Altronix ABH-B Series User manual

88
88
88
88
Digital 8-frequency conversion
active infrared detector
Installation guide
ABH-B series
Alert distance
Model
Outdoor
Indoor
No. of beams 4 beams
Detection mode 4 beams blocked simultaneous
Optical source Infrared digital pulse beam
Response speed 50 240msec adjustable
Alarm output Relay contact output: NO. NC contact rating: AC/DC30V 0.5AMax
Power supply
Power consumption
Operation temperature & humidity
-25 -55 5%-95%RH(relative humidity)
Tamper output Contact output: NC contact rating DC24V 0.3Amax
Optical axis adjustment(H)
Optical axis adjustment(V)
Material PC resin
Net weight 2000g(receiver +transmitter)
Gross
I. Specification
II. Parts
Wiring hole
Wiring terminal
Lens
Horizontal fine-tune knob Vertical fine-tune knob
Housing
Features:
1. Under BUS connection mode: The digital display of RX synchronize with the TX after the RX receive the signal from BUS
2. Anti-fog function: When signal strength decrease slowly to 0.8V,the detector will active anti-fog alarm( TBL output), when
signal decrease to 0.4V, will active alarm, when signal get back to 1.2V cancel alarm.
III. Installation notice
Impediment presents during setup
Receiver Receiver Receiver Receiver
Receiver
Transmitter
Receiver
Transmitter
Multi sensors may be used for long-distance
guarding. Please install according to the below
diagram to avoid interference between beams.
Receiver
Transmitter
Transmitter
Receiver
°
°
vertical ±10
Adjustable angle: horizontal ±90
The base is unstable
Direct sunlight,lamplight etc.
Horizontal 180 ( 90 ) vertical ±10°
Installation heigh 0.7m 1.0m
Guarding distance
Beam spread diameter
Model
Guarding distance
Beam spread diameter
IV.Installation method
1.Remove the cover 2.Attach the paper stencil onto the location
where the equipment is to be mounted, and
drill the holes in the positions on its mark.
3.Put the cable through the hole for wiring.
Wiring hole
4.Fix the main body onto the wall 5.Connect the cable to the wire terminal. Receiver
Transmitter
BUS
BUS
6. DIP setting
Transmitter Receiver
BUS address setting
Air terminal
Air terminal
BUS address setting
Buzzer ON/OFF setting
FRE.
Mode
Signal strength
Frequency mode
Address mode
Address/frequency alternately
display mode
Table 1 Table 2
Alarm output N.O/N.C setting
Frequency set mode Frequency set mode
Function set mode Function set mode
Function setting(table 2)
1. Under frequency mode: The digital display shows the frequency, Set frequency on DIP1.2.3(see table 1)
2. Under address mode: The digital display shows BUS address, set the address on DIP1.2.3.4.5.6
3.Under signal strength mode: The digital display shows the signal strength, the DIP1.2.3.4.5.6 under this mode is invalid
4.Under address/frequency alternately display mode: The digital display shows address and frequency alternately,
the DIP1.2.3.4.5.6 under this mode is invalid
Frequency setting:(First enter frequency setting mode, see table 2)
Then set DIP 1.2.3 to set detector's frequency( see table 1)
BUS address setting:(First enter address mode, see table 2)
Under address mode, Set DIP 1-6 to set the detector's zone address. first set DIP at ON,
the number of the one DIP which set ON puls the other one, then plus 1,
the final result of number is the zone number, example this is zone 18(17+1)

88
5
88
88
88
Receiver Transmitter Receiver Transmitter Receiver Transmitter
Set 0 Set 1 Set N
Special BUS panel or
special BUS module
Note:The transmitter can disconnect with BUS cable, when disconnect, the transmitter can't display signal strength,
can't auto-adjust transmitting frequency according to signal strength
7. BUS wiring:
8.Take back the cover after the adjustment of response time
Installation of fixed bracket
1. Drill a hole on the bracket
and extend out the cable from it 2. Take off the cover Fasten the base-plate to the bracket
3.
Wiring from power and BUS
Wire
Distance
Voltage
0.5mm (Diameter 0.8)
0.75mm (Diameter 1.0)
1.25mm (Diameter 1.2)
2.0mm (Diameter 1.6)
Note:Please insert waterproof plug into the hole of screw
(Back -to-back installation guiding diagram)
V. Beam alignment
1.Put the viewfinder on the TX/RX, observe the collimation effect
at a distance 5cm from the viewfinder, adjust to let the image of
opposite detector falls into the central part of the viewing hole
2. Vertical and horizontal adjust as below picture showed to get
a best signal strength, if signal strength less than 1.8,please
adjust again to get a better signal strength.
Vertical angle adjustment screw
Down
Up
Horizontal angle adjust knob
Right
Left
VII.Response time adjustment
50ms
240ms
Please see the diagram to adjust the response
time of receiver,Usually, the time set shall
be less than the time when the intruder crosses
the guarding area
High speed:1(6.9m/s) Fast running:2(4m/s)
Fast walking:3(1.2m/s) Normal walking:4(0.7m/s) Slow walking:5(0.4m/s)
IX.RX LED state
After finish setting, please make walk test.
Green LED Red LED
TX
RX
Flash when is BUS signal, light on when there is no BUS signal
Flash when is BUS signal, light on when there is no BUS signal
Always light on
Light on when alarming,light off as normal status
X.Structure & Dimension
Installation bracket T bracket
L bracket
I bracket
