Altec Mpa-k650 User manual

Portable Karaoke Party Speaker

MPA-K650

Warning

Contents

Warning 1

Important precautions 1

Package contents 2

Description of front panel 3

Description of rear panel 4

Description of Remote Control 5

Getting Started 6

Function Instructions 7

Connect with AUX Line in 8

Connect Wired Microphone 9

Warranty 10

CAUTION

RISK OF ELECTRIC

SHOCK DO NOT OPEN

The lighting ash with

arrowhead symbol, with an

equilateral triangle is

intended to alert the user to

the presence of uninsulated

dangerous voltage within

the products enclosure that

may be sufcient magnitude

to constitute a risk ofelectric

shock topersons.

CAUTION: TO REDUCE THE

RISK OF SHOCK, DO NOT

REMOVE COVER (OR BACK).

NO USER SERICEALBE PARTS

INSIDE REFEER SERVICING TO

QUALIFIED SERVICE

PERSONNEL.

The exclamation point

within an equilateral

triangle is intended alert

the user tithe presence of

important operating and

maintenance (servicing)

instructions in the l

iterature accompanying

the appliance.

Important precautions:

1. The apparatus shall not be exposed to dripping or splashing and that no objects lled with

liquids, suchas vases, shall be placed on the apparatus.

2. Minimum distances 100 cm around the apparatus for sufcient ventilation.

3. The ventilation should not be impeded by covering the ventilation opening swith items,

such as news papers, table-cloths or curtains.

4. No naked ame sources such as lighted candles,should be placed on the apparatus.

5. When the mainsplug or and appliance coupler is used as the disconnect device, the

disconnect device shall remain readily operable.

6. To be completely disconnected the power input, the mains plug of apparatus shall be

disconnected from the mainscom pletely.

7. The main plug of apparatus should not be obstructed or should be easily accessed

during intended use.

8. The use of apparatus in moderate climates.

9. Attention should be drawn to the environmental aspects of battery disposal.

10. Batteries shall not be exposed to excessive heat such as sunshine, re or the like.

11. Excessive sound pressure from earphones and headphones can cause hearing loss.

12. The internal battery is non-user replaceable.

13. Do not use this apparatus near the water.

Package contents

1.Speaker x 1

2.Remote control x 1

3.AC power cable x 1

4.User manual x 1

5.FM Antennax1

6.AUX- in Cablex1

7.Shoulder strapx1

2 3

DESCRIPTION OF FRONT PANEL

1. Volume Control

2. MIC Volume Control

3. MIC Echo

4. Display Window

5. Mode(function switch)

6. Play/Pause

7. LED Control

8. Battery Charging Indicator

9. Battery Full Power Indicator

10. SD Card Jack

11. USB Jack

12. AUX Jack

13. MIC Jack

14.Previous Track

15. Next Track

16. Power On/Off

17. Repeat

Consumed Power : 17W

FM: 87.5-108MHz

Speaker Size: 6 Inch x 1

Speaker Impedance: 3Ω x 1

Left&Right Response : 50Hz-20KHz

Input Sensitivity: 500mV

AC Power Supply: 110-240V

Battery: 7.4V/2000mAh

The Satellite Speakers Output

4 5

1 2 3

DESCRIPTION OF REAR PANEL DESCRIPTION OF REMOTE CONTROL

1.FM Antenna Jack

2.AC Power Connect Inlet

3.AC Power / Charging ON/OFF Switch

1. Power on/off

2. Mode

3. Mute

4. Volume +/CH-

5. Previous Track

6. Scan

7. 0-9 keys

8. EQ Function

9. Play/Pause

10. Next Track/CH+

11. Volume -

12. Repeat

To insert the remote control batteries:

1.Open the battery compartment.

2.Insert 2 x AAA batteries with correct polarity (+/-) as indicated.

The 2xAAA battery not include in our products.

3.Close the battery compartment.

CAUTION:

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

6 7

Getting Started

Connecting Power Cable

Warning:Ensure the AC/Charge switch is in OFF position before plugin.Plugin the AC

connector into the 110-240V 50Hz inlet socket in the rear panel of the unit and the other end

into the standard AC 120V wall socket.

1. Do not plug or unplug the power cable while you have wet hands.

2. To protect this apparatus from alightning storm, or when left unattended and unused for

long periods of time, unplug power cable from the wall outlet.

3. When unplugging the power cord from a wall outlet, always pull on the power plug only.

Never unplug it by pulling the power cord.

Charging the internal Battery

The speaker comes with a built-in rechargeable battery, follow the below steps

to charge it:

1. Connect the power cable and plug to the 110-240V 50Hz wall socket on the rear panel.

2. Turn the AC/Charge switch to "ON" position located at the bac of the unit.

The Red charging LED indicator on the front panel will light up,the battery is being charge.

3. When the Red LED indicator light off, the battery is fully charged when the green LED 

indicator light up, unplug the power cable to stop charging.

Note: please fully charge the product when it is not going to be used for a long time and

charge once a month to keep longer battery life.

Turning ON/OFF the speaker

1.The speaker can work with either connected AC power input (AC mode), or DC power

by build in battery(DC mode).

2.AC mode, connect the AC power cable provided to a wall socket. The speaker will be

to ON position.

3.DC mode, the speaker will be powered by the built in rechargeable battery. Set the DC

mode to ON position.

4.Use the remote control to turn it into Standby mode, press it again to power it on.

5.Set the Power switch to OFF position on the front panel to turn off the speaker.

Function Instructions

USB Operation

This unit has a USB port for play back MP3 music.

· Insert your USB device into the USB port and the unit will start playing automatically.

Press the [MODE] button to USBmode is selected.

· Press the or key to the previous or next track.

· Press the button to play or pause music

· Press button on the remote to repeat the current track, press it again to repeat all

tracks.

FM Radio Function

This Party Speaker comes with FM Radio Function.

Connect the FM Antenna to the “FM ANT” port at rear panel.

Press the [MODE] button repeatedly until FM function is selected.

Press the button on remote control or press play button on front panel to scan FM

station automatically.

Press the to select to the previous or next radio station.

Note: The performance of Radio station will affect by the different place of Party

Speaker or different weather.

Bluetooth mode

1. Press MODE Button on the Top Control panel or on the remote control to

switch to the Bluetooth mode.

2. Once on the Bluetooth mode,“bLUE ” will be displayed on the screen andis ashing on

the top right corner.

3. Open the Bluetooth on the external device and search the Bluetooth device name

"42686781" to pair.

4. Press connect to “PAIR” with the Party Speaker.

5. Once connected,you can hear a small sound from the unit, and is will static on the top

right corner, you can play the music with the speaker.

6. You can use the or button on the front panel to control the songs of the external device.

Note:This model does not need the password.

8 9

Connect with AUX Line in

1. Press【MODE】Button on the Top Control panel or on the remote control to switch to the AUX LINE in mode,

Line will be displayed on the screen.

2. Connect this unit AUX inserting jack and the device Earphone jack by provided AUX cable (included) Once

connected,turn on your external device .

3.Once connected,turn on your external device and play music.

Caution: Please turn off the unit before connect AUX cable in order to avoiding unexpected noise.

Connect with AUX Line in

Insert 6.35mm wired microphone, and use control knob to adjust

the sound level.

Connect to Wired Microphone

Connect with Wired Microphone

When playing with the wired microphone, please use this knob

to adjust the volume of microphone.

Important Notes

While using the microphone, avoid being put the microphone opposite

the bass of Party Speaker,as they may have Whistler Noisy.

To get the best singing performance, keep the micro phone within

5-15cm of the mouth and at a 45 degree angle.

When using the microphone, always pay attention to the battery.

If the battery is low, the indicator light will come on and the

performance will progressively become poor.

Caution: Please do not put the microphone directly face to the

Party speaker, it may damage the speaker.

When playing with the wired microphone, please use this knob to adjust the echo

volume of microphone.

FCC Warning

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this

device must accept any inte rference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following measures:

· Reorient or relocate the receiving antenna.

· Increase the separation between the equipment and receiver.

· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

· Consult the dealer or an experienced radio/TV technician for help.

Radiation Exposure Statement

The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
