Emerson RCBT100 User manual

Part No. F40BP75240000 Form No. BP7524
Revision: 170217 U.L. Model No: MR101F
Bluetooth®Ceiling Fan Control
with App Owner's Manual
3
2
1
0
Model Number
RCBT100
• 3- peed Hand Held Transmitter
• ingle Light
• upplied with Receiver
• Includes Light Dimming election witch
READ AND SAVE THESE INSTRUCTIONS
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service - 8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
www.emersonfans.com
• Spanish - page 9
• French - page 17
afety Instructions
WARNING: To avoid fire, shock, and serious personal injury, follow all instructions
carefully.
1. Read your Owner's Manual carefully before installing the receiver. Retain Owner's
Manual for future reference.
2. Be careful of the fan and blades when installing the receiver in the ceiling cover. Before
installing or servicing the ceiling fan or receiver, switch power off at service panel and
lock service panel to prevent power from being switched on accidentally. If the service
panel cannot be locked, securely fasten a warning device, such as a tag, to the service
panel.
ADDITIONAL AFETY IN TRUCTION FOR IN TALLATION
1. To avoid possible electrical shock, be sure electricity is turned off at the main fuse or
circuit breaker box before wiring.
2. Make certain no bare wires are exposed outside the wire connectors.
3. All wiring must conform to National and Local Electrical Codes.
4. Follow the recommended instructions for the proper method of wiring your new
receiver. If you feel you do not have enough electrical wiring knowledge or experience,
have your receiver installed by a licensed electrician. Any electrical work not described
in this manual should be performed by a licensed electrician.
5. For indoor use only. Do NOT install in damp locations.
WARNING
!

2
Table of Contents
U.L. Model No: MR101F
ection Page
Safety Instructions . . . . . . . . . . . . . . . . . . . 1
1. Unpacking . . . . . . . . . . . . . . . . . . . . . . . . 2
2. General . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3. Preset Memory Feature . . . . . . . . . . . . . 2
4. Installation of Battery . . . . . . . . . . . . . . . 3
5. Setting perating Frequency of
Transmitter and Receiver . . . . . . . . . . 3
6. peration . . . . . . . . . . . . . . . . . . . . . . . . 3
7. Installation of Storage Bracket . . . . . . . . 4
8. Installation of Receiver . . . . . . . . . . . . . . 4
9. Troubleshooting . . . . . . . . . . . . . . . . . . . 5
ection Page
10. Downloading the Emerson Bluetooth®
Ceiling Fan Control App . . . . . . . . . . 5
11. Connecting to Your Fan . . . . . . . . . . . . 5
12. Configuring Your Fan . . . . . . . . . . . . . . 6
13. Renaming Your Fan . . . . . . . . . . . . . . . 6
14. Reconfiguring Your Fan . . . . . . . . . . . . 6
15. perating Your Fan . . . . . . . . . . . . . . . . 7
16. Adding Additional Fans . . . . . . . . . . . . . 7
Emerson Air Comfort Limited Warranty . . . 8
Spanish . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
French . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Do not install or use fan if any part is
damaged or missing. Call Toll-Free:
1-800-654-3545
WARNING
!
2. General
3. Preset Memory Feature
1. Unpacking
Your Emerson receiver is equipped with a
preset memory feature. If the AC supply to the
receiver is powered through a wall switch,
when the switch is turned FF, the control will
remember the light intensity and fan speed.
When the switch is turned back N the light
and fan will resume operation as they were
prior to the switch being turned FF.
pen the carton containing the Bluetooth®
Ceiling Fan Control. Remove contents and
check to see that you have received the
following parts:
1. Transmitter (1)
2. Storage Bracket and Hardware (1 set)
3. A23/MN21 12V Alkaline Battery (1)
4. Receiver (1)
Your Emerson Bluetooth®Ceiling Fan Control
consists of a hand-held transmitter and a
receiver. The transmitter is designed to
separately control your ceiling fan speed and
light intensity. There are four push buttons
(0, 1, 2, 3) to set the fan speed and turn the
fan FF. The light ( ) push button turns
the light N and FF and controls the light
intensity. The blue indicator light will illuminate
while any button is pressed, indicating that the
battery is good.
The transmitter is powered by one A23/MN21
12V alkaline battery (supplied). To prevent
possible damage if the battery should leak, be
sure to remove the battery when the control is
not to be used for an extended period of time.
Code switches in the transmitter and receiver
may be set in 16 different positions. If your fan
and light go N and FF without using your
control, you may be getting interference from
other remote units such as garage door
openers, car alarms or security systems.
To remedy this situation, change the
combination code in your transmitter and
receiver.
STORAGE BRACKET
TRANSMITTER
A23/MN21 12 V BATTERY
RECEIVER
3
2
1
0
+ A23
4
3
2
1

3
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: MR101F
TRANSMITTER
A23/MN21 12 V
BATTERY
BATTERY COMPARTMENT
COVER
+ A23
DIP
1 2 3 4
ON
ON DIM
1. Remove the battery compartment cover by
pressing firmly below the arrow and sliding
the cover off the transmitter (retain for
future use).
2. Install one A23/MN21 12V alkaline battery
(supplied).
Your transmitter and receiver have code
switches which must be set in one of 16
possible code combinations. The four levers
(numbered 1, 2, 3, and 4) on the switches are
factory-set in the N (up) position. Do N T
use this setting. Change the switch settings as
follows:
1. Slide the four switch levers in the
transmitter to your choice of N (up) or
FF (down) positions. Use a ball-point pen
or small screwdriver and slide the levers
firmly up or down.
2. n the receiver, slide the four switch levers
to the same positions as set on the
transmitter. Make sure the levers on both
the transmitter and receiver are in the same
positions, otherwise the fan will not
operate.
3. The additional switch on the transmitter
marked N and DIM is for dimming control
of lights: Set switch to DIM to allow for
dimming of the lights. Set switch to N for
full brightness of the lights such as for
fluorescent bulbs.
4. Reinstall the battery compartment cover
onto the transmitter.
Figure 1
CODE SWITCHES
RECEIVER
TRANSMITTER
DIM SWITCH
DIP
1 2 3 4
ON
ON DIM
+ A23
DIP
1 2 34
ON
4
3
2
1
Figure 2
4. Installation of Battery (Figure 1)
5. etting Operating Frequency of Transmitter and Receiver
(Figure 2)
3
2
1
0
POWER INDICATOR LIGHT
HIGH TO LOW
BUTTONS
FAN OFF BUTTON
LIGHT BUTTON
Your transmitter has full control of your fan
and light.
NOTE: If your fan has pull chains, prior to
operation of the fan and light from the
transmitter, set the fan speed to HIGH and
turn the light ON.
1. To set the desired fan speed, press one of
the four buttons (0, 1, 2, 3) to operate your
fan from FF to HIGH speeds.
2. To turn the light N, press and release the
( ) button.
3. To vary the intensity of the light, hold the
( ) button down until the desired light
intensity is reached, then release the
button.
Note: When turning the light on, light will turn
on at the light intensity previously selected.
IMPORTANT
Fan installation must be completed,
including the installation of the fan
blades, before testing the transmitter.
Figure 3
6. Operation (Figure 3)

7. Installation of torage Bracket (Figure 4)
4U.L. Model No: MR101F
STORAGE BRACKET
STORAGE BRACKET
SCREWS (2)
Figure 4
A storage bracket is provided for holding your
transmitter when not in use. If you desire to
use the storage bracket, install it on a wall
that is away from excess heat or humidity.
Use the two screws provided with storage
bracket.
BARE GREEN/GROUND
ANTENNA
WHITE
TO
AC SUPPLY WHITE
BLACK
BLUE
BLACK
BLUE
RECEIVER
RED
HANGER
BALL
CEILING
COVER
ANTENNA
HANGER
BRACKET
RECEIVER
WHITE
FAN HOUSINGLIGHT
YELLOW
(if present)
Note: Make all wiring connections using only
listed wire connectors (supplied). Make sure
all connections are tight, including ground,
and no bare wire is visible at the wire
connectors, except for the supply circuit
ground wire.
1. After electricity has been turned off at main
fuse box or circuit breaker box, remove the
ceiling cover from the hanger bracket.
2. Disconnect the supply wiring to the fan by
removing wire connectors.
Note: Do not disconnect the BARE/GREEN
GR UND wires.
3. Connect the supply BLACK wire to the
receiver RED wire (AC IN L).
4. Connect the supply WHITE wire to the
receiver WHITE wire (AC IN N).
To avoid possible electrical shock, be
sure electricity is turned off at the
main fuse or circuit breaker box
before installing the receiver.
5. Connect the receiver WHITE wire
(T M T R N) to the fan WHITE wire.
6. Connect the receiver BLACK wire
(T M T R L) to the fan BLACK wire.
7. Connect the receiver BLUE wire (F R
LIGHT) to the fan BLUE wire and fan
YELL W wire (if present).
Note: This wiring configuration will control
the up light and down light together.
A maximum of 300W total lighting can be
used with this receiver. Exceeding this
wattage will damage the receiver and void
the warranty.
CAUTION: If no light exists on your
ceiling fan, cap the BLUE wire on the
receiver with a wire connector.
8. Push the connected wires up into the
junction box and position the receiver in
the hanger bracket above the hanger ball.
Lay the antenna wire on top of the
receiver.
9. Reinstall the ceiling cover and restore
electrical power to the circuit.
Figure 5
8. Installation of Receiver (Figure 5)
WARNING
!

5
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: MR101F
Fan/Light Fails to Operate
• Check that the speed switch on the fan is
set to HIGH speed.
• Check that the light switch is N.
• Check that the battery is good (power
indicator light should illuminate when any
button is pressed).
• Check that the receiver is wired properly.
• Check that code switches in the
transmitter and receiver are set in the
same position.
hort Range
• If the transmitter operates the fan when
close to it, but does not operate it at a
distance of 40 feet, try placing the antenna
wire outside of the ceiling cover.
9. Troubleshooting
11. Connecting to Your Fan
10. Downloading the
Emerson Bluetooth®Ceiling Fan Control App
1. Using your device go to the Apple®App
Store®or Google PlayTM Store.
2. Search for “Emerson Bluetooth Ceiling Fan
Control”.
3. Install the free App on your device
(Figure 6).
The App requires the following perating
System ( S) software to download:
°AndroidTM Version 6.0 or Later
°i S®version 10.0 or Later
Note: In the Apple®App Store®, the Emerson
Bluetooth®Ceiling Fan Control App will NLY
appear on an “iPhone®only” search. n an iPad®,
this will have to be changed in the App Store®.
Figure 6
1. Ensure power has been restored to your
fan after installing the receiver and
Bluetooth®is enabled on your device.
If Bluetooth®is not enabled you may be
prompted to do so when you launch the
App. If necessary, consult your device’s
owner’s manual on how to enable
Bluetooth®.
2. Launch the Emerson Bluetooth®Ceiling
Fan Control App from your device.
3. A list of available fans will be displayed.
By default, newly installed fans will be
named “CeilingFan” (Figure 7). You will
have the opportunity to rename the fan
during configuration.
4. Select the newly installed fan “CeilingFan”.
You will be prompted to enter a pin
(Figure 8).
5. Enter 000000 and press “Sign in” to pair
your device with the Bluetooth®receiver.
6. nce paired with your device, you will see
a message stating your fan is connected
and you will be prompted to begin
configuration.
Figure 8
Figure 7

6U.L. Model No: MR101F
12. Configuring Your Fan
1. If you have installed an Emerson Fan select
“Yes”. You will be prompted with a list of
preconfigured compatible fans to choose
from. If you have installed a non-Emerson
Fan select ”No” and the app will walk you
through the manual configuration of your
fan (Figure 9).
Note: If you have installed an Emerson Fan
but cannot locate it in the available list, the fan
is either an Eco model and not compatible with
this control or it is a newly released fan and an
update to the App has not been released to
add the model. In the case of a newly
released fan, answering “No” will be necessary
so you can manually setup your fan.
2. nce you have made your selection, you
will be prompted to name your fan.
Enter the desired name and select
“Confirm” (Figure 10).
3. After confirming the name, follow the
on-screen prompts to complete the
configuration of your fan.
Figure 9
Figure 10
1. To rename your fan, press the “Edit Name”
button in the upper right hand corner of the
fan control screen (Figure 11).
2. You will be prompted to name your fan.
Enter the desired name and select
“Confirm”.
Figure 11
Figure 12
1. To reconfigure your fan, press the
“Reconfigure fan setup” button in the
bottom left hand corner of the fan control
screen (Figure 12).
2. You will be prompted to configure your fan
as you did during initial configuration.
3. Follow the on screen prompts to complete
the reconfiguration of your fan.
Edit Name
13. Renaming Your Fan
14. Reconfiguring Your Fan
Yes
Confirm
Back CeilingFan

7
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: MR101F
1. To operate your fan, launch the Emerson
Bluetooth®Ceiling Fan Control App from
your device and select the desired fan from
the list of available fans.
2. After selecting the fan you will see the fan
control screen (Figure 13).
Note: Some options may not be available
depending on your fan and the selections you
made during configuration.
3. Use the “Fan Power” button to turn the fan
N and FF.
4. Use the slider under “Fan Power” to control
the speed of your fan.
5. Use the “Fan Direction” button (if available)
to change the rotation direction of your fan.
6. Use the “Light Power” button to turn the
light N and FF.
7. Use the slider under “Light Power” to
control the brightness of the lights if
dimming is enabled.
8. Use the slider under “Auto- ff Timer” to set
the number of hours and minutes until your
fan and lights turn off.
15. Operating Your Fan
Figure 13
1. If additional Emerson Bluetooth®Ceiling
Fan Controls have been purchased and
installed, they can be added to the App as
well (Figure 14).
2. Follow the instructions in the
“C NNECTING T Y UR FAN” and
“C NFIGURING Y UR FAN” sections to
add each additional fan.
Note: You will only be able to control one fan
at a time. Also, if an additional user is
connected to a fan, it will not be displayed on
your list of available fans until the additional
user disconnects from that fan.
Figure 14
16. Adding Additional Fans
Edit Name
Back Great Room

Part No. F40BP75240000 Printed in U.S.A. Form No. BP7524
Revision: 170217 02/17 U.L. Model No: MR101F
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service — 8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545 www.emersonfans.com
he Bluetooth®word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc., and any use of such marks
by Emerson is under license. Other trademarks and trade names are those of their respective owners.
Android and Google Play are trademarks of Google Inc.
App Store, Apple, iPhone and iPad are trademarks of Apple Inc., registered in the US and other countries.
iOS is a registered trademark of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
Retain this manual for future use
Air Comfort Products
DIVISION OF EMERSON ELECTRIC CO.
8100 W. Florissant • St. Louis, MO 63136
What The Warranty Covers:
All products covered by this Owner’s Manual are warranted against all defects in workmanship and materials. You must be the original
purchaser or user of the product to be covered.
What The Period Of Coverage Is:
All components are covered by this warranty for one year from the date you purchased your Emerson Bluetooth®Ceiling Fan Control.
ANY IMPLIED WARRAN Y OF MERCHAN ABILI Y OR FI NESS FOR A PAR ICULAR PURPOSE, MADE WI H RESPEC O
COMPONEN S AND ACCESSORIES IS ALSO LIMI ED O ONE YEAR.
What Will Emerson Company Do To Correct Problems:
Emerson Company will replace a defective Emerson Bluetooth®Ceiling Fan Control at no charge to you. We will ship the repaired
product or replacement to you at no charge, but you are responsible for all costs or removal, reinstallation and shipping of the product
to Emerson.
How Can You Get Service:
YOU MUS HAVE PROOF OF YOUR PURCHASE OF HE EMERSON BLUE OO H®CEILING FAN CON ROL O OB AIN LIMI ED
WARRAN Y SERVICE. KEEP YOUR RECEIP OR O HER PROOF OF PURCHASE. You can return the product to our factory or to
your nearest authorized service center.
• o return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products,
Division of Emerson Company, 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product with
your request.
• o return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson
Bluetooth®Ceiling Fan Control should be properly packed to avoid damage in transit since we will not be responsible for any such
damage.
What Is Not Covered:
his warranty also does not cover any defects, malfunctions or failures caused by:
• Repairs by persons not authorized by Emerson Company,
• Use of parts or accessories not authorized by Emerson Company,
• Mishandling, improper installation, modifications or damage to your Emerson Bluetooth®Ceiling Fan Control while in your possession,
or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• he original purchaser or user ceases to own the product, or
• he ceiling fan is moved from its original point of installation.
his warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties
apply, and no employee, agent, dealer or other person is authorized to give any warranties on behalf of Emerson Company.
REPAIR, REPLACEMEN OR A REFUND ARE HE EXCLUSIVE REMEDIES AVAILABLE UNDER HIS WARRAN Y AND EMERSON
IS NO RESPONSIBLE FOR DAMAGES OF ANY KIND, INCLUDING INCIDEN AL AND CONSEQUEN IAL DAMAGES. Incidental
damages include but are not limited to such damages as loss of time and loss of use. Consequential damages include but are not limited
to the cost of repairing or replacing other property which was damaged if this product does not work properly.
How State Law elates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may
not apply to you. his warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Emerson Air Comfort Limited Warranty
