Advanced Call Router
Advanced Call Router Manual 1
Advanced Call Router
Advanced Call Router is the standard AltiGen Call Router application plus
call router service. Advanced Call Router requires the purchase and
activation of an Advanced Call Router license.
Note: The workgroup to which incoming trunk calls will be routed via
Call Router must be assigned to the auto attendant whose Action is
set to “Adv - Advanced Call Router,” with Ext Num set to the
virtualextension you use to configureCallRouter.For information
on configuring auto attendants, refer to the Auto Attendant
Configuration chapter of the AltiWare Administration Manual.
New in Previous Release, 5.1
Supports the SKLR (Skill Level Requirement) setting added to AltiWare
ACM Administrator 5.1.
Installation
To install Advanced Call Router,
1. Runthe.exe file from the Advanced CallRouterfolderoftheAltiWare
5.2 Installation CD.
2. When prompted, enter the 20-digit license key for Advanced Call
Router in the field and click Next.
Setup will confirm the destination for the Call Router application
(defaultisC:\Program Files\AltiGen\CallRouter). Toselect adifferent
location, use the Browse button to choose the new location.
3. Click Next to proceed.
Note: Advanced Call Router Service requires the purchase and
activation of the Advanced Call Router license.

To Configure/Run Advanced Call Router
2Advanced Call Router Manual
To Configure/Run Advanced Call Router
1. Launch Call Router from the Windows Start menu.
2. Click the Connect button to enter the Call Router Server Name or IP
address to connect to, then click OK.
To disconnect from this server, click the Disconnect button.
3. Select Operation > Logon Info.

Advanced Call Router
Advanced Call Router Manual 3
4. In the LogonInfowindow,entertheServerNamethatAdvanced Call
Router will connect to, along with the Default Virtual Extension and
Password then click OK.
(Optional) Check Auto Start Service to have Advanced Call Router
start routing calls automatically, after the system restarts or after
Advanced Call Router service has been stopped and restarted.
Note: Up to 8 login attempts are allowed, after which login will be
disabled from 1 to 24 hours (depending on the setting in
AltiWare Administrator).
5. ClickStartto run Advanced Call Router.WhenAdvanced Call Router
is stopped, you can configure the server and login information.
6. Route Rules and Show Monitor can be configured after Advanced Call
Router is started.
Advanced Call Router Route Rules
To create route rules that will be used to route calls, select Operation >
RouteRuleto open the RouteRuleListwindow. This window also allows
you to view existing route rules, and modify and delete route rules.

Advanced Call Router Route Rules
4Advanced Call Router Manual
•Add - opens a Custom Record dialog box, where you can create a new
record and build the conditions for the record.
•Modify - opens the Customer Record dialog box to modify the record
selected in the Record List.
•Delete - deletes the record selected in the Record List.
•Delete All - deletes all records in the Record List.
• The Default Routing button opens a Default Routing Rule dialog
box, where you can specify the action for Call Router to take if no
match is found in the rules or in the database.

Advanced Call Router
Advanced Call Router Manual 5
Default Routing Action options: No Action, Goto Top Level,
Repeat Current Level, Call to Extension/Workgroup, Call to
Operator, Dial by Name, Collect Extension, Directory Service,
Record Message (specify target data in accompanying text box),
Mailbox Access, Disconnect, System Callback, Collect Digits
(specify fields in accompanying Collect Digit dialog box), Other
DDR Application (specify target data in accompanying text box),
Play WG Queue Status (specify target data in accompanying text
box).
Creating Route Rules
To create a route rule:
1. Select Operation > Route Rule.
2. Click the Add button to open a new Route Rule or Modify to modify
an existing rule in the Rules List dialog box.

Advanced Call Router Route Rules
6Advanced Call Router Manual
3. In the Rule Name field, enter or modify the rule name.
4. Select the data to match against routing rules.
•IfCaller Info contains—lets you select Call Route Request data to
match against the customer record.
a) Select “Match one” or “Match all” from the drop-down list.
b) Select the items you want.
c) Click in the Data column and type to specify the data.
To manually specify data for an item, right-click the item, select
Input data and enter information in the column.
• Caller Entered Digits must be numeric only.
• You can enter “*” as a wildcard character for any length of
digits, or “?” for a single digit.

Advanced Call Router
Advanced Call Router Manual 7
For example, if you specify Call ID Data “510252*,” this will
match all Caller IDs 510-252-xxxx. If you specify Call ID Data
“510252????,” this will match all Caller IDs 510 252-xxxx.
• To specify data from an existing database, right-click the item,
select From user database, and enter information in the
DataSource dialog box.
5. Select a Target action for Call Router to perform when Call Route
Request data matches this record.
Target action options: No Action, Goto Top Level, Repeat Current
Level, Call to Extension/Workgroup, Call to Operator, Dial by Name,
Collect Extension, Directory Service, Record Message (specify target
data in accompanying text box), Mailbox Access, Disconnect, System
Callback, Collect Digits (specify fields in accompanying Collect Digit
dialog box—see below), Other DDR Application (specify target data in
accompanying text box), Play WG Queue Status (specify target data in
accompanying text box—see Note below).
Collect Digit Dialog Box
•Tagname- forexample,“password”(gathered from a response
to an Auto Attendant prompt or another AltiLink Plus
application)
•Minimum Digits and Maximum Digits to collect
•PSTN and Web Timeout values

Advanced Call Router Route Rules
8Advanced Call Router Manual
Note: Play WG Queue Status - if you select “Play WG Queue
Status,” Advanced Call Router must log on as a workgroup
extension with password (View > Show Workgroup Status >
Add) and Call Router’s virtual extension and password. (The
virtual extension that Call Router uses does not have to be a
member of the workgroup.) Specify this workgroup extension
in the textbox that appears when you select Play WG Queue
Status. (See “Queue Announcements” on page 13.)
If you want to apply the “Play WG Queue Status” Target
action to several different workgroups,you must create separate
rules for each.
6. Enter optional data to match against the routing rule:
•Set Call Priority—Check the box and choose a call priority level.
•Set Call SKLR—Check the box and choose an SKLR level.
•User Data—Gathered from a response to an Auto Attendant
prompt or another AltiLink Plus application.
•Push URL (AltiWeb only).
•Prompt—The prompt to play to the callee.
7. Click OK.
Viewing Advanced Call Router History Menu
The Advanced Call Router window gives a history of all incoming trunk
calls to Advanced Call Router.
To specify Call Router History window content
1. Choose View > Select Column.
2. In the Select Columns dialog box, select the following columns to
display in the Call Router history window:
•CallerID
•IVRPath
•IVRdata
•DNIS

Advanced Call Router
Advanced Call Router Manual 9
Call Route Request Data
The “Call Router Request” message sent by AltiServ to Call Router
contains data about the incoming call, which Call Router attempts to match
against your routing rules. Call Route Request data consists of Caller ID,
IVR Path, IVR data and DNIS, all collected via real-time monitoring.
Note: IVR Path shows the Auto Attendant assignment for the workgroup
that receives the call. If the workgroup’s AA assignment is 5, this
item shows “0 & 5”; if the AA assignment is 3, the item shows “0
& 3,” and so on. The “0” indicates transfer to an Auto Attendant.
Call Route Response Data
The “Call Route Response” message, sent from Call Router to AltiServ,
contains the search results of the Call Route Request Message. In the Call
RouterHistory window, this datashowshowCallRouterhandled each call.
Call Route Response data includes Matching Record (routing rule Call
Router referred to for call routing) and Result (how and where the call was
routed), all collected via real-time monitoring.

Advanced Call Router Route Rules
10 Advanced Call Router Manual
Note: If no match is found between the Call Route Request Data and the
routing rules, the call is routed according to the business rules that
check monitored workgroups for the longest available agent,
maximum service level, and minimum expected delay.
Show Workgroup Status
To view real-time data on incoming trunks to workgroup, select View >
Show Workgroup Status.
• The main window box displays the following workgroup fields: ID,
Agents, Longest Idle Time, Service Level, Queue, Average Delay
and Default Wait Time.
•Add button—Click Add to log on to a workgroup whose incoming
trunk call data you want to monitor. This opens a Log On Work Group
dialog box.

Advanced Call Router
Advanced Call Router Manual 11
Enter the workgroup extension as the WorkGroup ID and password,
and enter the virtual extension’s password. In the field for Default
Wait Time in Queue, type in the desired minutes. (By default, the
Extension ID field is grayed out.)
•Delete button—click Delete to remove the selected workgroup from
the display.
•Change Default Wait Time—click this button to change the default
anticipated wait time associated with the workgroup queue.
Note: The workgroup to which incoming trunk calls will be routed via
Call Router must be assigned to the Auto Attendant whose Action
is set to “Avd - Advanced Call Router,” with Ext Num set to the
virtual extension you use to start Call Router. For information on
configuring Auto Attendants, refer to the “Auto Attendant
Configuration” chapter of the AltiWare Administrator Manual.
If you want to announce queue status to callers (Target action of
any routing rule is “Play WG Queue Status,”) complete the Virtual
Extension ID and Virtual Extension password fields using the
workgroup agent extension (and its password) specified in the rule.
To log on to multiple workgroups:
•ClickAdd again and enter the next Workgroup ID and Password.
•Change Start Calculate Call Count—click this button to change the
starting point for the number of calls to be reached for Call Router to
start calculating call data.

Clearing Advanced Call Router History Data
12 Advanced Call Router Manual
Clearing Advanced Call Router History Data
To clear data from the Advanced Call Router History window
1. Go to the directory “Program Files\AltiGen\Call Router” and locate the
Call Router.csv file.
2. Open Call Router.csv and delete all contents.
3. Save and close Call Router.csv.
Additional Advanced Call Router Features
Building SQL Queries
To build an SQL query that Call Router will send to your database, use the
CallerIdDatasource dialog box.The customer information retrieved from
your database will be used in the routing rule.

Advanced Call Router
Advanced Call Router Manual 13
To open the Datasource dialog box, right-click on a data Item you want to
specify using information from an existing database. Select From user
database:
To build a SQL query:
1. Enter User Name and Password information for the database.
2. Enter information for the database you are querying against. For
example:
DSN - BankAccount
Table Name - AccountBalance
Matched Field Name - CustomerPhoneNumber
Matched Field Data Type - char
Note: as you build the query, the SQL query sentence will appear in
the window at the bottom.
3. Specify the condition for this query.
a. Select the Caller Match Item data for this query - Caller ID, IVR
Path, DNIS, Item name or IVR data.
b. Add any additional condition. For example Where - &&
Balance>1000
4. Click OK. You will be returned to the Rule dialog box, where the SQL
query will be shown in the Data column and the database will be shown
in the DSN column.
Queue Announcements
Note: Queue announcements can now be done directly through
AltiWare. Or you may use Advanced Call router for this function
if you want.
If you use Advanced Call Router to inform callers of their position in a
workgroup queue, there are two requirements:
1. In Call Router, you must create a rule with Target action “Play WG
Queue Status.” In addition, enter an Item Name that matches the name
of the Auto Attendant’s “Advanced Call Routing” name. The
workgroup extension information you specify in the rule must also be
entered when Call Router logs on in the Monitor window. Thus, it is a

Additional Advanced Call Router Features
14 Advanced Call Router Manual
requirement to use the same virtual agent extension if you are writing
several different queue announcement rules.
2. In AltiWare Administrator, you must configure one of the Auto
Attendant numbers to which Call Router is assigned to “Advanced Call
Router.” 1) Enter the same “Item Name” you use in the rule discussed
immediately above. 2) Replace the “No Action” level with “Call – to
Ext./Workgroup,” and enter the workgroup extension number. For
further information on configuring Auto Attendants, see the AltiWare
Administration Manual and the AltiAPI Programmer Guide.
If your organization has multiple workgroups and you want queue
announcement for several or all of them, you must create separate rules for
each, with workgroup extension information pertinent to each workgroup.
Example:
Suppose you use virtual extension 700 to log in to Call Router, and you
have two workgroups, Sales and Support, with the following agent and
workgroup extensions:
Sales Support
Workgroup extension number 500 600
Call Router virtual extension number 700 700
For both workgroups, you want Call Router to check incoming calls for
Caller IDand IVR Path, and to play the WG queue status if a match isfound
and all agents are busy.
InAltiWareAdministrator,you configure the Auto Attendantto whichCall
Router is assigned as shown below. (The example uses Auto Attendant 2.)
Note that you must enter a different Item Name for each level.

Advanced Call Router
Advanced Call Router Manual 15
For Sales, you create a rule as shown below.

Additional Advanced Call Router Features
16 Advanced Call Router Manual
Similarly, for Support, you create a rule as shown below.
