Altronix NetwayXT User manual

Rev. 042409
®
Installation Guide
NetWayXT/NetWayXTX
Repeater
Overview:
Altronix NetWayXT (IEEE 802.3af (15W) compliant) and NetWayXTX (IEEE 802.3af (15W) and IEEE
802.3at (30W) compliant) repeater modules interface with NetWay midspans to extend data (video) for
an additional 100m. A maximum range of 600m for NetWayXT and even longer for NetWayXTX is
possible using multiple repeaters, based on camera/device port power requirement.
Features:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
• Repeater module extends range 100m each.
• Port status LEDs.
• Compact insulated housing.
• Plug-and-play installation.
• Auto detection and protection of legacy
non-PoE cameras.
• No external power required.
• Compatible with NetWay1/NetWay8/
NetWay8M/NetWay16 and NetWay16M.
Installation Instructions:
NetWayXT/NetWayXTX is not intended to be connected to outside plant leads.
1. Mount NetWayXT/NetWayXTX in desired location utilizing the mounting hole (Fig. 1a, pg. 1,
Fig. 2a, pg. 2). Use a proper fastener and/or wall anchor when securing NetWayXT to the wall.
2. Connect structured cable from port marked [OUT] on NetWay1/NetWay8/NetWay8M/NetWay16
or NetWay16M to port marked [IN] on the NetWayXT/NetWayXTX (Fig. 1b, pg. 1, Fig. 2b, pg. 2).
3. Connect structured cable from port marked [OUT] on NetWayXT/NetWayXTX to the PoE camera/
device or next NetWayXT/NetWayXTX repeater (Fig. 1b, pg. 1, Fig. 2b, pg. 2, Figs. 3-4, pg. 2).
4. Port status LEDs will illuminate on NetWayXT indicating the port is operational
(Fig. 1b, pg. 1, refer to Port LED definitions on pg. 1).
5. Power LED will illuminate indicating 12VDC output (Fig. 1b, pg. 1).
Port LED definitions for NetWayXT repeater:
Status Green LED Yellow LED
OFF Indicates it is connected as 10Base-T or no link. Indicates no link.
ON Indicates it is connected as 100Base-TX. Indicates a link.
Blinking --------------------------- Indicates activity.
NetWayXT
Fig. 1
next NetWayXT
Fig. 1a
Fig. 1a
NetwayXT
Repeater
IN
OUT
Power
Power
LED
Structured Cable from
NetWay1,
NetWay8, NetWay8M,
NetWay16, NetWay16M
or last NetWayXT
Structured
Device or
Cable to
PoE Camera/
LEDs
Port Status
www.altronix.com
I.T.E. 43KC
NetWayXTX
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
- 1 -

Port LED definitions for NetWayXTX repeater:
Status PoE/PoE+ Output LED PoE/PoE+ Input LED Yellow LED
OFF No PoE/PoE+ Output No PoE/PoE+ Input Indicates no link.
ON Normal PoE/PoE+ Output PoE/PoE+ Input Indicates a link.
Blinking ------- ------- Indicates activity.
NetWayXTX
Fig. 2 Fig. 2a
Fig. 2b
PoE/PoE+
Output
LED
Structured Cable from
NetWay1(X),
NetWay8, NetWay8M,
NetWay16, NetWay16M
or last NetWayXTX
Structured
Cable to
PoE/PoE+
Camera/Device or
next NetWayXTX
Port Status
LEDs
PoE/PoE+
Input
LED
NetwayXTX
Repeater
www.altronix.com
IN
OUT
I.T.E. 43KC
PoE/PoE+
Output
PoE/PoE+
Input
Typical Applications:
Fig. 3 - NetWayXT connected to NetWay1 Single Port Midspan Injector.
Video Monitor
NVR/Network Server
Network Switch
NetwayXT
Repeater
www.altronix.com
24VAC/
24VDC
input
Netway1
Single Port
Injector
(Midspan)
Port
Status
www.altronix.com
PoE Camera
CAT5e 100m
CAT5e 100m
NetWay1 NetWayXT
Port
shutdown
input
I.T.E.43KC
I.T.E.43KC
Fig. 4 - NetWayXTX connected to NetWay1X Single Port Midspan Injector.
NetWay1X NetWayXTX
NetwayXTX
Repeater
www.altronix.com
IN
OUT
I.T.E.43KC
PoE/PoE+
Output
PoE/PoE+
Input
CAT5e 100m
24VAC/VDC
Input Power ShutdownIN OUT
NetWay1X
Single Port Injector (Midspan)
Input:24VAC/VDC, 1.5A
Output: IEEE 802.3at (30W) and
IEEE 802.3af (15.4W)
compliant.
www.altronix.com
I.T.E.43KC Z109
Port
shutdown
input
CAT5e 100m
PoE/PoE+
Camera
NVR/Network Server
Network Switch
24VAC/24VDC
or 56VDC
Input
Video Monitor
- 2 - NetWayXTX
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]

Typical Applications (cont’d):
Fig. 5 - NetWayXT/ NetWayXTX connected to
NetWay8, NetWay8M, NetWay16 or NetWay16M Midspan.
NetWayXT/XTX
PoE Camera PoE Camera
Video Monitor
NVR/Network Server
Network Switch
CAT5e
100m
CAT5e
100m
CAT5e
100m
CAT5e
100m
NetWayXT/XTX NetWayXT/XTX NetWayXT/XTX
CAT5e
100m
CAT5e 100m
CAT5e
100m
PoE Camera
Fig. 6 - Connecting several NetWayXTs/NetWayXTXs on a single port.
NetWay
NetWayXT or NetWayXT or NetWayXT or
Midspan NetWayXT PoE Camera PoE Camera PoE Camera
(6W or less) (4W or less) (<3W or less)
CAT5e CAT5e CAT5e CAT5e CAT5e CAT5e
1 2 3 4 5
100m 100m 100m 100m 100m
NetWayXTX NetWayXTX or NetWayXTX or NetWayXTX or
PoE+ Camera PoE+ Camera PoE+ Camera
(21W or less) (19W or less) (<18W or less)
NetWayXT or
PoE Camera
(<1.5W or less) PoE
Camera
(Requires local
power)
100m
NetWayXTX or ... Continue
PoE+ Camera until power
(<16W or less) drops to 3W
NetWayXTX
Available from A1 Security Cameras
www.a1securitycameras.com email: [email protected]
- 3 -

Notes:
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
NetWayXTX F18O MEMBER
