BLISS™Automation by ALTA
15 CHANNEL REMOTE CONTROL
PROGRAMMING AND USERS GUIDE
Declarations
Safety Instructions
BLISS™ Remote Overview
BLISS™ Remote Functions
P1 Button Instructions
Initial Set-up
Adjust Limits
Favorite Position
Add or Remove Additional Remote
Adjust Motor Speed
Roller or Sheer Mode
Quick Index
Troubleshooting

BLISS REMOTE CONTROL | REFERENCE GUIDE
2
Declarations
U.S. RADIO FREQUENCY FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Any Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
ISED RSS WARNING:
This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’ISED applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.

AMP25B
Instruction
Attention
-1-
The motor is suitable for motorization of roller blinds, sheer shadings, roman shades, and zebra shades.
Never drop, knock, drill or submerge the motor. Keep the power cable in right position as following.
Important safety instructions to be read before installation.
Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.
Declarations
Do not dispose of in general waste.
Please recycle batteries and damaged electrical products appropriately.
-2-
Safety
1. Do not expose motor to humid, damp or extreme temperature conditions.
2. Do not drill into motor.
3. Do not cut the antenna and keep it clear from metal objects.
4. Do not allow children to play with this device.
5. If power cable or connector is damaged, do not use.
6. Ensure correct crown and drive adaptor are used.
7. Ensure power cable and aerial is clear and protected from moving parts.
8. Cable routed through walls shall be properly isolated.
9. Motor is to be mounted in horizontal position only.
10. Before installation, remove unnecessary cords and disable equipment not needed for powered
operation.
11. Installation and programming to be performed by a qualified professional, use or modification outside
the scope of this instruction may void warranty.
Features
Fields of Application
Specifications
Following data for reference
Working temperature: -10℃ ~ +50℃
Input Voltage: USB 5V 1A / USB 5V 2A
Radio Frequency: 433.925MHz
Maximum Running Time: 6 minutes
Model Rated Torque
(N.m)
Rated Speed
(rpm)
Rated Power
(W)
AMP25B - 0.7/34 0.7 34 8
AMP25B -1.1/28 1.1 28 8
Charging Instructions
This motor has a built in Li-ion battery pack with integrated charge management.
Max power input for recharging: 5V 2A.
Before first use please charge motor for 6 hours. Using 5V charger (most phones charger is 5V ) .
During operation, when the motor starts, the buzzer will beep 10 times, indicating a low-voltage alarm and
needs to be charged.
During operation, the voltage was detected to be too low, the battery was about to run out, the battery stopped
running and needed to be recharged.
Rechargeable Battery
Blinking red:
Low battery alert
Blinking green:
Charging is processing
Solid green:
Battery has
finished charging.
FCC Text - text 01
Add A zoom in on the
charging port
P1 Button Instructions
P1 button
Lithium Battery Switch
LED light
Micro-USB Port
Add visual explanation of P1 - file 02
Sheer
Roller Revolve Roman shades
Do not dispose of in general waste.
Please recycle batteries and damaged electrical products appropriately.
BLISS REMOTE CONTROL | REFERENCE GUIDE
3
Safety Instructions
Important Safety Instructions
Attention
1. Do not expose motor to humid, damp, or extreme temperature conditions.
2. Do not drill into motor.
3. Do not cut the antenna. Keep it clear from metal objects.
4. Do not allow children to play with this device.
5. If the power cable or connector is damaged, do not use.
6. Ensure the power cable and aerial is clear and protected from moving parts.
7. Cable routed through walls should be properly isolated.
8. Motor is to be mounted in horizontal position only.
9. Before installation, remove unnecessary cords and disable equipment not needed for powered operation.
10. Installation and programming should be performed by a qualied professional. Use or modication outside the scope of these instructions
may void warranty.
Never drop, knock, drill or submerge the motor. Keep the power cable in the proper position as shown below.
Read all safety instructions before installation.
Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.
× ×× ×

Roller
Shades
Honeycomb
Shades
Window
Shadings
Dual
Shades
Faux / Wood
Tilt-Only
Natural
Wovens
BLISS REMOTE CONTROL | REFERENCE GUIDE
4
BLISS Remote Overview
1. Available Products
2. Specications
3. Remote Button Instructions
P2
Switch
P2
LCD Display
Up
Stop
Down
Higher
Channel
Lower
Channel
4. Replace/Install CR2450 Battery
Battery
(CR2450)
a. Gently press down the cover and slide it o.
b. Install battery (CR2450) with positive (+) side facing up.
c. Slide the cover back onto the backside of the remote.
a. b. c.
Voltage 3V (CR2450)
Radio Frequency 433.92 MHz Bi-directional
Transmitting Power 10 milliwatt
Operating Temperature 14°F to 122°F (-10°C to 50°C)
RF Modulation FSK
Lock Function Yes
IP Rating IP20
Transmission Distance up to 200m (outdoor)

BLISS REMOTE CONTROL | REFERENCE GUIDE
5
BLISS Remote Function
1. Channel Options
Select A Channel
a. Press “<” button on the remote to select a lower
channel.
b. Press “>” button on the remote to select a higher
channel.
Hide Unused Channels
a. Press and Hold (about 3 sec) “<” and “>” buttons
simultaneously until remote control displays “C”
(channel).
b. Press “<” or “>” button to select required quanti-
ty of channel (between 1 to 15).
c. Press “Stop” button to conrm selection (the
example shows a 5-channel selection). The LED will
display “O” (OK) once to conrm selection.
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Remote Re-
sponse
Remote Re-
sponse
Remote Re-
sponse
a.
a.
b.
b.
c.
+ or
Higher
Channel
Higher
Channel
Higher
Channel
Lower
Channel
Lower
Channel
Lower
Channel
1
5
15
0
C 11
Stop
2. Advanced Setting - Disable Limit Setting
a. Remove the cover from the backside of remote,
the lock switch is in the right corner.
b. Move the switch to the “Lock” position to disable
the following commands, remote will show “L”
(lock):
- Change Motor Direction
- Setting the Upper and Lower Limit
- Adjust Limit
- Roller Mode or Sheer Mode
c. Move the switch to “Unlock” position to assess all
remote functions, remote will show “U” (unlock).
a.
b.
c.
Switch
Switch
LockUnlock
Switch
Lock
Unlock
*This advanced feature is intended to be used after
all shade programming is completed. User Mode will
prevent accidental or unintended changing of limits.
L
U

BLISS REMOTE CONTROL | REFERENCE GUIDE
6
P1 Button Instructions
1
2
3
4
5
Test Motor
1
2
6
10
14
Activate Pairing Mode
Sleep Mode
Reverse Direction
Reset To Factory Settings
Approx. 2
sec.
Happening as you press for 2 seconds
Happening as you press for 1 second
Happening as you press for 6 seconds
Happening as you press for 10 seconds
Happening as you press for 14 seconds
when released
when released
when released
when released
when released
Approx. 6
sec.
Approx. 10
sec.
Approx. 14
sec.
Until Shade:
Until Shade:
Motor Response:
Motor Response:
Motor Response:
Until Shade:
Until Shade: Motor Response:
Less than 1 sec.
Press P1
Press P1
Press P1
Press P1
Press P1
Motor Response: Wakes & Runs
Beep x1
Beep x2
Beep x3
Beep x4
Jog x3
Jog x4
Jog x1
Jog x2
2. P1 Button Instruction
2. P1 Button Location
BLISS Lift and BLISS Tilt motors do not beep
BLISS TILT BLISS 1.1 and BLISS 2.0 BLISS LIFT
P1 Button
LED light
P1 button
Lithium Battery Switch
Power line
Signal line
P1
Button

BLISS REMOTE CONTROL | REFERENCE GUIDE
7
Initial Set-up
1. Pair / Unpair Remote Control
2. Change Motor Direction (if necessary)
3. Setting the Upper and Lower Limits
Press “Up” or “Down” button to check if the shade
moves in the desired direction.
If you need to reverse the direction, press and hold
(about 2 sec) “Up” and “Down” buttons simultane-
ously until motor jogs x1 and beeps x1.
Set Upper Limit
a. Press “Up” button to raise the shade, then press
“Stop” button when it is in the desired upper limit.
b. Press and hold (about 5 sec) “Up” and “Stop”
buttons simultaneously until motor jogs x2 and
beeps x3.
Set Lower Limit
a. Press “Down” button to lower the shade, then
press “Stop” button when it is in the desired lower
limit.
b. Press and hold (about 5 sec) “Down” and “Stop”
buttons simultaneously until motor jogs x2 and
beeps x3.
a. Press “P1” button (about 2 sec) on the motor
head until motor jogs x1 and beeps x1.
b. In the next 10 secs, press and hold “Stop” button
on the remote control until motor jogs x2 and beeps
x3.
* Repeat the same procedure to unpair remote
control.
*The operation is only valid when there are no lim-
its. If the motor has already set the upper and lower
limit, then you can only switch direction by pressing
P1 button (See P1 button instructions).
*If you exit the limit setting status before you nish
the limit settings, the motor will take the previous
existing limits.
Action on
Remote Control
Action on
Motor
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
b.
a.
a.
a.
b.
b.
+
+
+
Jog x1
Jog x2
Jog x2
Jog x1
Beep x1
Jog x2 Beep x3
Beep x3
Beep x3
Beep x1
Stop
Up
Up Up Stop
Stop
Down
Down Down
BLISS Lift and BLISS Tilt motors DO NOT Beep
P1
P1
P1

BLISS REMOTE CONTROL | REFERENCE GUIDE
8
Adjust Limits
1. Adjust the Upper Limit
a. Press and hold (about 5 sec) “Up” and “Stop”
buttons simultaneously until motor jogs x1 and
beeps x1.
b. Use “Up” button to raise the shade to the desired
highest position, and use “Up” or “Down” button to
do the nal adjustment if necessary.
c. Press and hold (about 5 sec) “Up” and “Stop”
buttons simultaneously until motor jogs x2 and
beeps x3.
2. Adjust the Lower Limit
a. Press and hold (about 5 sec) “Down” and “Stop”
buttons simultaneously until motor jogs x1 and
beeps x1.
b. Use “Down” button to lower the shade to the
desired lowest position, and use “Up” or “Down”
button to do the nal adjustment if necessary.
c. Press and hold (about 5 sec) “Down” and “Stop”
buttons simultaneously until motor jogs x2 and
beeps x3.
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Motor Response
Motor Response
Motor Response
Motor Response
a.
a.
c.
c.
b.
b.
+
+
+
+
Stop
Stop
Stop
Stop
Up
Down
Up
Down
Jog x1
Jog x1
Jog x2
Jog x2
Beep x1
Beep x1
Beep x3
Beep x3
Up
Down
Favorite Position
1. Set Favorite Position
a. Use “Up” or “Down” button to move the shade to
desired Favorite position.
b. Press and hold (about 2 sec) one “P2” button on
the back of remote control until motor jogs x1 and
beeps x1.
c. Press and hold (about 2 sec) “Stop” button until
motor jogs x1 and beeps x1.
d. Once more, press and hold (about 2 sec) “Stop”
button until motor jogs x2 and beeps x3.
2. Send Shade to Favorite Position
Press and hold (about 2 sec) “Stop” button, motor
will move to Favorite position.
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Motor Response
Motor Response
Shade Response
a. b.
d.
c.
or
or
or
DownUp
Jog x1
Jog x2Jog x1
Beep x1
Beep x3Beep x1
P2
Stop
Stop
Stop

BLISS REMOTE CONTROL | REFERENCE GUIDE
9
3. Delete Favorite Position
a. Press and hold (about 2 sec) one “P2” button
until motor jogs and beeps x1.
b. Press and hold (about 2 sec) “Stop” button until
motor jogs and beeps x1.
c. Once more, press and hold (about 2 sec) “Stop”
button until motor jogs x1 and long beeps x1.
Action on
Remote Control
Action on
Remote Control
Motor Response
Motor Response
a. b.
c.
Jog x1 Jog x1
Jog x1
Beep x1 Beep x1
Beep x1
P2
Stop
Stop
Favorite Position
Add or Remove Additional Remote
1. Using Current Remote Control
a. On the current remote control, press and hold
(about 2 sec) one “P2” button until motor jogs x1
and beeps x1.
b. Once more, on the current remote control, press
and hold
(about 2 sec) one “P2” button until motor jogs x1
and beeps x1.
c. On the New remote control, press and hold
(about 2 sec) one “P2” button until motor jogs x2
and beeps x3.
2. New Remote Control
Follow instructions under the section Pair / Unpair Remote Control
Action on
Remote Control
Action on
Remote Control
Motor Response
Motor Response
a. b.
c.
Jog x1Jog x1
Jog x2
Beep x1
Beep x1
Beep x3
P2P2
P2
Current Remote
New Remote Control
Current Remote
*Repeat the same procedure to remove additional
remote control.

BLISS REMOTE CONTROL | REFERENCE GUIDE
10
Adjust Motor Speed
1. Acceleration Speed
a. Press one “P2” button until motor jogs x1 and
beeps x1.
b. Press “Up” button until motor jogs x1 and beeps
x1.
c. Once more, press “Up” button until motor jogs x2
and beeps x1.
2. Deceleration Speed
a. Press one “P2” button until motor jogs x1 and
beeps x1.
b. Press “Down” button until motor jogs x1 and
beeps x1.
c. Once more, press “Down” button until motor jogs
x2 and beeps x1.
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Motor Response
Motor Response
Motor Response
Motor Response
a.
a.
b.
b.
c.
c.
Jog x1
Jog x1
Jog x2
Jog x2
Jog x1
Jog x1
Beep x1
Beep x1
Beep x1
Beep x1
Beep x1
Beep x1
P2
P2
*If the motor has no response, it already
has a Maximum or Minimum speed.
Up
Down
Down
Up
Roller or Sheer Mode
1. Roller Shade Mode - continue
movement after a short press - Default
Mode
a. Press and hold (about 5 sec) “Up” and “Down”
buttons simultaneously until motor jogs x1.
b. Press and hold (about 2 sec) “Stop” button until
motor jogs x2 and beeps x3.
2. Sheer Shade Mode - jog movement
after a short press (continue movement
after a long press)
a. Press and hold (about 5 sec) “Up” and “Down”
buttons simultaneously until motor jogs x1.
b. Press and hold (about 2 sec) “Stop” button until
motor jogs x1 and beeps x1.
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Action on
Remote Control
Motor Response
Motor Response
Motor Response
Motor Response
a.
a.
b.
b.
+
+
Down
Down
Up
Up
Jog x1
Jog x1
Jog x2
Jog x1
Beep x3
Beep x1
Stop
Stop

Issues Possible Causes Solution
Battery in motor is depleted Recharge with proveded charger and/or check connection and positioning of solar panel
Insucient charging from Solar Panel Check connection and orientation of solar panel
Remote control battery is dead Replace battery
Battery is not inserted correctly Check battery polarity
The motor has no response Radio interference / shielding Kepp remote control and motor antenna away from metal objects
Receiver too far from Remote Control Move remote control to a closer position
Power failure Check power supply to motor is connected and active
Incorrect wiring Check that wiring is connected correctly
Motor beeps 10 times when
in use
Battery voltage is low / PV (solar panel
issue) Recharge with provided charger and/or check connection and positioning of solar panel
Always reserve an individual channel for programming functions
SYSTEM BEST PRACTICE - Provide an extra remote control for multi-motor projects that
provides individual control for each motor for programming purposes
Place all other motors into sleep mode (ref to P1 button instructions)
Cannot program a single
motor (multiple motors
respond)
Multiple motors are paired to the same
channel.
BLISS REMOTE CONTROL | REFERENCE GUIDE
11
Troubleshooting
Quick Index
Settings Steps
1 Pairing P1 (hold down for 2s) >Stop (hold down for 2s)
2 Switch Rotating Direction Up + Down (hold down for 2s)
3Setting Upper & Lower Limits
4 Add / Remove Favorite Position P2 >Stop >Stop
5Roller Mode & Sheer Mode Switch Up + Down (hold down for 5s) >Stop
6 Adjust Limits
7Pair / Unpair Additional Emitter P2 (existing) > P2 (existing) > P2 (new)
8 Speed Regulation
Upper Limit: Up (hold down for 2s) > Up + Stop (hold down for 2s)
Upper Limit: Up + Stop (hold down for 5s) > Up or Down > Up + Stop (hold down for 2s)
Acceleration: P2 > Up > Up
Lower Limit: Down (hold down for 2s) >Down + Stop (hold down for 2s)
Lower Limit: Down + Stop (hold down for 5s) > Up or Down >Down + Stop (hold down for 2s)
Deceleration: P2 >Down >Down
