SERVICE MANUAL
DVA-5210
DVD-VIDEO/CD/MP3/WMA Player
3 / 04-A
68E36313S01
TO ALPINE Home Page

<Cautions for Safe Repair Work>
The following cautions will prevent accidents in the workplace and will ensure safe products.
*The symbols indicate caution is needed to prevent injuries and damage to property.
The symbols and their meanings follow.
*The following symbols indicate two levels of cautions.
When you see this symbol, you have to be very careful.
When you see this symbol, you have to follow the instructions there.
Do not look squarely into the laser light Fuse Caution
coming from the pickup. Always use a designated fuse.
You may loose you sight. Use of an incorrect fuse may result in a fire.
Do not allow wiring to be caught in the Battery Caution
screw/chassis. Use the designated battery.
If wiring is caught in the screw/chassis, it may Confirm the correct polarity and seat of the battery.
cause a short circuit, resulting in a fire. An incorrect battery or an improperly connected or
seated battery may result in a fire.
High Temperature Caution Designated Parts Caution
Touching the heat sink may cause severe burns. Look up the part list and ensure that only
designated parts are used to prevent problems or
accidents.
Reverse Power Supply Connections o
r
Wiring Caution
Misconnections Caution Ensure that the wiring is correct when rewiring to
Reverse power supply connections or prevent problems with ignition/breakdown.
misconnections may cause ignition problems and
smoke may result.
Soldering Caution Wear Glove
s
Hot solder from solder splash may cause severe Wear gloves to prevent electrical shocks or injury
burns. from the end face of the metal.
For the FDA laser standard, the following CAUTION label is stuck on each product
.
Please be careful for repair.
If you ignore this symbol and handle the product incorrectly or unsafely,
injury or only material damage may result.
If you ignore this symbol and handle the product incorrectly or unsafely,
serious injury or death may result.
Warning
Caution
Warning
Caution
CAUTION-Laser radiation when open, DO NOT STARE INTO BEAM
- 2 -

DVA-5210
Contents
Packing Assembly Parts List
4
Packing Method View
4
Specifications
5 , 6
System Connections
7 to 10
Extension Cable
11
Block Diagram
12
Parts Layout on P.W.Boards and Wiring Diagram
13 to 16
Schematic Diagram
17 to 25
Terminal Voltage of IC/ TR
26 to 35
Description of IC Terminal
36 to 40
Exploded View (Cabinet)
41
Exploded View (DVD Deck Mechanism) (DV33M01B)
42
NOTE : Due to continuing product improvement, specifications and designs are subject to
change without notice.
- 3 -

102
TOPSIDE
106
103
105
104
101
BOTTOM
SIDE
102
X1
101 -1
X4
101 -2
101 -3 101 -4
103 104
105
DVA-5210
Packin
g
Assembl
y
Parts List
PartNo. PartNo.
101-1 03S60820Y16 SCR,MCH5X8 ZN A 102 15D00529K02 CASE,INNER
101-2 46A70667Y01 STUD,BOLT 103 01T75472Y01 ASSY,REMO RUE-4201
101-3 02B70670Y01 NUT,CUS 5X5.5 ZN A 104 01T25634Y02 ASSY,WIREVIDEO 2000
101-4 60S70585F01 BAT,LIT.3V (CR2025) 105 01T55561W32 ASSY,DINS/L B/B2000
101-5 36A11113W01 CAP,RUBBER(A) 106 68P04190K34 O/MAOEUAODL
101-6 03A60836Y01 SCR,CUS 5X7 ZN A
Packin
g
Method View
Symbol Description
No.
Symbol Description
No.
101 -5 101 -6
X1
X1
X1 X1
X1
X1
X1 X1
TO CONTENTS
- 4 -

DVA-5210
Specifications
<AUDIO>
Output Level (PREOUT 10k ohm, 1kHz) .................................................................. CD (TCD-782) : 1200±100mV
MP3 (SCD-4419) : 1200±100mV
WMA (SCD-5100) : 1200±100mV
VCD (TVD-581A) : 1200±100mV
DVD (TDV-540A) : 1200±100mV
Channel Balance (PREOUT 10k ohm, 1kHz) ...................................................................... CD (TCD-782) : 0±3dB
MP3 (SCD-4419) : 0±3dB
WMA (SCD-5100) : 0±3dB
VCD (TVD-581A) : 0±3dB
DVD (TDV-540A) : 0±3dB
T.H.D. (PREOUT 10k ohm, 1kHz) ......................................................................................... CD (TCD-782) : 0.3%
MP3 (SCD-4419) : 0.3%
WMA (SCD-5100) : 0.3%
VCD (TVD-581A) : 0.3%
DVD (TDV-540A, 48kHz sample) : 0.3%
Frequency Response (PREOUT 10k ohm, Ref. 1kHz) ............................................ CD (TCD-782) : 17Hz : 0±3dB
127Hz : 0±2dB
10.007kHz : 0±2dB
19.997kHz : 0±4dB
MP3 (SCD-4419) : 17Hz : 0±3dB
127Hz : 0±2dB
10.007kHz : 0±2dB
19.997kHz : 0±4dB
WMA (SCD-5100) : 17Hz : 0±3dB
127Hz : 0±2dB
10.007kHz : 0±2dB
19.997kHz : 0±4dB
VCD (TVD-581A) : 21Hz : 0±4dB
127Hz : 0±2dB
10.007kHz : 0±2dB
19.997kHz : 0±4dB
DVD (TDV-540A) : 17Hz : 0±4dB
127Hz : 0±2dB
10.007kHz : 0±2dB
19.997kHz : 0±4dB
S/N Ratio (PREOUT 10k ohm, 1kHz) .................................................................................... CD (TCD-782) : 75dB
MP3 (SCD-4419) : 75dB
WMA (SCD-5100) : 75dB
VCD (TVD-581A) : 80dB
DVD (TDV-540A, 48kHz sample) : 80dB
Separation (PREOUT 10k ohm, 1kHz) .................................................................................. CD (TCD-782) : 70dB
MP3 (SCD-4419) : 70dB
WMA (SCD-5100) : 70dB
VCD (TVD-581A) : 65dB
DVD (TDV-540A) : 65dB
De-Emphasis (PREOUT 10k ohm, Ref. 1kHz) ...................................................... CD (TCD-782) : 4kHz : -20±3dB
16kHz : -20±3dB
- 5 -
TO CONTENTS

<VIDEO>
Signal system ....................................................................................................................................... PAL System
Flash signal Output Voltage ........................................................................................... VCD (HLV-402) : 1±0.15V
DVD (V-509) : 1±0.15V
Flash signal Frequency Response .................................................................... VCD (TVD-581A) : 2MHz : -1±2dB
DVD (TDV-540A) : 6MHz : -3±2dB
Flash signal S/N Ratio ......................................................................................................... VCD (HLV-402) : 45dB
DVD (V-509) : 50dB
<Pickup>
Wave Length ................................................................................................................................................. 655nm
Laser Power .............................................................................................................................................. CLASS II
<GENERAL>
Power Supply ........................................................................................................................................... DC 14.4V
Dark Current ..................................................................................................................................................... 5mA
Dimensions (W x H x D) .................................................................................................... Nose : 188 x 58 x 18mm
Chassis : 178 x 50 x 158mm
Weight ............................................................................................................................................................. 1.5kg
NOTE : Due to Continuing product improvement, specifications and designs are subject to change without notice.
DVA-5210
TO CONTENTS
- 6 -

System Connections
•Connect properly.
Never connect to parts other than the ones indicated in these operating instructions.
•Also refer to the operating instructions of the other products in the system.
Setting the System Switch
Switch to operate from either an Ai-NET compatible head unit or Ai-NET compatible AV head unit connected to this unit.
Be sure to set the system switch before fastening the DVA-5210 in place.
1Disconnect the power plug.
2Set the system switch at the bottom of this unit with a pointed object.
1:
When connecting to an Ai-NET compatible head unit or Ai-NET compatible AV head unit.
If set to 2, with any of the Ai-NET compatible (AV) head units connected, you may not be able to operate from the
head unit, or listen to audio from some external devices, etc.
The factory default is 1.
2:
When connecting to an Ai-NET incompatible head unit or another manufacturer's head unit.
3Connect the power plug.
BATTERY
IGNITION
REMOTE IN
GND
Red
Yellow
White/Brown
Black
Fuse
(7.5A)
Yellow • Battery Lead
Connect this lead to the positive (+) post of the vehicle’s battery.
Red
• Switched Power Lead (Ignition)
Connect this lead to an open terminal on the vehicle’s fuse box
or another unused power source which provides (+)12V only
when the ignition is turned on or in the accessory position.
When connecting with the Ai-NET compatible AV head unit or
the Ai-NET compatible head unit, do not connect the ignition lead.
White/
Brown
• Remote Control Input Lead
This lead is used in combination with the Ai-NET compatible AV
head unit or the ALPINE monitor with a remote control output lead.
Black
• Ground Lead
Connect this lead to a good chassis ground on the vehicle. Make
sure the connection is made to bare metal and is securely fastened
using the sheet metal screw provided.
• Ai-NET Connector (Black)
Connect this to the output or input connector of other product
equipped with Ai-NET.
• Remote Control Eye Jack
Connect this to the remote control sensor unit. Not used when
using a monitor with a built-in remote control sensor unit. A remote
control sensor unit is needed when a monitor or navigation unit
made by other company is connected.
• Ai-NET Connector (Gray)
Connect this to the output or input connector of other product
equipped with Ai-NET.
• Audio Output Connectors
This output may be connected to a Rear Monitor with a volume
control or an auxiliary audio preamp. This is used to monitor the
DVD audio while the main audio system is being driven by
another source (such as Radio or CD).
White (L)
Red (R)
• Video Output Connector
This connector is used in combination with the video inputs of
another video product (AV head unit or TV monitor).
Yellow
Cable Color Cable Specifications
• Digital Output Terminal (Optical)
This terminal is used to connect DVA-5210 to ALPINE digital audio
processor (PXA-H700 etc.).
These products include a fiber optic cable that will plug directly into
the Digital Output Terminal of the DVA-5210.
Connect to a metal part of
chassis body with a screw
Ignition Key
To remote control output
lead
Remote Control Eye
(Sold Separately)
DVA-5210
- 7 -
TO CONTENTS

System Example
Precautions when Making System Upgrades
Connecting a non Ai-NET compatible Head Unit, Digital Audio Processor (PXA-H700, PXA-H900, etc.)
and TV Monitor
• If using in a system with a head unit that is not fully Ai-NET compatible (no processor control) and a digital audio processor, do not connect
the head unit’s Ai-NET cable. Only connect the DVA-5210 and digital audio processor using an optical fiber cable and its own Ai-NET cable.
Use the head unit’s analog output (Front or rear) connected to the analog input of the processor.
• When connecting only to a digital audio processor (with a non-Alpine head unit or Alpine head unit without Ai-NET), it is possible to use both
an optical fiber cable and an Ai-NET output cable.
• When connecting another brand of TV monitor, there is no need to connect the remote control input cord (white/brown). Use the optional
remote control sensor unit.
• Be sure to connect the switched (ignition) power lead.
•Also refer to the operating instructions of the other products in the system.
Please observe the following when using Fiber Optic Cable.
• Do not coil th Fiber Optic smaller than a 30 mm radius.
• Do not place anything on top of the Fiber Optic Cable.
Monitor
TME-M790, etc.
(Sold Separately)
Head Unit non -compatible
Ai-NET (Sold Separately)
AV-Interface Unit
TME-M790, etc.
(Sold Separately)
Digital Input
Terminal (Optical)
(for DVD Player)
Remote Control Input Lead
(White/Brown)
Remote Control Output Lead (AUX1)
(White/Brown)
Only when connecting with rear monitor
RCA Extension Cable
AUX Audio Input
Terminal (AUX1)
AUX Video Input
Terminal (AUX1)
Audio Output
Connector
Video Output
Connector RCA Extension Cable
DVD Player
DVA-5210 Digital Output
Terminal (Optical)
Digital Audio Processor
PXA-H700, etc.
(Sold Separately)
System Switch
Remote Turn-On Lead (Blue/White) Remote Turn-On Lead (Blue/White)
Fiber Optic Cable
1
2
RCA Extension Cable
Setting of DVA-5210
Setting Item
System switch
Ai-NET setting
Setting
2 (ST ANDALONE)
-
DVA-5210
• After connections are completed, it will be necessary to change the system settings of the DVA-5210. Before
on OWNER'S MANUAL.
When connecting the DVA-5210 to a head unit or Ai-NET compatible AV head unit, do not connect the switched
• When connecting the DVA-5210 to an Alpine TV monitor and Ai-NET compatible AV head unit together, the remote
control input cable (white/brown) of both units must be connected. Failing to do so will result in a loss of remote
control operation. When making connections to another brand of TV monitor, please use the optional remote contrl
sensor unit.
installing the product, please see “ Setting the System Switch ” on OWNER'S MANUAL and “ Setting the Ai-NET ”
(ignition) power lead.
The DVA-5210's system settings must be made after
connections are completed. Before fixing the unit in place,
refer to “ Setting the System Switch ” on OWNER'S MANUAL
and “ Setting the Ai-NET ” on OWNER'S MANUAL.
- 8 -
TO CONTENTS

Connecting an Ai-NET compatible Head Unit, Digital Audio Processor (PXA-H700, PXA-H900, etc.)
and TV Monitor
• Be sure to switch the head unit’s system switch before turning the power on.
•Also refer to the operating instructions of the other products in the system.
•To connect a rear monitor, connect to the front monitor’s RCA output (TV Tuner Box).
Please observe the following when using Fiber Optic Cable.
• Do not coil th Fiber Optic smaller than a 30 mm radius.
• Do not place anything on top of the Fiber Optic Cable.
The switched (ignition) power lead connection is not needed.
Digital Audio Processor
PXA-H700 etc
(Sold Separately)
Digital Input
Terminal (Optical)
(for DVD Player)
Digital Output
Terminal
(Optical)
Fiber Optic Cable
Ai-NET Cable
Ai-NET Connector
(Gray)
CD Changer
(Sold Separately)
DVD Player
DVA-5210
Only when connecting with rear monitor
Audio Output
Connector
RCA Extension
Cable
AUX Audio Input Terminal (AUX1)
AUX Video Input
Terminal (AUX1)
Remote Control
Output Lead (AUX1)
(White/Brown)
Remote Control
Input Lead
(White/Brown)
Video Output
Connector
RCA Extension Cable
Monitor
TME-M790 etc
(Sold Separately)
AV-Interface Unit
TME-M790 etc
(Sold Separately)
Head Unit
with Ai-NET
(Sold Separately)
Ai-NET Cable
Ai-NET Input
Connector
System Switch
1
2
Ai-NET Input
Connector
Ai-NET Cable
Ai-NET Connector
(Black)
Ai-NET
Connector
When connecting a digital audio
processor using Ai-NET feature, place
this switch in the EQ/DIV position.
EQ/DIV
System Switch
DVA-5210
Setting of DVA-5210
Setting Item
System switch
Ai-NET setting
Setting
1 (Ai-NET)
AV Head unit available after
December 2003 (IVA-D300R, etc.)
FULL
2004 (IVA-D900R, etc.) or head unit.
TIME
The DVA-5210's system settings must be made after connections are completed. Before fixing the unit in place,
AV head unit available before January
refer to “ Setting the System Switch ” on OWNER'S MANUAL and “ Setting the Ai-NET ” on OWNER'S MANUAL.
- 9 -
TO CONTENTS

Connecting an Ai-NET compatible Head Unit and TV Monitor
• Be sure to switch the head unit’s system switch before turning the power on.
•Also refer to the operating instructions of the other products in the system.
•To connect a rear monitor, connect to the front monitor’s RCA output (TV Tuner Box).
The switched (ignition) power lead connection is not needed.
Ai-NET Output
Connector
Ai-NET Cable
Ai-NET Connector
(Black)
Ai-NET Cable
Ai-NET Connector
(Gray)
CD Changer
(Sold Separately)
DVD Player
DVA-5210
Only when connecting with rear monitor
Audio Output
Connector
RCA Extension
Cable
AUX Audio Input Terminal (AUX1)
AUX Video Input
Terminal (AUX1)
Remote Control
Output Lead (AUX1)
(White/Brown)
Remote Control
Input Lead
(White/Brown)
Video Output
Connector
RCA Extension Cable
Monitor
TME-M790, etc.
(Sold Separately)
AV-Interface Unit
TME-M790, etc.
(Sold Separately)
Head Unit
with Ai-NET
(Sold Separately)
System Switch
NORM
System Switch
1
2
When an Ai-NET digital audio
processor is not used, place this
switch in the NORM position.
DVA-5210
Setting of DVA-5210
Setting Item
System switch
Ai-NET setting
Setting
1 (Ai-NET)
AV Head unit available after
FULL TIME
The DVA-5210's system settings must be made after connections are completed. Before fixing the unit in place,
AV head unit available before January
refer to “ Setting the System Switch ” on OWNER'S MANUAL and “ Setting the Ai-NET ” on OWNER'S MANUAL.
December 2003 (IVA-D300R, etc.) 2004 (IVA-D900R, etc.) or head unit.
- 10 -
TO CONTENTS

DVA-5210
Extension Cable
Extension Cable
(01E35217S01)
Main P.W.Board
DVD Deck Mechanism
* When repairing or measuring the voltage of this unit, connect with the Extension Cable as shown in below.
- 11 -
TO CONTENTS

DVD5V
u-COM
SERVO +7V
PWR+9V
SERVO 7V
DIGITAL OUT
DVD ACK
U-COM +B
BATT
BATT
RESET
PWR +4V
SERVO+5V
DVD+2V
BATT
BATT
9V
P-CONT4
P-CONT2
REM
JAC
RESET-IC
B-DET
DVD+3.3V
DVD+5V
BATT3.3V
SERVO 5V
BATT3.3V
DVD3.3V
9V
VUCOM
VUCOM
4V
DVD DI
DVD DI DVD ACK
2 INPUT
AND GATE
A-DET A-DET
DVD2V
P-CONT2
P-CONT2
P-CONT4
P-CONT1
BATT
SERVO7V
SERVO5V
MUTE
AUDIO Lch
AUDIO Rch
AI-NET IN
AI-NET OUT
BUS I/F
A-MUTE
V-MUTE
DVD RST
I/F
AI-NET BUS
CH3001
VIDEO OUT
CH3001
AUDIO(L) OUT
CH3001
AUDIO(R) OUT
IC3008
OPT OUT
MUTE
BUFF
BUFF
ISO
ISO
AUDIO +9V
LED +B
V-MUTE SW
PWR SAVE CTL
V MUTE
BATT
ACC
REMOCOM
EYE IN
D-MUTE
ROMOTE IN
BUFFER
EJECT SW
RESET SW
BUZZER
DISC-IN IND.
DVD VIDEO IND.
AUDIO CD IND.
VIDEO CD IND.
EJECT KEY
BUS <-> STANDALONE
SW
P-CONT1
4V
P-CONT3 P-CONT3
DVD Y OUT /
CVBS
AUDIO VCC
CH8001
Block Diagram DVA-5210
- 12 -
TO CONTENTS

BZ8001
C2001
C2002
C2003
C2004
C2006
C2008
C2018
C3012
C3013
C3014
C3017 C3018
C3019
C3020
C3021
C3024
C3025
C3026C3027
C3031
C3032
C3039 C3040
C5001
C5002
C5003
C5009
C5014C5015
C5019
C5105
C5106
C8010 C8011
C8012
C8030
D5004
C8041
CB3001
CB8001
CB8002
CH5001
TP9129
TP9128
TP9127
TP9104
TP9103
TP9106
D3007
R8045
DIN3001 DIN3002
E2001
E2002
E2004
R9219
E2007
Q8017
L2008 L2006
E3022
E3024
E3025
E3026
E5001
E5002
E5004
E8001
E8002
E8003
E8005
E8006
E8007
E8008
E8010
E8011
C3044
E8014
E8016
E8017
E8020
E8022
R5117
E8023
E8024
E8025
E8026
E8027
E8028 E8029
E8030
IC2001
IC3002IC3003 IC3004
C9220
C9213
IC3005 IC3006
C9212
IC3007
IC3008
IC5001
IC5002
IC8001
IC9202 IC8004
C3001
R3015
R9207
R9206
R9218
R9215
R9213
R9214
R9211
R9212
ZD8006
TP2003
C9201
R9210
R815
JK8002
C9211
L5001
L5002
L8002
L8004
VT2001
Q2003
C3043 C3042
R9622
R2008
R2009
R2010
R2014
R5116
C3041
C3028
R3017 R3018
R3021 R3022
R3023
R3024 R3026
R3027
R3036
R3037
R3040R3041 R3042R3043
R3044R3045
R3047
R3048
R3050
R3056
R3057
R3058
R3060R3061 R3062R3063
R3064R3065
R3067
R3068
R3069
R3070
R3075 R3078
R3080
R3081 R3087
R5005 R5006 R5007
R5008
R5009
R5010 R5011 R5012 R5013
R5014
R5015
R5025
R5030
R5040 R5047
R5051
R5052
C3006
C2023
R5096
R5103
R5104
R5105
R8002
R821
R8043
R8044
R8074
R819
R8078
R8098
R8101 R8102
R8103
R8104R8105
R8106
C3005
RA5081 RA5082 RA5083 RA5084
RA5085RA5086RA5087RA5088RA5089RA5090
RA5091
RA5092RA5093
RA5094
SW5001
TH5001
L5004
E5003
XL2001
XL5001
XL5002
Z2003
Z8001
Z8002
Z8004
ZD5002
ZD5003
ZD8002
ZD8003
R3016
R817
C3003
R813
C9221
C9219
C3004
C9218
XL2002
C3002
R9645
RA9502
TP9530
C9116
R9107
C9570
C9571
TP9114
TP9121
TP9120
TP9119
TP9118
TP9113
TP9126
TP9125
TP9124
TP9130
TP9117
TP9116
TP9115
TP9102
TP9101
TP9105
TP9532
R811
C8049
TP9531
TP9123
TP9122
TP9529
TP9528
TP9517
TP9507
TP9506
TP9505
TP9504
TP9503
TP9502
TP9501
TP9508
TP9509
TP9510
TP9511
TP9512
TP9513
TP9514
TP9515
TP9516
TP9518
TP9519
TP9520
TP9521
TP9522
TP9523
TP9524
TP9525
TP9526
TP9527
TP9533
R9608
R9104
R9105
R9597
IC9501
R9595
R9593
R9101
R9513
IC9502 IC9503 IC9505
R9607
IC9702 IC9201
R9586
R9594
R9596
R9609
R9600
L9802 L9803
C9210
CB9501
R9205
R9102
R9103
C9501 C9503
C9506 C9505C9509 C9508C9511 C9510
C9523 C9524
C9533
C9534
C9536
C9701
C9710
C9801
C9713
C9802
C9805
C9806
C9507
R9546
R9731
IC9506
R9805
R9591
R9564
R9592
R9612
R9642
R9109
R9801
C9209
R9802
R9701
C9208
R9534
R9545
R9587
R9588
R9589
R9590
C9207
R9806
C9718
R9120
R9631R9632
TP9550 TP9551
TP9552
TP9553
TP9554 TP9555
TP9556
XL9510
R9710
RA9527RA9526RA9525RA9524RA9523 RA9522RA9521RA9520
RA9519RA9518
RA9517RA9516
RA9515
RA9514RA9513RA9512
RA9511RA9510 RA9509RA9508
RA9507RA9506
RA9505RA9504
RA9503
RA5080
R5050
R5043
R5042
C2007
TP9534
R9619
C9115
L9502
TP9543
C9529
C9530
R9108
R9618
R9640
R9611 R9610
IC9103
RA9501
Z9516
Z9515
Z9514
Z9513
Z9512
Z9511 Z9510 Z9509 Z9508 Z9507 Z9506
Z9107
R2047
C5016
MAIN P.W.Board (Component Side View)
1
2
3
4
5
ABCDE FG
Parts Layout on P.W.Boards and Wiring Diagram (1/4)
Orange Color Pattern:Component Side Pattern
Blue Color Pattern:Foil Side Pattern
DVA-5210
- 13 -
TO CONTENTS

C2005
C2009
C2010 C2011 C2012 C2013
C2017
C3008C3009
C3010C3011
C3015C3016
C3033 C3034
C3036
C3037
C3038
C5004
C5005
C5006
C5007
C5008
C5010
C5011
C5012
C5013
C2024
C5017
C5018
C5020 C5021
C5022
C5100
C5104
C5107
C5108
C8001
C8002
C8003
C8004
C8005
C8006
C8007
C8008
C8015
C8016
C8017
C8018
C8019
C8020
C8021
C8022
C8024
C8026
C8028 C8029
C8033
C8034
C8035
C8036
C8038
C8039
C8040
C8042
C8043
C8044
C8046
C8047
C8048
TP3006
C9214
D2001
D2005
D3002
D3003
D5001
D5002
D5003
R5053
D8002 D8004
D8005
D8007
D8008
D8009 D8010 D8011 D8012
D8013
D8014
TP8013
ZD5005
TP8011
TP8012
TP8009
TP5010
TP5007
TP5008
TP5005
TP5006
TP5002TP5003TP5001
R5039
L2005
L2004
R2033
IC2003
R2043
R2042
Q5007
IC5003
IC5004
IC5106
IC8002
IC8003
C9215
IC8005
IC8006
IC8007
IC8008
IC8009 IC8011
R9201 R9202R9204 C9205
R9203 R9217 R9216
C9127
TP8014
TP5018
TP5017
Q8003
TP5016
TP5015
TP5014
TP5013 TP5012
TP5011
TO8078
TP3004
TP3001
R2046
TP3018
TP3017
TP3016TP3015TP3014
TP3019
TP3024
TP3023
TP3022
TP3021
TP3020
C9216
TP3008
R9208
R9209
C9204
R818
R816
C9206
L2001 L2002 L2003
L5003
TP8015
C9203
C9202
Q2004
Q2007
Q2008
Q3005
Q3006
Q3009
Q3010
Q3011
Q5001
Q5002
Q5003
Q5004
Q8001 Q8002
Q8005
Q8006
Q8007
Q8008
Q8010
Q8011
Q8012
Q8013
Q8014
Q8015
R2001
R2004
R9670
R9671
R2007
R2011
R2012
R2013
R2015
R2016
R2017
R2018
R2019
R2020
R2021
R2022
R2023
R2024
R2025
R2026
R2027 R2028
R2029
R2030
R2032
Q5005
R2037 R2038
R2039
R2040
R2041
R2044
R2045
R3019
R3020
R3025
R3030 R3031
R3032 R3033
R3034R3035
R3038
R3039
R3049
R3051
R3052 R3053
R3054
R3055
R3059
R3071 R3072
R3073 R3074
R3076R3077
R3079
R3083 R3084
R3085
R3086
R3088
R3090
R5001
R5002
R5003
R5016
R5017
R5018 R5019 R5020
R5021
R5022
R5023
R5024 R5026 R5027 R5028 R5029
R5031
R5032
R5033
R5034
R5035
R5036
R5037
R5038
R5041
R5048
R5049
R5095
R5106 R5107
R5109R5111
R5112
R5113
R5114
R5115
R8001
R8003
R8004 R8005
R8006
R8007
R8008
R8009
R8010
R8011
R8012
R8013
R8015R8016R8017
R8020R8021R8022
R8023R8024R8025
R8026
R8027R8028
R8029
R8030R8031R8032
R822
R820
R8035R8036R8037
R8038
R8039
R8040
R8041
R8042
R8050
R8051
R8052
R8053
R8054
R8055
R8059
R8060
R8061
R8062R8063
C2021
R8065
R8066
R8067
R8068
R8069
R8070 R8071
R8072
R8073
R8075
R8079
R8080
R8081 R8082
R8083 R8084
R8085
R8086
R8087
R8092
R8093
R8094
R8095
R8096
R8097
R8099
R8100
RND2001
TP2001
TP5104
TP5105
TP5108
TP5109
TP5112
TP5113
TP5114 TP5115
TP5118
TP8001
TP8002
TP8003
TP8004
TP8005
TP8006
Q8016
Z2001
Z8003
C2019
ZD8001
ZD8004
C2020
C2022
R3029
TP3010 TP3009
R3028
C3029
Q5006
L2007
TP5004
TP5009
TP8010
TP3011
IC2002
TP3012
R812
TP3003
TP2006
TP3005
TP2005
TP3002
C9217
R5044
R8014
R5045
C8009
R814
TP3025
TP5034
TP5103
TP3027
TP3026
TP5022
TP5023
TP5021
TP5020
TP5027
TP5026
TP5030
TP5029
TP5028
TP5033
TP5032
TP5031
TP8086
TP8085
TP8084
TP8083
TP8082
TP8081
TP8080
TP8079
TP8077
TP8076
TP8075
TP8074
TP8072
TP8071
TP8070 TP8069
TP8068
TP8067
TP8066
TP8065
TP8064
TP8063
TP8062
TP8061
TP8060
TP8059
TP8058
TP8057
TP8056
TP8055
TP8054
TP8053 TP8052
TP8051
TP8050
TP8049
TP8048
TP8047
TP8046
TP8045
TP8044
TP8043
TP8042
TP8041
TP8040
TP8039
TP8038
TP8037
TP8036
TP8035TP8034
TP8033
TP8032
TP8031
TP8030
TP8029
TP8028
TP8027
TP8026
TP8025
TP8024
TP8023
TP8022TP8021
TP3007
C5101
C5102
R9646
C9550
L9501
R9584
C9545
C9714
R9656
R9574
R9654
R8019
C9544
R9106
L9701
R9636
R9635 R9634
R9644
C9104
R9647
R8018
R9704
IC9701
R9653
L9201
IC9704
IC9703
R9638
C9110
R9637
TP9542
R9649
R9707
IC9705
IC9504
R9705
R9652
R9651
Q8004
L9503
L9801
R9708
Q9802
Q9801
IC9104
C9502 C9504
C9513
C9512
C9515
C9514
C9517
C9516
C9519
C9518
C9521
C9520
C9522
C9525
C9526
C9535
C9543
C9542
C9702
C9704C9703 C9706C9705
C9708
C9707
C9709
C9712 C9711
C9803 C9804 C9807 C9808
R9730
C9531
C9532
R9616
R9804 R9803
R9703
R9581
R9643
R9702
C9102
R9639
R9620
C9539
C9537
L9102
L9202
R9578
R9583
R9582
C9113
C9114
R9536
R9585
R9621
R9808 R9807
IC9101
C9717
C9739
C9715
C9552
R9110
R9111
R9630
R9633
R9650
R9720
C2026
R9657
TP5102
TP5101
TP5025
TP5024
R5110
R5108
R5004
C9112
C9108
C9106
R9575
R9576
R9658
C9540
C9549
R9706
C9528
L9101
C9541
R9580
C9527
R9547
Z9519
C9716
Q9701
R9579
Q9501
IC9102
R9655
R9648
TP9802TP9801
TP9575TP9574 TP9573TP9572
TP9571
TP9570
TP9569
TP9568
TP9567
TP9566
TP9565
TP9564
TP9563
TP9562
TP9561
TP9560
TP5107
TP5106
R8033
R8034
C3050
R2035R2034
L2009
C2025
MAIN P.W.Board (Foil Side View)
1
2
3
4
5
ABCDE FG
Parts Layout on P.W.Boards and Wiring Diagram (2/4)
Orange Color Pattern:Component Side Pattern
Blue Color Pattern:Foil Side Pattern
DVA-5210
- 14 -
TO CONTENTS

LD4003LD4002LD4001
C4001
LD4004
LD4007LD4008 LD4009
LD4010
Q4007 Q4008 Q4009
Q4010 Q4011
Q4012
R4003
R4004
R4009R4010
R4014
SW4001
SW4002
ZD4006 ZD4005ZD4004
ZD4003
C4003
C4002
R4027
CB4001
Q4003
Q4004
Q4005
Q4006
R4005 R4006
R4007
R4008
R4011
R4012
R4013
R4015 R4016 R4017 R4019 R4020 R4021
R4024
ZD4001
ZD4002
R4030
R4029
R4026
R4028
R4025
R4023
R4022
FRONT P.W.Board (Foil Side View)
FRONT P.W.Board (Component Side View)
1
2
3
4
5
ABCDE FG
Parts Layout on P.W.Boards and Wiring Diagram (3/4)
Orange Color Pattern:Component Side Pattern
Blue Color Pattern:Foil Side Pattern
DVA-5210
- 15 -
TO CONTENTS

SW406
TP417
TP418 C353
C351
C204
RA107 RA108
RA109
RA110
R118
R119
R120
R121
R123
R124
R125
R336
R601
R603
R604
R334
R707R708
R717R718
R521
R522
R301
R355
R356
R357
R129
R319
R320
R127
R126
R321
R350
C365
R209
R210
R438
R411 R412
R413
R414
R533
R611
R410
R203
R206
R702
R317
R511
R512
R128
R528
R529R530 R531 R544
R545
R351
R352
C800
R705R706
R614R615
R635
R724
R725
R726
R200
R722
R723
C340
C339
C702C703
C704 C705
C332
C336
C347
C521
C101
C202
C203
C205
R450
C304 C305
C309
C310
C311
C312
C313
C315
C316
C345
C359
C360
C363
C407
C519
C522
C528
C516
C518
C337
C338
C514 C515
C331
C335
E702
E202
E203
C802
SW401
SW402
SW403
SW405
R408
Q506
IC201
C803
IC601
IC202
R421
R645
R339
R801 C812
SW404
IC701 IC203
R647
R646
R644
R643
TP291
R427
R133
R212
R101
R641 R640
R638
R637
R132
IC204
C207
TP210
C810
R802
R337
R810
R811
SD603
R338
R451
C352
R204
R642
R639
R636
C813
R800
R419
C811
C801
R803
C356
C355
R208
R813R812
C822
C820
C821
C706
R313
R312 R309
R310
R311
C606 C357
TP449
TP450 TP448
TP451
TP452
R510
R506
R328
R507
RA105
RA106
RA101
RA102 RA103
RA104
R122
R630
R631
R404
R306
R307
R340
R519
R520
R345
R333
R331
R332
R406
R407
R302
R303
R304
R416
R437
R316
R439
R505
R329
R330
R503 R504
R322
R415
R440
R517
R442
R443
R305
R131
R318
R402
R403
R405
R423
R417
R508
R509
R518
C512
TP445
TP446
R425
R424
R422
IC401
C510
C320
C346
C604
C328
C525
C526
C301
C302C303
C307
C308
C314
C317
C319
C329
C348
R360
C354
C358
C361
C362
C364
C401
C402 C403
C404
C405
C406
C408
C410
C411
C502 C503C504
C505
C506
C507
C511
C712
C330
C318
C501
C333
C334
C523
C524
CB401
XL301
CB601
CB101
E503
E505
TH401
TH402
Q501
Q507
Q508
R409
R324 R323
R513
R308
C322
IC301
SD602
TP457
TP456
IC403
R804
C808
IC501
C804
C452
C806
TP444
TP443
TP442
TP441
TP440
IC402
C807
C321
CL401
CB602
TP214TP215
TP246
TP247
TP262TP263
TP264TP265
TP267
C417
C416
TP273
TP274
TP279
TP282
TP284
TP285
TP288
TP289
TP292
TP293 TP294TP295
TP296
TP301TP302TP303
TP304TP305
TP306
TP312
TP313
TP323 TP335
C809
C529
TP393 TP394
R426
TP405
TP406
E301
TP439
TP101
TP102
TP103
TP104
TP105
TP106 TP107
TP108
TP109
TP110
TP111
TP112
TP113
R102
TP138
TP139
TP140
TP141
TP142 TP143
TP144TP145
TP202
TP204
TP207
TP212TP213TP216
TP218
TP219
TP220
TP221
TP222
TP223
TP224
TP307
TP308
TP316
TP317
TP318
TP319
TP320
TP321
TP322
TP324
TP325
TP326
TP327
TP337
TP338
TP339
C530
TP344
TP351
TP352 TP353
TP354
TP355
TP356
TP357
TP358
TP359
TP360
TP363
TP364
TP367 TP368
TP369
TP381
TP382
TP383
TP384
TP385
TP386 TP387
TP388
TP390
TP391
TP400
TP401
TP402
TP403
TP404
TP409
TP410
TP411
TP412
TP413
TP414
TP415
TP416
TP429
TP430
SD402
C513
C451
C418
C415
R418
L301
C450
R325
R524
R808
R806
R809
R807
C454
C453
TP447
R428
C420
C419
R514
R515
TP453
MAIN-LSI P.W.Board
(Foil Side View)
FPC,LOAD P.W.Board
(Foil Side View)
FPC,DRIVE P.W.Board
(Foil Side View)
LIMIT P.W.Board
(Foil Side View)
MAIN-LSI P.W.Board
(Component Side View)
1
2
3
4
5
ABCDE FG
Parts Layout on P.W.Boards and Wiring Diagram (4/4)
Orange Color Pattern:Component Side Pattern
Blue Color Pattern:Foil Side Pattern
DVA-5210
The patterns should be short-circuited,
when the PICKUP is removed
from DVD Mechanism.
- 16 -
TO CONTENTS

TP9520
TP9521
TP9522
TP9523
TP9524
TP9525
TP9518
TP9526
TP9527
TP9528
TP9517
TP9516
TP9508
TP9515
TP9507
TP9514
TP9506
TP9513
TP9505
TP9512
TP9504
TP9511
TP9503
TP9510
TP9502
TP9509
TP9501
TP9533
TP9532
TP9531
C9543
2200p
C9544
1000p
C9539
2200p
C9540
1000p
C9542
1000p
C9541
2200p
CB9501
54104-5092
L9503
BLM18PG181SH1
TP9519
C9550
2200p
IC9506
TC7SET08FU
R9619
22k
R9618
22k
TP9555
TP9567
TP9566
TP9565
TP9564
TP9563
TP9562
TP9561
TP9560 RA9518
100x4
RA9519
100x4
RA9511
100x4
RA9510
100x4
RA9509
100x4
RA9508
100x4
RA9507
100x4
RA9506
100x4
IC9502
TC7MZ245FK
C9533
2200p
C9534 2200p
IC9503
TC7MZ245FK
R9575 100
R9574 100
R9578
4.7k
IC9504
TC7WH126FU
C9535
2200p
TP9568
TP9569
TP9570
TP9571
TP9575
TP9574
TP9573
TP9572
IC9505
TC7MZ245FK
TP9556
Q9501
UN5212
R9576
22k
C9537
2200p
TP9115
TP9113
R9103 33
R9101 33
R9607 120
R9608 68
R9609 120
R9610 120
R9611 120
R9612 120
BK1005LL680 Z9507
Z9506
BK1005LL680
BK1005LL680 Z9508
BK1005LL680 Z9509
BK1005LL680 Z9510
BK1005LL680 Z9511
C9518
2200p
C9519
2200p
C9520
2200p
C9521
2200p
C9523
2200p
C9524
2200p
C9522
2200p
R9636
22k
R9642
4.7k
R9633
4.7k
R9635
4.7k
R9634
4.7k
R9639
N.U.
R9640
4.7k
R9594 68 R9592 68 R9600 68 R9593 68
TP9542
RA9512 68x4
RA9513
68x4
R9591
68
R9649
4.7k
R9648
4.7k
RA9514
68x4
C9511
2200p
C9510
2200p
C9509
2200p
C9508
2200p
C9507
2200p
C9506
2200p
C9505
2200p
R9536 100
R9534 68
Z9519
BK1005LL680
RA9527
68x4
RA9526
68x4
RA9525
68x4
RA9524
68x4
RA9523
68x4
RA9522
68x4
RA9521
68x4
RA9520
68x4
R9513 68
C9501
10
C9503
10
C9502
2200p
C9504
2200p
C9532
2200p
C9570
12p
R9632
1k
C9571
12p
C9531
1000p
L9501
BLM18PG181SH1
R9658
4.7k
R9657
4.7k
R9656
4.7k
R9655
4.7k
R9654
4.7k
R9670
4.7k
R9650
4.7k
R9582
4.7k
R9585
4.7k
R9653
4.7k
R9652
4.7k
R9651
4.7k
XL9510
27.00MHz
C9530
2200p
C9529
2200p
C9528
2200p
C9527
2200p
C9526
2200p
C9525
2200p
R9595
100
R9631
1M
Z9512
BK1005LL100
Z9513
BK1005LL100
Z9514
BK1005LL100
Z9515
BK1005LL100
R9590
68
R9589
68
R9588
68
R9587
68
Z9516
BK1005LL100
R9586
68
R9583
4.7k
C9739
2200p
R9581
4.7k
R9584
4.7k
TP9543
R9564
68
RA9515
68x4
RA9502
68x4
RA9501
68x4
RA9503
68x4
ES6218SF
IC9501
C9512
2200p
L9502
BLM18PG181SH1
R9622
N.U.
R9630
N.U.
R9620
68
R9621
68
R9597
0
R9596
N.U.
C9549
0.1
C9513
1000p
C9514
2200p
C9515
2200p
C9516
2200p
C9545 0.1
R9671
4.7k
R9616
390
RA9516
100x4
RA9504
100x4
RA9505
100x4
RA9517
100x4
C9517 2200p
R9547
4.7k
R9643
4.7k
R9645
4.7k
R9644 4.7k
R9545
100
R9546
100
R9637
4.7k
R9638
4.7k
R9647
4.7k
R9646
4.7k
C9536
2200p
TP9550
TP9534
TP9554
TP9553
TP9529
TP9530 TP9551
TP9552
C9552
2200p
R9580
10k
R9579
4.7k
- 17 -
TO CONTENTS
TO PARTS LIST
TO P. W. BOARD

C9702
2200p
C9703
2200p
C9704
2200p
C9705
2200p
C9706
2200p
C9707
2200p
C9709
2200p
C9708
2200p
C9701
10
IC9701
HY57V641620HGT-HI
R9731
100 R9730
100
R9707
N.U.
R9708
100
C9717
N.U.
L9701
N.U.
C9715 2200p
C9716 1000p
IC9705
TC74VHCT374AFT
R9703
68
R9705
68
R9706
68
R9704
N.U.
R9710
N.U.
TP9120
C9714
2200p
R9702
4.7k
R9720
10k
Q9701
UN5212
IC9704
TC7SH32FU
C9718
N.U.
R9701
N.U.
IC9702
MBM29LV160TE90
C9710
10
C9713
2200p
C9712 2200p
C9711
1000p
IC9703
LC35256FT-70UHS
- 18 -
TO CONTENTS
TO PARTS LIST
TO P. W. BOARD

R9807
N.U.
R9805
N.U.
R9808
N.U.
C9807
N.U.
C9805
N.U.
C9806
N.U.
C9808
N.U.
R9803
330
R9804
330
C9803
2200p
C9804
N.U.
R9806
N.U.
R9802
75
R9205
68
R9801
75
L9803
N.U.
Q9802
N.U.
L9802
1uH Q9801
2SA1037AK
TP9802
TP9121
TP9801
L9801
BLM18PG181SH1
C9801
47p
C9802
100p
IC9201
PCM1742KE
C9211
10
L9201
BLM18PG181SH1
L9202
BLM18PG181SH1
C9207
10
C9209
10
C9210
0.022
C9208
0.022
C9212
3.3
C9213
3.3
R9207
5.6k
R9206
5.6k
R9211
2.2k
R9210
2.2k
R9213
10k
R9212
10k
R9219
47
R9218
47
R9203
6.8k
R9204
6.8k
R9202
6.8k
R9215
820
R9214
820
R9217
330k
R9216
330k
R9209
22k
R9208
22k
C9215
470p
C9214
470p
C9217
120p C9216
120p
IC9202
NJM4580V
IC9202
NJM4580V
C9219
180p
C9221 82p
C9220 82p
C9218 180p
C9206
0.022
C9205
0.022
C9204
10
R9201
6.8k
C9203
10
C9201
10
IC9103
TC7SET08FU
IC9104
TC7SET08FU
C9116
2200p
R9111
22k
R9110
22k
C9115
2200p
R9108
N.U.
R9107 33
Z9107
BK1005LL100 R9109
68
TP9118
C9202
0.022
TP9129
TP9128
TP9127
TP9126
TP9125
TP9124
TP9123
TP9122
TP9119
TP9117
TP9116
TP9114
TP9130
TP9106
TP9105
TP9103
TP9102
TP9101
TP9104
R9105 33
R9104 33
R9102 33
C9102
2200p
C9104
2200p
C9106
2200p
C9108
2200p
C9110
2200p
C9112
2200p
C9127
4.7
L9101
FBMJ2125HS420
L9102
FBMJ2125HS420
C9113
2200p
IC9101
TC7WH126FU
IC9102
TC7WH126FU
C9114
2200p
R9106
22k
R9120
22k
- 19 -
TO CONTENTS
TO PARTS LIST
TO P. W. BOARD

Q5004
FMC3
TP5010 TP5009 TP5008 TP5007 TP5006 TP5005 TP5003 TP5002
TP5001
TP5004
R5026 N.U.
R5025 0
R5028 N.U.
R5027 22k
R5029 22k
RA5084
1kx4
RA5083
1kx4
RA5082
1kx4
RA5081
22kx4
RA5080
22kx4
R5032
1k
R5031
1k
R5041
22k
R5024
22k
R5047
16k-F
RA5094
22kx4 TP5031
TP5032
C5009
1000p
TH5001
100k
C5018 0.1
C5010 0.022
R5030 1k
R5042 1k
R5043 1k
C5011 0.022
C5019 N.U.
R5050
470
C5022
0.022
E5001
220/10
R5095
N.U.
RA5093
1kx4
C5012
0.022
C5015
7p
C5014
7p
19.96MHz
XL5002
TP5018
TP5017
TP5016
TP5015
TP5014
TP5013
TP5012
TP5011
CH5001
BTFW14R-3RST
C5021
N.U.
C5020
N.U.
TP5030
Q5002
2SB710A
Q5003
DTC124EKA
D5002
DAN202K
R5049
2.7k-1/4
R5048
24k
RA5085
1kx4
RA5086
1kx4
RA5087
1kx4
RA5088
1kx4
RA5089
1kx4
RA5090
1kx4
R5096 1k
R5033 1k
R5034 470
SW5001
SSAC120100
TP5033
R5052
10k
R5051
100k
TP5034
R5044
22k
R5045
22k
R5053
22k
R5037
22k
R5036 22k R5035 22k
C5017
0.022
RA5091
1kx4
RA5092
1kx4
R5038
N.U.
R5039 22k
C5013 1
L5003
0.47uH
IC5001
D70F3032BY
R5040
22k
R5009 4.7k
R5010 470
R5011 470
R5012 470
R5013 470
XL5001
4.00MHz
C5001 24p
R5014
4.7k
R5015
4.7k
C5002
27p
TP5029
TP5028
TP5027
TP5026 TP5022 TP5023
TP5024 TP5025
IC5002
MB88385CPF L5001
1uH E5002
22/16
L5002 1uH
C5016
0.022
C5003
1
R5008
160-1/4
R5006
160-1/4
R5007
160-1/4
R5005
160-1/4
ZD5005
MAZS0560L
ZD5002
RLZ7.5A
ZD5003
RLZ7.5A
R5004
1.5k
R5003
2.2k
R5001 1.5k
R5002 2.2k
TP5021 TP5020
IC5004
NJM2903M
C5005
0.1
R5019
10k
R5020
27k
R5022
330k
R5023
470k
C5006
0.1
C5007
100p
D5001
DAN202K
IC5003
MC14538BFEL
Q5001
DTC124EKA
C5008 0.022
E5004 22/16
R5016 47k R5017 15k
R5018 8.2k
C5004
0.1
R5021
1M
C5104
10
R5108
68k
R5110
10k
R5116
470-1/4
L5004
0.47uH
R5112
22
R5113
1.5k
R5114
1.5k R5117
1.8k
C5105
0.1
Q5005
2SC2412K
Q5006
2SA1037AK E5003 100/10
C5106
0.1
C5108
10
Q5007
DTC343TK
D5004
1SS355
IC5106
TC74VHCT08AFT
R5109
33k
R5111
560
TP5105
TP5114
R5115
0-1/4
TP5118
C5107 0.022
TP5115
TP5104
TP5108
TP5109
TP5107
TP5106
C5100 N.U.
C5102 0.1
C5101 0.1
R5103 0
R5104 0
TP5101
TP5102 R5105
0
D5003
MA713
TP5103
TP5112
TP5113
R5106
10k
R5107
10k
- 20 -
TO CONTENTS
TO PARTS LIST
TO P. W. BOARD
