Altuscn KN2124v User manual

KVM Over the NET™
KN2124v / KN2140v / KN4124v / KN4140v /
KN2132 / KN4116 / KN4132
User Manual
www.aten.com
kn2124v-4132.book Page i Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
ii
FCC Information
This is an FCC Class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
RoHS
This product is RoHS compliant.
SJ/T 11364-2006
The following contains information that relates to China.
kn2124v-4132.book Page ii Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
iii
User Information
Online Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual
are subject to change without prior notification by the manufacturer. The
manufacturer makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties as to merchantability or fitness for any particular purpose. Any of
the manufacturer's software described in this manual is sold or licensed as is.
Should the programs prove defective following their purchase, the buyer (and
not the manufacturer, its distributor, or its dealer), assumes the entire cost of all
necessary servicing, repair and any incidental or consequential damages
resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation
of this system if the correct operational voltage setting was not selected prior
to operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS
CORRECT BEFORE USE.
International http://support.aten.com
North America ATEN TECH http://www.aten-usa.com/product_registration
ATEN NJ http://support.aten.com
International 886-2-8692-6959
North America ATEN TECH 1-888-999-ATEN
ATEN NJ 1-732-356-1703
kn2124v-4132.book Page iii Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
iv
Package Contents
The KVM Over the NETTM switch package consists of:
1 KN2124v,KN2140v,KN4124v,KN4140v,KN2132,KN4116,orKN4132
KVM Over the Net™ Switch
2 SA0142 Serial Adapters (RJ45-F to DB9-M; DTE to DCE)
1 Grounding Wire
1 Power Cord (KN4116 / KN2132 / KN4132 only)
2 Power Cords (KN2124v / KN2140v / KN4124v / KN4140v only)
1 5-in-1 Console Cable (KN2124v / KN2140v / KN4124v / KN4140v only)
1 Rack Mount Kit
1 Foot Pad Set (4 pcs.)
1 User Manual*
1 Quick Start Guide
Check to make sure that all of the components are present and in good order.
If anything is missing, or was damaged in shipping, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the switch or to any other
devices on the installation.
*Features may have been added since this manual was printed. Please visit our
website to download the most up to date version of the manual.
Copyright © 2006-2009 ATEN® International Co., Ltd.
Manual Part No. PAPE-0296-AX2G
F/W Version: 1.1.106
Manual Date: 2009-03-10
Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.
kn2124v-4132.book Page iv Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
v
Contents
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
SJ/T 11364-2006. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiii
Terminology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiii
Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xiv
Chapter 1.
Introduction
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
All Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
V-Series Exclusive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Local Client Computers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Remote Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
KVM Adapter Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Browsers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
KN2124v / KN2140v / KN4124v / KN4140v Front View . . . . . . . . . . .10
KN4132 / KN4116 / KN2132 Front View . . . . . . . . . . . . . . . . . . . . . . .10
KN2124v / KN2140v / KN4124v / KN4140v Rear View. . . . . . . . . . . .13
KN4132 / KN4116 / KN2132 Rear View . . . . . . . . . . . . . . . . . . . . . . .13
Chapter 2.
Hardware Setup
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Stacking and Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Stacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Rack Mounting - Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Rack Mounting - Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Single Stage Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
KN2124v / KN2140v / KN4124v / KN4140v
Single Stage Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
KN2132 / KN4116 / KN4132
Single Stage Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
kn2124v-4132.book Page v Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
vi
Adapter Cable Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Two Stage Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Two Stage Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Hot Plugging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
The Adapter ID Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Powering Off and Restarting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Port ID Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Chapter 3.
Super Administrator Setup
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
First Time Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Network Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Changing the Super Administrator Login . . . . . . . . . . . . . . . . . . . . . . 36
Moving On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Chapter 4.
Logging In
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Local Console Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Browser Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
WinClient AP Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
The Connection Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
The File Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Java Client AP Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 5.
The User Interface
The Web Browser Main Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Page Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
The Tab Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
The GUI Main Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
The Local Console GUI Main Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
The Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
WinClient Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Control Panel Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Hotkeys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
User Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
System Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Video Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Gamma Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
The Message Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
The Button Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Message Display Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Compose Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
kn2124v-4132.book Page vi Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
vii
User List Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Virtual Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Virtual Media Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
The On-Screen Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Mouse Pointer Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Mouse DynaSync Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Automatic Mouse Synchronization (DynaSync). . . . . . . . . . . . . . .77
Mac and Linux Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Manual Mouse Synchronization. . . . . . . . . . . . . . . . . . . . . . . . . . .78
Control Panel Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
The Java Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Chapter 6.
Port Access
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
GUI Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
The Port Selection Sidebar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
The Port Selection Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Port Views. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Port Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Port Properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Port Naming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Array . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Device Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Port Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
History. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Adding a Favorite. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Modifying a Favorite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
User Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Device Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Port Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
The Status Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
The Properties Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Saving Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Chapter 7.
User Management
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
kn2124v-4132.book Page vii Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
viii
Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
GUI Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Adding Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Modifying User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Deleting User Accounts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Creating Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Modifying Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Deleting Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Users and Groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Assigning Users to a Group From the User’s Notebook. . . . . . . . . .116
Removing Users From a Group From the User’s Notebook. . . . . . . 117
Assigning Users to a Group From the Group’s Notebook. . . . . . . . .118
Removing Users From a Group From the Group’s Notebook. . . . . . 119
Device Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Assigning Device Permissions From the User’s Notebook. . . . . . . . 120
Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Assigning Device Permissions From the Groups’ Notebook. . . . . . . 122
Chapter 8.
Device Management
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
GUI Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Device Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Service Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
NIC Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Redundant NIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
IP Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
DNS Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Network Transfer Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
ANMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
IP Installer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
SMTP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Log Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
SNMP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Syslog Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Disable Local Authentication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
RADIUS Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
LDAP / LDAPS Authentication and Authorization Settings. . . . . . . .134
CC Management Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
OOBC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
IP and MAC Filtering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Adding Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
kn2124v-4132.book Page viii Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
ix
Modifying Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .137
Deleting Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138
Login String. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138
Account Policy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138
Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Private Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Using a Private Encryption Key. . . . . . . . . . . . . . . . . . . . . . . . . .139
Importing a Signed SSL Server Certificate . . . . . . . . . . . . . . . . .139
Customization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140
Login Failures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140
Working Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141
Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Adapter Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
Reset on Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143
Date/Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144
Time Zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .144
Date. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145
Network Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .146
Chapter 9.
Maintenance
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
Web Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
GUI Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
Page Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
Firmware File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
The Main Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
Upgrading the Main Firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
Adapter Firmware Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
Firmware Upgrade Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
Adapter Cable Firmware Upgrade Recovery . . . . . . . . . . . . . . . . . . . . .152
Backup/Restore. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .153
Backup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .153
Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
Chapter 10.
Download
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155
Chapter 11.
Port Operation
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .157
The Port Toolbar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158
The Toolbar Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .159
Toolbar Hotkey Port Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160
Auto Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160
kn2124v-4132.book Page ix Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
x
Setting the Scan Interval: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Invoking Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Pausing Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Exiting Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Skip Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Recalling the Port Access Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
OSD Hotkey Summary Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Panel Array Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Panel Array Toolbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Multiuser Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Users and Buses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Chapter 12.
The Log Server
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Starting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
The Menu Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Configure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Search: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Maintenance:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
The Log Server Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
The List Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
The Event Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Chapter 13.
LDAP Server Configuration
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Install the Windows 2003 Support Tools . . . . . . . . . . . . . . . . . . . . . . . . 175
Install the Active Directory Schema Snap-in. . . . . . . . . . . . . . . . . . . . . . 176
Create a Start Menu Shortcut Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Extend and Update the Active Directory Schema. . . . . . . . . . . . . . . . . .177
Creating a New Attribute. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Extending the Object Class With the New Attribute . . . . . . . . . . . . . 179
Editing Active Directory Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Appendix
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Rack Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
North America. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
KN2124v / KN4124v . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
kn2124v-4132.book Page x Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
xi
KN2140v / KN4140v . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190
KN4116 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191
KN2132 / KN4132 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
General Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Mouse Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
Virtual Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .197
Web Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .197
The WinClient ActiveX Viewer and the WinClient AP . . . . . . . . . . . .198
Mac Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
The Java Applet and Java Client AP. . . . . . . . . . . . . . . . . . . . . . . . .199
Sun Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200
The Log Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201
Panel Array Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201
IP Address Determination. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202
The Local Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202
IP Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202
Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
Port Forwarding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204
PPP Modem Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Connection Setup Example (Windows XP). . . . . . . . . . . . . . . . . . . .206
KA7140 Configuration and Operation. . . . . . . . . . . . . . . . . . . . . . . . . . .207
Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .207
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .207
Additional Mouse Synchronization Procedures. . . . . . . . . . . . . . . . . . . .208
Windows:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208
Sun / Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .209
Additional Video Resolution Procedures. . . . . . . . . . . . . . . . . . . . . . . . .210
Trusted Certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .211
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .211
Installing the Certificate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .212
Certificate Trusted. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213
Fan Location and Speed Information . . . . . . . . . . . . . . . . . . . . . . . . . . .214
Fan Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214
Fan Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214
Temperature Sensor Location and Information. . . . . . . . . . . . . . . . . . . .215
Clear Login Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .216
Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .217
Serial Adapter Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .217
Supported KVM Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .218
Virtual Media Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .218
WinClient ActiveX Viewer / WinClient AP . . . . . . . . . . . . . . . . . . . . .218
Java Applet Viewer / Java Client AP. . . . . . . . . . . . . . . . . . . . . . . . .218
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .219
kn2124v-4132.book Page xi Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
xii
About This Manual
This User Manual is provided to help you get the most from your KVM Over
the NETTM system. It covers all aspects of installation, configuration and
operation. An overview of the information found in the manual is provided
below.
Overview
Chapter 1, Introduction, introduces you to the KN2124v / KN2140v /
KN4124v / KN4140v / KN2132 / KN4116 / KN4132 KVM Over the NETTM
System. Its purpose, features and benefits are presented, and its front and back
panel components are described.
Chapter 2, Hardware Setup, provides step-by-step instructions for setting
up your installation, and explains some basic operation procedures.
Chapter 3, Super Administrator Setup, explains the procedures that the
super administrator employs to set up the KVM Over the NETTM switch
network environment, and change the default username and password.
Chapter 4, Logging In, describes how to log in to the KVM Over the
NETTM switch with each of the available access methods: from a localconsole;
an internet browser; a stand-alone Windows application (AP) program; and a
stand-alone Java application (AP) program.
Chapter 5, The User Interface, describes the layout and explains the
components of the KVM Over the NETTM user interface.
Chapter 6, Port Access, describes the Port Access page and how to
configure the options it provides regarding port manipulation.
Chapter 7, User Management, shows super administrators and
administrators how to create, modify, and delete users and groups, and assign
attributes to them.
Chapter 8, Device Management, shows super administrators how to
configure and control overall KVM Over the NETTM switch operations.
Chapter 9, Maintenance, explains how to upgrade the KVM Over the
NETTM switch firmware, as well as the firmware of the KVM Adapter Cables
used to connect its ports to the installed devices.
Chapter 10, Download, describes how to download stand-alone AP
versions of the Win Client, the Java Client, the Log Server, and Power Over the
Net (PON) programs.
kn2124v-4132.book Page xii Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
xiii
Chapter 11, Port Operation, provides detailed information on accessing
and operating the devices connected to the KVM Over the NETTM switch ports.
Chapter 12, The Log Server, explains how to install and configure the
Log Server.
Chapter 13, LDAP Server Configuration, explains how to configure the
KVM Over the NETTM switch for LDAP / LDAPS authentication and
authorization with Active Directory or OpenLDAP.
An Appendix, at the end of the manual provides technical and
troubleshooting information.
Conventions
This manual uses the following conventions:
Terminology
Throughout the manual we make reference to the terms Local and Remote in
regard to the equipment used in a KVM Over the NETTM switch installation.
By Local, we mean the place where the user is operating from – whether
he is connecting to the switch from the Local Console right next to the
switch, or from a Local Client login located half-way around the world.
By Remote, we mean the equipment that connects to the switch via the
Adapter Cables – as in “remote servers.”
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means
to press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential
steps.
→Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start →Run means
to open the Start menu, and then select Run.
Indicates critical information.
kn2124v-4132.book Page xiii Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
xiv
Product Information
For information about all ALTUSEN products and how they can help you
connect without limits, visit ALTUSEN on the Web or contact an ALTUSEN
Authorized Reseller. Visit ALTUSEN on the Web for a list of locations and
telephone numbers:
International http://www.aten.com
North America ATEN TECH http://www.aten-usa.com
ATEN NJ http://www.aten.com
kn2124v-4132.book Page xiv Tuesday, March 10, 2009 11:29 AM

1
Chapter 1
Introduction
Overview
The KN2124v / KN2140v / KN4124v / KN4140v / KN2132 / KN4116 /
KN4132 switches are IP-based KVM control units that allow both local and
remote operators to monitor and access multiple computers from a single
console. A single KN4140v can control up to 40 computers, and by cascading
up to 40 compatible 16 port switches, as many as 640 computers can be
controlled on a complete two stage installation.
The switches are differentiated according to the number of buses they support
and the number of KVM ports they provide – as shown in the table below:
Each bus permits a separate user session so that up to three (KN2124v /
KN2140v / KN2132) or five (KN4124v / KN4140v / KN4116 / KN4132)
concurrent independent connections to the local servers can take place.
Since the KVM Over the NETTM switches use TCP/IP for their
communications protocol, they can be accessed via their IP addresses from
anywhere on the LAN, WAN, or Internet – whether the connecting computer
is located down the hall, down the street, orhalf-way around the world. Remote
operators can log in via their browser or make use of stand-alone Windows or
Java GUI applications. Java allows the switches to work with Sun Java
Runtime Environment (JRE) enabled operating systems – ensuring multi-
platform operability. The client software allows operators to exchange
keyboard, video and mouse signals with the computers attached to the KVM
Over the NETTM switches as if they were present locally and working on the
equipment directly.
Model Bus Support KVM Ports
KN2124v 1 Local; 2 Remote 24
KN2140v 1 Local; 2 Remote 40
KN4124v 1 Local; 4 Remote 24
KN4140v 1 Local; 4 Remote 40
KN2132 1 Local; 2 Remote 32
KN4116 1 Local; 4 Remote 16
KN4132 1 Local; 4 Remote 32
kn2124v-4132.book Page 1 Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
2
Up to 32 users can share the remote buses. A Message Board feature allows
them to communicate with each other to facilitate port sharing.
Administrators can handle a multitude of maintenance tasks with ease – from
installing andrunningGUIapplications, toBIOS leveltroubleshooting,routine
monitoring, concurrent maintenance, system administration, rebooting and
even pre-booting functions.
Local console operation is easily accomplished either by entering hotkey
combinations from the keyboard with a full screen GUI display.
Monitoring the installation’s activities couldn’t be easier. An convenient Auto
Scan feature permits automatic switching from port to ports at user-specified
intervals, while the Panel Array Mode can display the video output of up to 40
computers at the same time.
The switches feature RJ-45 connectors allowing them to use CAT 5e cable to
link to the computers. This space-saving innovation means that a full 16, 24,
32 or 40 port switch can be conveniently installed in a 1U system rack, and the
installation can take advantage of the internal network wiring built into most
modern commercial buildings.
Setup is fast and easy; plugging cables into their appropriate ports is all that is
entailed.Becausethe switchintercepts keyboardinputdirectly,thereis noneed
to get involved in complex software installation routines, or to be concerned
with incompatibility problems.
Since the firmware is upgradeable over the Net, you can stay current with the
latest functionality improvements simply by downloading firmware updates
from our website as they become available.
Local
Remote
Remote
Remote
Remote
KN4140v
1 - 20
21 - 40
TCP/IP
kn2124v-4132.book Page 2 Tuesday, March 10, 2009 11:29 AM

Chapter 1. Introduction
3
With its advanced security features, the KVM Over the NETTM switch provides
the fastest, most reliable, most cost effective way to remotely access and
manage widely distributed multiple computer installations.
KVM Over the NETTM switches have an Adapter ID function that stores port
information like the adapter ID, OS, keyboard language, adapter name,
operation modes and more, so that when you move a KVM Adapter Cable from
one port to another, the switch recognizes the same adapter cable at the new
location.Also,for greaterease ofusewhen movingthe adapter cableto another
switch, the adapter ID, OS, keyboard language, adapter name, and operation
modes of the port stay with the adapter.
With its advanced virtual media features, the KN2124v / KN2140v / KN4124v
/ KN4140v series of switches let you map DVD/CD drives and other storage
media to a remote server. This function allows you to conduct file transfers,
installs applications and OS patches, and perform diagnostics remotely. You
can upgrade your entire installation from a single remote console located
anywhere in the world.
The KN4140v offers dual power supplies so that if one of the power supplies
fails, the second power supply automatically takes over. In addition to
supporting dual power, the KN4140v guards against power failure from your
server room outlets. If your server room has more than one power source,
connecting the KN4140v power supplies to different power sources is a wise
choice. If one of the server room power supplies loses power, the KN4140v
will automatically adjust the power it draws from the second source to keep
functioning.
The KN2124v/2140v/4124v/4140v models have support for four temperature
sensors that can control up to six fans. The sensors regulate the fans to run at
optimum speed depending on the server room temperature, throttling down
when necessary, using energy more efficiently and prolonging the life of both
the fans and the switch.
The KN2124v/2140v/4124v/4140v models are audio enabled. On the local
unit, speakers and a microphone are supported; while remote units offer
support for speakers only.
kn2124v-4132.book Page 3 Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
4
Features
All Models
16, 24, 32, or 40 port remote access KVM switch – monitor and control up
to 16, 24, 32, or 40 computers on a single level, or control up to 640
computers in a two-level cascade
Two 10/100/1000 Mbps NICs for redundant LAN or two IP operation
Supports up to 5 bus sessions – 1 local and 2 (KN2132 / KN2124v /
KN2140v) or 4 (KN4116 / KN4132 / KN4142v / KN4140v) remote
administrators can simultaneously access separate ports
Multi-user support – up to 64 user accounts – 1 local and 2 (KN2132 /
2124v / KN2140v) or 4 (KN4116 / KN4132 / KN4142v / KN4140v)
remote users can simultaneously access separate ports – up to 32 users
share the remote buses
Remotely access computers via LAN, WAN, or the Internet; control your
installation when and where you want
Supports multiplatform server environments: Windows, Mac, Sun, Linux
and VT100 based serial devices
Uses RJ-45 connectors and CAT 5e cable for a neat and tidy, efficient
installation – supports PS/2, USB, Sun Legacy (13W3) and serial
(RS-232) connectivity
Local Console provides PS/2 and USB keyboard and mouse support
Multi-level authentication: super administrator; administrator; user;
viewer with no limit on the number of each type
Remote authentication support: RADIUS, LDAP, LDAPS, and MS Active
Directory
Advanced security features include password protection and advanced
encryption technologies – 1024 bit RSA; 168-bit 3DES; 256 bit AES; and
128 bit SSL
Flexible encryption design allows users to choose any combination of 56-
bit DES, 168-bit 3DES, 256-bit AES, 128-bit RC4, or Random for
independent KB/Mouse, video, and virtual media data encryption
Supports 10Base-T, 100Base-T, 1000Base-T, Auto-Sense, TCP/IP, HTTP,
DNS, DHCP, PPP, UDP, ARP, Ping
Pure web browser allows administrators to perform administrative tasks
without having Java or Active X installed
kn2124v-4132.book Page 4 Tuesday, March 10, 2009 11:29 AM

Chapter 1. Introduction
5
Total web solution features both a Windows Active X viewer and a Java
Applet viewer – you can open multiple viewers to control multiple ports
from the same login session
The switch can detect your browser and open either the Java or Active X
viewer accordingly – or you can specify which viewer you prefer to use
Browser access can be disabled – Windows and Java AP GUI programs
provided for non-browser connectivity
Full-screen GUI, Magic Control Panel and toolbars for convenient, user
friendly operation
Full-screen or sizable and scalable remote desktop window – in full-screen
mode the remote desktop display scales to user’s monitor display size
Mouse DynaSync for USB mice – local and remote mouse movement are
the same, no need to constantly resync the two movements
Panel Array Mode – view up to 40 ports at the same time, or view up to 42
ports for cascaded installations
Message Board for communication among remote users
Multi-language support with on-screen (software) keyboard
Bandwidth control – video quality and video tolerance can be adjusted to
optimize data transfer speed; monochrome color depth setting and
threshold and noise settings for compression of the data bandwidth in low
bandwidth situations
High video resolution: up to 1600 x 1200 @ 60Hz – 32 bit color depth for
the local console; up to 1600 x 1200 @ 60Hz with 24 bit color depth for
remote sessions
Supports ALTUSEN (CC) Control Center Management Series Software
PON (Power Over the NET™) support via Java
PPP modem dial-in/dial-back support – for low bandwidth operation
End Session feature – administrators can terminate running sessions
Windows-based Log Server, event logging and Syslog support
Backup and restore configuration and user account settings
SNMP trap and SMTP alert notification
Private CA support
RTC support to keep the timer running during times of no power
Firmware upgradeable via remote management application
Adapter ID; Exit Macros; Keyboard Passthrough; BIOS level support
kn2124v-4132.book Page 5 Tuesday, March 10, 2009 11:29 AM

KVM Over the NET™ User Manual
6
V-Series Exclusive
Features found only with the V-Series KVM Over the NETTM switches
(KN2124v, KN2140v, KN4124v, and KN4140v) include the following:
Audio – a microphone and speakers are supported on the Local Console;
speakers (only) are supported on the Local Client computers.
Dual power supply support – Log and UI reflect the power status
Virtual Media support
Variable fan speed – speed changes according to the switch’s temperature
kn2124v-4132.book Page 6 Tuesday, March 10, 2009 11:29 AM
