Altronix NetWayXT User manual

NetWayXT -1-
Overview:
Altronix NetWayXT repeater modules interface with NetWay midspans to extend power and data (video) an additional
100m (328 ft.). A maximum range of 600m (1968 ft.) is possible using multiple repeaters, based on camera/device port
requirement.
Installation Instructions:
NetWayXT is not intended to be connected to outside plant leads.
1. Mount NetWayXT in desired location utilizing the mounting hole (Fig. 1a, pg. 1).Use a proper fastener and/or wall
anchor when securing NetWayXT to the wall.
2. Connect structured cable from port marked [OUT] on NetWay1/NetWay8/NetWay16 to port marked [IN] on the
NetWayXT (Fig. 1b, pg. 1).
3. Connect structured cable from port marked [OUT] on NetWayXT to the PoE camera/device or next NetWayXT
repeater (Fig. 1b, pg. 1, Fig. 4 and 5, pg.2).
4. Port status LEDs will illuminate on NetWayXT indicating the port is operational
(Fig. 1b, pg. 1, refer to Port LED definitions on pg. 1).
5. Power LED will illuminate indicating 12VDC output (Fig. 1b, pg. 1).
Port LED definitions for NetWayXT repeater:
• UL/CUL Listed for Information
Technology Equipment
(UL 60950-1).
• CE approved.
• Repeater module extends range 100m (328 ft.) each.
• Port status LEDs.
• Compact insulated housing.
• Plug-and-play installation.
• Auto detection and protection of legacy non-PoE cameras.
• No external power required.
• Compatible with NetWay1, NetWay8 and NetWay16
Specifications:
NetwayXT
Repeater
IN
OUT
Power
Power
LED
Structured
Cable from
NetWay1, NetWay8
NetWay16 or
last NetWayXT
Structured
Cable from
PoE Camera/
Device or
next NetWayXT
Port Staus
LEDs
www.altronix.com
I.T.E. 43KC
Fig. 1
Fig. 1a
NetWayXT - Repeater Rev. 042409
Status Green LED Yellow LED
OFF Indicates it is connected as 10Base-T or no link. Indicates no link.
ON Indicates it is connected as 100Base-TX. Indicates a link.
Blinking ------- Indicates activity.
Fig. 1b
All manuals and user guides at all-guides.com
all-guides.com

Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IINetWayXT G21I
-2- NetWayXT
Video Monitor
NVR/Network Server
Network Switch
NetwayXT
Repeater
www.altronix.com
24VAC/
24VDC
input
Netway1
Single Port
Injector
(Midspan)
Port
Status
www.altronix.com
PoE Camera
CAT-5 100m (328 ft.)
CAT-5
100m (328 ft.)
NetWay1 NetWayXT
Port
shutdown
input
I.T.E. 43KC
I.T.E. 43KC
Fig. 3 - NetWayXT connected to NetWay1 Single Port Midspan Injector
Typical Applications:
MEMBER
OUT
IN
30W
1 2
30W
345678
OUT
IN
Video Monitor
NVR/Network Server
Network Switch
CAT-5
100m (328 ft.)
CAT-5
100m
(328 ft.)
PoE Camera
CAT-5
100m (328 ft.)
CAT-5
100m
(328 ft.)
PoE Camera
NetWayXT
NetWayXT
NetWayXT NetWayXT
CAT-5
100m (328 ft.)
CAT-5
100m (328 ft.)
CAT-5
100m
(328 ft.)
PoE Camera
Fig. 4 - NetWayXT connected to NetWay8 or NetWay16 Midspan
Fig. 5 - Connecting several NetWayXTs on a single port
NetWay
Midspan
CAT5
100m
CAT5
100m
CAT5
100m
CAT5
100m
CAT5
100m
CAT5
100m
NetWayXT
1
NetWayXT or
PoE Camera
(6W or less)
2
NetWayXT or
PoE Camera
(4W or less)
3
NetWayXT or
PoE Camera
(
< 3W or less)
4
NetWayXT or
PoE Camera
(
< 1.5W or less)
5
PoE
Camera
(Requires local
