Altimeters VISO II+ User manual

VISO II+™
MANUAL

REV. 02, SEPTEMBER 2022
VISO II+ is a trademark of LB Altimeters, Denmark.
LB Altimeters operates a policy of continuous development.
Therefore, we reserve the right to make changes and improvements to any of the
products described in this guide without prior notice.

3
FAILURE TO FOLLOW ALL WARNINGS, INSTRUCTIONS, AND REQUIRED
PROCEDURES MAY RESULT IN SERIOUS INJURY AND DEATH.
Always ensure your altimeter is adjusted to zero prior to jumping to account for any
changes in barometric pressure.
Altimeters may give erroneous readings if you are tumbling or the altimeter is in a
burble (wake), such as when sit ying or sky surng. Chest mount altimeters are more
vulnerable to this problem. If you are in doubt about how this limitation a󰀨ects your
skydiving, consult a licensed instructor.
DO NOT use this equipment unless you are in, or have passed an approved skydiving
course.
Use the VISO II+™ at your own risk.
WARNING

4
Introduction .....................6
Description......................9
Display ........................10
Main Window ...................14
Altimeter Mode ................14
Speedometer Mode.............16
Road Map ......................18
Customise the VISO II+™ Settings . 19
Altimeter/Speedometer Selector ...22
Feet/Meter Selector.............23
Mph/Kmh Selector..............24
Altitude O󰀨set .................25
Dive Type Selector .............26
True Airspeed (TAS)/
Skydiver’s Airspeed (SAS) .......28
Set Current Year Selector ........31
Set Current Date Selector ........32
Set Current Time Selector .......33
Preset Jump Counter Selector ....34
Reset Jump Counter Selector .....35
Turn VISO II+™ OFF Selector ....36
Lock Window ..................37
Backlight Setup Area ............38
Backlight ON/OFF ..............38
Zeroing the VISO II+™............39
Jump Mode.....................40
Daily Jump Counter..............41
Jump Data. .....................42
Logbook Area ..................42
Jump Number .................43
Exit Altitude ...................44
Deployment Altitude ............45
CONTENTS

5
Freefall Time ..................46
Max. Speed in Freefall ..........47
Max. Speed under Canopy .......48
Prole Area ....................50
Playback Altitude Versus Time ....51
Playback Speed Versus Time .....52
Air Filter .......................54
Resetting the VISO II+™ ..........55
Battery Replacement.............56
Battery Status ..................57
Firmware Version. . . . . . . . . . . . . . . . 58
Trouble-shooting ................59
Appendix ......................60
TAS and SAS .................60
Specications ..................63
Mechanical ...................63
Logbook......................63
Prole Storage.................64
Factory default settings ..........64
Other ....................... .65
Warranty .......................66

6
Congratulations on purchasing your new VISO II+™!
The VISO II+™ design is based upon the latest ndings in microcomputer technology
and freefall parameters. Please read ALL of the instructions prior to actual skydiving
use. The VISO II+™ consists of three instruments:
1 Digital Altimeter
Stores detailed altitude information about the last jump for later review
2 Digital Speedometer
Stores detailed speed information about the last jump for later review
3 Digital Logbook
Electronic logbook, storing and displaying information about the last 200 jumps.
• Can be used as an aid to track the amount of jumps made.
• Can be reset at any time, but time and date for the last reset remains stored and
cannot be erased.
INTRODUCTION

7
4 Daily Jump Counter
• Displays number of jumps completed on last date and/or 9 other jump dates.
Features
• Digital altimeter or speedometer
• Electroluminescent backlight for night jumping. Can remain ON for several hours
• Automatic calibration to local elevation
• LCD screen for easy and intuitive operation and information review
• Logbook with playback of altitude/speed prole for the last jump
• Operational at sub-zero temperatures
• Switches OFF automatically after 14 hours

8
Software & functions
• Stores up to 10 minutes of data from the last jump
Displays altitude and speed details from exit to landing
• Records and displays jump information about the last 200 jumps including exit
altitude, deployment altitude, freefall time, max. speed in freefall and max. speed
under canopy
• Choice of readings in feet or meter and mph or kmh
If you have any questions please e-mail us at [email protected]

9
1 UP button
3 DOWN button
4 LCD display
5 Reset button
(on rear side)
2 Middle button
DESCRIPTION

10
The display has the following characteristics by default (normal usage):
Date/Time Area
1 Date icon
2 Time icon
DISPLAY
1
Date/Time Area
Altitude/Speed Area
Status Area
24
5
6
7
810
11
12
9
3

11
3 Additional information, displaying:
- current date/time
- time in prole when in Prole Area
- date/time when in Logbook Area
4 Battery status
Battery Power Level icon – indicates the remaining battery capacity
Altitude/Speed Area
5 Main information, displaying:
- altitude when VISO II+™ is set to Altimeter mode
- speed when VISO II+™ is set to Speedometer mode
- detailed prole information when in Prole Area
- logbook information when in Logbook Area
- various setup information

12
Status Area
6 True Airspeed (TAS) / Skydiver’s Airspeed (SAS) status
7 Mph/Kmh status
8 OFF icon - Used to manually power OFF the VISO II+™
9 Speedometer indicator when VISO II+™ is set to Speedometer mode
10 Lock icon Used to indicate and control entrance to ACCESS mode
11 Feet/Meter status
12 Altimeter indicator when VISO II+™ is set to Altimeter mode
Power ON
The VISO II+™ has been powered OFF prior to shipping from our factory. To turn the
power ON, press and hold any key until the VISO II+™ beeps, then release the button.
Auto OFF
The VISO II+™ automatically switches OFF 14 hours after the last jump or 14 hours
after the last pressing of any key, whichever comes last.

13
Main Window
This represents the starting point for all further actions and subsequent displays.
The VISO II+™ runs a
self-test and displays
all icons
It then displays the
rmware version number
together with a factory
reference number...
...and switches to a
screen conguration
referred to as the “Main
Window”.

14
Explanation
The Main Window is the default window which displays current time, battery status and
either Altitude or Speed.
Altimeter Mode
MAIN WINDOW
When the VISO II+™ is set to Altimeter mode, the
“ALTI” and “Feet/Meter” icons are ON.
The VISO II+™ will display the altitude during
climb, in freefall and under canopy.
The date/time information switches OFF during
freefall and under canopy.
(When preset, press to view the current date).

15
Altimeter Displays
In Altimeter mode the LCD may show 3 di󰀨erent displays, depending on what altitude
value is shown.
If the altitude is below 1000 the altitude is displayed as nor-
mal. Altitude resolution is in 10 feet (5 meter) increments.
If the altitude is 1000-9999, the altitude is displayed as tens of
feet or meter. Altitude resolution is in 10 feet
(10 meter) increments

16
If the altitude is 10000 or higher, the altitude is displayed as
hundreds of feet or meter. Altitude resolution is in 100 feet
(100 meter) increments.
Speedometer Mode
When the VISO II+™ is set to Speedometer mode, the SPEED,
“Feet/Meter”, “Mph/Kmh” and “TAS/SAS” icons are ON.
The VISO II+™ will display the climb rate/speed during climb,
in freefall and under canopy.
The date/time information switches OFF during freefall and
under canopy.

17
Speedometer Display during the freefall
Speed resolution is in 1 Mph (1 Kmh) increments.
Important Notice about Speed Recordings
Experience has shown that when mounting the VISO II+™ on the hand or belly,
di󰀨erent air pressures induced by hand or body movements may result in incorrect
recordings of speeds.

18
It is recommended that you rst familiarize yourself with the VISO II+™
ROAD MAP which is a helpful tool when using the VISO II+™.
The ROAD MAP comprises four areas:
• Backlight Setup (see page 38)
• Prole (see page 50)
• Setup (see page 19)
• Logbook (see page 43)
ROAD MAP

19
The VISO II+™ can be customised to your personal settings. Your settings will be
stored and recalled after replacing batteries. When you rst get the VISO II+™, we rec-
ommend you to go through the SETUP Selector to customise the VISO II+™ settings.
SETUP Selector
In the Setup Area the following options can be selected:
• Altimeter/Speedometer
• Feet/Meter when set to Altimeter
• Mph/Kmh when set to Speedometer
• Altitude o󰀨set
• Dive Type
• True Airspeed (TAS)/Skydiver’s Airspeed (SAS)
• Set current year
• Set current date
• Set current time
CUSTOMISE THE VISO II+™ SETTINGS

20
• Preset jump counter
• Reset jump counter
• Turn the VISO II+™ OFF
• Lock window
Performing ACCESS:
Use to access Jump Prole, use to access Logbook information.
1 Press or and release quickly. The lock icon turns ON and OFF
2 When the lock icon turns ON again, immediately press the same button and keep it
pressed (lock turns OFF)
3 When the lock icon turns ON again, release immediately
General note: The VISO II+™ goes out of ACCESS and back to the Main Window if
no button has been pressed within 15 sec. ALL functions (except Power ON and back-
light access) can be performed ONLY when the VISO II+™ is in ACCESS mode.
