 10
Adjusting Volume .................................................... 10
Setting the Dimmer Control
(CDE-196DAB only).................................................. 10
Setting Time............................................................... 10
Radio
Listening to Radio.................................................... 11
Presetting Stations Manually............................... 11
Presetting Stations Automatically...................... 11
Tuning to Preset Stations ...................................... 11
Frequency Search Function.................................. 11
RDS
Turning AF (Alternative Frequencies)
ON/OFF........................................................................ 12
Receiving RDS Regional (Local) Stations ......... 12
PI SEEK Setting .......................................................... 12
Receiving Traffic Information............................... 12
PTY (Programme Type) Tuning ........................... 13
Receiving Traffic Information While Playing
USB Audio or Radio ................................................. 13
Displaying Radio Text ............................................. 13
DAB/DAB+/DMB
Listening to DAB/DAB+/DMB...............................14
Presetting Service Components Manually ......14
Presetting Ensemble/Service
Automatically.............................................................14
Tuning to Stored Ensemble...................................14
Tuning to Preset Service Components .............14
Service Component Search Function................15
PTY (Programme Type) Search Function..........15
About DAB/DAB+/DMB..........................................15
CD/MP3/WMA/AAC (CDE-196DAB only)
Playback .......................................................................16
Repeat and Random Play ......................................16
Searching for CD Text..............................................16
Folder/File Name Search
(concerning MP3/WMA/AAC) ..............................16
Folder Name Search mode................................16
File Name Search mode .....................................17
Search Position Memory ........................................17
About MP3/WMA/AAC ...........................................17
Terminology ...........................................................18
Sound Setting
Adjusting Subwoofer Level/Bass Level/
Treble Level/Balance (Between Left and Right)/
Fader (Between Front and Rear)/Defeat...........18
Sound Setting ............................................................19
Equalizer Presets ...................................................19
Setting BASS ENGINE SQ ON/OFF ..................19
Displaying the BASS ENGINE SQ
PARAMETER ............................................................19
Adjusting the Parametric Equalizer Curve
(9BAND P-EQ).........................................................19
Adjusting the Frequency (CENTER FRQ) ............19
Setting the Bandwidth (WIDTH (Q)) ....................19
Adjusting the Level....................................................20
Setting the Source Volume Level....................20
Adjusting the Crossover Settings
(X-OVER)...................................................................20
Selecting the Cut-Off Frequency
(FREQUENCY)...............................................................20
Adjusting the Slope (SLOPE) ..................................20
Adjusting the Level (LEVEL)....................................20
Turning Subwoofer ON/OFF.............................20
Setting the Subwoofer Phase...........................20
Setting the Subwoofer System........................20
Setting the Time Correction Unit
(LENGTH) .................................................................21
Adjusting the Time Correction (TCR).............21

4-EN
Contents ENGLISH
External Device..................................................... 21
Connecting to an External Amplifier
(POWER IC)....................................................................21
Setting the Media Xpander mode ................. 21
BASS ENGINE SQ Function.................................... 22
Switching BASS ENGINE SQ mode................. 22
Adjusting BASS ENGINE SQ Level................... 22
About Time Correction .......................................... 22
Example 1. Listening Position:
Front Left Seat....................................................... 22
Example 2. Listening Position: All Seats....... 22
About the Crossover ............................................... 24
Other Functions
Displaying the Text.................................................. 26
About “Text” .......................................................... 26
Using the Front AUX Input Terminal ................. 26
Option Menu Setting.............................................. 27
Applying Alpine TuneIt App ................................ 27
Adjusting the sound via the
Smartphone........................................................... 28
Facebook Notification Function ..................... 28
Receiving Notification ..............................................28
Displaying Notification List.....................................28
SETUP
Setting.......................................................................... 29
General Setting..................................................... 29
Setting the Time to automatically be
adjusted.........................................................................29
Turning the Clock Display ON/OFF......................29
Setting the Menu Language ..................................29
Setting the AUX SETUP mode................................29
Setting the AUX NAME mode ................................30
Setting the interrupt mode ....................................30
Playing MP3/WMA/AAC Data (PLAY MODE)
(CDE-196DAB only)....................................................30
Setting the stay on mode........................................30
Demonstration ............................................................30
Setting Adaptive Steering Remote Control ......30
Setting the Opening Screen Update...................31
Display Setting...................................................... 31
Changing Lighting Colour ......................................31
Dimmer Control ..........................................................31
Adjusting the Dimmer Level ..................................32
Scroll Setting (TEXTSCROLL) ..................................32
Scroll Type Setting .....................................................32
Tuner Setting ......................................................... 32
Setting the TUNER (FM) tone quality
(FM SET) .........................................................................32
Setting the DAB/DAB+/DMB display
(DAB DISP).....................................................................32
Setting the FM Switching ON/OFF
(FM SWITCH).................................................................32
Setting the DAB LINK ................................................32
Setting the DAB Antenna ON/OFF
(DAB ANT) .....................................................................33
Receiving weather information.............................33
Receiving sports information.................................33
Setting PTY31 (Emergency Broadcast)
reception .......................................................................33
Priority News................................................................33
Receiving Transport information..........................33
Receiving Warning/Service information............33
Receiving Event Announcement
information...................................................................33
Receiving Special Event information ..................33
Receiving Programme information .....................34
Receiving Financial Report information.............34
iPod Setting ...........................................................34
iPod/iPhone Search Mode Setting.......................34
Application Setting (APP) ..................................34
Setting the communication mode with a
Smartphone (ALPINE APP)......................................34
Setting the TTS (Text To Speech) volume..........34
BT Hands Free Calling
Setup Before Using ..................................................35
About Bluetooth® .................................................35
Before Using Bluetooth Function ...................35
How to connect to a Bluetooth compatible
device (Pairing)......................................................35
For Bluetooth compatible device with SSP
(Secure Simple Pairing) ............................................35
For Bluetooth compatible device without SSP
(Secure Simple Pairing) ............................................35
Auto pairing with an iPod/iPhone........................35
Bluetooth SETUP.......................................................36
Setting the Bluetooth Connection
(BT IN)........................................................................36
Setting the Auto Pairing with
iPod/iPhone ............................................................36
Setting the Bluetooth Device...........................36
Setting the Visible Mode....................................36
Setting the Bluetooth sound quality.............37
Adjusting the volume (SOURCE VOL) .................37
Sound Auto setting (TYPE SET) .............................37
Setting the caller information display
ON/OFF.....................................................................37
Setting the Phone Book Update .....................37
Setting the Phone Book Auto Update ON/OFF
(AUTO) ............................................................................37
Setting the Phone Book Manual Update ON/OFF
(MANUAL)......................................................................37
Changing the Phone book List Order ...........37
Selecting the output speaker...........................37
Displaying the firmware version .....................38
Updating the firmware .......................................38

5-EN
Contents ENGLISH
Hands-Free Phone Control ................................... 38
About the Hands-Free Phone.......................... 38
Answering a Call................................................... 38
Hanging up the Telephone .............................. 38
Calling ...................................................................... 38
Redialling a Number In Outgoing History.........38
Dialling a Number In Incoming History .............38
Dialling a Number In Incoming Missed Call
History ............................................................................39
Dialling a Number In The Phone Book ...............39
Phone book Alphabet Search Function .............39
Voice Control Operation.................................... 39
Call waiting function........................................... 39
Preset a number in the Phone Menu
(Shortcut dial)........................................................ 39
Dialling the preset number .............................. 40
Adjusting the volume when receiving a
Call............................................................................. 40
Muting the microphone input quickly
(Voice Mute)........................................................... 40
Call Switching Operation .................................. 40
Bluetooth Audio Operation.................................. 40
Recalling the Bluetooth Audio Mode ........... 40
Selecting the desired Song ............................. 40
Pausing .................................................................... 40
Selecting the desired Group ............................ 40
Searching for a desired song ........................... 40
USB Memory (optional)
Playback MP3/WMA/AAC/FLAC Files from USB
Memory (optional)................................................... 41
About MP3/WMA/AAC/FLAC File of USB
Memory ....................................................................... 41
iPod/iPhone (optional)
Connecting an iPod/iPhone................................. 42
Setting the iPod Control........................................ 42
Playback ...................................................................... 42
Searching for a desired Song............................... 43
Direct Search Function........................................... 43
Select Playlist/Artist/Album/Genre/Composer/
Episode ........................................................................ 44
Alphabet Search Function .................................... 44
Search Position Memory ....................................... 44
Random Play Shuffle (M.I.X.) ................................ 44
Repeat Play................................................................. 44
Displaying the Text.................................................. 45
Information
In Case of Difficulty ..................................................45
Basic...........................................................................45
Radio .........................................................................45
CD (CDE-196DAB only) .......................................45
MP3/WMA/AAC.....................................................46
Audio.........................................................................46
iPod............................................................................46
Indication for CD Player
(CDE-196DAB only) ..............................................46
Indication for USB Memory...............................46
Indication for iPod Mode ...................................47
Bluetooth mode....................................................47
DAB mode ...............................................................47
Specifications .............................................................48
Installation and Connections
WARNING .................................................... 49
CAUTION...................................................... 49
PRECAUTIONS............................................. 49
Installation ..................................................................50
Removal ...................................................................50
Mounting the Microphone....................................51
Connections ...............................................................52

6-EN
Operating Instructions
WARNING
This symbol means important instructions. Failure
to heed them can result in serious injury or death.
DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY
FROM SAFELY DRIVING YOUR VEHICLE.
Any function that requires your prolonged attention should only be
performed after coming to a complete stop. Always stop the vehicle
in a safe location before performing these functions. Failure to do so
may result in an accident.
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE
NOISES WHILE DRIVING.
Excessive volume levels that obscure sounds such as emergency
vehicle sirens or road warning signals (train crossings, etc.) can be
dangerous and may result in an accident. LISTENING AT LOUD
VOLUME LEVELS IN A CAR MAY ALSO CAUSE HEARING
DAMAGE.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, fire or electric shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in fire, etc.
KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF
CHILDREN.
Swallowing them may result in serious injury. If swallowed, consult
a physician immediately.
USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.
Failure to do so may result in fire or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result in fire.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in fire,
electric shock or other injury.
DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION
SLOTS OR GAPS.
Doing so may result in personal injury or damage to the product.
CAUTION
This symbol means important instructions. Failure
to heed them can result in injury or material
property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it to your authorized Alpine dealer or the nearest
Alpine Service Centre for repairing.
PRECAUTIONS
Product Cleaning
Use a soft dry cloth for periodic cleaning of the product. For more
severe stains, please dampen the cloth with water only. Anything
else has the chance of dissolving the paint or damaging the plastic.
Temperature
Be sure the temperature inside the vehicle is between +60°C
(+140°F) and −10°C (+14°F) before turning your unit on.
Moisture Condensation
You may notice the CD playback sound wavering due to
condensation. If this happens, remove the disc from the player and
wait about an hour for the moisture to evaporate.
Damaged Disc
Do not attempt to play cracked, warped, or damaged discs. Playing
a bad disc could severely damage the playback mechanism.
Maintenance
If you have problems, do not attempt to repair the unit yourself.
Return it to your Alpine dealer or the nearest Alpine Service Station
for servicing.
Never Attempt the Following
Do not grip or pull out the disc while it is being pulled back into the
player by the automatic reloading mechanism.
Do not attempt to insert a disc into the unit when the unit power is
off.
WARNING

7-EN
Inserting Discs
Your player accepts only one disc at a time for playback. Do not
attempt to load more than one disc.
Make sure the label side is facing up when you insert the disc.
“ERROR” will be displayed on your player if you insert a disc
incorrectly. If “ERROR” continues to be displayed even though the
disc has been inserted correctly, push the RESET switch with a
pointed object such as a ballpoint pen.
Playing a disc while driving on a very bumpy road may result in
skips, but this will not scratch the disc or damage the player.
New Discs
To prevent the CD from jamming, “ERROR” is displayed if discs
with irregular surfaces are inserted or if discs are inserted
incorrectly. When a new disc is ejected immediately after initial
loading, use your finger to feel around the inside of the centre hole
and outside edge of the disc. If you feel any small bumps or
irregularities, this could inhibit proper loading of the disc. To
remove the bumps, rub the inside edge of the hole and outside edge
of the disc with a ballpoint pen or other such instrument, and then
insert the disc again.
Irregular Shaped Discs
Be sure to use round discs only for this unit and never use any
special shaped discs.
Use of special shape discs may cause damage to the mechanism.
Installation Location
Make sure this unit will not be installed in a location subjected to:
•Directsunandheat
• High humidity and water
• Excessive dust
•Excessivevibrations
Correct Handling
Do not drop the disc while handling. Hold the disc so you will not
leave fingerprints on the surface. Do not affix tape, paper, or
gummed labels to the disc. Do not write on the disc.
Disc Cleaning
Fingerprints, dust, or soil on the surface of the disc could cause the
CD player to skip. For routine cleaning, wipe the playing surface
with a clean, soft cloth from the centre of the disc to the outer edge.
If the surface is heavily soiled, dampen a clean, soft cloth in a
solution of mild neutral detergent before cleaning the disc.
Disc Accessories
There are various accessories available on the market for protecting
the disc surface and improving sound quality. However, most of
them will influence the thickness and/or diameter of the disc. Using
such accessories can cause the disc to be out of standard
specifications and may create operational problems. We
recommend not using these accessories on discs played in Alpine
CD players.
On handling Compact Discs (CD/CD-R/CD-RW)
• Do not touch the surface.
• Do not expose the disc to direct sunlight.
• Do not affix stickers or labels.
• Clean the disc when it is dusty.
• Make sure that there are no bumps around the disc.
• Do not use commercially available disc accessories.
Do not leave the disc in the car or the unit for a long time. Never
expose the disc to direct sunlight. Heat and humidity may damage
the CD and you may not be able to play it again.
To cu st om er s using CD -R/ CD- RW
• If a CD-R/CD-RW cannot be played back, make sure the last
recording session was closed (finalised).
• Finalise the CD-R/CD-RW if necessary, and attempt playback again.
About media that can be played
Use only compact discs with the label side showing the CD logo
marks below.
If you use non-standard compact discs, correct performance cannot
be guaranteed.
You can play CD-Rs (CD-Recordables)/CD-RWs
(CD-ReWritables) which have been recorded only on audio devices.
You can also play CD-Rs/CD-RWs containing MP3/WMA/AAC
formatted audio files.
• Some of the following CDs may not play on this unit:
Flawed CDs, CDs with fingerprints, CDs exposed to extreme
temperatures or sunlight (e.g., left in the car or this unit), CDs
recorded under unstable conditions, CDs on which a recording failed
or a re-recording was attempted, copy-protected CDs which do not
conform to the audio CD industry standard.
Centre Hole
Centre Hole New Disc
Outside
(Bumps)
Bumps
CORRECT
INCORRECT CORRECT
Transparent Sheet Disc Stabilizer

8-EN
• Use discs with compressed audio files written in a format compatible
with this unit. For details, refer to “About MP3/WMA/AAC” on
page 17.
• Data files, other than audio, on the disc are ignored and are not
played back.
Protecting the USB Port
• Only USB Memory devices or iPod/iPhone can be connected to the
USB port on this unit. Correct performance using other USB
products cannot be guaranteed. A USB hub is not supported.
• Depending on the shape or size of a USB device, it may not be
connected to the USB terminal of this unit-a USB extension (sold
separately) is recommended for this connection.
Avoid connecting USB memory and Front Aux at the same time.
• If a USB device is inserted in the unit, it projects out and may be a
danger while driving.
Use a commercially available USB extension cable, and connect it in a
safe way.
• Depending on the connected USB memory device, the unit may not
function or some functions may not be performed.
• The audio file format that can be played back on the unit is MP3/
WMA/AAC/FLAC.
• Artist/song name, etc., can be displayed, however some characters
may not be correctly displayed.
On Handling USB Memory
CAUTION
Alpine accepts no responsibility for lost data, etc., even if data,
etc., is lost while using this product.
• To prevent malfunction or damage, note the following points.
Read the USB memory Owner’s Manual thoroughly.
• Fix the USB Memory in a location where driver operation will not be
hindered.
• USB memory may not function correctly at high or low temperature.
• Use only certified USB Memory Devices. Please pay attention that
even certified USB Memory, may not function correctly depending
on its type or state.
• USB memory function is not guaranteed. Use USB memory
according to the terms of agreement.
• Depending on the settings of the USB memory type, memory state or
encoding software, the unit may not play back or display properly.
• A file that is copy-protected (copyright protection) cannot be played
back.
• USB memory may take time to start playback. If there is a particular
file other than audio in the USB memory, it may take considerable
time before the file is played back or searched.
• The unit can play back “mp3”, “wma”, “m4a” or “flac” file extensions.
• Do not add the above extensions to a file other than audio data. This
non-audio data will not be recognised. The resulting playback may
contain noise that can damage speakers and/or amplifiers.
• It is recommended to back up important data on a personal
computer.
• Do not remove the USB device while playback is in progress. Change
SOURCE to something other than USB, and then remove the USB
device to prevent possible damage to its memory.
• Windows Media and the Windows logo are trademarks, or
registered trademarks of Microsoft Corporation in the United States
and/or other countries.
• iPhone, iPod, iPod classic, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S. and other countries.
• “Made for iPod,” and “Made for iPhone,” mean that an electronic
accessory has been designed to connect specifically to iPod, or
iPhone, respectively, and has been certified by the developer to meet
Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory
standards. Please note that the use of this accessory with iPod, or
iPhone may affect wireless performance.
•TheBluetooth
®word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Alpine
Electronics, Inc. is under license.
• MPEG Layer-3 audio coding technology licensed from Fraunhofer
IIS and Thomson. Supply of this product only conveys a licence for
private, non-commercial use and does not convey a licence nor
imply any right to use this product in any commercial (i.e.
revenue-generation) real time broadcasting (terrestrial, satellite,
cable and/or any other media), broadcasting/streaming via internet,
intranets and/or other networks or in other electronic content
distribution systems, such as pay-audio or audio-on-demand
applications. An independent licence for such use is required. For
details, please visit http://www.mp3licensing.com
• Android is a trademark of Google Inc.
• The Android robot is reproduced or modified from work created and
shared by Google and used according to terms described in the
Creative Commons 3.0 Attribution License.

9-EN
CDE-196DAB
UTE-93DAB
Note
• The buttons on this Owner’s Manual use CDE-196DAB as an example.
Accessory List
• Head Unit ..................................................................................1
• Power Cable ..............................................................................1
• Microphone ..............................................................................1
• Mounting Sleeve ......................................................................1
• Carrying Case............................................................................1
• Rubber Cap ...............................................................................1
• Hex Bolt.....................................................................................1
• Bracket Key ...............................................................................2
• Screw (M5 × 8) ..........................................................................4
• Owner’s Manual..................................................................1 set
Turning Power On and Off
Press t to turn on the unit.
Note
• The unit can be turned on by pressing any other button except 
(CDE-196DAB only) and e(Release).
Press and hold t for at least 2 seconds to turn off the
unit.
Note
• The first time power is turned on, the volume will start from level 0.
Demonstration Function
This unit will enter a demonstration mode to display its various
functions. When Demo mode is set to ON (initial setting), the unit starts
the demonstration if there is no operation for 30 seconds.
There are two methods to close the demonstration mode.
Method 1:
When installing this unit in a car for the first time, the DEMO OFF screen
will be displayed for 20 seconds after turning on the unit. Press
ENTER within 20 seconds to put the demonstration mode into
standby state*.
Method 2:
Setting DEMO MODE to OFF (standby state*) or QUITE OFF (completely
closed state*) in Setup menu.
*For details about standby state and completely closed state, please refer
to “Demonstration” on page 30.
Source Selection
Press VSOURCE to change the source.
TUNER DAB+/DMB DISC*1 USB AUDIO/iPod*2 
BT AUDIO*3 AUXILIARY*4 TUNER
*1 CDE-196DAB only.
*2 Displayed only when the iPod/iPhone is connected.
*3 Displayed only when BT IN is set to ON, refer to “Setting the
Bluetooth Connection (BT IN)” on page 36.
*4 Refer to “Using the Front AUX Input Terminal” on page 26.
Detaching and Attaching the Front Panel
Notes
• The front panel may become hot in normal usage (especially the
connector terminals on the back of the front panel). This is not a
malfunction.
• To protect the front panel, place it in the supplied carrying case.
• When detaching the front panel, do not apply excessive force as it may
result in malfunction.
Getting Started
/
e
/DIM.
/SETUP /ENTER

/SOURCE Rotary encoder
/
e
AUDIO/SETUP /ENTER

/SOURCE Rotary encoder
Turning the Demonstration mode Off
Detaching

10-EN
Notes
• Before attaching the front panel, make sure that there is no dirt or dust
on the connector terminals and no foreign object between the front
panel and the main unit.
• Attach the front panel carefully, holding the sides of the front panel to
avoid pushing buttons by mistake.
Initial System Start-Up
Be sure to press the RESET switch when using the unit for the first time,
after changing the car battery, etc.
Adjusting Volume
Turn the Rotary encoder until the desired sound is
obtained.
Setting the Dimmer Control
(CDE-196DAB only)
Press and hold DIM. for at least 2 seconds repeatedly to
select the DIMMER mode.
DIMMERAUTO DIMMER ON DIMMER OFF DIMMERAUTO
DIMMERAUTO mode:
Decrease the illumination brightness of the unit’s buttons with the
head lights of the vehicle ON. This mode decreases the unit’s
backlighting in sync with headlight usage.
DIMMER ON mode:
Keep the illumination brightness of the backlighting dimmed.
DIMMER OFF mode:
Keep the illumination brightness of the backlighting bright.
Note
• The setting items are the same as DISPLAY setting in SETUP mode.
For details, refer to “Dimmer Control” on page 31.
Setting Time
1 Press and hold YSETUP for at least 2 seconds to
activate the SETUP selection mode.
2 Turn the Rotary encoder to select GENERAL, and then
press ENTER.
3 Turn the Rotary encoder to select the CLOCK ADJ mode,
and then press ENTER.
The time indication will blink.
4 Turn the Rotary encoder to adjust the hours while the
time indication is blinking.
5 When the hour has been adjusted, press ENTER.
6 Turn the Rotary encoder to adjust the minutes while the
time indication is blinking.
7 Press and hold YSETUP for at least 2 seconds to return
to normal mode.
Notes
• To synchronise the clock to another clock/watch or radio time
announcement, press and hold ENTER for at least 2 seconds after
setting the “hour”. Minutes will reset to “00”. If the display shows over
“30” minutes when you do this, the time will advance one hour.
• Even when AUTO CLOCK is set to ON (refer to “Setting the Time to
automatically be adjusted” on page 29), the time can be adjusted
manually. At the same time, if there is an adjustment request from RDS,
the time will be adjusted automatically by RDS data.
•Pressingtwill return to the previous mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Attaching
RESET switch
Controllable with Remote Control
This unit can be controlled with an optional Alpine remote control.
For details, consult your Alpine dealer.
Point the optional remote control transmitter at the remote control
sensor.
Connectable to Remote Control Interface Box
With an optional Alpine Steering Wheel Remote Control Interface
Box (not included), this unit is controllable from the vehicles
steering wheel controls. For details, contact your Alpine dealer.
Remote control sensor
