Instruction Manual – LED6144T
MAIN FEATURES
Alpine Corporation is proud to introduce our New LED Garden Lighting.
These innovative lights will add character, class and ambiance to your
pond, garden and water feature.
●Super bright LED light, that offers low energy consumption, for
an environmentally friendly solution to standard lighting.
Multi Color Light with Color Changing Controller, Mega Bright
White Light and On/Off switch.
Sleek design housing constructed of High Grade Waterproof
Materials.
Waterproof Design can be used In or Out of Water.
All-purpose adjustable stand.
Low voltage design for safe handling and lower energy costs.
Product Name Mega Bright Color Changing LED Light with Controller
Model # LED6144T
Rated Voltage INPUT: 230V/50Hz or 120V/60Hz, OUTPUT: AC12V
Consumption Power 8 Watt
Light head Dimension Diameter “ x Height ”
Cable length 10 m (33 feet)
Caution:
(1) If used with a different transformer than what is included please
make sure it has the proper voltage rating.
(2) The transformer can get hot! Please be sure not to cover and is in a
location were it can receive sufficient air circulation.

Parts list
Parts Name Quantity (pcs)
1. Light housing 1
2. Base 1
3. Mounting Bracket 1
4. Controller (attached on the cable) 1
5. Adaptor 1
All the parts are assembled before packing except the transformer.
Operation:

1. Place the light in your pond, water feature or attach the garden stake
and place in your garden in the direction you would like to illuminate.
2. Connect the cable to the transformer: Plug the male connector pin into
the female connector on the transformer; turn the locknut clockwise
until tight.
3. Plug the transformer into a standard 110 Volt outlet and enjoy your new
light.
(1) Use the Power Switch on the cord to turn ON or turn OFF.
(2) Press the Mode Switch to select the desired color. Listed below is
the order of the different modes. Not all lights will start at the
same mode. For example, when first turned on, if the mode is
solid red, the next more will be solid blue.
Order of different modes
Slow pace multi-color (red, white and blue) changing
Medium pace multi-color (red, white and blue) changing
Fast pace multi-color (red, white and blue) changing
Solid red
Solid blue
Solid white
Solid red and blue
Solid white and blue
Solid white and red
Solid red, white and blue
Useful information:

Need more lighting to add to your landscape? Please contact your local
Alpine distributor.
1. You can also use this product with an Alpine Photocell & Timer to
automatically turn on your lighting at dusk and turn off at dawn or
programmed to turn on and off at your desired time. Photocell & Timer
is part number PL200 and is not included.
2. Attach either 5 or 10 lights to a single transformer system with Alpine
Garden Light Cable. Available in 25 foot with 5 outlet connectors or 50
foot with 10 outlet connectors. Garden Light Cables are part numbers
PL325 and PL350 and are not included.
3. Power all your Garden and Landscaping needs with just one
transformer. Alpine can meet all your needs and Alpine distributors
carry transformers ranging from 60 Watt all the way up to 300 Watt for
even your biggest landscape projects! Contact a local distributor today
and ask for more great products from Alpine Corporation!
